counted-float

This Python package provides functionality for...

counting floating point operations (FLOPs) of numerical algorithms implemented in plain Python, optionally weighted by their relative cost of execution
running benchmarks to estimate the relative cost of executing various floating-point operations (requires numba optional dependency for achieving accurate results)

The target application area is evaluation of research prototypes of numerical algorithms where (weighted) flop counting can be useful for estimating total computational cost, in cases where benchmarking a compiled version (C, Rust, ...) is not feasible or desirable.

1. Installation

Use you favorite package manager such as uv or pip:

pip install counted-float           # install without numba optional dependency
pip install counted-float[numba]    # install with numba optional dependency

Numba is optional due to its relatively large size (40-50MB, including llvmlite), but without it, benchmarks will not be reliable (but will still run, but not in jit-compiled form).

NOTE: the cli optional dependency is only useful when installing the code as a tool using e.g. uv or pipx (see below)

2. Counting Flops

2.1. CountedFloat class

In order to instrument all floating point operations with counting functionality, the CountedFloat class was implemented, which is a drop-in replacement for the built-in float type. The CountedFloat class is a subclass of float and is "contagious", meaning that it will automatically ensure results of math operations where at least one operand is a CountedFloat will also be a CountedFloat. This way we ensure flop counting is a 'closed system'.

On top of this, we monkey-patch the math module to ensure that all math operations that require counting (sqrt, log2, pow, ...) are also instrumented.

Example 1:

from counted_float import CountedFloat

cf = CountedFloat(1.3)
f = 2.8

result = cf + f  # result = CountedFloat(4.1)

is_float_1 = isinstance(cf, float)  # True
is_float_2 = isinstance(result, float)  # True

Example 2:

import math
from counted_float import CountedFloat

cf1 = CountedFloat(0.81)

s = math.sqrt(cf1)  # s = CountedFloat(0.9)
is_float = isinstance(s, float)  # True

2.2. FLOP counting context managers

Once we use the CountedFloat class, we can use the available context managers to count the number of flops performed by CountedFloat objects.

Example 1: basic usage

from counted_float import CountedFloat, FlopCountingContext

cf1 = CountedFloat(1.73)
cf2 = CountedFloat(2.94)

with FlopCountingContext() as ctx:
    _ = cf1 * cf2
    _ = cf1 + cf2

counts = ctx.flop_counts()   # {FlopType.MUL: 1, FlopType.ADD: 1}
counts.total_count()         # 2

Example 2: pause counting 1

from counted_float import CountedFloat, FlopCountingContext

cf1 = CountedFloat(1.73)
cf2 = CountedFloat(2.94)

with FlopCountingContext() as ctx:
    _ = cf1 * cf2
    ctx.pause()
    _ = cf1 + cf2   # will be executed but not counted
    ctx.resume()
    _ = cf1 - cf2

counts = ctx.flop_counts()   # {FlopType.MUL: 1, FlopType.SUB: 1}
counts.total_count()         # 2

Example 3: pause counting 2

from counted_float import CountedFloat, FlopCountingContext, PauseFlopCounting

cf1 = CountedFloat(1.73)
cf2 = CountedFloat(2.94)

with FlopCountingContext() as ctx:
    _ = cf1 * cf2
    with PauseFlopCounting():
        _ = cf1 + cf2   # will be executed but not counted
    _ = cf1 - cf2

counts = ctx.flop_counts()   # {FlopType.MUL: 1, FlopType.SUB: 1}
counts.total_count()         # 2

2.3. Weighted FLOP counting

The counted_float package contains a set of default, built-in FLOP weights, based on both empirical measurements and theoretical estimates of the relative cost of different floating point operations.

See fpu_data_sources.md for rationale behind choice of data sources and methodology.

>>> from counted_float.config import get_active_flop_weights
>>> get_active_flop_weights().show()

{
    FlopType.ABS        [abs(x)]        :    1
    FlopType.MINUS      [-x]            :    1
    FlopType.COMP       [x<=y]          :    1
    FlopType.RND        [round]         :    2
    FlopType.F2I        [float->int]    :    2
    FlopType.I2F        [int->float]    :    2
    FlopType.ADD        [x+y]           :    1
    FlopType.SUB        [x-y]           :    1
    FlopType.MUL        [x*y]           :    1
    FlopType.DIV        [x/y]           :    5
    FlopType.SQRT       [sqrt(x)]       :    6
    FlopType.CBRT       [cbrt(x)]       :   42
    FlopType.EXP        [e^x]           :   19
    FlopType.EXP2       [2^x]           :   29
    FlopType.EXP10      [10^x]          :   23
    FlopType.LOG        [log(x)]        :   19
    FlopType.LOG2       [log2(x)]       :   24
    FlopType.LOG10      [log10(x)]      :   19
    FlopType.POW        [x^y]           :   62
    FlopType.SIN        [sin(x)]        :   32
    FlopType.COS        [cos(x)]        :   31
    FlopType.TAN        [tan(x)]        :   34
}

These weights will be used by default when extracting total weighted flop costs:

import math
from counted_float import CountedFloat, FlopCountingContext


cf1 = CountedFloat(1.73)
cf2 = CountedFloat(2.94)

with FlopCountingContext() as ctx:
    _ = cf1 + cf2
    _ = cf1 ** cf2
    _ = math.log2(cf2)

flop_counts = ctx.flop_counts()
total_cost = flop_counts.total_weighted_cost()  # 1 + 62 + 24 = 87

Note that the total_weighted_cost method will use the default flop weights as returned by get_flop_weights(). This can be overridden by either configuring different flop weights (see next section) or by setting the weights argument of the total_weighted_cost() method.

