ann-router

🇫🇷  |  🇬🇧

Turning a photo, a sentence or a product into a vector — a list of numbers placed so that similar things land close together — is how most AI search works. A search engine, a recommendation system finding "more like this", a chatbot pulling the right paragraph out of a document: all of them do this.

The hard part comes next: finding the closest vectors to a query inside a database of millions or billions of them.

Checking every one of them does not scale, so real systems run an approximate search instead — trading a small, controlled amount of accuracy for a search that stays fast no matter how large the database grows.

The Promise

ann-router belongs to the AI Helpers suite. It is a router: you describe your approximate-nearest-neighbour (ANN) search problem in measured terms (how many vectors, how many dimensions, how much accuracy you actually need), and it selects, justifies, and can instantiate the right engine for that problem, instead of marrying you to a single library that fits today's corpus and not tomorrow's.

Local-first by design. A routing decision is a pure function of the criteria you pass plus a probe of the machine you are on: no account, no API key, no telemetry, no network call. The engines it then builds run inside your own process unless you deliberately point one at a server.

It is an indispensable component for RAG (retrieval-augmented generation: an AI system that looks up the relevant text before answering, instead of relying only on what a language model memorized during training).

It is the vector-search sibling of best-engine-ai-helper (which picks the best local LLM for a machine).

Same philosophy: measure the criteria → select the engine → return a discussable rationale.

The engines it routes among:

exact (brute force) · turbovec · HNSW (hnswlib) · FAISS (IVF/PQ) · Annoy · Qdrant · pgvector

(ScaNN was evaluated and dropped: no Apple-Silicon wheel exists, and the project has abandoned it as a supported backend; see CHANGELOG.md.)

Importing the package is cheap: no engine's optional dependency is loaded at import time, so import ann_router costs only the four declared core dependencies (numpy, click, pyyaml, os-helper), and a backend whose dependency is absent simply reports itself unavailable while the router routes around it: this is lazy importing.

Status

None of this is a one-off script. Every change runs through continuous integration (CI, automated checks triggered by each push and pull request): lint and format checks, then the full test suite, defined in .github/workflows/tests.yml, before anything reaches main. Each release is a semantic-versioned (MAJOR.MINOR.PATCH) git tag, visible with git tag, published to PyPI (the Python Package Index) as ann-router, so pip install ann-router always installs a version that already passed that gate.

The version number stays honest about where the project actually stands. At 0.3.x the public interface can still move between releases, and no other published AI Helpers package depends on ann-router yet. Read it today as a standalone routing utility with a tested, CI-gated core, not as a component with years of production mileage behind it elsewhere.

The recall floors pinned in tests/conftest.py (RECALL_THRESHOLDS) are the closest thing to a production contract this project makes: versioned numbers a release cannot quietly slip below.

Documentation

💻 Documentation

🗺️ Landscape

📋 Examples

Why route instead of just picking FAISS (or any one engine)?

Because the right engine is a function of the problem, and the problem changes: a corpus of a few hundred vectors wants an exact scan (instant, recall 1.0); a corpus with constant inserts/deletes wants turbovec (O(1) mutation); one needing SQL WHERE-filters wants pgvector; a frozen, memory-tight corpus wants Annoy. Hard-coding one library gets one of these right and the rest wrong. See LANDSCAPE.md.

How it works

Installation

Local (conda)

A minimal environment.yaml pins Python + pip and delegates every actual dependency to requirements.txt:

git clone https://github.com/warith-harchaoui/ann-router.git
cd ann-router
conda env create -f environment.yaml
conda activate ann-router
pip install -e '.[all]'        # or [hnsw]/[faiss]/... for one engine at a time

Server (Docker)

A single image builds every pip-installable backend plus the HTTP API door:

docker build -t ann-router .
docker run --rm -p 8018:8018 ann-router

# Or through Compose, which carries the port and a health probe — and, behind
# --profile backends, the two backends that need a server (qdrant, pgvector)
docker compose up --build
docker compose --profile backends up --build
curl -X POST localhost:8018/route -H 'content-type: application/json' \
    -d '{"n_vectors": 500000, "dim": 768, "dynamic": true}'

Plain pip

git clone https://github.com/warith-harchaoui/ann-router.git
cd ann-router
pip install 'os-helper'
pip install .

