FlowBlueprint

The Python architect: turn any Python script, Jupyter notebook or whole project folder into a clear architecture diagram (draw.io, SVG, HTML or Mermaid for your README), without running it.

Website: samtherocket.github.io/flowblueprint

FlowBlueprint reads your code and draws how it flows: what runs first, which functions are called, what goes in and out of each step (with data types), where loops and decisions are, which files, databases and storage are read or written, and where plots are made. Managers, product owners and new team members can understand a pipeline before reading a single line of code; developers get an architecture diagram that stays in step with the source.

Part of a family of standalone Python tools: FuncLoom (functionizer), RefacTrail (refactorizer) and FlowBlueprint (architect).

Status: alpha, version 0.2.1a0 on PyPI. Free and open source (MIT). Works offline: no AI model, account or internet connection needed.

Start in one minute

1. Install (needs Python 3.12 or newer; older Python? see below):

   pip install flowblueprint


2. Draw your script, notebook or whole project:

   flowblueprint my_script.py                  # writes my_script.drawio
   flowblueprint my_notebook.ipynb -o flow.svg # an image for slides
   flowblueprint my_project/ -o ARCHITECTURE.md  # renders on GitHub


3. Open the result. .drawio opens (and stays editable) in diagrams.net or VS Code's Draw.io Integration extension; .svg and .html open in any browser; .md shows the diagram on GitHub and GitLab. Your code is never run or changed.

Too many blocks? Add --level summary for a higher-level picture. pip install flowblueprint also installs FuncLoom and RefacTrail.

In VS Code

1. Install FlowBlueprint from the Extensions view (search FlowBlueprint).
2. Right-click a .py file, a notebook or a folder in the Explorer and choose Draw architecture of this file (or of this project). The Command Palette (Ctrl+Shift+P, type FlowBlueprint) works too.
3. Pick a format (.drawio, .svg, .html or .md). The diagram is saved next to your file (architecture.<format> for a folder) and opens straight away. The first time, click Install when asked.

What's new in 0.2.1a0

• New VS Code extension on the Marketplace: right-click to draw a file or a whole project.
• Older-Python projects: a step-by-step guide, tested with code for Python 3.8, 3.9 and 3.10.
• A simpler README. Drawing is unchanged; 0.2.0a0's project overviews, Mermaid and HTML output are in the changelog.

Your project uses an older Python?

No problem. FlowBlueprint only reads your code, so it runs on its own Python 3.12 or newer while your project stays on Python 3.8, 3.9, 3.10 or 3.11. Do this once:

1. Make a separate Python for the tools (no admin rights needed):

   # Windows (Command Prompt)
   py -3.12 -m venv %USERPROFILE%\py-tools
   %USERPROFILE%\py-tools\Scripts\python -m pip install flowblueprint

   # macOS / Linux
   python3.12 -m venv ~/py-tools
   ~/py-tools/bin/python -m pip install flowblueprint


   No Python 3.12 on the machine? Run pip install uv, then uvx --python 3.12 flowblueprint my_script.py: uv downloads Python 3.12 for you.

2. Run FlowBlueprint with that Python:

   %USERPROFILE%\py-tools\Scripts\python -m flowblueprint my_script.py     # Windows
   ~/py-tools/bin/python -m flowblueprint my_script.py                       # macOS / Linux


3. In VS Code, open Settings, search for flowblueprint.pythonPath and paste the path of that Python (for example C:\Users\YOU\py-tools\Scripts\python.exe).

Your project keeps using its own Python to run. More detail, limits and fixes for common errors: the older-Python guide.

If pip install flowblueprint says from versions: none, your Python is older than 3.12 (use the steps above) or your company's package mirror does not carry it yet (ask IT to allow it).

Output formats

The suffix of -o picks the format:

A Mermaid diagram lives in your repository as text and GitHub draws it. This one is flowblueprint station_report.py --level summary -o FLOW.md:

---
title: "station_report.py"
---
flowchart TD
    n1(["START"])
    n2["<b>Read and set</b><br/>Read settings; set summaries_list.<br/>in: CONFIG_PATH: str<br/>out: stations_list: list[str],<br/>threshold_float: float, folder_str:<br/>str"]
    n3{{"for station_str in stations_list"}}
    n4["<b>Load, repair and flag</b><br/>Load station readings; repair<br/>missing values; flag heat events.<br/>in: station_str: str, folder_str:<br/>str, threshold_float: float<br/>out: flagged_df: pd.DataFrame,<br/>event_count_int: int"]:::module1
    n5{"event_count_int == 0?"}
    n6["Print progress."]
    n7["<b>Summarise and append</b><br/>Summarise station; append<br/>summary_dict to summaries_list.<br/>in: flagged_df: pd.DataFrame,<br/>station_str: str<br/>out: summary_dict: dict"]
    n8{{"for station_str in stations_list"}}
    n9["<b>Compute and save</b><br/>Compute summary_df with DataFrame;<br/>save as CSV; save the data.<br/>in: summary_df: DataFrame,<br/>summaries_list: list"]
    n10[/"heat_summary.csv"/]
    n11[/"heat_summary.json"/]
    n12>"Plot Hot hours per station."]
    n13>"hot_hours.png"]
    n14(["END"])
    n1 --> n2
    n2 --> n3
    n3 --> n4
    n5 -->|"Yes"| n6
    n4 --> n5
    n5 -->|"No"| n7
    n7 --> n8
    n9 -.-> n10
    n9 -.-> n11
    n8 --> n9
    n12 -.-> n13
    n9 --> n12
    n12 --> n14
    n6 --> n8
    subgraph legend["Legend"]
        legend1["station_utils.py"]:::module1
    end
    classDef module1 fill:#dae8fc,stroke:#222222,color:#000000

