figmaclaw

Your coding agent can't open Figma. figmaclaw mirrors your Figma files into your git repo as plain markdown (every page, section, frame and prototype flow) and keeps that mirror in sync from GitHub Actions. Claude Code, Codex and plain rg can then read the design next to the code, instead of screenshots pasted into chat or slow, rate-limited API calls.

_{Recorded with docs/demo.tape. To run offline with no Figma token, docs/demo_fixture.py feeds a bundled page to figmaclaw's real pull code. On your own file, figmaclaw track <file-key> does that step.}

Install

uv tool install figmaclaw     # or: pipx install figmaclaw
figmaclaw --version

Needs Python 3.12+ on Linux or macOS (CI runs on Linux). On Windows, run it inside WSL: the CLI uses POSIX file locks and does not start natively.

To run the latest main instead: uv tool install git+https://github.com/aviadr1/figmaclaw.

Quick Start

mkdir design-memory && cd design-memory && git init

figmaclaw init                   # writes 4 GitHub Actions workflows (sync, webhook, variables, webhook management)
export FIGMA_API_KEY=figd_...    # a Figma personal access token
figmaclaw track <file-key>       # key from figma.com/design/<file-key>/...; registers the file and pulls it
rg -n "Checkout" figma/          # the design is now files

git add . && git commit -m "Mirror Figma into git"

To keep the mirror fresh, push the repo to GitHub and add FIGMA_API_KEY as a repository secret. The installed sync workflow then runs every hour. Optional extras:

• CLAUDE_CODE_OAUTH_TOKEN secret: CI also writes the frame descriptions.
• FIGMA_TEAM_ID variable: new files in your team are tracked automatically.
• Figma webhooks: re-sync on every save (needs a small webhook proxy).

docs/INSTALL.md covers all three. Then check the setup:

figmaclaw doctor              # install, API key, manifest, figma/ dir, workflows
figmaclaw workflows doctor    # are the installed workflows up to date with this figmaclaw?

What You Get

One markdown file per Figma page, at figma/<file>/pages/<page>.md. This is the page from the demo, exactly as figmaclaw wrote it:

---
enriched_schema_version: 0
file_key: demo01
flows: [['21:1', '21:2'], ['21:2', '21:3'], ['21:2', '22:1'], ['22:1', '21:2']]
frames: ['21:1', '21:2', '21:3', '22:1']
page_node_id: '12:40'
---

# Shop / Checkout

[Open in Figma](https://www.figma.com/design/demo01?node-id=12-40)

<!-- LLM: Write a 2-3 sentence page summary describing what this page covers -->

## Purchase (`20:1`)

<!-- LLM: Write a 1-sentence section intro if the section has a distinct theme -->

| Screen | Node ID | Description |
|--------|---------|-------------|
| Cart | `21:1` | (no description yet) |
| Checkout | `21:2` | (no description yet) |
| Order confirmation | `21:3` | (no description yet) |

## Errors (`20:2`)

<!-- LLM: Write a 1-sentence section intro if the section has a distinct theme -->

| Screen | Node ID | Description |
|--------|---------|-------------|
| Payment declined | `22:1` | (no description yet) |

## Screen Flow

```mermaid
flowchart LR
    n21_1["Cart"] --> n21_2["Checkout"]
    n21_2["Checkout"] --> n21_3["Order confirmation"]
    n21_2["Checkout"] --> n22_1["Payment declined"]
    n22_1["Payment declined"] --> n21_2["Checkout"]
```

• Frontmatter is machine state (node IDs, prototype flows, hashes). figmaclaw rewrites it on every sync.
• The body starts as a scaffold with <!-- LLM: ... --> placeholders. Fill it in by hand, or run figmaclaw claude-run, which launches Claude Code to screenshot the frames and write the descriptions. After the scaffold, code never rewrites the body, so that prose survives every re-sync.
• Node IDs are Figma's own, so any rg hit maps straight back to figma.com/design/<file-key>?node-id=<id>.

Why figmaclaw

• Files, not API calls. Agents search figma/** with rg and read design history with git log, with no Figma round-trip per question.
• Incremental sync. A file whose Figma version hasn't changed is skipped outright. A page whose content hash hasn't changed is not rewritten. Per-frame hashes mark only the changed screens as stale, so screenshots and descriptions are redone only where the design moved.
• Prose is never clobbered. Sync touches frontmatter only. The body-preservation invariants are written down in docs/body-preservation-invariants.md and enforced by tests.
• Runs itself. figmaclaw init installs thin caller workflows that call the reusable workflows in this repo. figmaclaw workflows doctor|upgrade detects and repairs drift after you upgrade figmaclaw.
• Polite to the Figma API. Requests are paced, and 429 Retry-After responses are honored.

