Calliope Studio
Calliope Studio is a web-based user interface for the Calliope energy system modelling framework.
It lets you define, edit, validate, run, and analyse Calliope models, all in a single tool.
It runs in a browser directly on your computer.
Installation
With uv:
# One-time setup for uv on macOS and Linux
curl -LsSf https://astral.sh/uv/install.sh | sh
# One-time setup for uv on Windows
# powershell -c "irm https://astral.sh/uv/install.ps1 | iex"
uv tool install calliope-studio
Then:
calliope-studio my-model # a model folder containing model.yaml or a solved results .nc
calliope-studio # no argument opens Calliope Studio with a model picker
To quit Calliope Studio, close its terminal window or press Ctrl+C inside it.
[!IMPORTANT] Calliope needs a solver to actually solve models. You can still use Studio to edit a model or analyse results that somebody else solved, but pressing Run will fail without a solver. Refer to the Calliope documentation for solver installation.
FAQ
- Why does "Run" fail with a solver error? See the note above: you probably have no solver installed.
- Why is the list of models wrong or outdated? The list of models you have opened lives in a small registry file, separate from the models themselves. Its location is reported as
registry_pathbyhttp://127.0.0.1:8000/api/healthwhile Calliope Studio is running. Deleting it resets the list without actually touching any of your models. - Where are model results stored? When running a model from inside Calliope Studio, results are saved in a
calliope-studio/folder next to themodel.yamlfile. This folder is created automatically when running a model for the first time and comes with its own.gitignorefile.
Development
Requires pixi.
pixi run serve # API on port 8000 with auto-reload
pixi run web-dev # Vite dev server, proxying /api to port 8000
serve opens ./example-model, scaffolding it from Calliope's national_scale template on first use.
Try pixi task list to see all the available development tasks. Some relevant ones:
pixi run solve-examplessolves both Calliope example models intoexamples/nc_files/. The data tests and the results smoke check read these files, and skip when they are absent.pixi run testruns the Python test suite.pixi run -e build buildproduces a wheel and an sdist with the frontend compiled in (the packaging tools live in thebuildenvironment).
The frontend tests run from web/:
cd web
pnpm test
Pixi is configured with a gurobi environment to test with Gurobi (needs a license):
pixi run -e gurobi calliope-studio my-model # Gurobi available as a solver
License
AGPL-3.0-or-later. See LICENSE.
