mcp-tollbooth 0.1.0

A security gateway for AI agents: a transparent MCP proxy that enforces policy, DLP, and audit on every tool call and result.

tollbooth sits between any MCP client and the servers it talks to, and enforces security policy, data-loss prevention, and a tamper-evident audit trail on every tool call and result that crosses the boundary.

---

Your AI agent's tool traffic — filesystem writes, shell exec, web fetches, API calls — flows unmediated today. There is no control point to deny a dangerous call, stop a secret from leaking out through a tool argument, redact a credential before it lands in the model's context, or produce a compliance-grade record of what the agent actually did.

tollbooth is that control point. It's a transparent MCP proxy: your client points at one server (tollbooth), tollbooth wraps the real upstream servers, and the gateway config file is the security boundary.

Caught in the act

A single config turns an unmediated agent into a governed one. The recording below is real tollbooth output — every frame is the live policy + DLP engine answering actual Claude Code hook events (reproduce it yourself with vhs demo/demo.tape):

Requests carrying secrets are blocked (egress is the exfil path). Secrets in results are redacted in place so the agent keeps working on real codebases instead of you disabling the control. Safe calls pass straight through, untouched. Every decision is hash-chained into a log you can prove wasn't edited — and the raw secret value appears in none of it.

Prefer text? The same run, line by line.

$ tollbooth hook pre  < curl-pipe-sh.json        # agent pipes a remote script to a shell
  ⛔ deny — "tollbooth: claude/Bash denied by policy rule 'no-curl-pipe-sh'."

$ tollbooth hook pre  < aws-key-to-github.json   # agent leaks an AWS key into a GitHub issue
  ⛔ deny — "github/create_issue blocked — sensitive data detected in arguments
            (aws-access-key). The flagged values were not forwarded upstream."

$ tollbooth hook post < result-with-creds.json   # a tool result comes back carrying creds
  ✏️  updatedToolOutput:
        aws_access_key_id = [REDACTED:aws-access-key]
        [REDACTED:aws-secret-key]

$ tollbooth hook pre  < safe-ls.json             # a safe call — no output, defers to Claude
  (silence)

$ grep -c AKIAIOSFODNN7EXAMPLE demo/demo-audit.jsonl
  0                                              # the raw key is nowhere in the log

$ tollbooth audit verify --log demo/demo-audit.jsonl
  ✅ OK: 4 event(s), head seq=3 hash=8d540adb…, mode=sha256 (unkeyed)

What it stops

Threat	tollbooth control
Agent coerced into curl … | sh, rm -rf, etc.	Policy engine — regex/field rules deny the call before it reaches the upstream
Path traversal / writes escaping the project (/etc/passwd)	not_prefix / prefix matchers on argument fields
Secret or PAN in a tool argument leaving for an upstream	DLP egress block — the call is stopped, pattern id logged, value never
Credential in a tool result entering model context	DLP redaction — [REDACTED:pattern-id] in place, rest intact
Prompt injection in returned tool output	Reference detector plugin — block or annotate (see limitations)
Audit log edited, truncated, or reordered to hide activity	Hash-chained JSONL (HMAC-keyed) — audit verify names the break
"Just turn the control off so the agent works" pressure	Direction-aware defaults keep agents usable; fail-closed on any internal error

How it works

client ──tool call──▶ tollbooth ──▶ [ policy → DLP-request → plugins ] ──▶ upstream
client ◀──result──── tollbooth ◀── [ DLP-result → plugins ] ◀──────────── upstream
                          │
                          └──▶ tamper-evident audit log (one event per decision)

One aggregating gateway process is an MCP server to your client and an MCP client to N upstream servers. It exposes the union of upstream tools, namespaced {server}_{tool}, routed through a mapping table (never string-splitting — server names can contain underscores). Absent any policy, behavior is identical to a direct connection.

