gst-python-ml 0.3.0

An ML package for GStreamer

GStreamer Python ML

This project provides Python base classes and GStreamer elements supporting a broad range of ML features.

Supported functionality includes:

1. object detection
2. tracking
3. video captioning
4. translation
5. transcription
6. speech to text
7. text to speech
8. text to image
9. LLMs
10. serializing model metadata to Kafka server

ML toolkits are supported via the MLEngine abstraction - we have nominal support for TensorFlow, LiteRT and OpenVINO, but all testing thus far has been done with PyTorch.

These elements will work with your distribution's GStreamer packages. They have been tested on Ubuntu 24 with GStreamer 1.24.

Python Version

All elements have been tested with Python 3.12, the installed version of Python on Ubuntu 24

Install

There are two installation options described below: installing on your host machine, or installing with a Docker container:

Host Install (Ubuntu 24)

Install packages

sudo apt update && sudo apt -y upgrade
sudo apt install -y python3-pip  python3-venv \
    gstreamer1.0-plugins-base gstreamer1.0-plugins-base-apps \
    gstreamer1.0-plugins-good gstreamer1.0-plugins-bad \
    gir1.2-gst-plugins-bad-1.0 python3-gst-1.0 gstreamer1.0-python3-plugin-loader \
    libcairo2 libcairo2-dev git

Install venv

python3 -m venv --system-site-packages ~/venv

Clone repo (host)

git clone https://github.com/collabora/gst-python-ml.git

Update .bashrc

export VIRTUAL_ENV=$HOME/venv
export PATH=$VIRTUAL_ENV/bin:$PATH
export GST_PLUGIN_PATH=$HOME/src/gst-python-ml/plugins

and then

source ~/.bashrc

Activate venv and install basic pip packages

source $VIRTUAL_ENV/bin/activate
pip install --upgrade pip

Install pip requirements

cd ~/src/gst-python-ml
pip install -r requirements.txt

Docker Install

Build Docker Container

Important Note:

This Dockerfile maps a local gst-python-ml repository to the container, and expects this repository to be located in ~/src i.e. ~/src/gst-python-ml.

Enable Docker GPU Support on Host

To use the host GPU in a docker container, you will need to install the nvidia container toolkit. If running on CPU, these steps can be skipped.

Add nvidia repository (Ubuntu)

curl -fsSL https://nvidia.github.io/libnvidia-container/gpgkey | sudo gpg --dearmor -o /usr/share/keyrings/nvidia-container-toolkit-keyring.gpg \
  && curl -s -L https://nvidia.github.io/libnvidia-container/stable/deb/nvidia-container-toolkit.list | \
    sed 's#deb https://#deb [signed-by=/usr/share/keyrings/nvidia-container-toolkit-keyring.gpg] https://#g' | \
    sudo tee /etc/apt/sources.list.d/nvidia-container-toolkit.list

Then

sudo apt update
sudo apt install -y nvidia-container-toolkit
sudo systemctl restart docker

Build Ubuntu 24.04 Container

docker build -f ./Dockerfile -t ubuntu24:latest .

Run Docker Container

a) If running on CPU, just remove --gpus all from command below b) This command assumes you have set up a Kafka network as described below

docker run -v ~/src/gst-python-ml/:/root/gst-python-ml -it --rm --gpus all --name ubuntu24 ubuntu24:latest /bin/bash

In the container shell, run

pip install -r requirements.txt

to install base requirements, and then

cd gst-python-ml to run the pipelines below. After installing requirements, it is recommended to open another terminal on host and run

docker ps to get the container id, and then run

docker commit $CONTAINER_ID to commit the changes, where $CONTAINER_ID is the id for your docker instance.

Docker Cleanup

If you want to purge existing docker containers and images:

docker container prune -f
docker image prune -a -f

IMPORTANT NOTE

To use the language elements included in this project, the nvidia-cuda-toolkit ubuntu package must be installed, and additional pip requirements must be installed from requirements/language_requrements.txt

Post Install

Run gst-inspect-1.0 python to see all of the pyml elements listed.

Building PyPI Package

Setup

1. Generate token on PyPI and add to .pypirc :

[pypi]
  username = __token__
  password = FOOBAR

2. pip install setuptools wheel twine

Build

python -m build

Upload

twine upload dist/*

Using GStreamer Python ML Elements

Pipelines

Below are some sample pipelines for the various elements in this project.

kafkasink

Setting up kafka network

docker network create kafka-network

and list networks

docker network ls

docker launch

To launch a docker instance with the kafka network, add --network kafka-network to the docker launch command above.

