Zeit: Change Detection and Time Series for Python

Zeit is a high-performance Python package for Earth Observation (EO) data cube processing and time series analysis. It bridges the gap between modern cloud-native data formats (STAC, Xarray, Dask) and state-of-the-art pixel-based trajectory algorithms (TWDTW, CCDC, LandTrendr).

Built with highly optimized C++ extensions (OpenMP and Eigen SIMD) bound to Python via pybind11, Zeit is designed to handle massive multi-spectral satellite image time series efficiently while keeping memory footprints strictly bounded.

Key Capabilities

• ARD Data Cube Ingestion: Fetch cloud-native STAC catalogs (via MGRS/WRS tiles or Bounding Boxes) or parse local TIFF directories into lazy Dask-backed xarray Datacubes.
• Semantic Cloud Masking: Automated extraction and translation of Quality Assessment (QA) bands for Landsat and Sentinel-2 directly inside the query pipeline, plus a temporal Tmask harmonic baseline model to catch clouds/shadows missed by the native QA mask.
• Temporal Regularization: Mathematical composite generation (e.g., Medoid, Median) to align irregular satellite acquisitions into uniform time steps (crucial for Deep Learning and DTW).
• High-Performance C++ Algorithms:
  • TWDTW (Time-Weighted Dynamic Time Warping): Highly optimized with LB_Keogh lower bounding, early abandonment, Sakoe-Chiba constraints, and multivariate Eigen vectorization.
  • Batch SOM (Self-Organizing Maps): Unsupervised multi-threaded clustering of massive spectral-temporal arrays.
  • CCDC / COLD: Continuous Change Detection and Classification via robust harmonic modeling.
  • LandTrendr: Trajectory-based disturbance and recovery detection.
  • BFAST, BFAST Monitor & BFAST Lite: Classic iterative trend+season break detection, near-real-time monitoring, and single-pass multiple-breakpoint detection (ported from R's bfast/strucchangeRcpp).
  • Phenology Extraction: 19 simultaneous phenological metrics from optimized curve-fitting models (Beck, Elmore, Gu, Zhang, Asymmetric Gaussian, Double Logistic), with QA-based per-observation weighting.
  • Mann-Kendall / Theil-Sen: Pixel-wise non-parametric trend test and slope estimation for detecting statistically significant greening/browning trends.
  • SNIC Segmentation: Superpixel segmentation of images and whole time series cubes (one segment = similar trajectories), matching the original SNIC's labels pixel for pixel, with tile-parallel processing for large scenes.
• Deep Learning (zeit.ai): Pre-built PyTorch architectures tailored for spatio-temporal Earth Observation (U-TAE, TempCNN, Siamese Networks), plus wrappers for Geospatial Foundation Models (ViT).
• Command-Line Interface: Every core algorithm is also available as a zeit subcommand, for running change detection on GeoTIFF stacks from bash scripts, cron jobs, or HPC environments without writing Python.

Installation

pip install zeit-cdts

(Note: Wheels are provided for Windows, Linux, and macOS. macOS runs in single-threaded mode by default due to Apple Clang lacking OpenMP).

For macOS users who want C++ OpenMP multi-threading: Apple's default Clang compiler disables OpenMP. To achieve maximum performance and enable multi-threading, you must install the libomp library and manually export the compilation flags before forcing a local compilation:

brew install libomp
export CFLAGS="-I$(brew --prefix libomp)/include"
export CXXFLAGS="-I$(brew --prefix libomp)/include"
export LDFLAGS="-L$(brew --prefix libomp)/lib -lomp"
pip install --no-binary zeit-cdts zeit-cdts

Cloud-Native ARD Cubes (STAC)

Fetch lazy evaluated, Dask-backed analysis-ready data cubes directly from STAC providers (e.g., Earth Search, Planetary Computer, Brazil Data Cube).

import zeit

# Build a lazy DataArray using MGRS/WRS tiles or Bounding Boxes
cube = zeit.build_time_series(
    source="earth_search",
    collection="sentinel-2-l2a",
    tiles=["22JFQ"], # Sentinel-2 MGRS or Landsat WRS-2 (e.g., "215065")
    start_date="2022-01-01",
    end_date="2022-12-31",
    bands=["red", "green", "blue", "nir"],
    apply_cloud_mask=True # Automatically fetches QA band and natively masks clouds/shadows
)

print(cube) # Returns an xarray.DataArray (Time, Band, Y, X)