Quickstart

git clone https://github.com/Realgagenichols/tollbooth.git
cd tollbooth
uv sync

# 1. Write a gateway config (see examples/tollbooth.yaml) — or bootstrap one
#    from your existing client config:
uv run tollbooth import ~/.claude/claude_desktop_config.json   # or .mcp.json
cp examples/tollbooth.yaml tollbooth.yaml                      # ...or by hand

# 2. Check it
uv run tollbooth validate -c tollbooth.yaml

# 3. Emit the client config block and paste it into your client's MCP config
#    (.mcp.json, claude_desktop_config.json, ...)
uv run tollbooth emit-config -c tollbooth.yaml

Your client then talks to tollbooth run -c tollbooth.yaml, which proxies everything through the pipeline.

Upstream servers

Each entry under servers: is classified by which field it declares — command for a local stdio server (a subprocess) or url for a remote streamable-HTTP server. An entry with neither, or both, is a config error.

servers:
  fs:                                    # stdio: tollbooth launches the subprocess
    command: my-fs-server
    args: [--root, /data]
    env:
      LOG_LEVEL: info
  remote:                                # http: tollbooth connects to the URL
    url: https://api.example.com/mcp
    headers:
      Authorization: Bearer ${REMOTE_TOKEN}

HTTP header values may reference environment variables as ${VAR}, resolved at startup — so tokens live in the environment, never in tollbooth.yaml. A referenced variable that is unset fails closed at startup, naming the variable (never its value). Errors about an HTTP upstream echo only the URL origin (scheme://host[:port]) — never userinfo, path, query, or header content. A dead HTTP upstream returns a clean error for its calls without taking the gateway down. tollbooth import brings both command and url entries in from an existing client config.

OAuth for HTTP upstreams (interactive login + token refresh) is not supported yet — use a ${VAR} bearer token from a long-lived or externally-refreshed credential. Tracked as a future change (N2).

Policy rules

policy:
  default: deny          # decision when no rule matches (allowlist posture)
  failure_mode: closed   # internal error => block (set `open` to log-and-continue)
  rules:
    - name: block-writes-outside-project
      action: deny       # allow | deny | require-approval
      server: fs         # exact server name or "*"
      tool: write_file   # exact tool name or "*"
      where:             # ALL fields must match; matchers: equals, regex,
        path:            #   prefix, not_prefix (exactly one per field)
          not_prefix: /Users/me/project

Rules are evaluated top-down; the first match decides. require-approval blocks the call with a message naming the rule and how to permit it — distinct from a hard deny, and an extensible enum so a future approval TUI / MCP elicitation slots in without reworking the model.

Gotcha: a rule with a where: block can only fire when that argument is present in the call. Negative matchers + default: allow can be bypassed by argument omission — prefer default: deny for guard configs.

DLP

Enabled by default (dlp.enabled: true). Direction-aware: a detection in a tool call's arguments blocks the call (egress is the exfil path); a detection in a result is redacted in place as [REDACTED:{pattern-id}] so the agent keeps working. Overlapping detections resolve to the most specific match. Dict keys and numeric values that would need redaction withhold the whole result instead — nothing sensitive passes because it arrived in an awkward shape.

Pattern id	Detects
aws-access-key	AWS access key IDs (AKIA...)
aws-secret-key	AWS secret key assignments
github-token	GitHub tokens (ghp_, gho_, ..., github_pat_)
private-key-pem	PEM private keys (full block redacted, incl. ENCRYPTED)
connection-string	DB URLs with credentials (postgres://user:pass@...)
api-key-assignment	Generic api_key=... assignments
password-assignment	password:/passwd:/pwd= assignments
pan	Payment cards (Visa/MC incl. 2-series/Amex/Discover), Luhn-validated
ssn	US Social Security Numbers
us-phone	US phone numbers (separators required)

Override per pattern and direction:

dlp:
  enabled: true
  overrides:
    private-key-pem:
      results: block       # withhold the whole result instead of redacting
    us-phone:
      requests: allow      # this CRM legitimately sends phone numbers
      results: allow

Request actions: block (default) | allow. Result actions: redact (default) | block | allow. Unknown pattern ids or actions fail validation at startup.