Set up kafka and zookeeper

Note: setup below assumes you are running your pipeline in a docker container. If running pipeline from host, then the port changes from 9092 to 29092, and the broker changes from kafka to localhost.

docker stop kafka zookeeper
docker rm kafka zookeeper
docker run -d --name zookeeper --network kafka-network -e ZOOKEEPER_CLIENT_PORT=2181 confluentinc/cp-zookeeper:latest
docker run -d --name kafka --network kafka-network \
  -e KAFKA_ZOOKEEPER_CONNECT=zookeeper:2181 \
  -e KAFKA_ADVERTISED_LISTENERS=INSIDE://kafka:9092,OUTSIDE://localhost:29092 \
  -e KAFKA_LISTENER_SECURITY_PROTOCOL_MAP=INSIDE:PLAINTEXT,OUTSIDE:PLAINTEXT \
  -e KAFKA_LISTENERS=INSIDE://0.0.0.0:9092,OUTSIDE://0.0.0.0:29092 \
  -e KAFKA_INTER_BROKER_LISTENER_NAME=INSIDE \
  -e KAFKA_BROKER_ID=1 \
  -e KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR=1 \
  -p 9092:9092 \
  -p 29092:29092 \
  confluentinc/cp-kafka:latest

Create test topic

docker exec kafka kafka-topics --create --topic test-kafkasink-topic --bootstrap-server kafka:9092 --partitions 1 --replication-factor 1

list topics

docker exec -it kafka kafka-topics --list --bootstrap-server kafka:9092

delete topic

docker exec -it kafka kafka-topics --delete --topic test-topic --bootstrap-server kafka:9092

consume topic

docker exec -it kafka kafka-console-consumer --bootstrap-server kafka:9092 --topic test-kafkasink-topic --from-beginning

non ML

GST_DEBUG=4 gst-launch-1.0 videotestsrc ! video/x-raw,width=1280,height=720 ! pyml_overlay meta-path=data/sample_metadata.json tracking=true ! videoconvert ! autovideosink

Note: make sure to set the following in .bashrc file :

export GST_PLUGIN_PATH=/home/$USER/src/gst-python-ml/plugins:$GST_PLUGIN_PATH

Bird's Eye View

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/soccer_single_camera.mp4 ! decodebin ! videoconvert ! pyml_birdseye ! videoconvert ! autovideosink

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/soccer_single_camera.mp4 ! decodebin ! videorate ! video/x-raw,framerate=30/1 ! videoconvert ! pyml_birdseye ! videoconvert ! openh264enc ! h264parse ! matroskamux ! filesink location=output.mkv

Classification

GST_DEBUG=4 gst-launch-1.0  filesrc location=data/people.mp4 ! decodebin ! videoconvert ! videoscale ! video/x-raw,width=640,height=480 ! pyml_classifier model-name=resnet18 device=cuda !  videoconvert !  autovideosink

Object Detection

TorchVision

pyml_objectdetector supports all TorchVision object detection models. Simply choose a suitable model name and set it on the model-name property. A few possible model names:

fasterrcnn_resnet50_fpn
ssdlite320_mobilenet_v3_large

fasterrcnn

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/people.mp4 ! decodebin ! videoconvert ! videoscale ! video/x-raw,width=640,height=480 ! pyml_objectdetector model-name=fasterrcnn_resnet50_fpn device=cuda batch-size=4 ! videoconvert ! pyml_overlay ! videoconvert ! autovideosink

fasterrcnn/kafka

a) run pipeline from host

GST_DEBUG=4 gst-launch-1.0  filesrc location=data/people.mp4 ! decodebin ! videoconvert ! videoscale ! video/x-raw,width=640,height=480 ! pyml_objectdetector model-name=fasterrcnn_resnet50_fpn device=cuda batch-size=4 ! pyml_kafkasink schema-file=data/pyml_object_detector.json broker=localhost:29092 topic=test-kafkasink-topic

b) run pipeline from docker

GST_DEBUG=4 gst-launch-1.0  filesrc location=data/people.mp4 ! decodebin ! videoconvert ! videoscale ! video/x-raw,width=640,height=480 ! pyml_objectdetector model-name=fasterrcnn_resnet50_fpn device=cuda batch-size=4 ! pyml_kafkasink schema-file=data/pyml_object_detector.json broker=kafka:9092 topic=test-kafkasink-topic

maskrcnn

GST_DEBUG=4 gst-launch-1.0   filesrc location=data/people.mp4 ! decodebin ! videoconvert ! videoscale ! pyml_maskrcnn device=cuda batch-size=4 model-name=maskrcnn_resnet50_fpn ! videoconvert ! pyml_overlay ! videoconvert ! autovideosink

yolo with tracking

GST_DEBUG=4 gst-launch-1.0   filesrc location=data/soccer_tracking.mp4 ! decodebin !  videoconvertscale ! video/x-raw,width=640,height=480 ! pyml_yolo model-name=yolo11m device=cuda:0 track=True ! pyml_overlay  ! videoconvert ! autovideosink