Temporal Regularization

Algorithms like TWDTW, SOM, and Deep Learning expect temporally aligned data. zeit natively regularizes irregular STAC acquisitions.

from zeit import regularize_time_series

# Aggregate observations into 16-day Medoid composites
# (Maintains xarray lazy evaluation via Dask graphs)
cube_16d = regularize_time_series(cube, freq="16D", method="medoid")

Change Detection (LandTrendr & CCDC)

Continuous structural monitoring using robust breakpoint and harmonic regression models directly on xarray Datacubes via pandas-like accessors (cube.zeit.run_...).

LandTrendr (Trajectory-based Disturbance)

Identify structural breakpoints in time-series (e.g., detecting exactly when deforestation occurred). Zeit scales LandTrendr to massive datasets using C++ OpenMP and Dask map_blocks.

import numpy as np
from zeit.metrics import extract_events

# 1. Prepare annual NBR data (Time, Y, X)
years = np.array([2018, 2019, 2020, 2021, 2022, 2023])

# 2. Run LandTrendr across the entire Dask datacube natively
lt_results = cube_nbr.zeit.run_landtrendr(
    years=years,
    max_segments=4,
    pval_threshold=0.05,
    n_jobs=-1
)

# Trigger Dask computation (runs the C++ core in parallel)
# Output shape is (2 * max_vertices, Y, X).
lt_array = lt_results.compute()

# 3. Analyze disturbances (e.g., finding the biggest drop in NBR)
events = extract_events(
    vertices_stack=lt_array,
    event_type="loss",      # Look for drops in the index (e.g., vegetation loss)
    sort_by="greatest",     # Get the segment with the largest magnitude
    min_magnitude=0.1       # Optional noise filter
)

# You now have 2D maps ready to be exported to GeoTIFF!
yod_map = events["year"]        # Year of Disturbance (YOD)
mag_map = events["magnitude"]   # Magnitude of the disturbance
dur_map = events["duration"]    # How many years the disturbance took
pre_map = events["pre_val"]     # Value before disturbance
post_map = events["post_val"]   # Value after disturbance

CCDC / COLD (Harmonic Modeling)

Extracts harmonic coefficients (Intercept, Slopes, Sine, Cosine) and detects intra-annual changes by fitting mathematical curves to multi-spectral data.

import numpy as np
from zeit.ccdc import predict_synthetic_image
from zeit.classify import train_ccdc_classifier, classify_ccdc_stack

# 1. Provide Julian dates and a Quality Assurance mask (Cloud/Shadow)
# cube_multi: 4D array (Bands, Time, Y, X)
# qa_mask: 3D array (Time, Y, X) with 0 for clear sky, 1 for clouds
dates_julian = np.array([100, 116, 132, 148, 164, 180])

# 2. Run CCDC directly as an xarray accessor
ccdc_results = cube_multi.zeit.run_ccdc(
    dates=dates_julian,
    qa_stack=qa_mask, # Automatically skips clouded pixels in regression
    max_segments=6,
    return_coefs=True,
    n_jobs=-1
)

# Run the C++ engine to generate the harmonic coefficient stack
coef_stack = ccdc_results.compute()

# 3. Generate Synthetic Images (Harmonic Reconstruction)
# Predict what the surface should look like on any arbitrary date without clouds!
# Output shape: (Bands, Y, X)
synthetic_image = predict_synthetic_image(
    ccdc_coefs_stack=coef_stack.values,
    target_julian_day=200, # Predict for Julian day 200
    num_bands=6
)

# 4. Land Cover Classification using the Harmonic Coefficients
# Train a Random Forest using harmonic coefficients as features
rf_model = train_ccdc_classifier(
    X_train=training_coefs, # Your extracted training samples
    y_train=training_labels,
    n_estimators=100
)

# Classify the entire CCDC cube into a categorical land cover map block-by-block
# (Handles memory efficiently by reading/writing chunks)
classify_ccdc_stack(
    clf=rf_model,
    coef_stack_path="output/ccdc_coefs.tif",
    output_path="output/land_cover_map.tif",
    chunk_size=512
)

Phenology Extraction

Extract 19 simultaneous phenological metrics (Gu, Zhang, Thresholds, Derivatives, LOS, POP) across massive datasets using optimized C++ curve-fitting models (Beck, Elmore, Gu, Zhang, Asymmetric Gaussian, Double Logistic) over Dask clusters.