Whole projects

Point FlowBlueprint at a folder to see the whole project: one block per script, module, package and notebook, with an arrow from each file to the project files it imports. Entry points sit at the top and the modules they rely on below them. Each block says what the file is (its docstring, the steps it runs, or the functions it provides), how many functions and classes it defines, and which files, databases and storage it reads and writes.

flowblueprint my_project/                        # my_project/architecture.drawio
flowblueprint my_project/ -o ARCHITECTURE.md     # Mermaid for the README
flowblueprint my_project/ --include-tests -o overview.html

Large projects stay readable: above 40 files, files are grouped into one block per sub-package (the deepest folder level that fits 40 blocks), each summing its files, functions, classes and data and naming the scripts it runs. --group-depth 2 picks the level yourself; --group-depth 0 draws every file.

Absolute, relative and sibling-script imports are resolved, including src layouts and folders inside packages. Virtual environments, caches, build output and hidden folders are skipped; test files are skipped unless you pass --include-tests. Files that cannot be parsed are listed as notes instead of stopping the run. In the draw.io and SVG output, an arrow that skips rows runs in its own lane beside the blocks, so it never passes behind one; the Mermaid output is laid out by Mermaid itself.

What you get

Descriptions come from docstrings. Without one, FlowBlueprint writes a short, deterministic description from the code itself ("Calculate distance." for calculate_distance). Types come from annotations, well-known library calls, literals and naming conventions such as _df or _list; anything else is shown as unknown rather than guessed.

Two levels: detailed and summary

One function is not always one block. --level detailed (the default) draws one block per call. --level summary packs consecutive operations into higher-level blocks (up to --group-size, default 4), each listing its operations with the inputs it needs and the outputs it leaves:

You choose the grouping when it matters, with an override file:

# blueprint.toml
[[groups]]
title = "prepare_readings"
description = "Load and clean the readings of one station."
functions = ["load_station_readings", "repair_missing_values"]

[blocks.flag_heat_events]
description = "Find the hours above the heat threshold."

flowblueprint station_report.py --overrides blueprint.toml

Classes and well-structured code

FlowBlueprint works directly on any readable script; you do not need to run FuncLoom or RefacTrail first. Classes are understood: Pipeline(...) becomes a Create the Pipeline block, pipeline.load() resolves to the method and its docstring, and when the entry point only hands over to one method (Pipeline(config).run()), that method's steps are drawn.

FlowBlueprint's own ARCHITECTURE.md is drawn this way (flowblueprint src/flowblueprint -o ARCHITECTURE.md).

Keep the diagram up to date

In GitHub Actions, the FlowBlueprint action draws the diagram on every push; commit it, or keep it as a build artifact:

- uses: actions/checkout@v4
- uses: SAMtheROCKET/flowblueprint@main
  with:
    path: .                     # a script, notebook or folder
    output: ARCHITECTURE.md     # .md, .mmd, .drawio, .svg or .html
    args: --level summary       # optional extra options
- uses: actions/upload-artifact@v4
  with:
    name: architecture
    path: ARCHITECTURE.md

With pre-commit, the flowblueprint-architecture hook redraws ARCHITECTURE.md whenever Python files or notebooks change:

repos:
  - repo: https://github.com/SAMtheROCKET/flowblueprint
    rev: main
    hooks:
      - id: flowblueprint-architecture

Checks

Every diagram is checked against block-diagram rules: start and end terminators, the script name, closed loops, no open-ended blocks, data sources on the left, the per-column limit, a legend for every colour, and verb-first titles. --check only checks and exits with 1 on errors. Statements that are not drawn (for example exception handlers) are reported with their line numbers.

Who uses it

• Developers and data scientists: document a pipeline, review a pull request, or explain a notebook to the team.
• Managers, product owners and project managers: see what a script does, step by step, before a review or planning meeting.
• Students and teachers: present coursework and assignments as a clear flowchart.
• Teams taking over code: get an architecture overview of unfamiliar scripts in seconds.

Safety

The code is parsed with Python's own ast module and is never imported or executed. The source file is never changed. Existing output files are not overwritten unless you pass --force.

Robustness: every file of the Python 3.12 standard library (584 files) and of a 6,988-file corpus of installed packages (NumPy, SciPy, SymPy, matplotlib, Twisted and others) is drawn in detailed and summary form and rendered as draw.io, SVG and Mermaid without an error, as are project overviews of all 92 packages in that corpus (SymPy's 801 files and 6,404 imports take under 5 seconds).

How it fits with FuncLoom and RefacTrail

FlowBlueprint installs FuncLoom and RefacTrail and uses them through absolute imports (for example RefacTrail's validated notebook reader). Use them together for one flow: FuncLoom turns long scripts and notebooks into functions and modules, RefacTrail checks, formats and refactors them, and FlowBlueprint draws the architecture.

Looking for a Python architecture diagram generator, code to flowchart, script to architecture, notebook to architecture, project architecture diagram, Python to Mermaid, workflow diagram generator or auto architecture generator (archgen)? That is what FlowBlueprint does.

Roadmap

• 0.3: cleaner arrow routing in large project overviews and more library knowledge for data types.
• Later, optional: AI-written descriptions, always shown with their source evidence and never required.

License

MIT. See LICENSE.