GST_DEBUG=4 gst-launch-1.0   filesrc location=data/soccer_tracking.mp4 ! decodebin ! videoconvertscale ! video/x-raw,width=640,height=480,format=RGB ! pyml_streammux name=mux   filesrc location=data/soccer_tracking.mp4 ! decodebin ! videoconvertscale ! video/x-raw,width=640,height=480,format=RGB ! mux.   mux. ! pyml_yolo model-name=yolo11m device=cuda:0 track=True ! pyml_streamdemux name=demux   demux. ! queue ! videoconvert ! pyml_overlay ! videoconvert ! autovideosink sync=false   demux. ! queue ! videoconvert ! pyml_overlay ! videoconvert !  autovideosink sync=false

yolo with overlay

 GST_DEBUG=4 gst-launch-1.0   filesrc location=data/soccer_tracking.mp4 ! decodebin ! videoconvert ! videoscale ! video/x-raw,width=640,height=480 ! pyml_yolo model-name=yolo11m device=cuda:0 track=True !  pyml_overlay ! videoconvert !  autovideosink

streammux/streamdemux pipeline

 GST_DEBUG=4 gst-launch-1.0   videotestsrc pattern=ball ! video/x-raw, width=320, height=240 ! queue ! pyml_streammux name=mux   videotestsrc pattern=smpte ! video/x-raw, width=320, height=240 ! queue ! mux.sink_1   videotestsrc pattern=smpte ! video/x-raw, width=320, height=240 ! queue ! mux.sink_2   mux.src ! queue ! pyml_streamdemux name=demux   demux.src_0 ! queue ! glimagesink  demux.src_1 ! queue ! glimagesink   demux.src_2 ! queue  ! glimagesink

Transcription

transcription with initial prompt set

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/air_traffic_korean_with_english.wav ! decodebin ! audioconvert ! pyml_whispertranscribe device=cuda language=ko initial_prompt = "Air Traffic Control은, radar systems를,  weather conditions에, flight paths를, communication은, unexpected weather conditions가, continuous training을, dedication과, professionalism" ! fakesink

translation to English

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/air_traffic_korean_with_english.wav ! decodebin ! audioconvert ! pyml_whispertranscribe device=cuda language=ko translate=yes ! fakesink

coquitts

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/air_traffic_korean_with_english.wav ! decodebin ! audioconvert ! pyml_whispertranscribe device=cuda language=ko translate=yes ! pyml_coquitts device=cuda ! audioconvert ! wavenc ! filesink location=output_audio.wav

whisperspeechtts

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/air_traffic_korean_with_english.wav ! decodebin ! audioconvert ! pyml_whispertranscribe device=cuda language=ko translate=yes ! pyml_whisperspeechtts device=cuda ! audioconvert ! wavenc ! filesink location=output_audio.wav

mariantranslate

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/air_traffic_korean_with_english.wav ! decodebin ! audioconvert ! pyml_whispertranscribe device=cuda language=ko translate=yes ! pyml_mariantranslate device=cuda src=en target=fr ! fakesink

Supported src/target languages:

https://huggingface.co/models?sort=trending&search=Helsinki

whisperlive

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/air_traffic_korean_with_english.wav ! decodebin ! audioconvert ! pyml_whisperlive device=cuda language=ko translate=yes llm-model-name="microsoft/phi-2" ! audioconvert ! wavenc ! filesink location=output_audio.wav

LLM

1. generate HuggingFace token

2. huggingface-cli login and pass in token

3. LLM pipeline (in this case, we use phi-2)

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/prompt_for_llm.txt ! pyml_llm device=cuda model-name="microsoft/phi-2" ! fakesink

stablediffusion

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/prompt_for_stable_diffusion.txt ! pyml_stablediffusion device=cuda ! pngenc ! filesink location=output_image.png

Caption

caption + yolo

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/soccer_tracking.mp4 ! decodebin ! videoconvert ! videoscale ! video/x-raw,width=640,height=480 ! pyml_yolo model-name=yolo11m device=cuda:0 track=True ! pyml_caption device=cuda:0 ! textoverlay ! pyml_overlay ! videoconvert ! autovideosink

caption

GST_DEBUG=4 gst-launch-1.0 filesrc location=data/soccer_tracking.mp4 ! decodebin ! videoconvert ! pyml_caption device=cuda:0 downsampled_width=320 downsampled_height=240 prompt="What is the name of the game being played?" ! textoverlay ! autovideosink