The smoothing, curve-fitting, and metric-extraction methodology is based on the R package phenofit (Kong et al., 2022, Methods in Ecology and Evolution, doi:10.1111/2041-210X.13870), reimplemented in C++/Eigen/OpenMP. See the Phenology tutorial for the full reference list and a real-world walkthrough.

import numpy as np
from zeit._core.phenology import CurveType

# 1. Provide dates corresponding to the time steps
dates_julian = np.arange(1, 366, 16) # Day of year

# 2. Run phenology curve fitting natively via the zeit accessor
pheno_results = cube_16d.zeit.run_phenology(
    dates=dates_julian,
    curve_type=int(CurveType.BECK), # Enum mapping to CurveType::BECK
    max_seasons=2,                  # Extract up to 2 growing seasons per year

    # Smoothing Configuration
    apply_whittaker=False,          # Turn off Whittaker
    apply_hants=True,               # Use HANTS (Fourier-based) instead
    hants_frequencies=3,

    # Fine-Grained Season Control
    min_season_length=90,           # Ignore noisy peaks shorter than 90 days
    min_amplitude=0.2,              # Ignore seasons with less than 0.2 NDVI growth
    return_annual=False,            # Return as purely sequential seasons

    n_jobs=-1                       # C++ multithreading (leave cores for OS)
)

# Trigger computation (runs C++ optimizer across Dask blocks)
# Output shape: (metric=19, season=2, Y, X)
pheno_array = pheno_results.compute()

# Extract Zhang's Greenup transition date for the first season
greenup_map = pheno_array.sel(metric="Greenup", season=0)

Down-weighting cloud/snow-contaminated observations: zeit.qc decodes a sensor's QA/QC band into per-observation reliability weights in [0, 1] (ported from phenofit's qcFUN.R), which feed the Whittaker/HANTS smoothing and the iterative curve fit instead of trusting every observation equally:

from zeit.qc import qc_modis_summary

# qa_cube: (time, y, x) MOD13 SummaryQA band, aligned with cube_16d
weights = qc_modis_summary(qa_cube)  # 0=good, 1=marginal, 2=snow/ice, 3=cloudy -> [1.0, 0.5, 0.2, 0.2]

pheno_results = cube_16d.zeit.run_phenology(
    dates=dates_julian,
    curve_type=int(CurveType.BECK),
    weights=weights,       # down-weights unreliable observations during smoothing/fitting
    season_retry=True,     # relax the trough threshold once if a pixel finds no season at all
)

Trend Analysis (Mann-Kendall)

Pixel-wise Mann-Kendall trend test + Theil-Sen slope, ported from pymannkendall (Hussain & Mahmud, 2019) to a C++/OpenMP backend, with the same Dask distribution strategy as Phenology Extraction. Useful for "is there a statistically significant greening/browning trend at this pixel?" questions on multi-year composite stacks. See the Mann-Kendall tutorial for the full method comparison (autocorrelation-corrected variants, seasonal test) and a real-world walkthrough.

import numpy as np

# annual_ndvi: (year, y, x) DataArray, one max-NDVI composite per year
trend = annual_ndvi.zeit.run_mann_kendall(
    method="hamed_rao",  # autocorrelation-corrected (recommended for annual composites)
    alpha=0.05,
)

result = trend.compute()
slope_map = result.sel(metric="slope")        # NDVI change per year
significant = result.sel(metric="h") == 1.0   # statistically significant at alpha=0.05
declining = (result.sel(metric="trend") == -1) & significant

Change Monitoring (BFAST Monitor)

Pixel-wise near-real-time structural change monitoring, ported from the R package bfast (Verbesselt et al.) to a C++/OpenMP backend, with the same Dask distribution strategy as Mann-Kendall. Unlike LandTrendr/CCDC (retrospective, whole-series segmentation), bfastmonitor fits a trend+harmonic model on a stable history period and asks "is a disturbance happening right now, in the most recent observations?" — verified bit-for-bit-scale accurate against R's bfastmonitor(). See the BFAST Monitor tutorial for the full method background and scope (only type="OLS-MOSUM" + history="all" are ported so far).

