fractale

Agentic state-machine orchestrator to support MCP Tools and Science

Design

We create a robust and asynchronous orchestrator for scientific workloads. It interacts with an mcp-server to register and load tools of interest. Tools of interest come from:

• flux-mcp: MCP tools for Flux Framework
• hpc-mcp: HPC tools for a larger set of HPC and converged computing use cases.

Abstractions

The library here has the following abstractions.

• Plan: a YAML, human generated manifest that any agent can read and deploy. (fractale/core/plan)
• Step: Units of work in a plan. A step can be of type:
  • plan: An instruction to go to a manager to generate a larger plan
  • agent: a sub-agent task that is a specialized expert at a specific function. Sub-agents call tools, prompts, and other sub-agents (and can recurse)
  • tool: an explicit tool call that includes inputs and outputs.
  • prompt: an explicit prompt endpoint that includes inputs, and an output prompt for an LLM
• Engine: The orchestration engine (native state machine) that instantiates agents (fractale/engines/native)
• Agents: are independent units of a state machine, a sub- or helper- agent that can be run under a primary orchestrating (state machine) agent. Optional agents that are exposed to the LLM as possible steps are under (fractale/agents), and agents that are essential to the top level orchestration are part of fractale/engines/native/agent.

Client

The client (high level) includes these calls:

# Run a specific, human generated plan
fractale run ./examples/plans/<plan.yaml>

# Run a specific sub-agent, first discovering and inspecting the environment to generate a more detailed prompt for it.
fractale agent optimize <Describe high level optimization task>

# Ask a random task (not necessarily an expert at anything, but access to all tools)
# This is a convenience wrapper to calling fractale agent ask_question
fractale prompt <General task to use server tools and prompts>

# Show all sub-agents available
fractale list
fractale list --json

Environment

The following variables can be set in the environment.

Name	Description	Default
FRACTALE_MCP_PORT	Port MCP server is on, if using http variant	8089
FRACTALE_MCP_TOKEN	Token for server	unset
FRACTALE_LLM_PROVIDER	LLM Backend to use (gemini, openai)	gemini
OPENAI_API_KEY	API Key for an OpenAI model	unset
OPENAI_BASE_URL	Base url for OpenAI	unset
GEMINI_API_KEY	API key to use Google Gemini

Note that for provider, you can also designate on the command line. The default is Gemini (gemini). To change:

fractale run --backend openai ./examples/plans/transform-retry.yaml

Agents

The fractale agent command provides means to request orchestration by a sub-agent. A sub-agent is an independent expert that is given access to all MCP endpoints and can orchestrate calls and user interaction to get to a desired outcome. Currently, sub-agent calls are passed through a manager that first inspects the environment to discover resources (compute, software, etc.) and come up with a scoped plan. This may change in the future.

Usage

Server

Let's install mcp-server to start a server with the functions we need.

pip install --break-system-packages git+https://github.com/converged-computing/mcp-server.git#egg=mcp-serve

Dependencies

To prototype with Flux, open the code in the devcontainer. Install the library and start a flux instance.

pip install -e .[all] --break-system-packages
pip install flux-mcp hpc-mcp[all] IPython --break-system-packages
flux start

Note that this needs to be run in an environment with Flux. I run both in the DevContainer. In a different terminal, export the same FLUX_URI from where your server is running. Ensure your credentials are exported.

export GEMINI_API_TOKEN=xxxxxxxxxx

Joke Example

Let's ask Gemini to tell us a joke. In one terminal:

mcpserver start --config ./examples/servers/run-job.yaml

fractale prompt Tell me a joke, and give me choices about the category.

Result Parser

Let's do an example where we add a one-off, on the fly tool, which is like a local registry. We can start an mcpserver in one terminal:

mcpserver start --config ./examples/servers/run-job.yaml

And then run fractale with our local tool defined (-r means registry to add):

fractale prompt -r ./examples/registry/parser-agents.yaml Write me a flux job that tells a joke, and then ask the result parser tool to derive a regular expression for the punchline.

LAMMPS Run

This requires LAMMPS (or similar) installed, and running a set of tools that include a database and the optimization agent.

mcpserver start --config ./examples/servers/run-job.yaml
fractale prompt -r ./examples/registry/analysis-agents.yaml Discover resources and run a LAMMPS job "lmp" with Flux using data in /code. Use the optimization agent step to optimize lammps, and keep retrying the run until the agent decides to stop.

Flux JobSpec Translation

We will need to start the server and add the validation functions and prompt. Start the server with the functions and prompt we need:

mcpserver start --config ./examples/servers/flux-gemini.yaml

And then:

fractale agent ./examples/plans/transform-retry.yaml

Spack Install and Run

git clone --depth 1 https://github.com/spack/spack /tmp/spack
export PATH=/tmp/spack/bin:$PATH
mcpserver start --config ./examples/servers/run-spack.yaml

fractale prompt Install cowsay with spack, load it, and use it to tell a joke.

Docker Build

Let's test doing a build. I'm running this on my local machine that has Docker, and I'm using Gemini.

export GEMINI_API_TOKEN=xxxxxxxxxx

Also install the functions from hpc-mcp:

pip install hpc-mcp --break-system-packages
pip install -e . --break-system-packages

Start the server with the functions and prompt we need:

mcpserver start --config ./examples/servers/docker-build.yaml

# In the other, run a plan explicitly, or do the same with a command line prompt
fractale run ./examples/plans/build-lammps.yaml
fractale prompt Build a container for lammps with an ubuntu 24.04 base

This works very well in Google Cloud (Gemini). I am not confident our on-premises models will easily choose the right tool.

Kubernetes

Note that I have a kind cluster running.

mcpserver start --config ./examples/servers/kubernetes-job.yaml

fractale prompt Deploy a basic hello world job to Kubernetes and get the output log.

TODO

• add saving of graph and transitions to state machine for research.
• where would we add algorithms here (as tools!)?
• get job logs / info needs better feedback for agent
