mirpy — ML embeddings for immune repertoires

mirpy v3 turns T-/B-cell receptor sequences into fixed-length numeric vectors you can cluster, visualize, and feed to ML models. It implements TCREMP — embedding each receptor by its alignment distances to a fixed set of prototype sequences — so that Euclidean distance in embedding space approximates pairwise alignment distance (Theory T1).

v3 is a slim, embedding-focused rewrite. The classical repertoire toolkit (parsing, overlap, diversity, TCRnet, GLIPH, …) lives on the legacy-v2 branch (mirpy-lib 2.x) and in the sibling tools vdjtools / vdjmatch.

Install

pip install mirpy-lib            # core: numpy, polars, scipy, scikit-learn, seqtree, vdjtools
pip install "mirpy-lib[bench]"   # + benchmark / theory experiments

Pure-Python wheel; the heavy lifting (alignment, Pgen, sampling) is reused from seqtree and vdjtools.

Quick start

import polars as pl
from mir.embedding.tcremp import TCREmp

model = TCREmp.from_defaults("human", "TRB", n_prototypes=3000)   # mode="vjcdr3" | "cdr123"
df = pl.DataFrame({
    "v_call":      ["TRBV10-3*01", "TRBV20-1*01"],
    "j_call":      ["TRBJ2-7*01",  "TRBJ1-2*01"],
    "junction_aa": ["CASSIRSSYEQYF", "CSARVSGYYGYTF"],
})
X = model.embed(df)          # (2, 9000) float32 — 3 distances × 3000 prototypes

Downstream (cluster antigen-specific TCRs — needs [bench] for the kneedle eps, and a real set of clonotypes rather than the two above):

from mir.embedding.pca import pca_denoise
from mir.bench.metrics import cluster, cluster_metrics
labels = cluster(pca_denoise(model.embed(vdjdb_df), n_components=50))

Paired chains concatenate per-chain embeddings via PairedTCREmp. Input/output are AIRR polars frames keyed by vdjtools.io.schema column names.

Command line

pip install mirpy-lib also installs a mir command for the two embedding scales — no Python needed. Inputs are any format vdjtools.io reads (AIRR TSV, vdjtools, MiXCR, immunoSEQ, parquet).

# one repertoire  ->  per-clonotype embedding table (e0…), the input to clustering / ML
mir embed clonotypes sample.tsv --pca 50 -o clonotypes.parquet

# a dataset of repertoires  ->  one fingerprint Φ(S) per sample, per chain (phi0…), on one
# shared basis so the rows are mutually comparable; --mmd also writes the pairwise MMD matrix
mir embed repertoires cohort/*.tsv.gz -o phi.tsv --mmd mmd.tsv

mir embed clonotypes -h / mir embed repertoires -h list every flag (species, locus, prototype count, weight, Φ blocks, …). Sample id defaults to the filename stem; the locus is inferred per file (or restrict with --locus).

Both commands drop non-coding clonotypes (stop codon / legacy out-of-frame markers in junction_aa) before embedding by default — pass --no-filter-functional to skip this. Without it, a stop codon silently produces a numerically meaningless embedding and an out-of-frame _ marker crashes the run outright (neither is a valid amino acid).

Recommended presets

TCREmp.from_defaults(species, locus) uses the per-chain preset when n_prototypes is omitted. Values are data-driven from the bundled prototypes (prototype geometry saturates by these counts; PC columns are the PCA dims retaining ~95% / ~99% variance):

Use 95% PCs for clustering/visualization (the paper's regime); use 99% PCs when reconstructing sequences with the neural inverse codec (diverse chains like IGH/TRD/TRA lose too much sequence detail at 95%). Programmatically: from mir.embedding import get_preset.

from mir.embedding import get_preset
from mir.embedding.pca import pca_denoise
p = get_preset("human", "IGH")
Xc = pca_denoise(X, n_components=p.n_components)          # clustering
Xr = pca_denoise(X, n_components=p.n_components_recon)    # codec reconstruction

Prototypes — which receptors, and how much do they matter?

