daicon 0.1.0

Low-rank adapters for convolutional PyTorch models

daicon

Differential Adapters In CONvolutional neural networks.

daicon adds small trainable low-rank residual adapters to frozen PyTorch Conv1d and Linear layers. It was built for finetuning BPNet/Cherimoya-style models to improve differential accessibility, but the core injection API works with explicit module paths in ordinary PyTorch models too.

Installation

daicon is available through PyPI:

pip install daicon

Or, with uv:

uv add daicon

Quickstart

Use explicit module paths for general PyTorch models:

import torch
from daicon import adapter_parameters, inject_adapters

model = torch.nn.Sequential(
    torch.nn.Conv1d(4, 16, kernel_size=7, padding=3),
    torch.nn.ReLU(),
    torch.nn.Conv1d(16, 16, kernel_size=1),
)

config = inject_adapters(
    model,
    targets=["0", "2"],
    architecture=None,
)

optimizer = torch.optim.AdamW(adapter_parameters(model), lr=3e-4)

Use BPNet convenience shorthands when your model exposes BPNet-style fields:

from daicon import inject_adapters

config = inject_adapters(
    accessibility_model,
    targets="rconvs+heads",
)

BPNet shorthand names expand to explicit paths before injection:

Shorthand	Paths
iconv	iconv
rconvs	rconvs.*
fconv	fconv
linear	linear
profile_only	fconv
count_only	linear
body_only	iconv, rconvs.*
heads_only	fconv, linear
all_conv	iconv, rconvs.*, fconv
all	iconv, rconvs.*, fconv, linear
rconvs+heads	rconvs.*, fconv, linear

Use Cherimoya convenience shorthands when your model exposes Cherimoya-style fields named iconv, blocks, fconv, and linear:

from daicon import inject_adapters

config = inject_adapters(
    cherimoya_model,
    targets="all_postblock",
    architecture="cherimoya",
    block_rank=8,
)

Cherimoya block shorthands wrap whole blocks.* modules instead of replacing the layers inside each block. This keeps the frozen Cheri blocks intact while training small residual adapters around them.

Shorthand	Paths	Block adapter
heads_only	fconv, linear	none
all_postblock	blocks.*, fconv, linear	post-block bottleneck
late_postblock	last 4 blocks.*, fconv, linear	post-block bottleneck
early_postblock	first 3 blocks.*, fconv, linear	post-block bottleneck
mid_depthwise	blocks.2 through blocks.5, fconv, linear	parallel depthwise

Saving Adapters

Adapters are saved separately from base model weights:

from daicon import count_adapter_parameters, module_specs, save_adapter_bundle

manifest = {
    "adapter_config": config,
    "layer_specs": module_specs(accessibility_model),
    "trainable_params": count_adapter_parameters(accessibility_model),
}

save_adapter_bundle("celltype_f0.adapter.pt", accessibility_model, manifest)

Load them back into a matching base model:

from daicon import load_adapter_bundle

accessibility_model, manifest = load_adapter_bundle(
    accessibility_model,
    "celltype_f0.adapter.pt",
)

By default, bundle helpers expect adapters directly on the module you pass in. This matches the common post-training workflow of loading only a ChromBPNet accessibility module for inference or interpretation.

If you are working with a full ChromBPNet-style object and the adapters live under model.accessibility, pass adapter_root="accessibility":

save_adapter_bundle("celltype_f0.adapter.pt", model, manifest, adapter_root="accessibility")
model, manifest = load_adapter_bundle(
    model,
    "celltype_f0.adapter.pt",
    adapter_root="accessibility",
)

API

The main public functions are:

• inject_adapters(module, targets, ...)
• resolve_adapter_targets(targets, module=None, architecture="bpnet")
• adapter_parameters(module)
• adapter_state_dict(module)
• save_adapter_bundle(path, model, manifest, adapter_root=None)
• load_adapter_bundle(model, adapter_path, adapter_root=None)

Adapter wrappers:

• LowRankConv1dAdapter
• LowRankLinearAdapter
• CheriPostBlockAdapter
• CheriParallelDepthwiseAdapter

Injected adapters compute:

base(x) + scale * up(dropout(down(x)))

The up layer is zero-initialized, so injection is prediction-equivalent to the base model before training. Base layer parameters are frozen inside each adapter. Cherimoya post-block adapters remix frozen block outputs positionwise, while parallel depthwise adapters add a small dilated spatial branch at the block's native dilation.

Artifact Contract

An adapter bundle is a torch.save file containing:

{
    "manifest": {
        "format_version": 1,
        "adapter_config": {...},
        "layer_specs": {...},
        ...
    },
    "state_dict": {...},
}

The state dict contains only adapter branch weights, keyed by injected module path. Frozen base.* weights are intentionally excluded.

Notes

• While the adapters were designed with bpnet-lite and cherimoya in mind, and injection code defaults have been written for these model architectures, daicon is kept intentionally light-weight/general and depends only on PyTorch.
• Conv1d and Linear adapter defaults follow prior ChromBPNet/BPNet tuning: conv_rank=16, linear_rank=4, dropout=0, and alpha-style scaling with alpha=8, i.e. default conv_scale=8 / conv_rank and linear_scale=8 / linear_rank.
• BPNet shorthands assume fields named iconv, rconvs, fconv, and linear.
• Cherimoya shorthands assume fields named iconv, blocks, fconv, and linear; all_postblock is the recommended differential fine-tuning default, with block_rank=8, block_adapter="postblock", and block_scale=1 / block_rank when no explicit scale is provided.
• The historical implementation handoff lives in notes/ADAPTER_HANDOFF.md.