2.4. Configuring FLOP weights

We showed earlier that the get_flop_weights() function returns the default FLOP weights. We can change this by using the set_flop_weights() function, which takes a FlopWeights object as an argument. This way we can configure flop weights that might be obtained using benchmarks run on the target hardware (see later sections).

from counted_float.config import set_active_flop_weights
from counted_float import FlopWeights

set_active_flop_weights(weights=FlopWeights(...))  # insert own weights here

2.5. Inspecting built-in data

2.5.1. Default, pre-aggregated flop weights

Built-in flop weights can be inspected using the following functions:

from counted_float.config import get_default_consensus_flop_weights

>>> get_default_consensus_flop_weights(rounded=False).show()

{
    FlopType.ABS        [abs(x)]        :   0.63673
    FlopType.MINUS      [-x]            :   0.64396
    FlopType.COMP       [x<=y]          :   1.20756
    FlopType.RND        [round]         :   1.54041
    FlopType.F2I        [float->int]    :   1.99099
    FlopType.I2F        [int->float]    :   1.84601
    FlopType.ADD        [x+y]           :   1.00000
    FlopType.SUB        [x-y]           :   1.00586
    FlopType.MUL        [x*y]           :   1.37238
    FlopType.DIV        [x/y]           :   5.07465
    FlopType.SQRT       [sqrt(x)]       :   5.90559
    FlopType.CBRT       [cbrt(x)]       :  42.39375
    FlopType.EXP        [e^x]           :  18.58228
    FlopType.EXP2       [2^x]           :  28.88672
    FlopType.EXP10      [10^x]          :  22.86839
    FlopType.LOG        [log(x)]        :  18.89135
    FlopType.LOG2       [log2(x)]       :  24.34792
    FlopType.LOG10      [log10(x)]      :  18.55085
    FlopType.POW        [x^y]           :  61.79155
    FlopType.SIN        [sin(x)]        :  31.91490
    FlopType.COS        [cos(x)]        :  30.79295
    FlopType.TAN        [tan(x)]        :  34.37970
}

The default weights that are configured out-of-the-box in the package are the integer-rounded consensus weights.

2.5.2. Custom-aggregated flop weights

We can retrieve built-in flop weights in a more fine-grained manner, by custom filtering and the aggregating them with the geometric mean.

from counted_float.config import get_builtin_flop_weights

>>> get_builtin_flop_weights(key_filter="arm").show()

{
    FlopType.ABS        [abs(x)]        :   0.97313
    FlopType.MINUS      [-x]            :   0.99098
    FlopType.COMP       [x<=y]          :   1.03987
    FlopType.RND        [round]         :   1.35111
    FlopType.F2I        [float->int]    :   1.52648
    FlopType.I2F        [int->float]    :   1.63320
    FlopType.ADD        [x+y]           :   1.00000
    FlopType.SUB        [x-y]           :   1.00058
    FlopType.MUL        [x*y]           :   1.44952
    FlopType.DIV        [x/y]           :   5.00897
    FlopType.SQRT       [sqrt(x)]       :   5.15597
    FlopType.CBRT       [cbrt(x)]       :  39.30448
    FlopType.EXP        [e^x]           :  17.22817
    FlopType.EXP2       [2^x]           :  15.82232
    FlopType.EXP10      [10^x]          :  21.20195
    FlopType.LOG        [log(x)]        :  17.51472
    FlopType.LOG2       [log2(x)]       :  18.32529
    FlopType.LOG10      [log10(x)]      :  17.19903
    FlopType.POW        [x^y]           :  47.63289
    FlopType.SIN        [sin(x)]        :  29.58923
    FlopType.COS        [cos(x)]        :  28.54904
    FlopType.TAN        [tan(x)]        :  31.87442
}

3. Benchmarking

If the package is installed with the optional numba dependency, it provides the ability to micro-benchmark floating point operations as follows:

>>> from counted_float.benchmarking import run_flops_benchmark
>>> results = run_flops_benchmark()

