Physical AI Studio Backend

FastAPI server for demonstration data management and VLA model training orchestration.

Overview

The backend provides RESTful APIs and services for:

• Camera Management - Configure and stream from multiple camera sources (RealSense, USB, GenICam)
• Dataset Management - Store and organize demonstration recordings
• Training Orchestration - Launch and monitor policy training jobs
• Model Management - Track trained models and export configurations
• WebRTC Streaming - Real-time video streaming for data collection

Architecture

backend/src/
├── api/          # FastAPI route handlers
├── core/         # Business logic and domain models
├── db/           # Database models and migrations (SQLAlchemy + Alembic)
├── repositories/ # Data access layer
├── schemas/      # Pydantic request/response schemas
├── services/     # Business logic services
├── utils/        # Shared utilities
├── webrtc/       # WebRTC signaling and streaming
└── workers/      # Background task workers

Setup

Prerequisites

• Python 3.12+
• uv package manager

Install Dependencies

Choose the torch variant that matches your hardware:

cd application/backend

# Choose one matching your hardware:
uv sync --extra cpu     # CPU only
# uv sync --extra cuda  # NVIDIA GPU (CUDA)
# uv sync --extra xpu   # Intel GPU (XPU)

This installs all backend dependencies including FastAPI, SQLAlchemy, aiortc, and the physicalai library.

(Optional) Enable hardware acceleration for video encoding

Using hardware acceleration for video encoding can improve the speed of recording significantly. Please check out this document for more information.

Usage

Start Server

# Activate virtual environment
source .venv/bin/activate

# Run server (backend with in-process training; local by default)
uv run physicalai-studio serve

# Equivalent thin wrapper
./run.sh

Server starts at http://localhost:7860 by default.

To change the host/port:

# Option A: CLI flags
uv run physicalai-studio serve --host 127.0.0.1 --port 8000

# Option B: environment variables
HOST=127.0.0.1
PORT=8000

Remote Training

The serve process supports local and remote training at the same time. Configure remote trainer URLs in the Studio UI, then choose the execution target when you submit a training job. run.sh is a thin wrapper around the CLI.

To run training on a separate, GPU-enabled machine, deploy and configure a Physical AI Trainer service from docs/remote-trainer.md, then register its URL as a remote trainer in the Studio UI. The backend sends dataset snapshots to the service, monitors the training job, and imports the resulting model.

Alternatively, the backend can provision a job-scoped trainer over SSH on a server you can reach directly. This feature is off by default and has no authentication model of its own — see docs/explanation/ssh-remote-trainer.md before enabling it.

Database Migrations

# Create new migration
uv run alembic revision --autogenerate -m "description"

# Apply migrations
uv run alembic upgrade head

# Rollback migration
uv run alembic downgrade -1

CLI Commands

# Initialize database
uv run physicalai-studio db init

# Run migrations
uv run physicalai-studio db migrate

API Documentation

Once the server is running:

• Interactive API Docs - http://localhost:7860/docs (Swagger UI)
• Alternative Docs - http://localhost:7860/redoc (ReDoc)
• OpenAPI Schema - http://localhost:7860/api/openapi.json

Configuration

Configuration via environment variables (see src/settings.py):

Variable	Description	Default
STORAGE_DIR	Root directory for persistent artifacts (datasets/, models/, snapshots/, robots/, cache/, logs/)	Linux: ${XDG_DATA_HOME:-~/.local/share}/physicalai; macOS: ~/Library/Application Support/physicalai

Create .env file in backend directory for local overrides.

Development

Code Quality

# Format code
uv run ruff format .

# Lint code
uv run ruff check .

# Type check
uv run mypy src/

# Type check (Pyrefly)
uv run pyrefly check -c pyproject.toml

Project Structure

• API Layer (api/) - HTTP endpoints, request validation
• Service Layer (services/) - Business logic, orchestration
• Repository Layer (repositories/) - Database queries
• Core (core/) - Domain models and pure business logic
• Schemas (schemas/) - Input/output data validation

Adding New Endpoints

1. Define Pydantic schemas in schemas/
2. Create repository methods in repositories/
3. Implement service logic in services/
4. Add route handlers in api/
5. Register routes in main.py

Troubleshooting

Data/Storage Migration Behavior

On startup (./run.sh), the backend runs migration checks before Alembic:

• Storage migration: old ~/.cache/physicalai -> STORAGE_DIR
• Database migration: old data/physicalai.db, Docker legacy /app/data/physicalai.db, or a legacy $DATA_DIR/physicalai.db -> $STORAGE_DIR/data/physicalai.db

In interactive terminals, users are prompted for confirmation when a migration is needed.

Camera Not Detected

• RealSense: Install librealsense
• GenICam: Install vendor-specific SDKs
• USB: Check permissions (sudo usermod -a -G video $USER)

See Also

• Application Overview - Full application architecture
• UI - React frontend
• Library - Python SDK for training
