ballistic-solver 1.0.0

Numerical launch-angle solver for moving targets under gravity and quadratic drag.

Official repository notice

This is the only official repository for ballistic-solver.

Official repository: https://github.com/ujinf74/ballistic-solver

Do not download ZIP files, binaries, or installers from third-party copies, mirrors, or reuploads. Use only the Releases page of this repository.

ballistic-solver is a native C/C++ numerical solver that computes launch angles to intercept moving targets under gravity and quadratic air drag, with optional wind.

Unlike vacuum / closed-form solvers, this project simulates the projectile and solves the intercept numerically, aiming for robust real-time use even when trajectories are strongly curved.

Applications. The solver only sees relative kinematics, so the same code fits many domains — robotics (interception / capture), perimeter security and counter-UAS, agricultural bird/pest deterrence, games and simulation, and defense. An optional position-only tracker (bs.TargetTracker) adds lead-fire from a noisy track. See benchmarks/intercept_eval.py and examples/viz/ for cross-domain examples and accuracy comparisons.

---

Quick start

Python (PyPI)

pip install ballistic-solver

Requires Python >= 3.10.

import ballistic_solver as bs

result = bs.solve(
    relPos0=(120, 30, 5),
    relVel=(2, -1, 0),
    v0=90,
    kDrag=0.002,
)

print(result["theta"], result["phi"], result["miss"])
print(result["success"], result["status"], result["message"])

For tighter convergence without manually tuning every knob:

params = bs.params_preset("precise")
result = bs.solve((120, 30, 5), (2, -1, 0), 90, 0.002, params=params)

For repeated solves, Python also provides a thin convenience wrapper:

solver = bs.Solver.preset("precise")
result = solver.solve((120, 30, 5), (2, -1, 0), 90, 0.002)

---

Demo (Unity)

Highly curved trajectories under strong air drag, still converging to a hit against moving targets.

https://github.com/user-attachments/assets/c0c69cdd-0dd4-4606-9c7d-f21dd002d7f7

---

Why this solver

Many launch-angle solvers depend on vacuum assumptions or partially linearized models. This project instead simulates the projectile and solves the intercept numerically, targeting robustness in real-time simulations and integration scenarios.

---

Key properties

• Moving targets supported
• Constant-acceleration targets supported via the extended API
• Strong air resistance (quadratic drag) supported
• Low / High arc selection (since v0.2)
• Wind vector supported (since v0.3)
• Extended C ABI utilities (since v0.4)
• Quartic vacuum-lead initialization for moving targets (since v0.6)
• High-arc moving-target auxiliary multi-start fallback (since v0.6.1)
• Coordinate-residual Gauss–Newton core with vacuum-seeded Jacobian (default since v1.0; ~15–25% faster, auxiliary-residual method kept as solve_aux)
• Fast / balanced / precise solver presets
• Physical drag helper: kDrag = 0.5 * rho * Cd * area / mass
• Robust in strongly nonlinear regimes (no analytic assumptions)
• Best-effort result returned even without perfect convergence
• Explicit success / failure reporting (+ diagnostic message)
• Stable C ABI for multi-language use
• Header-only C++ core
• Easy install via PyPI: pip install ballistic-solver

---

Python API

solve(...)

solve(relPos0, relVel, v0, kDrag, arcMode=None, params=None, relAcc=None) -> dict

• relPos0: target relative position at t=0 (x,y,z)
• relVel: target relative velocity (x,y,z)
• v0: muzzle speed (scalar)
• kDrag: quadratic drag coefficient
• arcMode: 0/1 or "low"/"high" (case-insensitive); None keeps the params value
• params: optional BallisticParams for advanced tuning (gravity, wind, integrator and solver knobs)
• relAcc: optional constant target relative acceleration (x,y,z); same as solve_accel

Returned dict keys include:

• success (bool)
• theta, phi (radians)
• miss (closest-approach distance)
• tStar (time of closest approach)
• relMissAtStar (3-vector miss at tStar)
• status (SolveStatus integer)
• message (short diagnostic string)
• plus convergence diagnostics (iterations, acceptedSteps, lastLambda, lastAlpha)

solve uses the coordinate-residual core (Gauss–Newton on the 3D closest-approach miss, vacuum-seeded Jacobian, multistart fallback). It is the same signature as before and a drop-in replacement, typically ~15–25% faster at equal robustness.

solve_aux(...)

solve_aux(relPos0, relVel, v0, kDrag, arcMode=None, params=None, relAcc=None) -> dict

The previous default: the auxiliary-residual method (re-aim through the vacuum inverse, solved by damped least squares with a multistart fallback). Same return dict as solve. Kept for compatibility and for reproducing the auxiliary-residual results.

solve_predicted(...)

solve_predicted(predictor, v0, kDrag, arcMode=None, params=None) -> dict

Lead-fire against a position-only trajectory predictor instead of explicit relVel/relAcc. predictor(t) returns the predicted relative position (x, y, z) at time t >= 0 (e.g. from a Kalman/IMM track). Internally a local constant-acceleration model is fitted at the intercept time and iterated to a fixed point — exact for constant-velocity / constant-acceleration predictors and second-order accurate at the intercept for smoothly curving tracks. Returns the same dict as solve.

