xraptor 0.4.0

Fast as websocket easy as http

X-raptor

By: CenturyBoys

Fast as a WebSocket, easy as HTTP. X-raptor is an abstraction over the websockets package that lets you register get, post, put, sub and unsub asynchronous handlers with HTTP-like route registration. Every message on the wire is a request or a response object.

To allow multiple asynchronous responses per route, X-raptor uses each request_id as an antenna — a pubsub channel that yields string messages back to the client.

⚠️ Pre-1.0: the public API may still change between minor versions. Pin a version if you depend on it.

📦 Installation

pip install xraptor
# or with uv
uv add xraptor

Optional extras: redis_version (Redis antenna) and uvloop (faster event loop).

🚀 Quick start

Register a route with the as_<method> decorators, then load the routes and serve:

import asyncio

import xraptor


@xraptor.XRaptor.register("/send_message_to_chat_room").as_post
async def send_message(request: xraptor.Request) -> xraptor.Response:
    return xraptor.Response.create(
        request_id=request.request_id,
        header={},
        payload='{"ok": true}',
        method=request.method,
    )


_xraptor = xraptor.XRaptor("localhost", 8765)
_xraptor.set_antenna(xraptor.antennas.MemoryAntenna)

asyncio.run(_xraptor.load_routes().serve())

Routes are registered at import time with the decorators (as_get, as_post, as_put, as_sub, as_unsub), then loaded into the server with load_routes().

📨 Message format

Every inbound message is a request and every outbound message is a response, both JSON objects. payload is always a string (usually JSON-encoded).

Request

{
  "request_id": "01H...",
  "payload": "{\"text\": \"hello\"}",
  "header": {"token": "..."},
  "route": "/send_message_to_chat_room",
  "method": "POST"
}

Response

{
  "request_id": "01H...",
  "payload": "{\"ok\": true}",
  "header": {},
  "method": "POST"
}

method is case-insensitive on the way in. Unmatched routes get a {"message": "Not registered"} response; malformed messages are dropped.

🖥️ Start server

import asyncio

import xraptor

_xraptor = xraptor.XRaptor("localhost", 8765)

xraptor.antennas.RedisAntenna.set_config({"url": "redis://:@localhost:6379/0"})
_xraptor.set_antenna(xraptor.antennas.RedisAntenna)

asyncio.run(_xraptor.load_routes().serve())

serve() runs until stop() is called or a SIGTERM/SIGINT is received, then shuts down gracefully (closing the server and its connections). Connection limits can be tuned on the constructor:

_xraptor = xraptor.XRaptor(
    "localhost",
    8765,
    max_size=2**20,      # max inbound payload in bytes (DoS guard)
    max_queue=32,        # per-connection backpressure
    ping_interval=20,    # keepalive; detects half-open connections
    ping_timeout=20,
)

🔗 Middleware

Middleware functions run before route handlers. They can inspect/modify requests, short-circuit responses, or handle cross-cutting concerns like authentication and rate limiting (there is no built-in auth or rate limiting — this is the hook).

import xraptor


@xraptor.XRaptor.middleware(priority=1)
async def auth_middleware(request: xraptor.Request, connection) -> xraptor.Response | None:
    if not request.header.get("token"):
        return xraptor.Response.create(
            request_id=request.request_id,
            header={},
            payload='{"error": "unauthorized"}',
            method=request.method,
        )
    return None  # continue to the next middleware/handler

• Priority: lower numbers run first; each priority must be unique.
• Pattern matching: restrict a middleware to routes with an optional regex.
• Short-circuiting: return a Response to stop the chain and skip the handler; return None to continue.

