openclaw-k8s-toggle-operator 0.0.19

Matrix-controlled Kubernetes deployment toggle operator

openclaw-k8s-toggle-operator

Matrix-controlled Kubernetes deployment toggle operator. Connects to a Matrix homeserver with E2E encryption and listens for chat commands to scale a K8s deployment between 0 and 1 replicas.

Bot Commands

Send these as plain text messages in a Matrix room with the bot (encrypted or unencrypted):

Command	Action
start / on	Scale deployment to 1 replica
stop / off	Scale deployment to 0 replicas
status	Show deployment replica counts
help	Show available commands

Only users listed in ALLOWED_USERS can send commands. The bot auto-accepts room invitations from allowed users.

Architecture

• Runs as a single-replica Deployment in a dedicated namespace
• Uses the Kubernetes Python client with in-cluster config to patch deployment scale
• Connects to Matrix via minimatrix (wraps matrix-nio with E2E encryption, session reuse, and device trust)
• Session reuse — persists Matrix access token and device ID across restarts (no re-login or key loss)
• Auto-join — accepts pending room invites on startup
• TOFU device trust — automatically trusts all devices of allowed users
• Multiple auth methods — password, SSO, or JWT via Keycloak (ROPC + JWKS)
• Crypto store must be on a persistent volume or the bot loses decryption keys on restart
• Auto-reconnect loop with exponential backoff (max 20 retries)

Configuration

Variable	Required	Default
MATRIX_HOMESERVER	no	http://synapse.matrix.svc.cluster.local:8008
MATRIX_USER	yes	—
MATRIX_PASSWORD	yes	—
ALLOWED_USERS	yes	— (comma-separated full Matrix user IDs)
DEPLOYMENT_NAME	no	clawdbot
DEPLOYMENT_NAMESPACE	no	clawdbot
CRYPTO_STORE_PATH	no	/data/crypto_store
ECHO_MODE	no	true (echo user messages with lobster emoji before processing)
LOGURU_LEVEL	no	DEBUG

JWT Authentication

When AUTH_METHOD=jwt is set, the operator authenticates via Keycloak ROPC (Resource Owner Password Credentials) grant instead of direct Matrix password login. This enables centralized identity management through Keycloak while allowing non-interactive bot authentication.

See HOWTO_MATRIX_KEYCLOAK_OAUTH.md for a step-by-step setup guide covering Keycloak client creation, Synapse configuration, and verification.

Authentication Flow

sequenceDiagram
    participant Bot as Bot/Service
    participant KC as Keycloak
    participant Syn as Synapse

    Bot->>KC: 1. ROPC grant (username + password)
    KC-->>Bot: 2. JWT access token
    Bot->>Syn: 3. Matrix login (JWT)
    Syn->>KC: 4. Validate JWT (JWKS or introspection)
    KC-->>Syn: JWT valid
    Syn-->>Bot: 5. Matrix access token

Supported Login Types

Login Type	Synapse Config	Validation Method	Use Case
com.famedly.login.token.oauth (default)	synapse-token-authenticator oauth:	JWKS endpoint	Recommended — automatic key rotation
com.famedly.login.token	synapse-token-authenticator jwt:	Symmetric secret (HS512)	Internal services with shared secret
org.matrix.login.jwt	Native jwt_config:	Public key (RS256)	Simple setup, manual key management

Environment Variables

Variable	Required	Default
AUTH_METHOD	no	password
KEYCLOAK_URL	yes (if jwt)	—
KEYCLOAK_REALM	yes (if jwt)	—
KEYCLOAK_CLIENT_ID	yes (if jwt)	—
KEYCLOAK_CLIENT_SECRET	no	"" (empty for public clients)
JWT_LOGIN_TYPE	no	com.famedly.login.token.oauth

---

Complete Setup Guide

This section describes the full setup for JWT authentication with Keycloak and Synapse.