Add engines as needed (per-backend extras), or everything at once:

pip install 'ann-router[hnsw]'      # one engine
pip install 'ann-router[all]'       # every pip-installable engine + cli + api

Full, platform-specific instructions, including the Apple Silicon annoy caveat and pgvector notes, are in INSTALL.md.

Quick start

import numpy as np
import ann_router as ar

# 1. Describe the problem in measured terms.
criteria = ar.Criteria(
    n_vectors=2_000_000,
    dim=768,
    dynamic=True,  # frequent adds/removes
    target_recall=0.85,  # below HIGH_RECALL=0.9, turbovec's calibrated ceiling
    hardware=ar.detect_hardware(),
)

# 2. Ask which backend, and why.
choice = ar.route(criteria)
print(choice.backend)
# turbovec
print(choice.rationale)
# corpus receives frequent updates: turbovec offers O(1) add_with_ids/remove(id)
# with no index rebuild, plus TurboQuant 2-4 bit (~16x) compression — graph
# indexes degrade under deletes, so they are avoided here. target_recall=0.85
# is below HIGH_RECALL=0.9, within turbovec's calibrated range.

# 3. Or route + build in one call, then search.
vectors = np.random.default_rng(0).standard_normal((5_000, 768)).astype("float32")
index, choice = ar.auto_index(vectors, ar.Criteria(n_vectors=5_000, dim=768))
print(choice.backend)
# hnsw           (5 000 is already past the calibrated EXACT_MAX_N=1000)
ids, distances = index.search(vectors[:3], k=10)
print(ids.shape)
# (3, 10)

At the house default target_recall=0.95, this same dynamic=True corpus routes to hnsw instead: turbovec's own calibration (bench/results/calibrated_policy.yaml) consistently undershoots recall 0.9, so the router prefers HNSW's better recall over turbovec's O(1) mutation once the target climbs past HIGH_RECALL=0.9.

Every backend speaks the same ANNIndex interface:

index.build(vectors, ids=None)
index.add(vectors)
index.add_with_ids(vectors, ids)
index.remove(ids)
ids, distances = index.search(queries, k)
index.save(path)
index.load(path)
Backend.capabilities()  # supports_remove / supports_filter / persistent / needs_gpu ...

Operations a backend genuinely cannot do (e.g. Annoy.remove) raise a clear NotSupported; a backend whose dependency is missing raises BackendUnavailable with the pip install line that fixes it.

The five doors (one core, five surfaces)

1. Library: everything above (ann_router).
2. CLI: ann-router, built with click. Subcommands: route, build, search, bench, capabilities.
3. HTTP API: uvicorn ann_router.api:app ([api] extra, or the Docker image above): POST /route, GET /capabilities, GET /bench.
4. MCP server: ann-router-mcp, equivalently python -m ann_router.mcp_server ([mcp] extra), the same route/capabilities/bench operations as the HTTP API, auto-exposed as MCP tools via fastapi-mcp at http://127.0.0.1:8019/mcp (Streamable HTTP, not stdio).
5. Skill: skills/ann-router/SKILL.md, so an agent knows when to reach for the router.

ann-router route --n-vectors 2000000 --dim 768 --dynamic --markdown
ann-router bench --n 5000 --dim 128 -k 10
ann-router capabilities

How selection works

The decision tree (tunable via policy.yaml / ANN_ROUTER_POLICY):

flowchart TD
    Q[["n_vectors, dim, target_recall,<br/>dynamic, persistence, hardware..."]]
    Q --> D1{n < EXACT_MAX_N?}
    D1 -->|yes| EXACT([exact])
    D1 -->|no| D2{frequent updates?}
    D2 -->|yes| D2R{target_recall <<br/>HIGH_RECALL?}
    D2R -->|yes| TURBOVEC([turbovec])
    D2R -->|no| HNSW
    D2 -->|no| D3{n >= FAISS_MIN_N<br/>and GPU/batch?}
    D3 -->|yes| FAISS([faiss])
    D3 -->|no| D4{persistence or<br/>metadata filtering?}
    D4 -->|yes, DB in place| PGVECTOR([pgvector])
    D4 -->|yes, no DB| QDRANT([qdrant])
    D4 -->|no| D5{tight memory<br/>budget?}
    D5 -->|yes| ANNOY([annoy])
    D5 -->|no| HNSW([hnsw · default])