@xraptor.XRaptor.middleware(priority=2, pattern=r"^/api/.*")
async def api_only_middleware(request, connection):
    # only runs for routes starting with /api/
    return None

📡 Antenna

An antenna is the pubsub backend. There is a default in-memory antenna (not recommended for production); you can implement your own against the interface or use one of the extras.

from abc import ABC, abstractmethod
from collections.abc import AsyncIterator


class Antenna(ABC):
    @abstractmethod
    def subscribe(self, antenna_id: str) -> AsyncIterator[str]:
        """async generator that yields messages from the channel"""

    @abstractmethod
    async def stop_listening(self) -> None:
        """stop listening for messages on this subscription"""

    @abstractmethod
    async def post(self, antenna_id: str, message: str) -> None:
        """publish a message to a channel"""

    @abstractmethod
    async def is_alive(self, antenna_id: str) -> bool:
        """whether the channel still has an active subscriber"""

    @classmethod
    @abstractmethod
    def set_config(cls, config: dict) -> None:
        """set the config map for this antenna"""

Built-in implementations:

• xraptor.antennas.MemoryAntenna — in-memory, single process (default).
• xraptor.antennas.RedisAntenna — Redis pubsub (via the redis_version extra).
• xraptor.antennas.NatsAntenna — NATS core pubsub (via the nats extra).

is_alive (used by Broadcast to prune dead members) needs a per-channel subscriber count, which only Redis exposes natively. On NATS it always returns True, so member cleanup relies on the connection layer (websocket keepalive + disconnect) instead.

📤 Broadcast

A broadcast room lets multiple members join a shared space and automatically receive every message posted to it — like a chat room, without polling. It is built on the registered antenna and auto-cleans disconnected members.

class Broadcast:
    @classmethod
    def get(cls, broadcast_id: str) -> "Broadcast":
        """get (or create) a broadcast instance by id"""

    def add_member(self, member: str):
        """add a member (antenna id); opens the room on the first member"""

    def remove_member(self, member: str):
        """remove a member; closes the room when the last one leaves"""

📊 Observability

The server exposes two HTTP endpoints on the same port (intercepted before the WebSocket handshake), enabled by default:

• GET /health — JSON liveness for load balancers: {"status": "ok", "uptime_seconds": ..., "active_connections": ...}.
• GET /metrics — Prometheus text format: xraptor_connections_total, xraptor_connections_active, xraptor_requests_total, xraptor_request_errors_total, xraptor_uptime_seconds.

Paths are configurable (or set to None to disable); counters are also readable in-process via XRaptor.get_metrics().

_xraptor = xraptor.XRaptor(
    "localhost", 8765,
    health_path="/health",   # None to disable
    metrics_path="/metrics",  # None to disable
)

⚡ Performance

• Request/response (de)serialization uses orjson.
• Install the uvloop extra and start the server with XRaptor.run() to use uvloop when available (falling back to asyncio otherwise):

_xraptor.load_routes().run()   # uvloop if installed, else asyncio.run

🧩 Extras

Redis

Adds the redis package for the Redis antenna.

pip install 'xraptor[redis_version]'
# or
uv add 'xraptor[redis_version]'

Configure the connection string on the antenna via set_config:

import xraptor

xraptor.antennas.RedisAntenna.set_config({"url": "redis://:@localhost:6379/0"})

NATS

Adds nats-py for the NATS antenna.

pip install 'xraptor[nats]'
# or
uv add 'xraptor[nats]'

import xraptor

xraptor.antennas.NatsAntenna.set_config({"servers": "nats://localhost:4222"})

uvloop

Optional faster event loop (excluded on Windows).

pip install 'xraptor[uvloop]'

🧮 Full example

A minimal chat implementation exercising the sub, post and unsub routes (uses the redis_version extra):

• Server: example/server.py
• Client: example/client.py

🗓️ Versioning & support

• SemVer. While on 0.x, the public API may change between minor versions — pin a version if you depend on it. See the CHANGELOG.
• Python support follows a SPEC 0-style policy: a Python version is supported until roughly 3 years after its release. Currently tested on 3.11, 3.12, 3.13 and 3.14.
• Type-checked and typed: the package ships a py.typed marker (PEP 561), so downstream type checkers see its annotations.
• Path to 1.0 — the API will be frozen once these are in place: a stable Antenna interface, built-in observability (metrics/health), and validation under real-world load.

🛠️ Development

The project uses uv and ruff + mypy + pytest.

uv sync --all-extras --dev   # install
uv run pytest                # tests (with coverage)
uv run ruff check .          # lint
uv run ruff format .         # format
uv run mypy xraptor/         # type check

Load/soak testing lives in loadtest/ (run manually):

uv run python loadtest/run.py smoke      # quick sanity
uv run python loadtest/run.py all        # full load-ramp + broadcast + soak