TargetTracker

tracker = bs.TargetTracker(processNoise=1.0, measNoise=0.25)
for t, pos in measurements:        # (timestamp, relative position)
    tracker.update(t, pos)
lead = tracker.predict(1.5)        # predicted relative position 1.5 s ahead
result = tracker.solve(v0=95.0, kDrag=0.0015)   # lead-fire via the predictor seam

A position-only constant-acceleration Kalman tracker (per-axis, white-noise-jerk model). It denoises the track and recovers velocity/acceleration without finite-difference noise, then feeds the predictor seam — so callers never supply relVel/relAcc. See benchmarks/predictor_eval.py for a lead-prediction accuracy comparison against a constant-velocity baseline.

A real-time 3D showcase — the tracker leading a noisy, diving moving target with range rings, tracer trails, and a live hit-rate HUD — is in examples/godot/ (default scene demo/intercept_demo.tscn).

https://github.com/user-attachments/assets/7de04137-61d9-4cf0-be5e-9804d6a9c67b

Utilities

params = bs.params_preset("fast")  # or "balanced", "precise"
kDrag = bs.k_drag_from_physical(
    airDensity=1.225,
    dragCoefficient=0.30,
    area=0.00426,
    mass=0.145,
)

For constant-acceleration targets:

result = bs.solve_accel(
    relPos0=(120, 30, 5),
    relVel=(2, -1, 0),
    relAcc=(0, 0.2, 0),
    v0=90,
    kDrag=0.002,
    params=bs.params_preset("precise"),
)

---

Solver validity note

The solver internally integrates projectile motion using:

• 4th-order Runge–Kutta (RK4)
• Fixed timestep dt
• Quadratic drag: a = (0, 0, -g) - kDrag * |v - wind| * (v - wind)
• Wind as air velocity

To match in-game ballistics, your runtime simulation must use the same physical model and integrator configuration.

If your game uses a different integrator (e.g., Euler) or a different timestep, the computed launch angles may not hit even if the solver reports success.

---

C ABI (stable interface)

Primary intercept API:

void ballistic_inputs_init(BallisticInputs* in);
int32_t ballistic_solve(const BallisticInputs* in, BallisticOutputs* out);

Return value policy:

• 0: API call completed and out was filled.
• <0: API-level failure, such as null pointers or an internal exception.
• Numerical solve success is reported separately by out->success and out->status.
• ABI v3 adds convergence diagnostics to BallisticOutputs: iterations, acceptedSteps, lastLambda, and lastAlpha.
• ABI v4 adds a preset field to BallisticInputs (0=Fast, 1=Balanced, 2=Precise). ballistic_inputs_apply_preset records it so that the full preset tuning (line-search, lambda tries, finite-difference step, golden-section) is carried into ballistic_solve, not only dt/tMax/tolMiss/maxIter.

Callers should check both:

int32_t rc = ballistic_solve(&in, &out);
if (rc != 0) {
    /* API call failed */
}
if (!out.success) {
    /* Solver ran but did not satisfy the requested tolerance. */
}

Since v0.4.0, additional utility functions are available:

void ballistic_rk4_step(...);

int32_t ballistic_simulate_trajectory(...);
int32_t ballistic_simulate_trajectory_from_angles(...);

int32_t ballistic_find_closest_approach(...);

int32_t ballistic_vacuum_arc_angles_to_point(...);
void ballistic_initial_guess_vacuum_lead(...);

Additional extended APIs include:

void ballistic_accel_inputs_init(BallisticAccelInputs* in);
int32_t ballistic_solve_accel(const BallisticAccelInputs* in, BallisticOutputs* out);
int32_t ballistic_inputs_apply_preset(BallisticInputs* in, int32_t preset);
int32_t ballistic_k_drag_from_physical(...);
int32_t ballistic_make_relative_motion(...);

See ballistic_solver_c_api.h for full signatures and parameter definitions.

This enables usage from:

• C / C++
• Python (ctypes via the C ABI)
• C# / .NET / Unity (P/Invoke)
• Unity (UnityEngine.Vector3 wrapper example)
• Godot 4 (GDExtension addon-style example)
• Others via FFI

Prebuilt native binaries are provided via GitHub Releases.