Running FLOPS benchmarks using counted-float 0.9.5 ...
(Expected duration: ~87.8 seconds)

baseline                           : wwwwwwwwwwwwwww.........................   [  74.43 ns ±  2.6% |   302 cpu cycles ±  2.6% ]  /  1000 iterations
add                                : wwwwwwwwwwwwwww.........................   [ 662.35 ns ±  0.2% | 2.69K cpu cycles ±  0.2% ]  /  1000 iterations
add_minus                          : wwwwwwwwwwwwwww.........................   [   1.23 µs ±  0.2% | 4.98K cpu cycles ±  0.2% ]  /  1000 iterations
add_abs                            : wwwwwwwwwwwwwww.........................   [   1.23 µs ±  0.4% | 4.99K cpu cycles ±  0.4% ]  /  1000 iterations
add_add                            : wwwwwwwwwwwwwww.........................   [   1.29 µs ±  0.2% | 5.23K cpu cycles ±  0.2% ]  /  1000 iterations
add_sub                            : wwwwwwwwwwwwwww.........................   [   1.29 µs ±  0.2% | 5.23K cpu cycles ±  0.2% ]  /  1000 iterations
add_round                          : wwwwwwwwwwwwwww.........................   [   1.44 µs ±  0.1% | 5.84K cpu cycles ±  0.1% ]  /  1000 iterations
add_sqrt                           : wwwwwwwwwwwwwww.........................   [   3.96 µs ±  0.2% | 16.1K cpu cycles ±  0.2% ]  /  1000 iterations
add_cbrt                           : wwwwwwwwwwwwwww.........................   [  25.42 µs ±  0.2% |  103K cpu cycles ±  0.2% ]  /  1000 iterations
add_log                            : wwwwwwwwwwwwwww.........................   [  11.69 µs ±  0.3% | 47.4K cpu cycles ±  0.3% ]  /  1000 iterations
add_log_exp                        : wwwwwwwwwwwwwww.........................   [  22.57 µs ±  0.1% | 91.5K cpu cycles ±  0.1% ]  /  1000 iterations
add_log2                           : wwwwwwwwwwwwwww.........................   [  12.00 µs ±  0.2% | 48.7K cpu cycles ±  0.2% ]  /  1000 iterations
add_log2_exp2                      : wwwwwwwwwwwwwww.........................   [  22.48 µs ±  0.2% | 91.2K cpu cycles ±  0.2% ]  /  1000 iterations
add_log10                          : wwwwwwwwwwwwwww.........................   [  11.50 µs ±  0.2% | 46.6K cpu cycles ±  0.2% ]  /  1000 iterations
add_log10_exp10                    : wwwwwwwwwwwwwww.........................   [  24.68 µs ±  0.2% |  100K cpu cycles ±  0.2% ]  /  1000 iterations
add_sin                            : wwwwwwwwwwwwwww.........................   [  18.64 µs ±  0.3% | 75.6K cpu cycles ±  0.3% ]  /  1000 iterations
add_cos                            : wwwwwwwwwwwwwww.........................   [  18.92 µs ±  0.3% | 76.7K cpu cycles ±  0.3% ]  /  1000 iterations
add_tan                            : wwwwwwwwwwwwwww.........................   [  20.91 µs ±  0.2% | 84.8K cpu cycles ±  0.2% ]  /  1000 iterations
pow                                : wwwwwwwwwwwwwww.........................   [  24.12 µs ±  0.3% | 97.8K cpu cycles ±  0.3% ]  /  1000 iterations
pow_pow                            : wwwwwwwwwwwwwww.........................   [  48.15 µs ±  0.2% |  195K cpu cycles ±  0.2% ]  /  1000 iterations
sub                                : wwwwwwwwwwwwwww.........................   [ 661.55 ns ±  0.2% | 2.68K cpu cycles ±  0.2% ]  /  1000 iterations
sub_sub                            : wwwwwwwwwwwwwww.........................   [   1.29 µs ±  0.2% | 5.24K cpu cycles ±  0.2% ]  /  1000 iterations
mul                                : wwwwwwwwwwwwwww.........................   [ 961.78 ns ±  0.2% | 3.90K cpu cycles ±  0.2% ]  /  1000 iterations
mul_mul                            : wwwwwwwwwwwwwww.........................   [   1.92 µs ±  0.2% | 7.78K cpu cycles ±  0.2% ]  /  1000 iterations
div                                : wwwwwwwwwwwwwww.........................   [   2.45 µs ±  0.2% | 9.92K cpu cycles ±  0.2% ]  /  1000 iterations
div_div                            : wwwwwwwwwwwwwww.........................   [   5.00 µs ±  0.2% | 20.3K cpu cycles ±  0.2% ]  /  1000 iterations
lte_addsub                         : wwwwwwwwwwwwwww.........................   [   1.71 µs ±  0.2% | 6.94K cpu cycles ±  0.2% ]  /  1000 iterations

>>> results.flop_weights.show()