Every embedding is distances to prototypes, so the prototype set is the coordinate system. mirpy ships one per chain, and you get them without downloading anything:

Is my result an artefact of which prototypes I drew? Take a replicate. The file order is itself a uniform shuffle, so each disjoint block of n rows is an independent draw from the same pool — n_replicates() of them, 10 at n=1000, 5 at n=2000:

from mir.embedding.prototypes import n_replicates
from mir.embedding.tcremp import TCREmp

scores = [my_metric(TCREmp.from_defaults("human", "TRB", 1000, replicate=r).embed(df))
          for r in range(n_replicates("human", "TRB", 1000))]   # 10 draws; spread = sensitivity

Same from the shell: mir embed clonotypes sample.tsv --n-prototypes 1000 --replicate 3.

How much does it matter? Usually very little, and you can check for yourself — bench.theory.prototype_source_correlation(queries, protos_a, protos_b) correlates the pairwise junction-distance geometry under two prototype sets. Two independent draws, 400 held-out human-TRB queries:

So the geometry is essentially draw-independent from n≈500 up: at the default counts, which prototypes you drew is not what your result rests on. Below n≈250 it starts to be.

Each replicate is a different coordinate system. Distances within one are comparable; distances across two are not. The prototype hash covers the replicate index, so codecs, RepertoireSpace and DonorCohort all refuse to mix them — compare summary statistics across replicates (AUC, F1, cluster counts), never raw embeddings. Sweeping n_prototypes instead is a nested comparison (draw r=0 at n=500 is a prefix of n=1000), which answers "how many do I need", not "does it matter which".

Provenance and the regenerate command are in SOURCES.md.

What's inside

Background subtraction & clustering (mir.density)

TCRNET/ALICE find antigen-driven convergent clusters by neighbour enrichment. mir.density does the same test with neighbour-counting in the embedding space instead of on a sequence graph (Theory T6): the enrichment E(z) = f_obs(z)/f_gen(z) is estimated by an adaptive-bandwidth balloon estimator with a per-clonotype Poisson/binomial significance test and BH q-values — no graph, and it scales to whole repertoires.

from mir.density import fit_density_space, neighbor_enrichment, enriched_mask, denoise_and_cluster
from mir.embedding.tcremp import TCREmp

model = TCREmp.from_defaults("human", "TRB", n_prototypes=1000)
# background = a control repertoire (TCRNET) or generate_background(...) (ALICE, P_gen)
space, obs_emb, bg_emb = fit_density_space(model, obs_df, control_df, n_components=20, space="full")
res  = neighbor_enrichment(obs_emb, bg_emb, test="binomial")   # balloon + water-level calibration
hits = obs_df.filter(enriched_mask(res, alpha=0.05))            # background-subtracted clones
labels, mask = denoise_and_cluster(obs_emb, res)               # noise-filter + DBSCAN the hits

Use a biological control as the background when you have one (e.g. pre- vs post-vaccination, patient vs healthy) — differential enrichment cancels generic public convergence and isolates the antigen-specific response. No control of your own? Pooled healthy-donor repertoires are one fetch away (HF isalgo/airr_control, read with vdjtools.io.read — see SOURCES.md). Failing that, generate_background(locus, n) samples the vdjtools P_gen model (the ALICE regime); the "water level" of a naive repertoire is handled by the empirical-null calibration. Pass source="arda" there when your data is arda-annotated (same allele namespace as the prototypes), and species="mouse" for mouse — both need a vdjtools shipping the bundled arda model set. The density benchmarks (YFV, ankylosing-spondylitis B27, TCRNET) live in the companion 2026-mirpy-analysis repo.