Prerequisites

• Keycloak instance (any recent version)
• Synapse homeserver
• Admin access to both Keycloak and Synapse

Step 1: Keycloak Realm Setup

Create a dedicated realm for Matrix (or use an existing one). A dedicated realm simplifies user management since any user in the realm can authenticate to Matrix.

Via Keycloak Admin Console:

1. Navigate to Realm Settings → Create Realm
2. Set realm name (e.g., matrix)
3. Enable the realm

Recommended realm settings:

• registrationAllowed: false — disable self-registration (admin creates users)
• loginWithEmailAllowed: false — use usernames, not emails (Matrix localparts)
• registrationEmailAsUsername: false — important for Matrix username compatibility

Step 2: Create OAuth Client for Bot Authentication

Create a confidential client with ROPC (Direct Access Grants) enabled. This client is used by bots and services to obtain JWT tokens via username/password.

Via Keycloak Admin Console:

1. Navigate to Clients → Create Client
2. Set Client ID (e.g., synapse-oauth)
3. Configure:
   • Client authentication: ON (confidential client)
   • Authorization: OFF
   • Authentication flow: Enable only Direct access grants (ROPC)
   • Standard flow: OFF (not needed for bots)
   • Service accounts: OFF (not needed)

Key settings summary:

Setting	Value	Reason
publicClient	false	Confidential client with secret
clientAuthenticatorType	client-secret	Use client secret for auth
directAccessGrantsEnabled	true	Required — enables ROPC grant
standardFlowEnabled	false	No browser redirects needed
serviceAccountsEnabled	false	Not using service account

After creation:

1. Go to Credentials tab
2. Copy the Client secret — you'll need this for the bot configuration

Step 3: Create Bot User in Keycloak

Create a user account for the bot in your Keycloak realm.

Via Keycloak Admin Console:

1. Navigate to Users → Add user
2. Set username (e.g., clawdbot-operator) — this becomes the Matrix localpart
3. Set email (optional)
4. Enable the user
5. Go to Credentials tab → Set password
6. Set a password and disable "Temporary"

Important: The Keycloak username must match the desired Matrix localpart. Synapse extracts the username from the preferred_username JWT claim.

Step 4: Install synapse-token-authenticator

The synapse-token-authenticator module adds additional login types to Synapse for JWT/OIDC authentication.

Installation:

pip install synapse-token-authenticator

For Docker deployments, add to your container startup:

pip install --no-cache-dir synapse-token-authenticator

Or create a custom Synapse image with the module pre-installed.

Step 5: Configure Synapse

Add the synapse-token-authenticator module to your homeserver.yaml. The configuration depends on which login type(s) you want to support.

Option A: OAuth with JWKS Validation (Recommended)

Login type: com.famedly.login.token.oauth

This is the recommended configuration. Synapse validates JWT signatures against Keycloak's JWKS endpoint, enabling automatic key rotation.

modules:
  - module: synapse_token_authenticator.TokenAuthenticator
    config:
      oauth:
        jwt_validation:
          # Keycloak JWKS endpoint for signature validation
          jwks_endpoint: "https://keycloak.example.com/realms/<realm>/protocol/openid-connect/certs"
          # JWT claim containing the Matrix localpart
          localpart_path: "preferred_username"
          # Require token expiry (recommended)
          require_expiry: true
          # Validator type: "exist" just checks the user exists
          validator:
            type: exist
        # Auto-register users on first login
        registration_enabled: true

Advantages:

• Automatic key rotation — no manual key updates when Keycloak rotates keys
• Standard OIDC/OAuth2 flow
• Works with any OIDC provider

Option B: JWT with Symmetric Secret

Login type: com.famedly.login.token

Uses a shared symmetric secret (HS512) for JWT validation. Simpler but requires secure secret distribution.

modules:
  - module: synapse_token_authenticator.TokenAuthenticator
    config:
      jwt:
        # Shared secret (must match token signing key)
        secret: "your-256-bit-secret-here"
        algorithm: HS512
        # Don't auto-register users
        allow_registration: false
        # Require token expiry
        require_expiry: true

Use case: Internal services where you control both token generation and validation.