{
    FlopType.ABS        [abs(x)]        :   0.90556
    FlopType.MINUS      [-x]            :   0.90089
    FlopType.COMP       [x<=y]          :   1.67297
    FlopType.RND        [round]         :   1.24118
    FlopType.ADD        [x+y]           :   1.00000
    FlopType.SUB        [x-y]           :   0.99928
    FlopType.MUL        [x*y]           :   1.52656
    FlopType.DIV        [x/y]           :   4.06589
    FlopType.SQRT       [sqrt(x)]       :   5.26487
    FlopType.CBRT       [cbrt(x)]       :  39.49190
    FlopType.EXP        [e^x]           :  17.34508
    FlopType.EXP2       [2^x]           :  16.70475
    FlopType.EXP10      [10^x]          :  21.03351
    FlopType.LOG        [log(x)]        :  17.59412
    FlopType.LOG2       [log2(x)]       :  18.08932
    FlopType.LOG10      [log10(x)]      :  17.27955
    FlopType.POW        [x^y]           :  38.32044
    FlopType.SIN        [sin(x)]        :  28.67006
    FlopType.COS        [cos(x)]        :  29.11818
    FlopType.TAN        [tan(x)]        :  32.28703
    FlopType.F2I        [float->int]    :       nan
    FlopType.I2F        [int->float]    :       nan
}

4. Installing the package as a command-line tool

An alternative way of using (parts) of the functionality is installing the package as a stand-alone command-line tool using uv or pipx:

uv tool install git+https://github.com/bertpl/counted-float@main[numba,cli]         # latest official release
uv tool install git+https://github.com/bertpl/counted-float@develop[numba,cli]      # or latest develop version

This installs the counted_float command-line tool, which can be used to e.g. run flops benchmarks.

4.1. Running benchmarks

counted_float benchmark

after which the results will be shown as .json.