The default backend is "kdtree" (exact scipy cKDTree, all cores). At whole-repertoire scale pass backend="ann" (approximate pynndescent, ~30× faster past ~10⁵ clones, trading a small conservative undercount; pip install "mirpy-lib[ann]").

Sample-level (repertoire) embedding (mir.repertoire)

One fixed vector Φ(S) per repertoire — an order-invariant multiset of clonotypes with clone sizes — depth-robust into the low-coverage bulk-RNA-seq regime (Theory §T.7). Φ(S) sketches the empirical measure ρ_S = Σ_σ w_σ δ_{φ(σ)} in three blocks: an RFF kernel mean (depth-robust, codebook-free — no K, no clustering), a coverage-standardized Hill diversity profile, and a second-moment Fisher vector carrying clonotype co-occurrence (HLA-linked public structure). Repertoire distance is the MMD ‖Φ₁(S) − Φ₁(S')‖.

The per-clonotype weights w_σ = g(a_σ)/Σ_τ g(a_τ) come from a clone-size transform g (weight= on sample_embedding/fit_repertoire_space/mir embed repertoires --weight): "log2p1" — g=log2(1+a) — is the default, concave so one hyperexpanded clone can't dominate; "duplicate_count" weights linearly by clone size (g=a); "distinct" ignores size entirely (g≡1, presence only). "log1p" (natural log) and "anscombe" remain available.

from mir.repertoire import fit_repertoire_space, sample_embedding, mmd_matrix, class_witness
from mir.embedding.tcremp import TCREmp
import polars as pl

model  = TCREmp.from_defaults("human", "TRB", n_prototypes=1000)
space  = fit_repertoire_space(model, pl.concat(samples))   # ONE basis for the whole cohort
embs   = [sample_embedding(space, s) for s in samples]     # Φ(S): mean ‖ diversity ‖ second moment
D      = mmd_matrix(embs, unbiased=True)                    # pairwise repertoire distance (unbiased MMD²)
motifs = class_witness(space, pos_samples, neg_samples, candidates)   # public clones separating two groups

Comparability invariant (as with the codecs / density): every sample in a cohort must be embedded through one prototype set and one PCA+RFF basis, or the measures are incomparable — fit_repertoire_space fits that basis once and RepertoireSpace refuses a prototype-hash mismatch.

Use the unbiased MMD (unbiased=True) whenever samples differ in depth/diversity — the biased V-statistic's 1/n_eff self-term otherwise inflates low-diversity samples and fakes a signal. When a nuisance batch is present, compare within-batch contrasts (residualize Φ on the batch indicator): a batch offset is first-order and cancels, while a batch-orthogonal signal (e.g. HLA) survives. The empirical rule of thumb — diversity for how-even, the embedding for which-clones: clone-size phenotypes (age, CMV) are a diversity summary's turf, while clonotype identity (HLA — strongest in TRA and class II) lives in the second moment / witness. A learned co-equal set encoder (Set-Transformer / DeepRC) is in mir.ml.set_encoder ([ml] extra). Recorded results and theory (T7) live in the companion 2026-mirpy-analysis repo (benchmarks/{BENCHMARKS,THEORY}.md) alongside the benchmark scripts.

Sub-probability embeddings: the deficient measure

Φ(S) above is the kernel mean embedding of a probability measure — the weights sum to 1, so every sample asserts one full unit of confidence. At RNA-seq depth that premise fails. Measured: the median tissue TRB sample holds 21 unique clonotypes (blood TRB 254, 1st percentile 1), so w_σ = a_σ/Σa is 1/n for a technical draw size, not a clonal frequency — the true frequencies live at 1e-5…1e-8, and one singleton's weight spans 21,454× across blood TRB purely from sample size. Worse, normalising to 1 forces a 5-clonotype tumour to assert full confidence, so it lands somewhere arbitrary on the unit sphere instead of where it belongs, and callers respond with a minimum-clonotype floor which in tumour deletes the immune desert — the phenotype of interest. (A floor once cut 7,179 labelled donors to 2,129.)