Option C: Native Synapse JWT (No Module Required)

Login type: org.matrix.login.jwt

Uses Synapse's built-in JWT support with the realm's RSA public key.

Get the realm public key:

curl -s "https://keycloak.example.com/realms/<realm>" | jq -r '.public_key'

Add to homeserver.yaml:

jwt_config:
  enabled: true
  secret: |
    -----BEGIN PUBLIC KEY-----
    <paste the public key here>
    -----END PUBLIC KEY-----
  algorithm: "RS256"
  subject_claim: "preferred_username"
  issuer: "https://keycloak.example.com/realms/<realm>"

Disadvantages:

• Manual key management — must update homeserver.yaml when Keycloak rotates keys
• No automatic key rotation

Combined Configuration (All Methods)

You can enable multiple authentication methods simultaneously:

modules:
  - module: synapse_token_authenticator.TokenAuthenticator
    config:
      # Option A: OAuth/JWKS (com.famedly.login.token.oauth)
      oauth:
        jwt_validation:
          jwks_endpoint: "https://keycloak.example.com/realms/<realm>/protocol/openid-connect/certs"
          localpart_path: "preferred_username"
          require_expiry: true
          validator:
            type: exist
        registration_enabled: true

      # Option B: Symmetric JWT (com.famedly.login.token)
      jwt:
        secret: "your-256-bit-secret-here"
        algorithm: HS512
        allow_registration: false
        require_expiry: true

      # Option C: OIDC Token Introspection (com.famedly.login.token.oidc)
      # For real-time token validation (slower but supports revocation)
      oidc:
        issuer: "https://keycloak.example.com/realms/<realm>"
        client_id: "synapse"
        client_secret: "your-oidc-client-secret"
        allow_registration: true

Step 6: Restart Synapse

After updating homeserver.yaml, restart Synapse to load the new configuration.

Step 7: Test the Setup

Use the included test script to verify the JWT authentication flow:

KEYCLOAK_URL=https://keycloak.example.com \
KEYCLOAK_REALM=matrix \
KEYCLOAK_CLIENT_ID=synapse-oauth \
KEYCLOAK_CLIENT_SECRET=your-client-secret \
MATRIX_USER=clawdbot-operator \
MATRIX_PASSWORD=your-password \
MATRIX_HOMESERVER=https://matrix.example.com \
ALLOWED_USERS=@admin:matrix.example.com \
./test-jwt-login.sh

The script performs:

1. Step 1: Obtains JWT from Keycloak via ROPC grant
2. Step 2: Decodes and displays JWT claims (for debugging)
3. Step 3: Tests Matrix login via the configured login type

Test different login types:

# Test OAuth/JWKS (default)
./test-jwt-login.sh

# Test symmetric JWT
./test-jwt-login.sh --login-type com.famedly.login.token

# Test native Synapse JWT
./test-jwt-login.sh --login-type org.matrix.login.jwt

# Test password auth (skip Keycloak)
./test-jwt-login.sh --auth-method password

test-jwt-login.sh Reference

Command-line options:

Option	Description	Default
-t, --login-type TYPE	JWT login type	com.famedly.login.token.oauth
-m, --auth-method TYPE	Auth method (password or jwt)	jwt
-s, --skip-decode	Skip JWT decoding step	false
-v, --verbose	Show detailed output including full responses	false
-h, --help	Show help message	—

Exit codes:

Code	Meaning
0	All tests passed
1	Configuration error (missing environment variables)
2	Keycloak token request failed
3	JWT decode failed
4	Matrix login failed

Notes:

• The script auto-detects the local .venv directory for running connectortest
• For password auth (-m password), Keycloak variables are not required
• Use -v (verbose) to see full HTTP responses when debugging failures