4.2. Show built-in data

[~] counted_float show-data

                                                       ABS     MINUS       ADD       SUB      COMP       MUL       RND       I2F       F2I       DIV      SQRT     LOG10       EXP       LOG     EXP10      LOG2      EXP2       COS       SIN       TAN      CBRT       POW
ALL                                                   0.64      0.64      1.00      1.01      1.21      1.37      1.54      1.85      1.99      5.07      5.91     18.55     18.58     18.89     22.87     24.35     28.89     30.79     31.91     34.38     42.39     61.79
 ├─arm                                                0.97      0.99      1.00      1.00      1.04      1.45      1.35      1.63      1.53      5.01      5.16     17.20     17.23     17.51     21.20     18.33     15.82     28.55     29.59     31.87     39.30     47.63
 │  ├─v8_x                                            0.92      0.97      1.00      1.00      1.12      1.35      1.25      1.94      1.58      3.88      4.09     16.56     16.59     16.86     20.41     17.64     15.23     27.48     28.49     30.69     37.84     45.86
 │  │  ├─benchmarks                                   0.85      0.95      1.00      1.00      1.26      1.22      1.05        /         /       2.93      3.12     15.11     15.14     15.39     18.63     16.10     13.90     25.09     26.00     28.01     34.54     41.85
 │  │  │  ├─m3_max_macbook_pro_16                     0.80      1.00      1.00      1.01      1.01      1.01      0.89        /         /       2.19      1.85        /         /         /         /      14.40     11.59        /         /         /         /      46.48
 │  │  │  └─m3_max_macbook_pro_16_v2                  0.90      0.90      1.00      1.00      1.58      1.47      1.24        /         /       3.93      5.25     17.23     17.26     17.55     21.24     18.01     16.68     28.60     29.64     31.93     39.38     37.68
 │  │  └─specs                                        1.00      1.00      1.00      1.00      1.00      1.50      1.50      2.12      1.73      5.12      5.37        /         /         /         /         /         /         /         /         /         /         /
 │  │     ├─arm_v8_cortex_a76                         1.00      1.00      1.00      1.00      1.00      1.50      1.50      3.00      2.00      5.12      5.45        /         /         /         /         /         /         /         /         /         /         /
 │  │     ├─arm_v9_cortex_n1                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      3.00      2.00      5.12      5.45        /         /         /         /         /         /         /         /         /         /         /
 │  │     ├─arm_v9_cortex_v1                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  │     └─arm_v9_cortex_x1                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  ├─v9_0                                            1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  │  └─specs                                        1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  │     ├─arm_v9_cortex_n2                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  │     ├─arm_v9_cortex_v2                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  │     ├─arm_v9_cortex_x2                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  │     └─arm_v9_cortex_x3                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      5.12      5.29        /         /         /         /         /         /         /         /         /         /         /
 │  └─v9_2                                            1.00      1.00      1.00      1.00      1.00      1.50      1.31      1.50      1.50      6.33      6.33        /         /         /         /         /         /         /         /         /         /         /
 │     └─specs                                        1.00      1.00      1.00      1.00      1.00      1.50      1.31      1.50      1.50      6.33      6.33        /         /         /         /         /         /         /         /         /         /         /
 │        ├─arm_v9_cortex_v3                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      6.50      6.50        /         /         /         /         /         /         /         /         /         /         /
 │        ├─arm_v9_cortex_x4                          1.00      1.00      1.00      1.00      1.00      1.50      1.50      1.50      1.50      6.50      6.50        /         /         /         /         /         /         /         /         /         /         /
 │        └─arm_v9_cortex_x925                        1.00      1.00      1.00      1.00      1.00      1.50      1.00      1.50      1.50      6.00      6.00        /         /         /         /         /         /         /         /         /         /         /
 └─x86                                                0.42      0.42      1.00      1.01      1.40      1.30      1.76      2.09      2.60      5.14      6.76        /         /         /         /      32.35     52.74        /         /         /         /      80.16
    ├─amd                                             0.44      0.44      1.00      1.01      1.81      1.18      1.02      2.19      2.61      4.85      6.94        /         /         /         /      32.91    173.48        /         /         /         /      94.73
    │  ├─2017_zen1                                    0.46      0.48      1.00      1.04      1.57      1.14      1.14      2.22      3.51      4.46      5.06        /         /         /         /      32.94    173.63        /         /         /         /      94.81
    │  │  ├─analysis_uops_info_zen1+                  0.33      0.33      1.00      1.00      2.33      1.33      0.67      2.11      3.33      4.33      6.67        /         /         /         /         /         /         /         /         /         /         /
    │  │  └─benchmark_ryzen_1700x                     0.64      0.69      1.00      1.08      1.06      0.97      1.97        /         /       4.58      3.83        /         /         /         /      34.68    182.82        /         /         /         /      99.82
    │  ├─2020_zen3                                    0.33      0.33      1.00      1.00      1.97      1.01      0.76      2.01      2.45      4.42      6.67        /         /         /         /         /         /         /         /         /         /         /
    │  │  ├─analysis_agner_fog_r7_5800x               0.33      0.33      1.00      1.00      1.67        /       1.00      2.33      2.00      4.50      6.67        /         /         /         /         /         /         /         /         /         /         /
    │  │  └─analysis_uops_info_zen3                   0.33      0.33      1.00      1.00      2.33      1.00      0.58      1.73      3.00      4.33      6.67        /         /         /         /         /         /         /         /         /         /         /
    │  ├─2022_zen4                                    0.33      0.33      1.00      1.00      1.28      1.02      0.83      1.63      2.00      4.33      6.89        /         /         /         /         /         /         /         /         /         /         /
    │  │  ├─analysis_agner_fog_r9_7900x               0.33      0.33      1.00      1.00      1.33        /       1.00      2.00      2.00      4.33      7.00        /         /         /         /         /         /         /         /         /         /         /
    │  │  ├─analysis_uops_info_zen4                   0.33      0.33      1.00      1.00      2.33      1.00      0.58      1.63      3.00      4.33      7.00        /         /         /         /         /         /         /         /         /         /         /
    │  │  └─specs_amd                                 0.33      0.33      1.00      1.00      0.67      1.00      1.00      1.33      1.33      4.33      6.67        /         /         /         /         /         /         /         /         /         /         /
    │  └─2024_zen5                                    0.71      0.71      1.00      1.00      2.72      1.66      1.50      3.17      2.72      6.50     10.00        /         /         /         /         /         /         /         /         /         /         /
    │     ├─analysis_agner_fog_r7_9800x3d             1.00      1.00      1.00      1.00      3.00        /       1.50      3.50      3.00      6.50     10.00        /         /         /         /         /         /         /         /         /         /         /
    │     └─specs_amd                                 0.50      0.50      1.00      1.00        /       1.50      1.50        /         /       6.50     10.00        /         /         /         /         /         /         /         /         /         /         /
    └─intel                                           0.40      0.40      1.00      1.01      1.09      1.43      3.02      1.99      2.58      5.45      6.59        /         /         /         /      31.80     16.03        /         /         /         /      67.83
       ├─2017_coffee_lake_gen_8                       0.25      0.25      1.00      1.00      0.74      1.00      2.00      1.41      1.62      3.56      4.29        /         /         /         /         /         /         /         /         /         /         /
       │  ├─analysis_agner_fog_coffee_lake            0.25      0.25      1.00      1.00        /       1.00      2.00      1.50      1.50      3.37      3.87        /         /         /         /         /         /         /         /         /         /         /
       │  └─analysis_uops_info_coffee_lake            0.25      0.25      1.00      1.00      0.75      1.00      2.00      1.32      1.75      3.75      4.75        /         /         /         /         /         /         /         /         /         /         /
       ├─2019_sunny_cove_gen_10                       0.25      0.25      1.00      1.00      0.66      0.98      2.00      1.38      1.66      3.62      4.44        /         /         /         /         /         /         /         /         /         /         /
       │  ├─analysis_agner_fog_ice_lake               0.25      0.25      1.00      1.00      0.50        /       2.00      1.50      1.50      3.37      3.87        /         /         /         /         /         /         /         /         /         /         /
       │  ├─analysis_uops_info_ice_lake               0.25      0.25      1.00      1.00      0.75      1.00      2.00      1.32      1.75      3.75      4.75        /         /         /         /         /         /         /         /         /         /         /
       │  └─analysis_uops_info_tiger_lake             0.25      0.25      1.00      1.00      0.75      1.00      2.00      1.32      1.75      3.75      4.75        /         /         /         /         /         /         /         /         /         /         /
       ├─2021_golden_cove_gen_12                      0.64      0.64      1.00      1.07      1.39      1.53      3.93      2.54      3.46      7.61      8.07        /         /         /         /      40.46     20.40        /         /         /         /      86.31
       │  ├─analysis_uops_info_alder_lake_p           0.41      0.41      1.00      1.00      1.22      1.63      3.27      2.16      2.86      6.12      7.76        /         /         /         /         /         /         /         /         /         /         /
       │  ├─benchmark_core_i7_1265u                   1.28      1.25      1.00      1.21      1.47      1.10      4.65        /         /      10.27      7.54        /         /         /         /      48.46     24.43        /         /         /         /     103.37
       │  └─specs_intel                               0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
       ├─2022_raptor_cove_gen_13_14                   0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
       │  └─specs_intel                               0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
       └─2023_redwood_cove_ultra_1                    0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /
          └─specs_intel                               0.50      0.50      1.00      1.00      1.50      2.00      4.00      2.50      3.50      7.00      9.00        /         /         /         /         /         /         /         /         /         /         /