Audit log

Point the trail at a file for one JSON event per decision:

audit:
  log: ./tollbooth-audit.jsonl
  record: metadata        # or "full" — see below

{"event": "decision", "call_id": "2a2b0cca…", "path": "request", "server": "fs", "tool": "write_file", "decision": "deny", "reason_id": "block-writes-outside-project", "v": 2, "ts": "2026-06-12T10:00:00+00:00", "seq": 5, "prev": "df412ac5…", "session": "f32a7ae3…"}

DLP decisions are audited by pattern id, never value: a blocked request logs "reason_id": "dlp:pan", a redacted result logs "reason_id": "redacted:aws-access-key". Decisions made because a security check was skipped (fail-open) are tagged fail-open:<stage> — the trail never hides a degraded state. (audit_log: <path> is the pre-M3 spelling and still works.)

Tamper evidence

Every event carries a monotonic seq and prev — the SHA-256 of the previous log line — so edits, deletions, and reordering break the chain, which also spans gateway restarts:

tollbooth audit verify --log tollbooth-audit.jsonl
# OK: 10 event(s), head seq=9 hash=0a8e09b2…, mode=sha256 (unkeyed)

Record the reported head externally: a log truncated back to an earlier event still verifies on its own, but won't match your recorded head. Set TOLLBOOTH_AUDIT_KEY (environment variable, never a flag) to upgrade the chain to HMAC-SHA-256 — then an attacker who can rewrite the whole file still can't forge a valid chain without the key. Verification exit codes: 0 clean, 1 tamper/unreadable finding, 2 usage error.

Payload recording & session replay

By default (record: metadata) no argument or result values are ever written. record: full additionally records post-enforcement payloads only: arguments of allowed requests and result content after redaction — exactly what crossed the boundary. Denied or blocked traffic never has payloads recorded, enforced inside the logger itself.

Each gateway run is a session (with a session-start event carrying the gateway version and a config digest, never config contents). Query and replay the trail:

# Filtered events as JSONL — by server, tool, decision, session, time window
tollbooth audit query --log audit.jsonl --decision deny --since 2026-06-12T00:00:00

# Chronological timeline of one session; renders payloads when recorded,
# degrades to a decision timeline on metadata-only logs
tollbooth audit replay <session-id> --log audit.jsonl

Plugins

Beyond the built-in policy and DLP stages you can load your own interceptors, declared in config as module:factory import specs. Plugins run after the built-ins, in declared order — they can tighten a verdict but never loosen one (the first non-allow decision short-circuits), under the same fail-closed semantics: a plugin that raises at runtime denies the call (or withholds the result).

plugins:
  - plugin: examples.plugins.prompt_injection:create   # importable module:factory
    settings:
      action: annotate    # plugin-specific settings dict, passed to the factory

Loading is fail-fast: an import error, a factory that raises, a name collision with a built-in, or an interceptor implementing neither hook aborts startup naming the plugin (reporting the exception type only — settings values are never echoed). Auto-discovery is deliberately not supported: the config file is the security boundary, so installing a package must never silently insert an interceptor.

Write one against the public API (from tollbooth import ...):

from tollbooth import ToolCall, PolicyResult, Decision, ResultEdit, BlockResult

class TagInternalHosts:
    name = "tag-internal-hosts"          # unique; used in audit reason_ids

    def check_request(self, call: ToolCall) -> PolicyResult:
        # Return DENY/REQUIRE_APPROVAL to short-circuit, or ALLOW to pass.
        if "10.0." in str(call.args.get("url", "")):
            return PolicyResult(decision=Decision.DENY, rule_name=self.name,
                                message="internal host blocked")
        return PolicyResult(decision=Decision.ALLOW, rule_name=None, message="ok")

    def check_result(self, call: ToolCall, content: str) -> ResultEdit:
        # Transform content, or `raise BlockResult(reason_id)` to withhold it.
        return ResultEdit(content=content)

def create(settings: dict) -> "TagInternalHosts":
    return TagInternalHosts()

An interceptor may implement check_request, check_result, or both. Exported types: ToolCall, PolicyResult, ResultEdit, BlockResult, Decision, RequestInterceptor, ResultInterceptor. The shipped examples/plugins/prompt_injection.py is a reference result-path detector — see limitations.