---

Comparison: Login Types

Feature	com.famedly.login.token.oauth	com.famedly.login.token	org.matrix.login.jwt
Key management	Automatic (JWKS)	Manual (shared secret)	Manual (public key)
Key rotation	Automatic	Manual secret update	Manual config update
Algorithm	RS256 (asymmetric)	HS512 (symmetric)	RS256 (asymmetric)
Module required	Yes	Yes	No
Token revocation	Via introspection mode	No	No
Setup complexity	Medium	Low	Low
Recommended for	Production	Internal services	Simple setups

---

Troubleshooting

Common Issues

"Invalid username or password" from Synapse:

• Verify the Keycloak user exists and password is correct
• Check that preferred_username in JWT matches an existing Matrix user (or registration_enabled: true)
• Verify JWKS endpoint is accessible from Synapse

"ROPC grant failed" from Keycloak:

• Ensure directAccessGrantsEnabled: true on the client
• Verify client secret is correct
• Check user is enabled in Keycloak

"JWT signature validation failed":

• For JWKS: verify the endpoint URL is correct and accessible
• For native JWT: ensure public key is correctly formatted with PEM headers
• Check issuer matches the JWT iss claim

Useful Keycloak Endpoints

Endpoint	Purpose
/realms/<realm>/.well-known/openid-configuration	OIDC discovery document
/realms/<realm>/protocol/openid-connect/certs	JWKS endpoint (public keys)
/realms/<realm>/protocol/openid-connect/token	Token endpoint (ROPC)
/realms/<realm>	Realm info (includes public key)

Kubernetes Deployment

RBAC

The operator requires a ServiceAccount with a Role scoped to the target namespace:

apiVersion: v1
kind: ServiceAccount
metadata:
  name: openclaw-toggle-operator
  namespace: clawdbot
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: openclaw-toggle-operator
  namespace: clawdbot
rules:
  - apiGroups: ["apps"]
    resources: ["deployments", "deployments/scale"]
    verbs: ["get", "patch"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: openclaw-toggle-operator
  namespace: clawdbot
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: openclaw-toggle-operator
subjects:
  - kind: ServiceAccount
    name: openclaw-toggle-operator
    namespace: clawdbot

Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: openclaw-toggle-operator
  namespace: clawdbot
spec:
  replicas: 1
  selector:
    matchLabels:
      app: openclaw-toggle-operator
  template:
    metadata:
      labels:
        app: openclaw-toggle-operator
    spec:
      serviceAccountName: openclaw-toggle-operator
      containers:
        - name: operator
          image: xomoxcc/openclaw-k8s-toggle-operator:latest
          env:
            - name: MATRIX_USER
              value: "clawdbot-operator"
            - name: MATRIX_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: openclaw-toggle-operator
                  key: matrix-password
            - name: ALLOWED_USERS
              value: "@henning:matrix.example.com,@openclaw:matrix.example.com"
            # - name: MATRIX_HOMESERVER
            #   value: "http://synapse.matrix.svc.cluster.local:8008"  # default
            # - name: DEPLOYMENT_NAME
            #   value: "clawdbot"                                      # default
            # - name: DEPLOYMENT_NAMESPACE
            #   value: "clawdbot"                                      # default
            # - name: CRYPTO_STORE_PATH
            #   value: "/data/crypto_store"                            # default
            # - name: ECHO_MODE
            #   value: "true"                                          # default
          volumeMounts:
            - name: crypto-store
              mountPath: /data/crypto_store
          resources:
            requests:
              cpu: 50m
              memory: 64Mi
            limits:
              cpu: 500m
              memory: 128Mi
      volumes:
        - name: crypto-store
          persistentVolumeClaim:
            claimName: openclaw-toggle-operator-crypto

Installation

From PyPI

pip install openclaw-k8s-toggle-operator

From source

git clone https://github.com/vroomfondel/openclaw-k8s-toggle-operator.git
cd openclaw-k8s-toggle-operator
make venv
source .venv/bin/activate
pip install .

Docker

docker build -t openclaw-k8s-toggle-operator .

Or via Makefile:

make docker

Multi-arch build script

build-container-multiarch.sh builds and pushes multi-arch images (amd64 + arm64).

