e2c-client

ALMA Ethernet-To-CAN socket server Python client package for LRU monitoring and control.

The e2c-client package provides an application and libraries for CAN-based monitoring and control of hardware devices through the Ethernet-To-CAN module socket server.
See ALMA-70.35.10.14-00.00.00.00-A-ICD for the ICD between Computing/E2C Socket Server Protocol and ALMA operations.

Installation

pip install e2c-client

If installed for user only in an APEx virtual environment, it may be necessary to unset the user PYTHONPATH environment variable for the current session:

unset PYTHONPATH

Installation for development

git clone ssh://git@bitbucket.alma.cl:7999/eng/e2c-client.git
cd e2c-client
make venv
source venv/bin/activate
pip install -e .
e2c-client --help

Usage

Following is a non-exhaustive list of available commands, for illustrative purposes only. Use the following command for all available options:

e2c-client --help
e2c-client version

Monitor-related commands

e2c-client monitor --help
e2c-client monitor request --host <host> --channel <channel> --node <node> --rca <RCA> # perform AMB monitor request
e2c-client monitor nodes --host <host> # list all nodes and ESNs reported by E2C

Control-related commands

e2c-client control --help
e2c-client monitor request --host <host> --channel <channel> --node <node> --rca <RCA> --data <data> # perform AMB control request

Auxiliary tools

e2c-client tools temperature --host <host> --channel <channel> --node <node> # perform AMB monitor request for temperature
e2c-client tools revision --host <host>
e2c-client tools revision --all
e2c-client tools cmpr --host <host> # perform AMB monitor requests for Compressor status
e2c-client tools cmpr --all # obtain compressor status for all antennas
e2c-client tools cryo --host <host> # perform AMB monitor requests for Cryostat status
e2c-client tools cryo --all # obtain cryostat status for all antennas

Examples

Command-line client

List all CAN nodes (LRUs) reported by DV10 E2C

$ e2c-client monitor nodes --host dv10-e2c
Channel: 0, Node id:  0X22, ESN: 0x1080E126010800A2, LO Reference Receiver [LORR]
Channel: 0, Node id:  0X29, ESN: 0x10CD504101080009, IF Processor [IFProc]
Channel: 0, Node id:  0X2A, ESN: 0x10697E41010800D3, IF Processor [IFProc]
Channel: 0, Node id:  0X30, ESN: 0x1060264601080068, Digitizer Clock [DGCK]
Channel: 0, Node id:  0X32, ESN: 0x10CEB326010800D2, First LO Offset Generator [FLOOG]
Channel: 0, Node id:  0X40, ESN: 0x10986F4101080027, 2nd LO Synthesizer [LO2]
Channel: 0, Node id:  0X41, ESN: 0x100FA82601080076, 2nd LO Synthesizer [LO2]
Channel: 0, Node id:  0X42, ESN: 0x10E435460108006C, 2nd LO Synthesizer [LO2]
Channel: 0, Node id:  0X43, ESN: 0x10C58041010800F6, 2nd LO Synthesizer [LO2]
Channel: 0, Node id:  0X50, ESN: 0x108CFC4901080045, DTS Transmitter Module [DTX]
Channel: 0, Node id:  0X51, ESN: 0x1090D84901080084, DTS Transmitter Module [DTX]
Channel: 0, Node id:  0X52, ESN: 0x1007F149010800BB, DTS Transmitter Module [DTX]
Channel: 0, Node id:  0X53, ESN: 0x10724A41010800EB, DTS Transmitter Module [DTX]
Channel: 0, Node id:  0X60, ESN: 0x10C23E410108009E, Power Supply (analog rack) [PSA]
Channel: 0, Node id:  0X61, ESN: 0x105C3B7E020800D8, Power Supply (digital rack) [PSD]
Channel: 1, Node id:  0X24, ESN: 0x107F054A010800B3, Water Vapour Radiometer [WVR]
Channel: 1, Node id:  0X13, ESN: 0x10DA070401080072, Front End Monitor & Control [FEMC]
Channel: 1, Node id:  0X26, ESN: 0x107FB44C01080038, Frontend Power Supply [FEPS]
Channel: 1, Node id:  0X28, ESN: 0x103D754101080051, Calibration Widgets [ACD]
Channel: 2, Node id:  0X25, ESN: 0x104D994C010800AF, Compressor [CMPR]