Claude Code hooks

The same policy + DLP engine runs as Claude Code PreToolUse/PostToolUse hooks, governing the client's own tools (Bash, Edit, ...) — not just proxied MCP servers. tollbooth hook pre|post reads the hook event JSON on stdin and answers on stdout:

• pre — deny → permissionDecision: "deny" naming the rule; require-approval → "ask" with the approvable message; allow → no output, deferring to Claude Code's own permission prompt (tollbooth never auto-approves).
• post — DLP redactions come back via updatedToolOutput; a per-pattern block override replaces the output with a withholding message.

Native tools route as server claude (e.g. a rule for server claude, tool Bash); MCP tools arrive as mcp__{server}__{tool} and route as (server, tool). Any internal error — malformed stdin, broken config, a pipeline crash — fails closed and never echoes input values. Audit events append under Claude's session_id, with cross-process locking so concurrent hook invocations keep the hash chain intact.

tollbooth emit-config --claude-hooks -c tollbooth.yaml   # merge into .claude/settings.json

Design decisions that matter

The point of tollbooth isn't that it proxies MCP — it's the judgment calls a security control has to get right:

• Fail-closed by default. Any error in policy, DLP, or redaction denies the call; a result that can't be redacted is withheld. A control that fails open is not a control. Fail-open is an explicit, audited opt-in.
• Detected values never appear in logs or errors. Audit records pattern/rule ids, not matches. Payload recording is opt-in and post-enforcement only — the log holds what crossed the boundary, never blocked secrets.
• Direction-aware DLP — requests block, results redact. Redacting outbound arguments would silently corrupt calls; blocking every result would make agents unusable and get the control disabled. Egress is the true exfil path, so that's where the hard stop lives.
• Tamper evidence is keyed. The hash chain detects edits, deletions, and reordering; with TOLLBOOTH_AUDIT_KEY set, an attacker who rewrites the whole file still can't forge a valid chain.
• The config file is the security boundary. Plugins are explicitly declared module:factory specs with fail-fast loading — never entry-point auto-discovery, so installing a package can't silently insert an interceptor.
• Plugins run after built-ins and only tighten. A plugin can never pre-empt a built-in deny; the hook adapter's allow defers to the client's own prompt rather than auto-approving.

Limitations

Stated plainly, because a security tool that overclaims is worse than one that doesn't:

• Prompt-injection detection is a reference, not production-grade. The shipped detector proves the plugin interface; it matches a small set of instruction-override heuristics and will miss real attacks. Treat it as an integration example.
• No OAuth for HTTP upstreams yet (N2) — use a ${ENV_VAR} bearer token.
• tollbooth governs tool traffic, not the LLM API itself. It does not see or modify model completions.
• Non-tool MCP traffic (resources, prompts) is proxied transparently but not yet scanned — a later milestone.
• Local, single-process. No graphical UI and no hosted/multi-tenant deployment; tollbooth runs alongside the client.

Architecture

Module	Responsibility
main	CLI: run, emit-config, validate, import, audit verify|query|replay, hook pre|post
config	Load + pydantic-validate tollbooth.yaml; emit/import client config
proxy	Client-facing MCP server; tool aggregation + namespacing; routes through the pipeline
upstream	UpstreamTransport interface + StdioUpstream / HttpUpstream (supervised); build_upstream factory
policy	YAML rules, field matchers, first-match-wins, extensible Decision enum
pipeline	Ordered interceptor chain (request + result paths); policy and DLP are interceptors
dlp	Secrets / PAN (Luhn) / PII patterns; overlap suppression; direction-aware actions
audit	Hash-chained JSONL log; opt-in HMAC + payload recording; query/replay
plugins	Config-declared interceptor loading + fail-fast validation; documented public API
hook	Claude Code hook adapter: stdin event → pipeline → hook decision JSON

Stack: the official mcp Python SDK, pydantic, and pyyaml — no other runtime dependencies. The project is built spec-first: every feature traces to an RFC 2119 requirement with Given/When/Then scenarios that map directly to tests.

Development

uv run pytest          # 319 tests, incl. a real-subprocess gateway E2E
uv run ruff check .    # lint

License

MIT © Gage Nichols
