ZEDprofiler

CPU-first 3D image feature extraction toolkit for high-content and high-throughput image-based profiling.

This repository is used for image-based feature extraction of objects in 3D microscopy images. In this use case we extract features from single cells in 3D volumetric microscopy images. We developed ZEDprofiler to be used on high-content and high-throughput microscopy images, which are often large in size and require efficient processing. ZEDprofiler is extensible to any fluorescence microscopy image modality, and is designed to be modular.

Install environment

uv sync --group dev --group docs --group notebooks

Data Contract

Where:

• x is the width of the image in pixels
• y is the height of the image in pixels
• z is the depth of the image in pixels

Different fields use different dimensions for different meanings. We use x and y to refer to the same dimensions captured in a 2D image, and z to refer to the "depth" dimension in a 3D image if looking down into the image stack. The x, y, and z dimensions are less description and more absolute while depth is relative to angle of observation.

Accepted image formats (order matters):

• Single channel: (z, y, x)

Command-line interface

ZedProfiler run extracts features for a single well/field-of-view (FOV) shard: it loads one image set from explicit file paths, runs a selected subset of featurizers, and writes one Parquet per feature table to an output directory. It is the command a workflow manager (for example Nextflow via SLURM sbatch) dispatches once per shard.

After uv sync (or pip install .) the ZedProfiler console script is available; from a checkout you can also use uv run ZedProfiler run .... Run ZedProfiler run --help for the authoritative, up-to-date list of arguments.

ZedProfiler run \
  --image=DNA=/path/to/channel1.tif \
  --label=Nuclei=/path/to/nuclei_mask.tiff \
  --anisotropy-spacing 1.0 1.0 1.0 \
  --patient-tumor NF0014_T1 \
  --plate PLATE01 \
  --well A1 \
  --fov 1 \
  --out-dir ./shard_output \
  --features Intensity

Arguments

Feature types

VolumeSizeShape, Intensity, Neighbors, Texture, and Granularity are single-channel features run per channel x compartment. Colocalization is a two-channel feature run per ordered channel pair x compartment.

Outputs

Each request writes {compartment}_{channel}_{feature_type}_cpu_features.parquet into --out-dir. Every table carries Metadata_Imaging_ImageID (deterministically built from the patient-tumor, plate, well, and FOV coordinates) and Metadata_Experiment_ImageSet so downstream tables can rejoin. Writes are atomic (temp file + replace), so a crashed shard never leaves a partial file that --skip-existing would mistake for a complete one.

Two-channel colocalization example

ZedProfiler run \
  --image=DNA1=/path/to/channel1.tif \
  --image=DNA2=/path/to/channel2.tif \
  --label=Nuclei=/path/to/nuclei_mask.tiff \
  --anisotropy-spacing 1.0 1.0 1.0 \
  --patient-tumor NF0014_T1 --plate PLATE01 --well A1 --fov 1 \
  --out-dir ./shard_output \
  --feature=Colocalization,channel1=DNA1,channel2=DNA2,compartment=Nuclei,fast_costes=Faster

Quality Gates

We lint and format code with our pre-commit configuration.
