cvxsimulator 1.5.1

Simple simulator for investors

🔄 cvxsimulator

A simple yet powerful simulator for investment strategies and portfolio backtesting.

Given a universe of $m$ assets we are given prices for each of them at time $t_1, t_2, \ldots t_n$, e.g. we operate using an $n \times m$ matrix where each column corresponds to a particular asset.

In a backtest we iterate in time (e.g. row by row) through the matrix and allocate positions to all or some of the assets. This tool helps to simplify the accounting. It keeps track of the available cash, the profits achieved, etc.

📥 Installation

Install cvxsimulator via pip:

pip install cvxsimulator

📊 Creating Portfolios

The simulator is completely agnostic to the trading policy/strategy. Our approach follows a rather common pattern:

• Create the builder object
• Loop through time
• Build the portfolio

We demonstrate these steps with simple example policies. They are never good strategies, but are always valid ones.

Create the builder object

The user defines a builder object by loading prices and initializing the amount of cash used in an experiment:

import pandas as pd
from cvx.simulator import Builder

# For doctest, we'll create a small DataFrame instead of reading from a file
dates = pd.date_range('2020-01-01', periods=5)
prices = pd.DataFrame({
    'A': [100, 102, 104, 103, 105],
    'B': [50, 51, 52, 51, 53],
    'C': [200, 202, 198, 205, 210],
    'D': [75, 76, 77, 78, 79]
}, index = dates)
b = Builder(prices=prices, initial_aum=1e6)

Prices have to be valid, there may be NaNs only at the beginning and the end of each column in the frame. There can be no NaNs hiding in the middle of any time series.

It is also possible to specify a model for trading costs. The builder helps to fill up the frame of positions. Only once done we construct the actual portfolio.

Loop through time

We have overloaded the __iter__ and __setitem__ methods to create a custom loop. Let's start with a first strategy. Each day we choose two names from the universe at random. Buy one (say 0.1 of your portfolio wealth) and short one the same amount.

import numpy as np

np.random.seed(42)  # Set seed for reproducibility

for t, state in b:
    # pick two assets deterministically for doctest
    pair = ['A', 'B']  # Use first two assets instead of random choice
    # compute the pair
    units = pd.Series(index=state.assets, data=0.0)
    units[pair] = [state.nav, -state.nav] / state.prices[pair].values
    # update the position
    b.position = 0.1 * units
    # Do not apply trading costs
    b.aum = state.aum
    # Check the final positions
    b.units.iloc[-1][['A', 'B']]

Here t is the growing list of timestamps, e.g. in the first iteration t is $t1$, in the second iteration it will be $t1, t2$ etc.

A lot of magic is hidden in the state variable. The state gives access to the currently available cash, the current prices and the current valuation of all holdings.

Here's a slightly more realistic loop. Given a set of $4$ assets we want to implement the popular $1/n$ strategy.

b2 = Builder(prices=prices, initial_aum=1e6)

for t, state in b2:
    # each day we invest a quarter of the capital in the assets
    b2.position = 0.25 * state.nav / state.prices
    b2.aum = state.aum

# Check the final positions
b2.units.iloc[-1]

Note that we update the position at the last element in the t list using a series of actual units rather than weights or cashpositions. The builder class also exposes setters for such alternative conventions.

b3 = Builder(prices=prices, initial_aum=1e6)

for t, state in b3:
    # each day we invest a quarter of the capital in the assets
    b3.weights = np.ones(4) * 0.25
    b3.aum = state.aum

    # Check the final positions
b3.units.iloc[-1]

Build the portfolio

Once finished it is possible to build the portfolio object:

b3 = Builder(prices=prices, initial_aum=1e6)

for t, state in b3:
    b3.weights = np.ones(4) * 0.25
    b3.aum = state.aum

# Build the portfolio from one of our builders
portfolio = b3.build()
# Verify the portfolio was created successfully
type(portfolio).__name__

📈 Analytics

The portfolio object supports further analysis and exposes a number of properties, e.g.:

b3 = Builder(prices=prices, initial_aum=1e6)

for t, state in b3:
    b3.weights = np.ones(4) * 0.25
    b3.aum = state.aum

portfolio = b3.build()

It is possible to generate a snapshot of the portfolio:

b3 = Builder(prices=prices, initial_aum=1e6)
for t, state in b3:
    b3.weights = np.ones(4) * 0.25
    b3.aum = state.aum
portfolio = b3.build()

# Generate a snapshot (returns a plotly figure)
fig = portfolio.snapshot()

🛠️ Development

UV Package Manager

Start with:

make install

This will install uv and create the virtual environment defined in pyproject.toml and locked in uv.lock.

Marimo Notebooks

We install marimo on the fly within the aforementioned virtual environment. Execute:

make marimo

This will install and start marimo for interactive notebook development.

📚 Documentation

• Full documentation is available at cvxgrp.org/simulator/book
• API reference can be found in the documentation
• Example notebooks are included in the repository under the book directory

🤝 Contributing

Contributions are welcome! Here's how you can contribute:

1. Fork the repository
2. Create a feature branch: git checkout -b feature-name
3. Commit your changes: git commit -m 'Add some feature'
4. Push to the branch: git push origin feature-name
5. Open a pull request

Please make sure to update tests as appropriate and follow the code style of the project.

📄 License

This project is licensed under the Apache License 2.0 - see the LICENSE file for details.

Copyright 2023 Stanford University Convex Optimization Group