Let the measure be sub-probability instead:

from mir.repertoire import contrast_embedding, missing_mass, naive_reference, sample_embedding

emb = sample_embedding(space, sample, missing_mass="chao")   # or "turing"; "none" = old behaviour
emb.mass                                    # retained mass 1 − M₀ ∈ [0, 1]
ref = naive_reference(space)                 # kernel mean of 20k naive V(D)J recombinations (~8 s)
psi = contrast_embedding(emb, ref)           # Ψ = mass·(Φ − naive): signed, magnitude-carrying

• missing_mass estimates the mass M₀ of the clonotypes that were never drawn — Good–Turing (f₁/N) or bias-corrected Chao1 (S_u/(N+S_u), S_u = f₁(f₁−1)/(2(f₂+1)); never the classical f₁²/2f₂, undefined when no clone was seen exactly twice, which is common here). missing_mass= only sets .mass; the blocks are untouched, and the "none" default is bit-identical to before.
• Not a negative measure. Φ's value is that ‖Φ_P − Φ_Q‖ is the MMD and that a convex combination of two Φ's is the Φ of a real pooled repertoire (what makes mir.twin and trajectory interpolation mean anything); a measure allowed to go negative on a set is not a probability measure and loses both. A sub-probability measure costs neither.
• naive_reference gives the unseen block a principled location — the germline recombination model (vdjtools.model.generate), not the corpus centroid. This is the load-bearing choice: shrinking toward the centroid is James–Stein toward the mean and it measurably hurt (it piles shallow samples into a dense ball that is itself depth-correlated), while the germline draw dropped R²(PC1, depth) from 0.259 to 0.001 (blood TRB) and 0.067 to 0.006 (tissue IGH) with kNN label entropy unchanged or better.
• contrast_embedding is where legitimate negativity lives: a signed difference of two probability measures, negative wherever the sample is depleted relative to unselected recombination, still an ordinary RKHS element with ‖Ψ_S‖ = MMD(S, naive). Magnitude then reads as confidence × deviation-from-naive: an immune desert has M₀ → 1 and lands at the origin, the right place for "no infiltrate detected", and a shallow blood sample says so by its norm instead of being dropped. Give the caller mass to weight with; don't add a floor.

⚠ Scale a magnitude-carrying block with one global scalar, never per column. Per-column standardisation forces every coordinate to unit variance across samples, so a matrix where half the rows sit at the origin comes out looking exactly like one where none do — it deletes the deficiency it was built to preserve. Use ChannelBuilder.add(..., preserve_magnitude=True), which applies one pooled RMS per channel and fills holes with 0. (stack_embeddings warns if it is handed deficient-mass embeddings, since Φ.vector does not carry the mass.)

Functional diversity, compartments, and depth

Four more consequences of the same measure algebra, all of them cheap once Φ is a kernel mean:

from mir.repertoire import (band_embeddings, depth_threshold, mixture_weights,
                            rao_q, rarefy_embedding, sample_statistics)

rao_q(emb)                          # 1 − ‖Φ₁‖² — Rao's quadratic entropy, exactly
depth_threshold(embs).kappa         # the size below which Φ is mostly sampling noise
bands = band_embeddings(space, sample)              # singleton / expanded / top (or IGH isotypes)
mixture_weights(emb, bands)["weights"]              # π per compartment, by NNLS
rarefy_embedding(space, sample, depth=20_000).v_rep # matched-depth Φ + its replicate noise

