This library is written independent of any specific IMU. The idea is you pass in the appropriate measurements and error terms from your IMU and get the desired output.

This is still under heavy development

Reference Frames

• ECI: Earth-centered Inertial is an inertial frame where Newton's laws of motion apply. It has its origin at the center of the Earth with:
  • x-axis in the direction of the vernal equinox
  • z-axis is parallel to the rotation of the Earth
  • y-axis completes the right-handed coordinate system
• ECEF: Earth-centered, Earth-fixed has the same origin as ECI, but rotates with the Earth and the x-axis points towards the zero/prime meridian. The ECEF frame rotates at 7.2921E-5 rads/sec with respect to the ECI frame
• LLA(H): Latitude, Longitude, Altitude(Height) is similar to the ECEF frame, but is the frame historically used for GPS navigation

WGS84

wgs = WGS84()

# here are a bunch of useful constants in WGS84 class
wgs.rf = 298.257223563
wgs.f = 1/self.rf
wgs.a = 6378137.0
wgs.b = self.a - self.a * self.f
wgs.e = np.sqrt(1 - (self.b ** 2 / self.a ** 2))
wgs.r = (2*self.a + self.b) / 3
wgs.rotation_period = 23*3600 + 56*60 + 4.09053
wgs.rate = 7.2921157e-5  # Rotation rate of Earth [rad/s]
wgs.sf = 1.2383e-3       # Schuller frequency

# translate ecef(x,y,z) <=> llh(lat,lon,alt)
wgs.ecef2llh(loc)
wgs.llh2ecef(loc)

wgs.gravity(lat)   # gravity changes by latitude[deg]
wgs.radius(lat)    # Earth's radius changes by latitude[deg]
wgs.haversine(a,b) # calculates distance between locations a and b

Navigation Frames

While ECEF can be used to navigate the globe, often, you only need to travel 100's of meters or kilometers. Thus a local navigational frame that is tangental to the curvature of the Earth is more useful (and intuitive). Two common ones are:

• ENU: East North Up a local navigation frame, where up and the z-axis align, but clockwise right turns are negative
• NED: North East Down a local navigation frame, where up and the z-axis are opposite, but the direction of right (clockwise) turns are in the positive direction and is the standard vehicle roll-pitch-yaw frame

ref = (40,-90,100) # origin of local frame (lat[deg], lon[deg], altitude[m])
frame = NavigationalFrame(ref)

# allof these will calculate position relative to your local
# frame origin
loc = [x,y,z]
frame.ecef2ned(loc)
frame.ecef2enu(loc)
frame.ned2ecef(loc)
frame.enu2ecef(loc)
frame.enu2ned(loc)
frame.ned2enu(loc)

Other Good Navigation Libraries

• lat_lon_parser allows you to convert between measurements formats like -45 deg 12' 36.0 sec, 45.21 W, and -45.21 easily
• nvector has a lot of capability
• navpy appears to be simple grad student work but code is well referenced (BSD)
• navigation does GPS navigation and way points