# annual_ndvi: (time, y, x) DataArray, 16-day composites (frequency=23/year) from 2010
result = annual_ndvi.zeit.run_bfast_monitor(
    start_time=2010.0,
    monitor_start_time=2022.0,  # monitor everything from 2022 onward
    frequency=23,
)

result = result.compute()
disturbed = result.sel(metric="has_break") == 1.0
break_time = result.sel(metric="breakpoint")  # fractional-year time of the first detected break

Change Detection (BFAST Lite)

Pixel-wise, single-pass multiple-breakpoint detection, ported from the R package bfast's bfastlite() and its strucchangeRcpp dependency's breakpoints() (the Bai & Perron optimal multiple-breakpoint dynamic program) to a C++/OpenMP backend. Unlike bfastmonitor above (single break, near-real-time), this retrospectively segments the whole series into the optimal number of pieces (via the LWZ model-selection criterion) — no STL decomposition needed. Verified exactly against R's bfastlite() across 6 scenarios (~3.1x faster single-threaded than R; n_jobs=-1 adds a further ~5.5x on top of that by reserving one CPU core and parallelizing across the rest — a smaller gap than bfastmonitor's, since this workload is genuinely CPU-bound dynamic programming on both sides, not dominated by R's per-call overhead). See the BFAST Lite tutorial for the full method background, scope, and validation details (including two real numerical bugs caught and fixed along the way).

# annual_ndvi: (time, y, x) DataArray, 16-day composites (frequency=23/year) from 2010
result = annual_ndvi.zeit.run_bfast_lite(
    start_time=2010.0,
    frequency=23,
    max_breaks_output=5,
)

result = result.compute()
n_breaks = result.sel(metric="n_breaks")
first_break_idx = result.sel(metric="breakpoint_idx_1")  # NaN where n_breaks == 0

Time-Series Classification (TWDTW)

The C++ TWDTW engine handles multivariate sequences simultaneously using Eigen's $L^2$ norms and aggressively skips non-matching pixels using $O(N)$ Lower Bounding techniques.

from zeit.twdtw import classify_twdtw
import numpy as np

# 1. Prepare your regularized data (Y, X, Time, Bands) and temporal axis
dates = np.arange(1, 366, 16) # Day of the year (DOY) for a 16-day composite

# 2. Extract or define temporal patterns (Signatures)
# A signature is a 1D or 2D array representing the expected phenological curve of a class.
# Example: 23 time steps, 4 bands (Red, Green, Blue, NIR)
forest_sig = np.random.rand(23, 4)
soy_sig = np.random.rand(23, 4)

patterns = {
    "Forest": (forest_sig, dates),
    "Agriculture": (soy_sig, dates)
}

# 3. Run the TWDTW Classifier using the C++ OpenMP engine
# It calculates the multi-dimensional distance using the L2 Norm (Euclidean)
# and aligns the series dynamically in time, bounded by max_time_warp.
classes_map, dist_map, class_names = classify_twdtw(
    values_array=cube_16d.values,
    dates_array=dates,
    patterns=patterns,
    alpha=0.1,             # Steepness of the time penalty
    beta=0.05,             # Midpoint of the time penalty
    max_time_warp=60,      # Max allowed temporal shift in days
    n_jobs=-1              # Use all CPU cores minus 1 to keep OS responsive
)

# 4. Filter predictions by similarity (distance)
# TWDTW distance represents similarity (lower is better).
# Mask out pixels that matched poorly with all known signatures (Unclassified)
max_acceptable_distance = 15.0
final_classification = np.where(
    dist_map < max_acceptable_distance,
    classes_map,
    -1 # Assign -1 for Unclassified/Unknown pixels
)

Unsupervised Clustering (SOM)