Request AMBSI temperature monitor point of DV10 LORR (raw data)

$ e2c-client monitor request --host dv10-e2c --channel 0 --node 0x22 --rca 0x30003
Error: 0  (No error)
Data:
0x55, 0x0, 0x8, 0x10

Request AMBSI temperature of DV10 LORR (utility function)

$ e2c-client monitor temperature --host dv10-e2c --channel 0 --node 0x22
Temperature: 42.1875 [C]

Get E2C processor temperature in degrees Celsius (response data is a 4 bytes float, according to ICD):

$ e2c-client monitor request --host dv10-e2c --channel 5 --node 0x16 --rca 0x0E --interpret ">f"
Error: 0  (No error)
Data:
0x42, 0x28, 0x74, 0x92
Interpreted data:
42.11383819580078

Set BB attenuators on IFP0 of DA63 to A:12 dB, B:12.5 dB, C:9 dB, D:8.5 dB

$ e2c-client control request --host da63-e2c --channel 0 --node 0x29 --rca 0x0181 --data "0x60 0x64 0x48 0x44"

Obtain cryostat status for DV01 (e.g., after a power outage):

$ e2c-client tools cryo --host dv01-e2c

                                                                                          Cryostat AMB Monitor request (2026-05-31 03:51:52.410611)
┏━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━━┳━━━━━━━━━━━┓
┃ Host     ┃ Supply     ┃ Pumping    ┃ Backing    ┃ Turbo     ┃ Turbo pump ┃ Gate      ┃ Solenoid   ┃  0: 4K    ┃  1: 4K     ┃  5: 15K   ┃  6: 15K    ┃  8: 15K   ┃  9: 110K   ┃ 10: 110K  ┃ 12: 110K   ┃ Vacuum    ┃ Sensor 0   ┃ Sensor 1  ┃
┃          ┃ Current    ┃ substate   ┃ pump       ┃ pump      ┃ speed      ┃ valve     ┃ valve      ┃ cryocool… ┃ plate near ┃ cryocool… ┃ plate near ┃ shield    ┃ cryocooler ┃ plate     ┃ shield top ┃ gauge     ┃ [mbar]     ┃ [mbar]    ┃
┃          ┃ [A]        ┃            ┃            ┃           ┃            ┃           ┃            ┃ [K]       ┃ link1  [K] ┃ [K]       ┃ link [K]   ┃ top [K]   ┃ [K]        ┃ near link ┃ [K]        ┃           ┃            ┃           ┃
┃          ┃            ┃            ┃            ┃           ┃            ┃           ┃            ┃           ┃            ┃           ┃            ┃           ┃            ┃ [K]       ┃            ┃           ┃            ┃           ┃
┡━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━━╇━━━━━━━━━━━┩
│ dv01-e2c │ N/A        │ UNKNOWN    │ OFF        │ N/A       │ N/A        │ UNKNOWN   │ N/A        │ 3.00      │ 3.28       │ 18.03     │ 18.38      │ 18.89     │ 79.34      │ 95.17     │ 109.00     │ OFF       │ 8.06e-08   │ 3.75      │
└──────────┴────────────┴────────────┴────────────┴───────────┴────────────┴───────────┴────────────┴───────────┴────────────┴───────────┴────────────┴───────────┴────────────┴───────────┴────────────┴───────────┴────────────┴───────────┘

Use with --all to get cryostat status of all antenna elements.