• rao_q — Rao's quadratic entropy is 1 − ‖Φ₁‖² exactly (verified against an explicit Gram to ~1e-16), so the norm of the kernel mean is a diversity statistic and no Gram matrix is needed. It is the diversity the Hill block cannot express: every Hill number is a functional of the clone-size distribution alone, hence invariant to permuting which receptor carries which abundance, while Rao's Q weights each pair by how different the receptors are. Measured: this one scalar recovers R² 0.74–0.85 of classical diversity, and embedding derivatives reach R² 0.974–0.994 for Shannon. Valid only on the uncentred Φ₁ — centring preserves differences (MMD) but not norms.
• depth_threshold — the damage depth does to a kernel mean is not bias but variance ∝ 1/n. Regressing ‖Φ_S − Φ̄‖² on 1/n splits the spread into between-sample signal τ² and sampling noise σ², so κ = σ²/τ² is the size at which they are equal. Measured κ ≈ 40–70 clonotypes across four independent views, with 23–69% of samples below it. Report κ for your cohort instead of importing a cutoff — and note the library still applies no floor.
• band_frames / band_embeddings / mixture_weights — Φ₁ is an average, which is the right operation for a population mean and the wrong one for a minority signal: writing the repertoire as (1−π)ρ_naive + π ρ_expanded shows a compartment-confined effect reaching Φ₁ attenuated to πΔ while the naive compartment supplies the noise. Bands (singleton / expanded / top 1%, or IGH isotypes from c_call) are embedded through the same frozen space — never refit, or band-to-band distances stop meaning anything — and bands under 5 clonotypes are recorded absent (None), not upsampled. Because mixture linearity Φ(S) = Σ π_c Φ(c) is exact, a non-negative least squares recovers each compartment's share (exact in exact arithmetic; float32 embeddings put the realised residual near 1e-5). Measured on IGH isotypes: class-switched IgG carries π = 0.070 of Φ₁(IGH) (IgM 0.230, IgA 0.176, 0.520 uncalled) — the dilution factor measured rather than assumed, and a power calculation before you spend compute: a subset with π ≈ 0.001 is not detectable by any aggregate distance, so use the per-clonotype witness. Straight about the negative: on survival endpoints the bands did not beat a diversity reference (0/22 pre-registered cells), though singleton reproduced a clinical-only score and expanded reproduced the whole-repertoire score exactly as the mixture argument predicts, and banding did win on kNN entropy in tissue IGH (0.3875 vs 0.4686).
• rarefy_embedding — averaging Φ over multinomial subsamples is itself a kernel mean (of the mixture over subsamples), so it is the only depth correction that keeps MMD, Rao and mixture linearity exactly (~1e-15); an orthogonal projection breaks the norm identity and a per-coordinate rescale breaks both. It also hands you a free per-sample noise estimate, because Rao(Φ̄) = mean_r Rao(Φ_r) + v_rep holds exactly — the excess diversity of the average is the replicate variance. Not a default: rarefying a cohort to its shallowest useful depth throws away the deep samples' advantage.

Also sample_statistics / cohort_statistics (the sampling fingerprint: f₁/f₂/f₃₊, singleton fraction, missing mass, top-clone fraction, library size — the stats= input below, and candidate biology in their own right) and mir.cohort.depth_report, which regresses the leading PCs on that fingerprint. Read it beside explained_variance: with the deficient measure, R²(PC1, depth) fell 0.259 → 0.001 and best-of-PC1–5 0.253 → 0.047 while PC1's explained variance was unchanged, which is what distinguishes "a different direction" from "a collapsed one".

⚠ mir.cohort.residualize(..., shrink=True) for batch offsets fitted from few samples in many dimensions. Plain per-group centring can make the batch easier to read, measured out-of-sample: batch-identity AUC 0.863 raw → 0.985 after centring, 0.978 after ComBat. The mechanism is estimation error — ‖µ̂ − µ‖ ≈ √(σ²d/n) was ≈16 against a true offset of 7–24, so subtracting it injects a batch-constant vector as large as the one it removes, invisible in-sample by construction. Positive-part James–Stein shrinkage recovered most of it: 0.985 → 0.889.

