pikobrowser 0.2.27

Piko browser.

Piko

Overview

Piko is a terminal-based interactive internet browser that works with a lightweight XML file format. It provides a simple, text-based interface for browsing content and interacting with web applications.

Using the Browser

Installation

Install using this command:

pip3 install pikobrowser

Uninstall with:

pip3 uninstall pikobrowser

Starting the Browser

Start using this command:

piko

Or manually:

python3 -m pikobrowser

File Format

XML Format (.xml)

XML-based format for structured content definition.

File Structure

<piko type="m100_xml" background="black" foreground="white">
  <container direction="row" width="100pc">
    <text align="center">Hello World</text>
  </container>
  <action name="search">
    visit("http://localhost:3000/search?q=" + encode(value))
  </action>
</piko>

XML Elements

Root Element:

• <piko> - Root element with type and color attributes

Container Elements:

• <container> - Layout container
• <table> - Table layout
• <row> - Table row
• <cell> - Table cell

Content Elements:

• <text> - Text content
• <link> - Navigation link
• <input> - Input field
• <br> - Line break

Action Elements:

• <action> - Script action with name and code

Attributes

Container Attributes:

• width - Element width (pixels or percentage with pc)
• height - Element height
• border - Border style (line, dotted thin, dotted thick)
• direction - Layout direction (row, column)
• padding - Padding values
• background - Background color
• foreground - Text color

Text Attributes:

• align - Text alignment (left, center, right)
• style - Text styling
• font - Custom font
• preserve - Preserve whitespace (true/false)

Link Attributes:

• key - Keyboard shortcut (required)
• url - Target URL (required)
• width - Link width
• background - Background color
• foreground - Text color

Input Attributes:

• submit - Action to call on submit
• change - Action to call on value change (as user types)
• initial - Initial value
• width - Input width
• icon - Icon character
• autofocus - Auto-focus behavior
• mask - Character to mask the input value (e.g., "*" for password fields)
• lines - Number of lines for multi-line input (default: 1 for single line)

Actions

Actions provide interactivity through JavaScript-like code:

<action name="search">
    visit("http://example.com?q=" + encode(value))
</action>

Built-in Functions:

• visit(url) - Navigate to URL
• encode(text) - URL encode text
• var(name, value) - Set variable
• getvar(name) - Get variable
• action(name) - Call action
• debug(text) - Debug output
• geturlparam(param) - Extract URL parameter from current URL
• setvalue(id, text) - Set the value of an input element by ID

Navigation

• Number Keys - Activate numbered links (e.g., press 1 for [1] Link Name)
• Tab - Cycle through focusable input fields
• Escape - Toggle URL bar focus (press twice to change URL)
• Enter - Submit input fields or activate links
• Arrow Keys - Navigate and scroll
• Alt+Q - Unfocus from input fields

URL Bar

• Press Escape to focus on the URL bar or lose focus on an input
• Type a URL and press Enter to navigate

Debug Mode

• Press Alt+K to toggle debug mode
• Debug output appears at the bottom of the screen
• Use debug() function in actions for custom debug output

URL Protocols

Supported Protocols

1. piko:// - Local piko files in the browser's local directory
2. file:// - Local files on the system
3. http:// - HTTP requests
4. https:// - HTTPS requests

Request Headers

Piko browser sends requests with Content-Type: Piko header for server identification.