Obtain helium compressor status for DV01:

$ e2c-client tools cryo --host dv01-e2c

                                                                                        Compressor AMB Monitor request (2026-05-31 03:55:13.151434)
┏━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━┳━━━━━━━━━━━┳━━━━━━━━━━┳━━━━━━━━━━━┓
┃ Host     ┃ Compress… ┃ Compress… ┃ Line      ┃ Line      ┃ Compress… ┃ Compress… ┃ Compress… ┃ Compress… ┃ Compress… ┃ Compress… ┃ Time      ┃ Time      ┃ Fault     ┃ Compress… ┃ Compress… ┃ Compres… ┃ Compress… ┃ Compres… ┃ Compress… ┃
┃          ┃ Drive     ┃ Interlock ┃ Pressure  ┃ Pressure  ┃ Temp 1    ┃ Temp 2    ┃ Temp 3    ┃ Temp 4    ┃ Aux 2     ┃ ECU Type  ┃ since     ┃ since     ┃ Status    ┃ Alarms    ┃ Alarms    ┃ ICCU     ┃ ICCU      ┃ FETIM    ┃ FETIM     ┃
┃          ┃           ┃           ┃ Supply    ┃ Return    ┃ [C]       ┃ [C]       ┃ [C]       ┃ [C]       ┃ [mA]      ┃           ┃ last      ┃ last      ┃ Error     ┃ Pressure  ┃ Temperat… ┃ Error    ┃ Error     ┃ Error    ┃ Error     ┃
┃          ┃           ┃           ┃ [mPa]     ┃ [mPa]     ┃           ┃           ┃           ┃           ┃           ┃           ┃ power ON  ┃ power OFF ┃           ┃           ┃           ┃ Status   ┃ Cable     ┃ Status   ┃ Cable     ┃
┃          ┃           ┃           ┃           ┃           ┃           ┃           ┃           ┃           ┃           ┃           ┃ [Sec]     ┃ [Sec]     ┃           ┃           ┃           ┃          ┃           ┃          ┃           ┃
┡━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━╇━━━━━━━━━━━╇━━━━━━━━━━╇━━━━━━━━━━━┩
│ dv01-e2c │ OFF       │ Override  │ 2.06      │ -1.00     │ 332.91    │ 332.91    │ 332.91    │ 332.91    │ 0.25      │ European  │ 42949672… │ 42949672… │ True      │ False     │ False     │ True     │ True      │ True     │ True      │
│          │           │           │           │           │           │           │           │           │           │ unit      │           │           │           │           │           │          │           │          │           │
└──────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴───────────┴──────────┴───────────┴──────────┴───────────┘

Use with --all to get compressor status of all antenna elements.

Python library

>>> import e2c_client
>>> with E2CClient(host="dv10-e2c", port=2000, verbose=False) as client:
>>>     # LORR on bus 0, node 0x22, relative CAN address 0x30003 (GET_AMBIENT_TEMPERATURE), mode 0 (monitor):
>>>     error, data = client.send_request(resource_id=0, bus_id=0, node_id=0x22, can_addr=0x30003, mode=0, data=b"")
>>>     print(", ".join(hex(b) for b in data))
0x54, 0x0, 0x9, 0x10

>>>     # LORR on bus 0, node 0x22, relative CAN address 0x00082 (SET_CLEAR_FLAGS), mode 1 (control):
>>>     error, data = client.send_request(resource_id=0, bus_id=0, node_id=0x22, can_addr=0x00082, mode=1, data=b"\x01")

>>>     # Get E2C internal monitor point (GET_SERIAL_NUMBER, i.e., MAC address):
>>>     error, data = client.send_request(resource_id=0, bus_id=client.E2C_INTERNAL_CHANNEL,node_id=client.E2C_INTERNAL_NODE, can_addr=0x0000, mode=0, data=b"")
>>>     print(", ".join(hex(b) for b in data))
0x0, 0xc, 0x69, 0xff, 0x0, 0xad, 0x0, 0x0

WARNING: the e2c-client library does not (currently) support any rate limitation when communicating with the E2C module. Exercise caution when sending monitoring (or control) requests in a loop to avoid potentially overloading the channel. Always add a reasonable delay (e.g., time.sleep(1)) in each iteration.

TODO

Feel free to contribute on the following pending tasks:

• Improve error handling
• Add real testing pytest template files.
• Code additional auxiliary/support functions for critical recovery tasks like cryostat temperature and pressure monitoring, power supply status, etc.
• Real-time console plotting.