    classDef exact fill:#808080,color:#fff,stroke:#808080
    classDef turbovec fill:#AF52DE,color:#fff,stroke:#AF52DE
    classDef faiss fill:#FF9500,color:#fff,stroke:#FF9500
    classDef pgvector fill:#28CD41,color:#fff,stroke:#28CD41
    classDef qdrant fill:#79DBDC,color:#003333,stroke:#79DBDC
    classDef annoy fill:#FFCC00,color:#3d2e00,stroke:#FFCC00
    classDef hnsw fill:#007AFF,color:#fff,stroke:#007AFF
    classDef decision fill:#F8F8F8,color:#000000,stroke:#F8F8F8

    class EXACT exact
    class TURBOVEC turbovec
    class FAISS faiss
    class PGVECTOR pgvector
    class QDRANT qdrant
    class ANNOY annoy
    class HNSW hnsw
    class D1,D2,D2R,D3,D4,D5,Q decision

The shipped values are EXACT_MAX_N=1000, FAISS_MIN_N=20000 and HIGH_RECALL=0.9, each carrying its calibration note in ann_router/policy.yaml.

Row 1's EXACT_MAX_N scales with Criteria.latency_budget_ms: a brute-force scan's cost is ~linear in n for fixed dim, so a budget looser than the 10 ms reference extends the exact/ANN crossover proportionally, and a tighter one shrinks it; see ann_router.policy.effective_exact_max_n.

EXACT_MAX_N/FAISS_MIN_N are calibrated from measured recall/latency data rather than guessed; see bench/README.md for the sweep and bench/results/decision_tree.md for this project's own tree with the measured thresholds filled in, per embedding dimension. ann_router/policy.yaml ships the conservative reduction of those per-dim values into the single scalars the table above uses (see bench/results/calibrated_policy.yaml for the full evidence).

The router returns not just the name but the criteria that drove it and the alternatives it considered (including any preferred-but-uninstalled engine it fell back from), so the choice is auditable and overridable.

How close was the call?

The rules are threshold-based, so a rationale can read equally confident a hair either side of a boundary. target_recall=0.89 routes to turbovec; target_recall=0.90 routes to hnsw. One percentage point — well inside the noise of how anyone picks a recall target — changes the engine, and nothing in the wording suggests it.

So every decision also carries sensitivity: the small changes to your criteria that would change the answer, nearest first.

choice = route(Criteria(n_vectors=500_000, dim=768, dynamic=True, target_recall=0.89))
choice.sensitivity
# [{'criterion': 'target_recall', 'from': 0.89, 'to': 0.9,
#   'backend': 'hnsw', 'relative_change': 0.0112}]

An empty list is the reassuring case: no criterion flips the verdict within 25 %, so the pick is robust to how roughly you measured.

It is a probe, not a hand-written note, which is why it catches things nobody would have thought to mention. At n_vectors=900 it flags the latency budget as well as n_vectors — both sit near a boundary there:

route(Criteria(n_vectors=900, dim=128)).sensitivity
# [{'criterion': 'latency_budget_ms', 'from': 10.0, 'to': 9.0,
#   'backend': 'hnsw', 'relative_change': 0.1},
#  {'criterion': 'n_vectors', 'from': 900, 'to': 1008,
#   'backend': 'hnsw', 'relative_change': 0.12}]

Criteria (the input spec)

n_vectors, dim, target_recall, latency_budget_ms, memory_budget_gb, dynamic, metadata_filtering, hardware (cpu/gpu/apple_silicon, auto-detectable), persistence, batch_queries, metric (cosine/l2/ip). Only n_vectors and dim are required.

More

• EXAMPLES.md: a runnable cookbook.
• LANDSCAPE.md: how ann-router compares to just picking one engine.
• CODING.md: the coding standard this repo holds itself to.
• bench/README.md: the measured calibration harness.
• CONTRIBUTING.md · CHANGELOG.md · TRIGGERS.md

Author

Warith HARCHAOUI, Ph.D.

License

BSD-3-Clause; see LICENSE.