5. Known limitations

currently any non-Python-built-in math operations are not counted (e.g. numpy)
not all Python built-in math operations are counted (e.g. log, log10, exp, exp10)
flop weights should be taken with a grain of salt and should only provide relative ballpark estimates w.r.t computational complexity. Production implementations in a compiled language could have vastly differing performance depending on cpu cache sizes, branch prediction misses, compiler optimizations using vector operations (AVX etc...), etc...

Appendix A - Flop counting / analysis details

This appendix provides detailed information about how each floating-point operation (FLOP) type is counted and analyzed in the counted-float package. For each flop type, you will find:

Relevant scalar instructions for ARM (v8+) and x86 (SSE2+)
Python operations that are counted for this flop type
Python operations that are not counted for this flop type

Flop Types

FlopType.ABS (`abs(x)`)

Relevant CPU instructions
- ARM: FABS
- x86: ANDPD
Counted Python operations: abs(x) where x is a CountedFloat
Not counted: numpy.abs, complex abs, abs on non-CountedFloat

FlopType.MINUS (`-x`)

Relevant CPU instructions
- ARM: FNEG
- x86: XORPD
Counted Python operations: Unary minus (-x) for CountedFloat
Not counted: Negation on non-CountedFloat, numpy negation

FlopType.COMP (`x<=y`, `x>y`, `x==y`, `x==0.0`, ...)

Relevant CPU instructions
- ARM: FCMP
- x86: (U)COMISD
Counted Python operations: x == y, x != y, x <= y, ... and min(x,y), max(x,y) for CountedFloat
Not counted: Comparisons on non-CountedFloat, numpy comparisons

FlopType.RND (`round`)

Relevant CPU instructions
- ARM: FRINT
- x86: ROUNDSD
Counted Python operations: round(x, 0) for CountedFloat (returns float)
Not counted: numpy.round, rounding with decimals, rounding on non-CountedFloat

FlopType.F2I (`float->int`)

Relevant CPU instructions
- ARM: FCVTZS
- x86: CVTSD2SI
Counted Python operations: int(x), math.floor(x), math.ceil(x), math.trunc(x), round(x) for CountedFloat (returns int)
Not counted: Conversions on non-CountedFloat, numpy conversions

FlopType.I2F (`int->float`)

Relevant CPU instructions
- ARM: SCVTF
- x86: CVTSI2SD
Counted Python operations: Construction of CountedFloat from int, any binary operation where one operand is an int and the other a CountedFloat (e.g., x + 3, 3 * x, etc.)
Not counted: float(n), unitary operations (e.g. math.sqrt on integers -> convert to CountedFloat first)

FlopType.ADD (`x+y`)

Relevant CPU instructions
- ARM: FADD
- x86: ADDSD
Counted Python operations: x + y or y + x for CountedFloat
Not counted: Addition on non-CountedFloat, numpy addition

FlopType.SUB (`x-y`)

Relevant CPU instructions
- ARM: FSUB
- x86: SUBSD
Counted Python operations: x - y or y - x for CountedFloat
Not counted: Subtraction on non-CountedFloat, numpy subtraction

FlopType.MUL (`x*y`)

Relevant CPU instructions
- ARM: FMUL
- x86: MULSD
Counted Python operations: x * y or y * x for CountedFloat
Not counted: Multiplication on non-CountedFloat, numpy multiplication

FlopType.DIV (`x/y`)

Relevant CPU instructions
- ARM: FDIV
- x86: DIVSD
Counted Python operations: x / y or y / x for CountedFloat
Not counted: Division on non-CountedFloat, numpy division

FlopType.SQRT (`sqrt(x)`)

