WiDiT 0.1.0a1

Windowed Diffusion Transformer in 2D and 3D

WiDiT is a SwinIR-style DiT backbone that unifies 2D images and 3D volumes with N-D windowed attention, optional Swin shifts, and AdaLN-Zero conditioning.

• Single model class: widit.models.WiDiT

• Optional timestep conditioning (pass timestep=None if unused)

• Shared blocks for 2D/3D via N-D window partitioning

• Presets for quick experiments in both 2D and 3D

Installation

Install using pip:

pip install widit

Or

pip install git+https://github.com/rbturnbull/widit.git

WiDiT depends on torch and timm (for the 2D patch embedding path).

Warning

WiDiT is currently in alpha testing phase. More updates are coming soon.

Quick Start (2D)

import torch
from widit.models import WiDiT

# Example: 2D RGB input & conditioning (e.g., low-res guidance)
N, C, H, W = 2, 3, 128, 96
x      = torch.randn(N, C, H, W)
cond   = torch.randn_like(x)
t      = torch.randint(0, 1000, (N,), dtype=torch.long)  # optional

model = WiDiT(
    spatial_dim=2,
    input_size=(H, W),        # kept for API parity; not required at forward
    patch_size=2,             # must divide H and W
    in_channels=C,
    hidden_size=256,          # must be divisible by num_heads and even
    depth=6,
    num_heads=8,
    window_size=8,            # can be int or (wh, ww)
    mlp_ratio=4.0,
    learn_sigma=True,         # output channels = 2*C if True
)

# Timestep is optional; pass None to disable conditioning
y = model(x, cond, t)         # (N, 2*C, H, W) if learn_sigma=True

Quick Start (3D)

import torch
from widit.models import WiDiT

# Example: 3D single-channel volumes
N, C, D, H, W = 1, 1, 64, 64, 48
x    = torch.randn(N, C, D, H, W)
cond = torch.randn_like(x)

model = WiDiT(
    spatial_dim=3,
    input_size=(D, H, W),
    patch_size=2,             # must divide D/H/W
    in_channels=C,
    hidden_size=256,
    depth=4,
    num_heads=8,
    window_size=(4, 4, 4),    # can be int or (wd, wh, ww)
    mlp_ratio=4.0,
    learn_sigma=False,        # output channels = C if False
)

y = model(x, cond, timestep=None)  # (N, C, D, H, W)

Presets

Presets provide ready-made configurations for common model sizes (2D & 3D), all using patch_size=2 and Swin-style window attention:

from widit.models import PRESETS

# 2D: B, M, L, XL
model_2d = PRESETS["WiDiT-L/2"](in_channels=3, learn_sigma=True)

# 3D: B, M, L, XL
model_3d = PRESETS["WiDiT3D-M/2"](in_channels=1, learn_sigma=False)

# Run
y2d = model_2d(x2d, cond2d, timestep=None)
y3d = model_3d(x3d, cond3d, timestep=torch.randint(0, 1000, (x3d.shape[0],)))

API Overview

WiDiT(
    *,
    spatial_dim: int,                          # 2 (images) or 3 (volumes)
    input_size: int | Sequence[int] | None = None,
    patch_size: int | Sequence[int] = 2,       # per-axis tuple allowed
    in_channels: int = 1,
    hidden_size: int = 768,                    # even; divisible by num_heads
    depth: int = 12,
    num_heads: int = 12,
    window_size: int | Sequence[int] = 8,      # per-axis tuple allowed
    mlp_ratio: float = 4.0,
    learn_sigma: bool = True,
)

forward(
    input_tensor:       torch.Tensor,          # (N, C, *spatial)
    conditioned_tensor: torch.Tensor,          # (N, C, *spatial), same shape as input_tensor
    timestep:           torch.Tensor | None = None,  # (N,) or None
) -> torch.Tensor                              # (N, out_channels, *spatial)

Shapes & contracts

• *spatial is (H, W) for 2D and (D, H, W) for 3D.

• patch_size must evenly divide each spatial dimension.

• window_size can be an int or a per-axis tuple; internal padding ensures full windows (removed before returning).

• hidden_size must be even (split across the two patch embedders) and divisible by num_heads.

• If learn_sigma=True, output channels = 2 * in_channels (mean + sigma style).

Conditioning

• timestep is optional. Pass None to disable AdaLN conditioning (the block falls back to standard LN + residual).

• If provided, the model uses widit.timesteps.TimestepEmbedder to produce a per-sample vector projected to the token dimension.

Building Blocks

These are used internally, but you can also import them for custom stacks.

• widit.blocks.WiDiTBlock – N-D windowed MSA + MLP with AdaLN-Zero

• widit.blocks.WiDiTFinalLayer – final projection head with AdaLN-Zero

• widit.patch.PatchEmbed – unified 2D/3D patch embedding

• widit.timesteps.TimestepEmbedder – sinusoidal → MLP conditioning

All of the above expose init_weights() so the model can initialize components cleanly (adaLN-Zero policy for blocks & head; Xavier for projections; Normal for timestep MLP weights).

Training Snippet

import torch
from torch.optim import AdamW
from widit.models import WiDiT

device = "cuda" if torch.cuda.is_available() else "cpu"

model = WiDiT(
    spatial_dim=2,
    in_channels=3,
    hidden_size=256,
    depth=6,
    num_heads=8,
    patch_size=2,
    window_size=8,
    learn_sigma=True,
).to(device)

opt = AdamW(model.parameters(), lr=1e-4, weight_decay=0.01)

for step in range(100):
    x    = torch.randn(8, 3, 128, 96, device=device)
    cond = torch.randn_like(x)
    t    = torch.randint(0, 1000, (x.shape[0],), device=device)

    y = model(x, cond, t)                      # (N, 6, H, W) here (mean+sigma for C=3)
    target = torch.randn_like(y)

    loss = torch.nn.functional.mse_loss(y, target)
    opt.zero_grad(set_to_none=True)
    loss.backward()
    opt.step()

Tips & Gotchas

• Patch size equality in unpatchify: currently the unpatchify path enforces equal patch size along all axes (e.g., patch_size=2 or (2,2,2)). Mixed per-axis patch sizes for output reconstruction are not supported yet.

• Token grid divisibility: ensure every spatial dimension is divisible by patch_size. Window attention will pad internally to complete windows and crop back, but patch embedding is stride-based.

• Timestep optional: pass timestep=None to run the model without diffusion conditioning (AdaLN defaults reduce to a vanilla transformer residual path).

• Mixed precision: standard AMP (torch.cuda.amp) works out-of-the-box.

Reference Shapes

2D

• Input: (N, C, H, W)

• Output: (N, 2*C, H, W) if learn_sigma=True, else (N, C, H, W)

3D

• Input: (N, C, D, H, W)

• Output: (N, 2*C, D, H, W) if learn_sigma=True, else (N, C, D, H, W)

Credits

Robert Turnbull - Melbourne Data Analytics Platform (MDAP), The University of Melbourne
