drawspec

Declarative diagram spec → clean, themeable SVG. Writable by an LLM with no coordinates to get wrong.

For anyone — person or language model — who puts diagrams in docs, specs and READMEs and is tired of arrows that miss their boxes:

pip install drawspec && drawspec render diagram.json -o diagram.svg

See every kind drawn in the gallery →

Status: it draws. All thirty-six kinds render — flow, tree, cycle, stack, timeline, columns, matrix, pyramid, rings, funnel, chart, quadrant, scatter, curve, files, states, sequence, lanes, entities, gantt, board, fishbone, venn, journey, treemap, sankey, numberline, barmodel, waterfall, pie, mindmap, argument, familytree, meter, rag and clock — and each of the eleven failure families below has a test asserting it cannot be expressed. The vocabulary opened from nine to thirteen on evidence: see docs/kinds-wanted.md, which sorts all 89 hand-drawn originals by the kind that would have to draw them. scatter is the fourteenth, added on a different kind of evidence: a real consumer's need for two continuous, ticked axes, which quadrant refuses. files is the fifteenth: a directory listing drawn from its paths, as pictures or as the tree-style text a code block wants. states is the sixteenth: a state machine, with its initial and final dots, labelled transitions, self-loops, and a refusal for any state nothing reaches. sequence is the seventeenth: messages between participants, in order, with activation bars inferred from each call and its reply. lanes is the eighteenth: a flow document whose actors are drawn as swimlanes, so every hand-off between parties is an arrow crossing a lane. entities is the nineteenth: ER models, database schemas and class diagrams as one kind — boxes of fields, relations that can land on one row, crow's feet or multiplicities at the ends, and inheritance with a hollow triangle. gantt is the twentieth: a plan, one row per task, with phases, milestones, finish-to-start dependencies and marks such as today — on a numbered axis in a unit you name, never dates. board is the twenty-first: cards sorted into columns — a kanban board with work-in-progress limits drawspec counts, a retrospective, or a story map whose releases are slices across the columns with a heavy cut under the first. fishbone is the twenty-second: one effect and the causes investigated, grouped by category on bones slanting into a spine — the root cause drawn heavy. venn is the twenty-third: two or three equal circles (four equal ellipses), each region's words named by the sets it is in and placed inside it — no coordinates, no sizes. journey is the twenty-fourth: one person's feeling, a named level per stage, drawn as a line through every stage over what they do there — no scores. treemap is the twenty-fifth: the parts of one known total, each a rectangle by its area with its label inside it — a few proportions stated, not explored. sankey is the twenty-sixth: where a known quantity goes, each flow a band as thick as its amount, columns derived from the flows — a few flows stated, not explored. numberline is the twenty-seventh: values and ranges on one scale, each end of a range in or out of it — an inequality, the pH scale, a spectrum; not when, which is timeline. barmodel is the twenty-eighth: a word problem as bars of parts in proportion, braced with their checked totals — the bar model, or tape diagram, of primary maths. waterfall is the twenty-ninth: how one total became another, step by step, every subtotal checked against the running sum — the bridge chart of a budget paper. pie is the thirtieth: the shares of one known total as labelled sectors — a few proportions stated, as on a treemap, with a donut as a theme's choice. mindmap is the thirty-first: a topic in the middle and its branches round it as peers, nested three deep and balanced on two sides — where a tree would rank them. argument is the thirty-second: a claim and the points for and against it, tagged and hatched by stance, co-premises under one bracket — the argument map of a law or critical-thinking course. familytree is the thirty-third: people, the couples they form and their children, a generation to a row and numbered for you (II-3), in the standard's symbols — the pedigree of a genetics clinic, and the family tree of a history lesson. meter is the thirty-fourth: one amount against its scale — a progress bar, a fundraising thermometer, a dial or a bullet graph, alone or a few to a panel, every band named in words. rag is the thirty-fifth: workstreams or risks rated red, amber or green — a highlight report, a risk register — each rating a word and a shape, never colour alone, with its trend written in words. clock is the thirty-sixth: analogue clock faces showing a time, for teaching it — the hour hand moving on with the minutes, the time in words under each face or hidden for a worksheet, and how long since an earlier time shaded round the face. A flow also draws a causal loop diagram: a sign on every arrow, delay marks, and named loops marked R or B, the type derived from the signs, never written.