---

Arc mode (since v0.2)

C ABI convention:

• arcMode = 0 → Low
• arcMode = 1 → High

High arc example:

https://github.com/user-attachments/assets/4334ed87-597e-4ad4-b21e-c1a1a17e8cd8

---

Wind (since v0.3)

C ABI convention:

• wind[3] = air velocity vector (same frame as relPos0/relVel)
• Drag uses relative airspeed: v_rel = v_projectile - wind

Wind demo:

https://github.com/user-attachments/assets/1cd998cf-34db-4a74-8817-c6393227ef4e

---

Using prebuilt binaries (C ABI)

Download the archive for your platform from Releases.

Each release contains:

• Shared library

  • Windows: ballistic_solver.dll
  • Linux: libballistic_solver.so
  • macOS: libballistic_solver.dylib

• C ABI header: ballistic_solver_c_api.h

---

C# / Unity usage

A C# P/Invoke example is available in:

examples/dotnet/

On Windows, place ballistic_solver.dll next to the executable (or ensure it is discoverable via PATH), then call ballistic_solve via DllImport.

This works directly inside Unity.

---

How it works (high level)

1. Build a vacuum-lead initial guess from the moving-target quartic.
2. Seed the inverse Jacobian analytically from the vacuum-arc map (no trajectory integration), as a cheap preconditioner.
3. Simulate projectile motion using RK4 integration with drag (+ wind) and track the closest approach between projectile and target.
4. Use the 3D closest-approach miss vector itself as the residual (it is well-conditioned), and solve the launch angles by Gauss-Newton on it.
5. Refine the Jacobian with Broyden-style rank-1 updates; take full steps (no Levenberg–Marquardt damping, no line search).
6. If the warm start does not reach tolerance, retry from a small arc-appropriate theta-grid multistart.
7. Return the best solution found.

solve uses this coordinate-residual core. The earlier auxiliary-residual method (re-aim through the vacuum inverse, with damped least squares) remains available as solve_aux for compatibility and reproducibility.

Failure cases are explicitly detected and reported.

---

When solving can fail

The solver returns a best-effort result even when it cannot satisfy tolMiss. Common causes include:

• invalid inputs (v0 <= 0, non-positive g, dt, tMax, or maxIter)
• geometrically unreachable vacuum targets
• targets that require an intercept beyond tMax
• strong drag or high-arc cases where the selected arc branch cannot be maintained
• iteration limits that are too tight for the requested tolerance

Use success, status, message, and miss together when deciding whether to accept a solution.

---

Status codes (SolveStatus)

BallisticOutputs.status / Python result["status"] corresponds to:

• 0 = Ok
• 1 = InvalidInput
• 2 = InitialResidualFailed
• 3 = JacobianFailed
• 4 = LMStepSingular
• 5 = ResidualFailedDuringSearch
• 6 = LineSearchRejected
• 7 = LambdaTriesExhausted
• 8 = MaxIterReached

The default coordinate-residual solve emits Ok, InvalidInput, JacobianFailed, or MaxIterReached. The Levenberg–Marquardt codes (4–7) are specific to the auxiliary-residual solve_aux path.

message contains a short diagnostic string.

---

Build from source

cmake -S . -B build
cmake --build build -j
ctest --test-dir build

The shared library target is ballistic_solver.

Regression and benchmark

Distributed regression and benchmark scripts are available:

python tests/random_regression.py
python benchmarks/linear_cases.py

The CI workflow runs CTest smoke coverage plus the Python regression script. The regression script includes analytic vacuum checks, constructed moving-target vacuum cases, unreachable-target checks, randomized linear cases, and constant-acceleration API smoke coverage.

Benchmark numbers depend on CPU, OS, compiler, build type, Python version, and whether native or Python entrypoints are measured. The local reference below was measured on Windows NT 10.0.26200.0, AMD Ryzen 9 6900HS, Python 3.12.8, MSVC 14.44.35207, x64 Release build, through the Python native extension.

Reference preset result from the same local Release build:

fast:     500/500, median 0.054 ms, p95 0.237 ms, p95 miss 2.810e-02 m
balanced: 500/500, median 0.115 ms, p95 0.492 ms, p95 miss 7.053e-03 m
precise:  500/500, median 0.168 ms, p95 0.669 ms, p95 miss 5.596e-06 m

Current default solver (coordinate-residual core) results from 10,000 generated cases with seed 20260503. The last row is the high-arc moving-target stress case:

Case set	Success	Median runtime	P95 runtime	P95 miss
Low arc, moving target	10000/10000 (100.00%)	0.168 ms	0.510 ms	6.450e-03 m
High arc, stationary target	10000/10000 (100.00%)	0.785 ms	1.604 ms	8.018e-03 m
High arc, moving target	10000/10000 (100.00%)	1.126 ms	2.350 ms	8.341e-03 m

---

ABI notes

• Plain C layout across the ABI boundary
• Fixed-size arrays only
• No dynamic allocation across the boundary

---

License

MIT License
