AstraLint

AstraLint is a Python linter for Space Physics data files, validating conformance to standards such as ISTP and PDS4.

🚀 Try it online — no installation required!

Install

AstraLint is published on PyPI. The simplest way to install is with pip:

pip install astralint

Note: PyPI package names are case-insensitive; pip install AstraLint also works. If you prefer using a virtual environment, create and activate one before installing.

Overview

AstraLint validates data files against conformance suites using a codec-agnostic architecture:

1. Codecs transform file formats (e.g., CDF) into a common abstract representation ( File)
2. Suites define collections of validation rules (e.g., ISTP, PDS4)
3. Rules check specific requirements, defined either in Python or YAML

Usage

# Lint a file against the default ISTP suite
astralint lint myfile.cdf

# Lint a multiple files at once
astralint lint file1.cdf file2.cdf file3.cdf

# Lint against a specific suite
astralint lint myfile.cdf --suite PDS4

# Select specific rules to run filtering by reference ID or name, regex supported
astralint lint myfile.cdf --suite ISTP --select "ISTP-MD-003" --select ".*GlobalAttributes"

# Ignore specific rules by reference ID or name, regex supported
astralint lint myfile.cdf --suite ISTP --ignore "ISTP-MD-00[0-9]" --ignore "MandatoryGlobalAttributes"

# Show every check, including the ones that passed (full tree)
astralint lint myfile.cdf --show-passed

# Show only failed assertions, pruning passed and skipped from the full tree
astralint lint myfile.cdf --show-passed --failed-only

# List available suites
astralint list-suites

# Strict mode: exit with error on warnings too
astralint lint myfile.cdf --strict

# Auto-fix deterministic ISTP issues and write a corrected copy (<stem>.fixed.cdf)
astralint fix myfile.cdf

# Dry run: list the proposed fixes without writing anything
astralint fix myfile.cdf --apply none

By default the console output is quiet, like a typical linter: it lists only the errors and warnings that need attention, sorted by severity, and ends with a one-line verdict (e.g. ✗ Found 7 problems (3 errors, 4 warnings), plus 13 info findings). Use --show-passed to see the full nested tree of every check, and --output html for an interactive, filterable report.

AstraLint returns exit code 1 on validation errors (or warnings with --strict), making it suitable for CI/CD pipelines.

Auto-fixing

AstraLint can propose and apply deterministic fixes for many ISTP issues. When you lint a CDF, the verdict is followed by a hint pointing at the fix command:

✗ Found 8 problems (5 errors, 3 warnings)

→ 5 auto-fixable, 3 need review — run: astralint fix myfile.cdf

astralint fix runs a convergence loop — validate → propose fixes → apply the safe ones → re-validate — until the file is clean or no further progress is made, then writes a corrected copy:

# Apply the safe (auto) fixes; writes <stem>.fixed.cdf
astralint fix myfile.cdf

# Dry run: list every proposed fix (auto + staged) without writing
astralint fix myfile.cdf --apply none

# Choose the output path
astralint fix myfile.cdf --output corrected.cdf

Every proposed fix carries its source, confidence, and a one-line provenance note, and falls into one of three dispositions:

• auto — deterministic and safe, applied automatically. Examples: a missing FILLVAL set to the ISTP default for the variable's type; VAR_TYPE/DEPEND_0 inferred from the variable reference graph; Logical_file_id/Logical_source derived from an ISTP-conventional filename; an out-of-range FILLVAL reset to the standard fill; Generation_date reformatted to yyyymmdd. For the PDS4 suite, astralint fix also re-saves the CDF uncompressed and contiguous in one lossless step, clearing the CDF-A compression and fragmentation requirements.
• staged — computed but lossy or ambiguous, so it is suggested for review and never applied automatically. Examples: truncating an over-long CATDESC/FIELDNAM/LABLAXIS; a closest-name suggestion for a dangling DEPEND_i/LABL_PTR_i pointer.
• needs your input — irreducibly human and never fabricated (e.g. UNITS, PI_name, DOI).

Physical/numeric values (UNITS, VALIDMIN/VALIDMAX, …) and identity/provenance attributes (PI_name, DOI, …) are never invented — they are only ever reported, not auto-filled.

Configuration

AstraLint can be configured via pyproject.toml or .astralint.yaml. Configuration is loaded with the following precedence (highest to lowest):

1. CLI arguments
2. .astralint.yaml (project root)
3. pyproject.toml [tool.astralint]
4. Built-in defaults

Quick Start

# Generate a starter config file
astralint config init

# Validate your config file
astralint config validate

# Show resolved configuration (merged from all sources)
astralint config show

Example .astralint.yaml

suite: ISTP

select:
  - "MandatoryGlobalAttributes"
  - "ISTP-VAR-.*"

ignore:
  - "DeprecatedRule"

severity_overrides:
  ISTP-VAR-001: WARNING

extra_rules:
  - "./custom_rules/"

output:
  format: console
  verbose: false
  show_passed: true

Example pyproject.toml

[tool.astralint]
suite = "ISTP"
select = ["MandatoryGlobalAttributes"]

[tool.astralint.output]
format = "html"
verbose = true

📖 Full Configuration Reference →

Architecture

flowchart TD
    subgraph Input["📥 Input"]
        A[📄 Data File]
    end

    subgraph Codecs["🔌 Codecs (pluggable)"]
        B1[CDF Codec]
        B2[NetCDF Codec]
        B3[... more]
    end

    subgraph Core["⚙️ Core"]
        C[📦 Abstract File Model]
        D[📋 Conformance Suite]
        E[✅ Rules & Assertions]
    end

    subgraph Suites["📚 Suites (pluggable)"]
        S1[ISTP]
        S2[PDS4]
        S3[... more]
    end

    subgraph Reports["📊 Reports (pluggable)"]
        R1[Console]
        R2[JSON]
        R3[... more]
    end