The problem

Language models draw diagrams by emitting SVG with absolute x/y coordinates, and they fail at the same things every time: arrows with a head but no shaft, text that escapes its box, lines that stop short of the shape they point at, a different font size in every element.

These are not failures of judgement. In a corpus of 87 LLM-written diagrams reviewed by a human, 63 drew a complaint, and every one was about placement, not content — nobody disputed what the diagram said, only where things ended up. See docs/brief.md for the measured breakdown.

Placement failures cannot be reviewed away: a cheap mechanical check over finished SVG catches 17 of those 63 and misses 46. They have to be made impossible to express.

The approach

The author writes what the diagram means — nodes, edges, labels, and a semantic role for each. Everything that can be got wrong without seeing the result is not in the format at all:

Output is SVG that can be pasted inline into a Markdown document: colour inherited from the surrounding page, no global <style>, no ids that collide when two diagrams share a page, and no information carried by colour alone — so it survives dark mode and greyscale printing. For anywhere an SVG cannot go — a chat, a slide, an attachment — the same drawing comes out as a PNG on a light, dark or transparent background (pip install 'drawspec[png]', one self-contained wheel; no PDF, no JPEG).

What it looks like

Three documents and the drawings they produced. Nothing was positioned by hand, and every one of these is a file in docs/reference/ that make gallery renders — so the picture is always the render of the spec beside it.

A flow

{
  "version": 1,
  "kind": "flow",
  "title": "Triaging a report",
  "nodes": [
    {"id": "arrive", "text": "A report arrives", "role": "start"},
    {"id": "repro", "text": "Does it reproduce?", "role": "decision"},
    {"id": "fix", "text": "Schedule a fix", "role": "step"},
    {"id": "ask", "text": "Ask for the document", "role": "terminal"}
  ],
  "edges": [
    {"from": "arrive", "to": "repro"},
    {"from": "repro", "to": "fix", "label": "yes"},
    {"from": "repro", "to": "ask", "label": "no"}
  ]
}

The role on each node is the only appearance decision in the file, and it is a semantic one: start and terminal came out as pills and decision as a diamond because the theme says those roles look like that. Change the theme and every diagram in your project changes with it.

A timeline

The thirty-six kinds are the part people do not expect, so here is one that is not a box-and-arrow diagram at all:

{
  "version": 1,
  "kind": "timeline",
  "title": "How the work went",
  "items": [
    {"text": "Brief", "note": "March"},
    {"text": "Specification", "note": "April"},
    {"text": "Plan", "note": "May"},
    {"text": "Foundation", "note": "June to July"},
    {"text": "Kinds", "note": "August"}
  ]
}

Above the line is what happened; below it is when. That is what note means on a timeline, and it is the only kind that draws one.

A chart

{
  "version": 1,
  "kind": "chart",
  "title": "Where the tickets went",
  "axes": {
    "horizontal": { "label": "Quarter", "min": 0, "max": 5 },
    "vertical": { "label": "Incidents" }
  },
  "series": [
    { "name": "Platform", "mark": "bar", "data": [[1, 34], [2, 41], [3, 28], [4, 22]] },
    { "name": "Service desk", "mark": "bar", "data": [[1, 52], [2, 47], [3, 55], [4, 38]] },
    { "name": "Still open", "mark": "line", "data": [[1, 12], [2, 18], [3, 9], [4, 6]] }
  ]
}

No colours are named anywhere in that file. The series are told apart by fill pattern as well as by hue, which is what lets the same drawing survive greyscale printing — a theme is checked against that invariant by drawspec theme check.

There are no coordinates in any of them, and none may be written. x, font_size, stroke and twenty-odd other fields are refused by name, with the JSON pointer of the place they were written. A document may size the whole canvas — width and height at the top level — and may not size one box in it.

Try it

pip install drawspec               # or drawspec[png] for PNG export

drawspec render diagram.json -o diagram.svg   # or to stdout
drawspec render diagram.json -o diagram.png   # needs drawspec[png]; --background dark, --scale 3
drawspec render diagram.json --theme blueprint -o sheet.png  # on a drafting sheet, like the banner
drawspec validate diagram.json                # every violation, by JSON pointer
drawspec theme check default                  # including the greyscale invariant
drawspec theme from site.css -o house.toml    # a theme from your brand's CSS or design tokens
drawspec schema --out drawspec-v1.schema.json # for editor completion

Put "$schema": "https://nuncaeslupus.github.io/drawspec/schema/drawspec-v1.schema.json" at the top of a document and any editor with JSON Schema support completes the fields and flags a refused one while you type it, rather than after a render.