The matching evaluation criterion is recoverability, not competition: mir.bench.recovery_report(X, stats, groups) runs a grouped-CV ridge from the embedding's PCs back to each basic repertoire statistic (richness, Shannon, top-clone fraction, singleton fraction, Chao unseen fraction, library size) and reports R² — high means the statistic is carried inside the embedding and nothing has to be bolted on beside it. Renormalising to mass 1 deletes the magnitude, so coverage and richness are unrecoverable from Φ by construction; the deficient measure should win that question as a design consequence. It sits beside mir.cohort.missingness_report as the other "is this object honest" check.

Exposure trajectory, generative loop, digital twin

A repertoire cohort often has a known covariate (HLA, batch, vaccine arm) but an unknown or noisy progression axis (days since exposure, response severity). mir.track.fit_exposure_trajectory recovers that latent trajectory tau while disentangling it from the covariate — a PhenoPath-style model (Campbell & Yau 2018, Nat. Commun. 10.1038/s41467-018-04696-6, adapted from genes×cells to repertoire-channels×samples) over any per-sample channel matrix (a stacked Φ, a ChannelBuilder build, or a raw embedding block):

from mir.explain import stack_embeddings
from mir.track import fit_exposure_trajectory

X, spec = stack_embeddings(embs)                 # channels: mean ‖ diversity ‖ second
fit = fit_exposure_trajectory(X, hla_indicator, channel_names=spec.names)
fit.tau                    # inferred exposure/progression pseudotime, one per sample
fit.top_interactions(5)    # which channels respond to progression differently by covariate

Complementing that, mir.generate.DescriptorDensity fits a (optionally class-conditional) density over RepertoireDescriptor vectors — sample draws brand-new synthetic donor states, evolve perturbs one donor along a coordinate ("what if hotter") and propagates the coupled shift through every other coordinate via the fitted covariance's conditional mean. mir.ml.diffusion ([ml] extra) is the non-linear alternative — a compact conditional DDPM/DDIM generator with classifier-free guidance, sharing the same sample(n, condition=…) call shape so it drops in unchanged. mir.twin.DonorTwin glues a donor's descriptor + trajectory position + covariate into one object you perturb or resample through, instead of threading the three APIs together by hand:

from mir.generate import fit_descriptor_density
from mir.twin import make_twins

density = fit_descriptor_density(descriptors, labels=tumor_type)
twins = make_twins(descriptors, conditions=tumor_type, donor_ids=sample_ids)
hotter = twins[0].perturb(density, coordinate="infiltration", delta=2.0)
synthetic = twins[0].simulate(density, n=20)     # 20 new synthetic peers of donor 0

See examples/trajectory_and_twin.py for a runnable end-to-end demo.

Reproduce the paper

The self-contained theory notebooks run on bundled data:

pip install "mirpy-lib[examples]"
marimo edit examples/theory.py          # supplementary S1–S3 (distance laws, D↔d, prototype robustness)
marimo edit examples/quickstart.py      # embed + cluster (epitope colours need a local VDJdb dump)

The full benchmark suite (VDJdb Table S1, density, repertoire/TCGA) and result docs live in the companion analysis repo 2026-mirpy-analysis — this repo is the library + CI tests only.

Method: Kremlyakova et al., TCREMP: a bioinformatic pipeline for efficient embedding of T-cell receptor sequences, J Mol Biol 437 (2025) 169205.

Performance & parallelism

mirpy is CPU-parallel by default and uses the GPU for the neural codecs. Knobs, by hot path:

Rule of thumb: leave threads=0 (all cores) for embedding; leave density on the default backend="kdtree" (exact, multicore) and switch to "ann" only at whole-repertoire scale; the GPU is used only by mir.ml.

Development

Repo-local .venv via uv (bash/zsh): bash setup.sh — add --dev-parents to editable-install the sibling seqtree / vdjtools / vdjmatch checkouts and --tests to run the fast suite. Tests: python -m pytest tests/ -q. See CLAUDE.md for the architecture and reuse map.