Unsupervised classification and dimensionality reduction of time series with a C++ port of Python minisom (online and Batch SOM) that reproduces its results bit-for-bit, 30-190x faster.

from zeit.ai import SOM

# Flatten cube to (Pixels, Features)
X_train = cube_16d.values.reshape(-1, cube_16d.shape[2] * cube_16d.shape[3])

# Train a 10x10 SOM grid (Batch SOM, 20 passes over the data, OpenMP-parallel)
som = SOM(x=10, y=10, input_len=X_train.shape[1], sigma=1.5)
som.random_weights_init(X_train)
som.train(X_train, num_iters=20, algorithm="batch", n_jobs=-1)

# Predict Best Matching Units (BMUs) for new data
bmus = som.predict(X_train, n_jobs=-1)

Pre and Post-Processing

Before classifying, it is highly recommended to smooth temporal trajectories. After classifying, pixel-based maps often suffer from noise. Zeit provides fast functions to regularize your data in both dimensions:

from zeit import apply_savgol_filter, apply_majority_filter, apply_mmu_filter, save_raster
from zeit.smooth import apply_whittaker_filter

# Temporal Smoothing: Savitzky-Golay (fast, general-purpose)...
smoothed_array = apply_savgol_filter(raw_array, window_length=5, polyorder=2)

# ...or Whittaker (often better for NDVI/EVI, supports per-observation weights)
smoothed_array = apply_whittaker_filter(raw_array, lmbd=10.0, weights=clear_sky_weights)

# Spatial Regularization (Mode filter)
regularized_map = apply_majority_filter(classified_map, size=3)
save_raster(regularized_map, "results/classified_regularized.tif", reference_cube=cube)

# Minimum Mapping Unit (MMU): operates on a GeoTIFF on disk, not an in-memory array
# Erase isolated patches smaller than 11 pixels
apply_mmu_filter(
    input_path="results/classified_regularized.tif",
    output_path="results/classified_final.tif",
    mmu_pixels=11,
)

Exporting Geospatial Data

Seamlessly dump predicted arrays back to the disk, preserving the metadata from the original STAC cube.

from zeit import save_raster

save_raster(
    array=final_map,
    output_path="output/land_cover.tif",
    reference_cube=cube, # Copies Affine Transform and CRS
    nodata=255
)

Command-Line Interface

Every core algorithm is also available as a zeit subcommand, so you can run change detection directly on GeoTIFF stacks from bash scripts, cron jobs, or HPC batch systems without writing any Python:

zeit landtrendr input_stack.tif output_dir/ --start-year 2000 --max-segments 6 --jobs -1

See the CLI reference for the full list of subcommands and options.

Architecture & Threading Safety

Zeit safely blends Python-based distributed workflows (Dask) with highly parallel C++ routines:

• OpenMP CPU Scaling: All C++ algorithms expose the n_jobs parameter, and default to it (n_jobs=-1) in their Python entry points. n_jobs=-1 reserves one CPU core (std::max(1, max_threads - 1)) so the host OS stays responsive during intensive workloads — standardized across every parallel algorithm (LandTrendr, CCDC, TWDTW, SOM, Phenology, Mann-Kendall, BFAST Monitor, BFAST Lite). Pass an explicit positive integer to use a specific thread count instead (e.g. all cores with no reservation, or fewer to leave more headroom).
• Memory Footprint: Algorithms like TWDTW are strictly optimized via a 2-Row Dynamic Programming algorithm, restricting mathematical matrices to the CPU's L1 cache and avoiding heavy allocations.
• Cross-Platform Compatibility: Uses safe #ifdef _OPENMP boundaries to gracefully fallback to single-threaded operations on macOS environments using Apple Clang (which lacks native libomp), allowing pip install to succeed universally.

License

Zeit is free software, licensed under the GNU General Public License v2.0 or later (GPL-2.0-or-later). Several algorithms are ports of existing open-source implementations (bfast, strucchangeRcpp, GLMnet, pymannkendall, GERSL/CCDC, ...); their origins, licenses and copyright notices are listed in THIRD_PARTY_NOTICES.md. Because the CCDC lasso solver derives from GPL-2.0-only code, the compiled extension as a whole is distributed under GPL version 2.