Relevant CPU instructions
- ARM: FSQRT
- x86: SQRTSD
Counted Python operations: math.sqrt(x) for CountedFloat
Not counted: numpy.sqrt, sqrt on non-CountedFloat

FlopType.CBRT (`cbrt(x)`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.cbrt(x) for CountedFloat
Not counted: numpy.cbrt, cbrt on non-CountedFloat

FlopType.EXP (`e^x`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.exp(x) for CountedFloat
Not counted: math.exp(x) on non-CountedFloat, numpy.exp, math.expm1, math.e ** x

FlopType.EXP2 (`2^x`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: 2 ** x, pow(2, x) or math.exp2(x) for CountedFloat
Not counted: exp2 on non-CountedFloat, numpy.exp2

FlopType.EXP10 (`10^x`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: 10 ** x, pow(10, x) for CountedFloat
Not counted: 10 ** x on non-CountedFloat

FlopType.LOG (`log(x)`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.log(x) for CountedFloat
Not counted: numpy.log, log on non-CountedFloat

FlopType.LOG2 (`log2(x)`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.log2(x) for CountedFloat
Not counted: numpy.log2, log2 on non-CountedFloat

FlopType.LOG10 (`log10(x)`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.log10(x) for CountedFloat
Not counted: numpy.log10, log10 on non-CountedFloat

FlopType.POW (`x^y`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: x ** y, pow(x, y) for CountedFloat
Not counted: pow on non-CountedFloat, numpy.pow

FlopType.SIN (`sin(x)`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.sin(x) for CountedFloat
Not counted: sin on non-CountedFloat, numpy.sin

FlopType.COS (`cos(x)`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.cos(x) for CountedFloat
Not counted: cos on non-CountedFloat, numpy.cos

FlopType.TAN (`tan(x)`)

Relevant CPU instructions
- ARM: (software)
- x86: (software)
Counted Python operations: math.tan(x) for CountedFloat
Not counted: tan on non-CountedFloat, `numpy.tan

Project details

These details have been verified by PyPI

Project links

GitHub Statistics

Maintainers

bert_pluymers

Release history Release notifications | RSS feed

1.0.3

Nov 7, 2025

1.0.2

Oct 15, 2025

1.0.0

Oct 9, 2025

0.9.7

Oct 9, 2025

0.9.6

Oct 9, 2025

This version

0.9.5

Oct 5, 2025

0.9.4

Oct 4, 2025

0.9.3

Sep 28, 2025

0.9.2

Sep 20, 2025

0.9.1

Sep 18, 2025

0.8.4

Sep 13, 2025

0.8.3

Sep 6, 2025

0.8.2

Sep 5, 2025

0.8.1

Aug 12, 2025

0.8.0

Aug 11, 2025

Download files

Download the file for your platform. If you're not sure which to choose, learn more about installing packages.

Source Distribution

counted_float-0.9.5.tar.gz (55.2 kB view details)

Uploaded Oct 5, 2025 Source

Built Distribution

If you're not sure about the file name format, learn more about wheel file names.

The dropdown lists show the available interpreters, ABIs, and platforms. Enable javascript to be able to filter the list of wheel files.

counted_float-0.9.5-py3-none-any.whl (68.7 kB view details)

Uploaded Oct 5, 2025 Python 3

File details

Details for the file counted_float-0.9.5.tar.gz.

File metadata

Download URL: counted_float-0.9.5.tar.gz
Upload date: Oct 5, 2025
Size: 55.2 kB
Tags: Source
Uploaded using Trusted Publishing? Yes
Uploaded via: twine/6.1.0 CPython/3.13.7

File hashes

Hashes for counted_float-0.9.5.tar.gz
Algorithm	Hash digest
SHA256	`6f433d91ae1121855a17a3032b319fe90bb120f05f3caa16e651161344061385`
MD5	`5028880c9348738d652a4ba28ad4d484`
BLAKE2b-256	`bc9496fc51278f29ed60b677ed431d69af5b8b7eca7d1eed97b6b36e759aa69a`

See more details on using hashes here.

Provenance

The following attestation bundles were made for counted_float-0.9.5.tar.gz:

Publisher: push_to_main.yml on bertpl/counted-float

Attestations: Values shown here reflect the state when the release was signed and may no longer be current.

Statement:
- Statement type: https://in-toto.io/Statement/v1
- Predicate type: https://docs.pypi.org/attestations/publish/v1
- Subject name: counted_float-0.9.5.tar.gz
- Subject digest: 6f433d91ae1121855a17a3032b319fe90bb120f05f3caa16e651161344061385
- Sigstore transparency entry: 584338441
- Sigstore integration time: Oct 5, 2025
Source repository:
- Permalink: bertpl/counted-float@bb3d486d951c92c0787c60db2caaf6bc14d01291
- Branch / Tag: refs/heads/main
- Owner: https://github.com/bertpl
- Access: public
Publication detail:
- Token Issuer: https://token.actions.githubusercontent.com
- Runner Environment: github-hosted
- Publication workflow: push_to_main.yml@bb3d486d951c92c0787c60db2caaf6bc14d01291
- Trigger Event: push

File details

Details for the file counted_float-0.9.5-py3-none-any.whl.