    A --> B1 & B2 & B3
    B1 & B2 & B3 --> C
    C --> D
    S1 & S2 & S3 -.->|loads| D
    D --> E
    E --> R1 & R2 & R3

    style C fill:#fff3e0
    style Core fill:#f5f5f5,stroke:#999
    style Codecs fill:#e3f2fd,stroke:#1976d2
    style Suites fill:#fce4ec,stroke:#c2185b
    style Reports fill:#e8f5e9,stroke:#388e3c

File Model

The abstract File model is the core data structure that all codecs produce. Rules and assertions operate on this unified representation:

File
├── filename: str                            # File name or identifier
├── extension: str                           # File extension (e.g., "cdf")
├── compression: str                     # e.g., "gzip", "none"
├── attributes: {name → Attribute}       # Global metadata
│   ├── "Project"      → Attribute
│   ├── "PI_name"      → Attribute
│   └── ...
└── variables: {name → Variable}         # Data variables
    ├── "Epoch" → Variable
    │   ├── name: str                    # "Epoch"
    │   ├── shape: [int]                 # e.g., [1440]
    │   ├── compression: str             # "gzip", "none"
    │   ├── data_type: DataType          # TT2000, FLOAT64, ...
    │   ├── record_variance: bool
    │   └── attributes: {name → Attribute}
    │       ├── "CATDESC"  → Attribute
    │       ├── "FILLVAL"  → Attribute
    │       └── ...
    ├── "Temperature" → Variable
    └── ...

Attribute
├── name: str
├── data_type: [DataType]                # List of data types
└── shape: [int]                         # Attribute dimensions

DataType = CHAR | UINT8 | UINT16 | UINT32 | UINT64
         | INT8 | INT16 | INT32 | INT64
         | FLOAT32 | FLOAT64
         | TT2000 | CDFEPOCH | CDFEPOCH16

Path Navigation

Rules use /-separated paths with regex support to navigate the model:

Lists are accessed using numeric indices: path/to/list/0, path/to/list/1, etc.

Defining Rules in YAML

Rules can be defined declaratively in YAML files. Example from MandatoryGlobalAttributes.yaml:

name: MandatoryGlobalAttributes
description: "All mandatory global attributes must be present"
url: "https://..."
reference: "ISTP-MD-003"
severity: ERROR
suite: ISTP

assertions:
  - path: "attributes"
    check: contains_keys
    keys:
      - Data_type
      - Logical_source
      - PI_name
    message: "Missing mandatory global attribute: {key}"

  - path: "variables/.*/attributes"
    check: contains_keys
    keys: [ CATDESC, FIELDNAM, FILLVAL ]
    message: "Variable missing required attribute: {key}"

Available Assertions

📖 Full Assertions Reference →

Supported File Formats

Available Conformance Suites (WIP/Demo)

• ISTP - ISTP Metadata Guidelines
• CDAWeb - CDAWeb ingestion profile: inherits ISTP and promotes the CDAWeb-required attributes (Instrument_type, Mission_group) to errors, plus CDAWeb-specific entry limits
• PDS4 - PDS4 CDF archiving profile (CDF-A): inherits ISTP and adds the constraints from the Guide to Archiving CDF Files in PDS4 — no file/variable compression, CDF version ≥ 3.4, a required spase_DatasetResourceID, contiguous (non-fragmented) variables, and zVariables only.
• SOLARNET - SOLARNET Metadata Recommendations

The PDS4 suite covers every CDF-A structural requirement that applies. Contiguity and zVariable-only checks use Variable.is_contiguous / is_zvariable from pycdfpp ≥ 0.11 (older pycdfpp simply skips those two checks). The single-file requirement is satisfied by construction — AstraLint only loads single-file CDFs. (See issue #2.)

Extending AstraLint

Adding a New Codec

Create a new codec in src/astralint/codecs/. Subclasses register themselves automatically via __init_subclass__, so simply defining the class and importing the module is enough to make the codec available:

from astralint.base import Codec, File


class MyCodec(Codec):
    @classmethod
    def supported_extensions(cls) -> list[str]:
        return ["ext"]

    @staticmethod
    def load(file_url_or_bytes: str | bytes) -> File | None:
        # Transform your file format into the abstract File model
        ...

For remote files, AstraLint provides get_remote_file(url) -> bytes to fetch remote content and is_remote_file(url) -> bool to detect URLs.

Adding a New Assertion Type

Create a new assertion in src/astralint/base/yaml_rules/assertions/. Subclasses of BaseAssertion are auto-registered into the discriminated union via the check field's Literal value:

from typing import Any, Literal

from astralint.base import File, Severity, ValidationResult
from astralint.base.yaml_rules.assertions.base import BaseAssertion


class MyAssertion(BaseAssertion):
    check: Literal["my_check"] = "my_check"

    # Add custom fields as needed; they are populated from the YAML rule definition.
    # expected_value: Any

    def single_assertion(
        self,
        file: File,
        path: str,
        value: Any,
        severity: Severity,
        captures: dict[str, str] | None = None,
    ) -> ValidationResult:
        # Called once per (path, value) pair that matched the base assertion's path
        # pattern. `captures` holds named groups from {name} placeholders, if any.
        ...

Project Docs

For how to install uv and Python, see installation.md.

For development workflows, see development.md.

For instructions on publishing to PyPI, see publishing.md.

This project was built from simple-modern-uv.