The gallery

Every kind, drawn, on one page →

One document per kind lives in docs/reference, and make gallery renders every one of them into docs/gallery/index.html, which is what that link publishes. It is the fastest way to see the whole vocabulary, and the fastest way to see what a change did — looking at it is how four rendering defects were found that no gate had caught.

It is committed as well as published, so a diff shows what a change did to the pictures.

Every kind is drawn to the theme's one canvas width, and a diagram narrower than it is centred in it rather than cropped to its own ink. That is what makes the three above the same type size at the same column width — and it is the whole reason the width belongs to the theme. Set [canvas] width_mode = "ink" for a diagram meant to be sized on its own.

Every kind is also framed alike: [canvas] margin is the blank between the drawing and the edge of the figure, one number applied in one place. Before it existed each family invented its own, so a timeline above a flow chart bled to the edge beside the flow's quarter-inch of white.

What it is not

drawspec draws simple, declarative diagrams well, and it is the wrong tool for several jobs it might look like it does.

• It is not a Graphviz replacement. Graphviz is a graph-layout engine with decades of work behind its layered and force-directed placement, and it will lay out a hundred-node graph that drawspec refuses. drawspec's layout exists to serve thirty-six named diagram shapes at the sizes a document reads at; past each kind's readability budget (fifteen boxes on a flow) it will tell you to split the diagram into an overview and details rather than produce something dense and unreadable, which is deliberate but is not what a graph tool does.
• It is not charting software. chart has lines, bars, areas, stacks, point labels and a legend. It has no statistics, no interactivity, no dates, no log scales, no error bars, and no second axis. If you are exploring data, use a plotting library; if you are stating a small number you already know, this draws it in the same ink and at the same type size as every other diagram on the page, which a plotting library will not. treemap and sankey are held to the same line: ten parts and one level of groups at most, every part labelled inside itself; fourteen nodes in four columns, every flow balanced and thick enough to see — a few proportions and flows you already know, not a disk-usage explorer or a flow analyser.
• It is not a drawing program. A document has no coordinates in it, on purpose — see The approach above. Anything whose whole point is where things are (a floor plan, a map, a picture of two overlapping Wi-Fi cells) has no declarative description, and drawspec should decline it rather than pretend.
• It is not a rich-text system. Text carries **bold** and `code` spans and nothing else.

What it is good at is the long tail of ordinary explanatory diagrams — the kind that fills a set of course notes, a design document or a runbook — drawn consistently, reviewably, and without an author ever choosing a coordinate.

Documentation

The guide is the way in, and it is meant to be enough on its own — install, a first diagram, choosing a kind, embedding the output, validating in a build, and writing a theme. Under it sit three references, each generated from the code it describes, so none of them can quietly go out of date:

make docs regenerates all three; a test fails if what is committed is not what the code would write, which is the same arrangement the published JSON Schema has.

If you are an agent, or pointing one here

AGENTS.md is the whole format on one page — whether to draw at all, which kind fits what the reader must understand, the readability budget, the roles, worked examples, and what each refusal is telling you to do. It is written to be read in a single pass rather than navigated, which is what the guide and the references are for. llms.txt is the index that points at it.

And if your client speaks MCP, pip install 'drawspec[mcp]' gives you drawspec-mcp: validate, render and kinds as tools, so a refusal arrives as {"pointer": "/edges/0/to", "message": …} in the model's own loop instead of as prose on stderr it has to read. Same checks, same messages, no shell. See the guide.

For agents that load Agent Skills, copy skills/drawspec/ into your skills directory: a short pointer that installs drawspec, reads AGENTS.md, and validates before rendering.

It cannot drift either: a test asserts that every kind in the vocabulary is named in it, that every role the theme declares appears, and that every example in it is a document that still validates. An agent copying from a stale brief is the failure that file exists to prevent, so it is held to the same standard as the generated references.

Repository layout

Everything you would look in, and the two directories you can ignore.

Development

make sync     # install with dev extras
make lint     # ruff + strict mypy
make test     # pytest
make gallery  # render every reference document and look at it
make docs     # regenerate the format, CLI and theme references
make schema   # regenerate the published JSON Schema