./build-container-multiarch.sh              # login + full multi-arch build & push
./build-container-multiarch.sh onlylocal    # login + local-only build (no push)
./build-container-multiarch.sh login        # Docker Hub login only

Usage

# Run directly
openclaw-k8s-toggle-operator

# Or via Python module
python -m openclaw_k8s_toggle_operator

Connectivity test

Test Matrix homeserver connectivity without starting the full operator (useful as a pre-flight check or container readiness probe):

# Via console script (after pip install)
openclaw-k8s-toggle-operator-conntest

# Via Python module
python -m openclaw_k8s_toggle_operator conntest

Exits 0 on successful login, 1 on failure. Only tests Matrix — does not require in-cluster K8s access.

Scripts

repo_scripts/blurimage.py — OCR-based screenshot redaction

Blurs sensitive text in terminal/K9s screenshots using Tesseract OCR. Designed for redacting secrets, usernames, session IDs, device IDs, and other sensitive information before sharing screenshots.

Features:

• Multi-pass OCR with three preprocessing strategies (weighted grayscale, max-channel, blue-channel) to handle colored terminal text on dark backgrounds
• OTSU thresholding for clean black/white separation instead of naive inversion
• Upscaling (default 2x) for better recognition of small monospaced fonts
• Two-level matching: word-level (single tokens) and line-level (multi-word patterns), with targeted blurring that only redacts the matched words, not entire lines
• Literal and regex patterns: --blur for case-insensitive literal phrases, --blur-regex for case-sensitive regex patterns

Dependencies: tesseract-ocr (system), pytesseract + opencv-python (auto-installed)

Usage:

# Blur usernames, domain, client secret, session IDs, and device IDs
python repo_scripts/blurimage.py \
  --blur matrixadmin henning elasticc.io \
  --blur-regex "rVFe\S+" "session id \S+" "[A-Z]{8,}" \

# Debug mode — show what Tesseract detects
python repo_scripts/blurimage.py --debug --blur myuser screenshot.png

# Skip inversion for light-background images
python repo_scripts/blurimage.py --no-invert --blur myuser screenshot.png

# Higher upscaling for very small text (slower)
python repo_scripts/blurimage.py --scale 3 --blur myuser screenshot.png

Pattern types:

Argument	Case sensitivity	Description
--blur	case-insensitive	Literal phrases, auto-escaped for regex safety
--blur-regex	case-sensitive	Raw regex patterns (add (?i) in pattern for case-insensitive)
(hardcoded)	case-insensitive	PXL*, *.png, *.jpg, *.mp4, *.json filenames

See the module docstring in repo_scripts/blurimage.py for a detailed explanation of the preprocessing pipeline, multi-pass OCR strategy, and two-level matching approach.

---

Development

Makefile targets

Target	Description
make venv	Create virtualenv and install all dependencies
make tests	Run pytest
make lint	Format code with black (line length 120)
make isort	Sort imports with isort
make tcheck	Static type checking with mypy
make commit-checks	Run pre-commit hooks on all files
make prepare	Run tests + commit-checks
make pypibuild	Build sdist + wheel with hatch
make pypipush	Publish to PyPI with hatch
make docker	Build Docker image

License

This project is licensed under the LGPL where applicable/possible — see LICENSE.md. Some files/parts may use other licenses: MIT | GPL | LGPL. Always check per‑file headers/comments.

Authors

• Repo owner (primary author)
• Additional attributions are noted inline in code comments

Acknowledgments

• Inspirations and snippets are referenced in code comments where appropriate.

⚠️ Note

This is a development/experimental project. For production use, review security settings, customize configurations, and test thoroughly in your environment. Provided "as is" without warranty of any kind, express or implied, including but not limited to the warranties of merchantability, fitness for a particular purpose and noninfringement. In no event shall the authors or copyright holders be liable for any claim, damages or other liability, whether in an action of contract, tort or otherwise, arising from, out of or in connection with the software or the use or other dealings in the software. Use at your own risk.