For Design-System Migrations

Migrating a Figma file from one design system to another is where a one-shot agent pass looks right but produces silent corruption: inheritance leaks, frozen literals after an unbind, instances detached from their masters. Round 1 of a real-world migration produced 365 silently-incorrect bindings (write-up).

The audit-page / audit-pipeline / apply-tokens commands turn those passes into checked pipelines. Every change is a manifest that is linted against accumulated rules (the FCLAW namespace), emitted as use_figma batches (<prefix>-NNNN.{json,use_figma.js} + manifest.json), and verified via REST. apply-tokens and audit-page swap share a --dry-run / --emit-only / --execute mode switch. The emitted scripts catch errors per row, so one bad row doesn't roll back the rows that succeeded, and the swap scripts never call .detach().

See docs/migration-pipeline.md for the full pipeline.

How It Works

Designer saves in Figma
  -> Figma webhook  -> figmaclaw apply-webhook   (re-syncs the changed file)
  -> hourly cron    -> figmaclaw pull            (re-syncs every tracked file)
       updates frontmatter; scaffolds new pages; skips unchanged files and pages
  -> figmaclaw claude-run (optional enrichment with Claude Code)
       inspect           : which pages and frames need descriptions?
       screenshots --stale: download only the changed frames
       write-body        : write the prose, keeping frontmatter intact
       mark-enriched     : record what was described
  -> git commit + push

Common Commands

• figmaclaw init: install the GitHub Actions workflows into a repo.
• figmaclaw track <file-key>: register a Figma file and run its first pull.
• figmaclaw list <team-id-or-url>: discover files in a Figma team.
• figmaclaw pull: sync all tracked files.
• figmaclaw sync <page.md>: re-sync one page file.
• figmaclaw diff: show what designers changed between Figma versions (frames added, removed, renamed; flow changes).
• figmaclaw inspect <page.md>: report structure and enrichment state.
• figmaclaw inspect-instance: diff one INSTANCE against its master.
• figmaclaw screenshots <page.md>: download frame screenshots.
• figmaclaw write-body / mark-enriched: write prose, then record that enrichment is done.
• figmaclaw census / variables: snapshot published components and the design-system variable catalog.
• figmaclaw workflows doctor|upgrade: detect or repair workflow template drift.
• figmaclaw self update / self skill: upgrade figmaclaw, or print the bundled agent skill.

Run figmaclaw --help for the full list. Global options such as --repo-dir PATH and --json go before the command: figmaclaw --repo-dir ../design-memory init.

Upgrade

Upgrade a PyPI install with uv tool upgrade figmaclaw (or pipx upgrade figmaclaw).

figmaclaw self update reinstalls from GitHub main (uv tool install --force --reinstall --upgrade git+https://github.com/aviadr1/figmaclaw@main), so use it only on a git install.

Documentation

• Installation and CI setup: docs/INSTALL.md
• Token auth and rotation: docs/token-auth-and-rotation.md
• Markdown schema: docs/figmaclaw-md-format.md
• Migration / lint / apply-tokens pipeline: docs/migration-pipeline.md
• Body preservation design: docs/body-preservation-design.md
• Body preservation invariants: docs/body-preservation-invariants.md
• Failure postmortem and lessons: docs/failure-postmortem-2026-04-03.md

Relationship To issueclaw

figmaclaw follows the same core architecture as issueclaw (webhook -> fetch -> render -> commit) but targets Figma. Consumer repos can use both (figma/ + linear/) together.

Development

git clone https://github.com/aviadr1/figmaclaw
cd figmaclaw
uv sync
uv run pre-commit install

uv run ruff format --check .
uv run ruff check .
uv run --group dev python -m basedpyright
uv run python -m pytest -q --cov=figmaclaw --cov-report=term-missing --cov-fail-under=70

To regenerate the demo GIF on Linux or macOS, install VHS (with ttyd and ffmpeg), rg and the DejaVu Sans Mono font, then from the repo root:

uv sync
vhs docs/demo.tape    # writes docs/demo.gif

Troubleshooting

• ModuleNotFoundError: No module named 'fcntl': you are on native Windows. Run figmaclaw inside WSL.
• FIGMA_API_KEY environment variable is not set.: track, pull and sync need a Figma personal access token in FIGMA_API_KEY.
• Claude credentials file not found or Could not find a Figma OAuth access token: the MCP-based commands need FIGMA_MCP_TOKEN, or Figma authenticated inside Claude Code (~/.claude/.credentials.json).
• MCP servers without an Mcp-Session-Id: supported. FigmaMcpClient handles both sessionful and stateless MCP responses.
• pre-commit missing locally: run uv run --with pre-commit python -m pre_commit install.

License

MIT
