flux-batch

Python SDK to generate Flux batch jobs and services

Related Projects

• flux-mcp: MCP functions for Flux.
• flux-mcp-server: MCP server.
• fractale-mcp: (fractale) MCP orchestration (agents, databases, ui interfaces).
• hpc-mcp: HPC tools for a larger set of HPC and converged computing use cases.

If you are looking for flux batch please see the documentation here. This library supports Flux Framework and is experimental.

Services

• flux-scribe: Write job events to a local sqlite database via the JournalConsumer (not added yet, written and needs testing)

Usage

This is a small Flux utility that makes it easy to create Flux batch jobs and services. The use case is to submit work (one or more jobs) under an instance, and run a custom service, or epilog and prolog commands. We will provision several services here, and you can also provide your own name to start / stop.

Setup

Install the library and start (or be in) a flux instance.

flux start
pip install -e . --break-system-packages

Examples

We have a few simple examples:

Saving Logs

python3 ./examples/save_logs.py

Usernetes

Here is an example to deploy the usernetes module.

# Create a Flux allocation
flux alloc -N2 --time 4h

# Ensure Flux Python bindings on path (e.g., import flux, flux.Flux() works)
export PYTHONPATH=/usr/lib64/python3.12/site-packages

# Ensure you have the code here!
git clone https://github.com/converged-computing/flux-batch
cd flux-batch
pip install -e .

# Run the example
python examples/usernetes_module.py

# The module files are written here. If you need them recreated, delete again.
ls ~/.flux-batch

# Join commands are here. We will need to get the flux job id instead of this uuid
ls ~/.usernetes/join-commands

# Look in /tmp/control-plane.log and /tmp/worker.log for logs
# Look in /tmp/<username>/usernetes for usernetes!
# . source_env.sh then use kubectl

Flux Scribe Module

export FLUX_SCRIBE_DATABASE=sqlite:///flux-batch-job.db
python3 ./examples/flux_scribe_module.py

General Test

Or run the controlled example to see a batch job with prolog and epilog run and complete:

python3 ./tests/test_flux_batch.py

Flux Batch Module Test
[OK] Connected to Flux.
[*] Creating batch jobs...
[*] Mapping attributes to BatchJobspecV1...
[*] Previewing submission (Dryrun -> Wrapper)...
#!/bin/bash
echo 'Batch Wrapper Starting'
flux submit --wait /bin/echo 'Job 1 starting'
flux submit --wait /bin/sleep 5
flux submit --wait /bin/echo 'Job 2 finished'
flux job wait --all
echo 'Batch Wrapper Finished'
[*] Performing submission (Dryrun -> Wrapper -> Submit)...
[SUCCESS] Batch submitted! Flux Job ID: ƒMX29AwFu

$ flux jobs -a
       JOBID USER     NAME       ST NTASKS NNODES     TIME INFO
   ƒMX29AwFu vscode   test-batch  R      1      1   4.213s 68e8c4399c15

$ flux jobs -a
       JOBID USER     NAME       ST NTASKS NNODES     TIME INFO
   ƒMX29AwFu vscode   test-batch CD      1      1   6.354s 68e8c4399c15

Here is an explicit (manual) example to do the same:

import flux
import flux_batch

# for pretty printing
# from rich import print

handle = flux.Flux()

# Create your batch job with some number of commands
batch = flux_batch.BatchJobV1()
batch.add_job(["echo", "Job 1 starting"])
batch.add_job(["sleep", "5"])
batch.add_job(["echo", "Job 2 finished"])

# Wrap it up into a jobspec
spec = flux_batch.BatchJobspecV1.from_jobs(
    batch,
    nodes=1,
    nslots=1,
    time_limit="10m",
    job_name="test-batch",
    # Add saving of logs, info, and metadata
    logs_dir="./logs",
)

# Add a prolog and epilog
spec.add_prolog("echo 'Batch Wrapper Starting'")
spec.add_epilog("echo 'Batch Wrapper Finished'")

# Add a service (this assumes user level that exists)
spec.add_service("flux-scribe")

# Preview it (batch wrapper), or generate the jobspec (json)
print(flux_batch.submit(handle, spec, dry_run=True))
jobspec = flux_batch.jobspec(spec)

# Submit that bad boi.
jobid = flux_batch.submit(handle, jobspec)

See the examples directory for more script examples.

TODO

• How to control a variable number of ranks for different services (ref)
• Need to add env directive to flux module start for the job id.