File metadata

Download URL: counted_float-0.9.5-py3-none-any.whl
Upload date: Oct 5, 2025
Size: 68.7 kB
Tags: Python 3
Uploaded using Trusted Publishing? Yes
Uploaded via: twine/6.1.0 CPython/3.13.7

File hashes

Hashes for counted_float-0.9.5-py3-none-any.whl
Algorithm	Hash digest
SHA256	`cc00385a171d09f30cdd6c0bddde081c404a6d1bc1e321ca74f6d5e3c903cc12`
MD5	`8411f371c1a749af79c2b7e5a2f943cb`
BLAKE2b-256	`584fc590e95d2e2dcc30963c34cfa9040d7538f3354b12fb38b5fb00b7fe5a63`

See more details on using hashes here.

Provenance

The following attestation bundles were made for counted_float-0.9.5-py3-none-any.whl:

Publisher: push_to_main.yml on bertpl/counted-float

Attestations: Values shown here reflect the state when the release was signed and may no longer be current.

Statement:
- Statement type: https://in-toto.io/Statement/v1
- Predicate type: https://docs.pypi.org/attestations/publish/v1
- Subject name: counted_float-0.9.5-py3-none-any.whl
- Subject digest: cc00385a171d09f30cdd6c0bddde081c404a6d1bc1e321ca74f6d5e3c903cc12
- Sigstore transparency entry: 584338442
- Sigstore integration time: Oct 5, 2025
Source repository:
- Permalink: bertpl/counted-float@bb3d486d951c92c0787c60db2caaf6bc14d01291
- Branch / Tag: refs/heads/main
- Owner: https://github.com/bertpl
- Access: public
Publication detail:
- Token Issuer: https://token.actions.githubusercontent.com
- Runner Environment: github-hosted
- Publication workflow: push_to_main.yml@bb3d486d951c92c0787c60db2caaf6bc14d01291
- Trigger Event: push

counted-float 0.9.5

Navigation

Verified details

Project links

GitHub Statistics

Maintainers

Unverified details

Meta

Project description

counted-float

1. Installation

2. Counting Flops

2.1. CountedFloat class

2.2. FLOP counting context managers

2.3. Weighted FLOP counting

2.4. Configuring FLOP weights

2.5. Inspecting built-in data

2.5.1. Default, pre-aggregated flop weights

2.5.2. Custom-aggregated flop weights

3. Benchmarking

4. Installing the package as a command-line tool

4.1. Running benchmarks

4.2. Show built-in data

5. Known limitations

Appendix A - Flop counting / analysis details

Flop Types

FlopType.ABS (abs(x))

FlopType.MINUS (-x)

FlopType.COMP (x<=y, x>y, x==y, x==0.0, ...)

FlopType.RND (round)

FlopType.F2I (float->int)

FlopType.I2F (int->float)

FlopType.ADD (x+y)

FlopType.SUB (x-y)

FlopType.MUL (x*y)

FlopType.DIV (x/y)

FlopType.SQRT (sqrt(x))

FlopType.CBRT (cbrt(x))

FlopType.EXP (e^x)

FlopType.EXP2 (2^x)

FlopType.EXP10 (10^x)

FlopType.LOG (log(x))

FlopType.LOG2 (log2(x))

FlopType.LOG10 (log10(x))

FlopType.POW (x^y)

FlopType.SIN (sin(x))

FlopType.COS (cos(x))

FlopType.TAN (tan(x))

Project details

Verified details

Project links

GitHub Statistics

Maintainers

Unverified details

Meta

Release history Release notifications | RSS feed

Download files

Source Distribution

Built Distribution

File details

File metadata

File hashes

Provenance

File details

File metadata

File hashes

Provenance

FlopType.ABS (`abs(x)`)

FlopType.MINUS (`-x`)

FlopType.COMP (`x<=y`, `x>y`, `x==y`, `x==0.0`, ...)

FlopType.RND (`round`)

FlopType.F2I (`float->int`)

FlopType.I2F (`int->float`)

FlopType.ADD (`x+y`)

FlopType.SUB (`x-y`)

FlopType.MUL (`x*y`)

FlopType.DIV (`x/y`)

FlopType.SQRT (`sqrt(x)`)

FlopType.CBRT (`cbrt(x)`)

FlopType.EXP (`e^x`)

FlopType.EXP2 (`2^x`)

FlopType.EXP10 (`10^x`)

FlopType.LOG (`log(x)`)

FlopType.LOG2 (`log2(x)`)

FlopType.LOG10 (`log10(x)`)

FlopType.POW (`x^y`)

FlopType.SIN (`sin(x)`)

FlopType.COS (`cos(x)`)

FlopType.TAN (`tan(x)`)