Scripting System

Action Execution

Actions are executed using JavaScript-like syntax with custom functions:

<action name="submit_form">
    var("user_input", value)
    visit("http://example.com/submit?data=" + encode(value))
</action>

Variable System

• Global variables - Stored in browser context
• Action variables - Passed to action execution
• Element values - Accessible through action context

Action Context

When an action is triggered, the following variables are available:

• value - The value from the triggering element (e.g., input field content)
• visit(url) - Function to navigate to a URL
• encode(text) - Function to URL encode text
• var(name, value) - Function to set a global variable
• getvar(name) - Function to get a global variable
• action(name) - Function to call another action
• debug(text) - Function to output debug text

Input Events

Input elements support two types of events:

Submit Event (submit):

• Triggered when the user presses Enter on an input field
• Typically used for form submission or final actions
• Example: Submitting a form, navigating to a URL

Change Event (change):

• Triggered every time the user types a character in an input field
• Useful for real-time variable updates as the user types
• Example: Storing form values in browser context for later use

Combined Usage: You can use both events on the same input field for different purposes:

<input submit="submit_form" change="store_value" initial="" width="50pc"/>
<action name="store_value">
    var("user_input", value)
</action>
<action name="submit_form">
    visit("http://example.com/submit?data=" + encode(getvar("user_input")))
</action>

Multi-line Input Navigation: For input fields with lines > 1, additional navigation controls are available:

• Arrow Keys - Navigate within the current line (left/right) or between lines (up/down)
• Enter - Insert a new line (instead of submitting the form)
• Backspace - Delete characters or merge lines when deleting newlines
• Tab - Move to the next focusable element
• Escape - Unfocus from the input field

Multi-line inputs maintain the same submit and change events as single-line inputs, with the entire multi-line content passed as the value.

URL Parameter Extraction: Use geturlparam() to extract parameters from the current URL:

<action name="[start]">
    var("token", geturlparam("token"))
    var("user_id", geturlparam("user_id"))
</action>

Layout System

Responsive Design

• Percentage-based sizing - Elements can use pc units for responsive design
• Flexible containers - Containers can arrange children in rows or columns
• Padding and borders - Support for spacing and visual separation
• Text wrapping - Automatic text wrapping with width constraints

Styling

Colors:

• black, white, blue, red, green, yellow, magenta, cyan

Text Styles:

• bold, underline, normal

Borders:

• line - Single line border
• dotted thin - Thin dotted border
• dotted thick - Thick dotted border

Development Guidelines

Creating Piko Files

1. Start with piko root element - Include type and color attributes
2. Use containers for layout - Organize content with containers
3. Add interactive elements - Include links and input fields
4. Define actions for behavior - Create actions for user interactions
5. Test navigation and input - Verify all interactions work correctly

Best Practices

• Use percentage-based sizing for responsiveness
• Provide keyboard shortcuts for all links
• Include error handling in actions
• Use comments for documentation
• Test on different terminal sizes

Debugging

• Enable debug mode with Alt+K
• Use debug() function in actions
• Check terminal output for errors
• Verify URL loading and parsing

Examples

Simple Page

<piko type="m100_xml" background="black" foreground="white">
  <container direction="column" width="100pc">
    <text align="center" style="bold">Welcome to Piko Browser</text>
    <br/>
    <link key="1" url="piko://help" background="cyan" foreground="black">Help</link>
    <link key="2" url="piko://settings" background="cyan" foreground="black">Settings</link>
  </container>
</piko>

Interactive Form

<piko type="m100_xml">
  <container direction="column" width="100pc">
    <text>Enter your name:</text>
    <input submit="greet" change="store_name" initial="" width="50pc"/>
    <action name="store_name">
      var("user_name", value)
    </action>
    <action name="greet">
      visit("piko://welcome?name=" + encode(getvar("user_name")))
    </action>
  </container>
</piko>

Login Form with Password Masking

<piko type="m100_xml" background="black" foreground="white">
  <container direction="column" width="100pc" padding-top="3">
    <text align="center" style="bold">Login</text>
    <br/>
    <text>Username:</text>
    <input submit="do_login" change="set_username" initial="" width="50pc"/>
    <br/>
    <text>Password:</text>
    <input mask="*" submit="do_login" initial="" width="50pc"/>
    <action name="set_username">
      var("username", value)
    </action>
    <action name="do_login">
      visit("http://localhost:3000/auth/login?username=" + encode(getvar("username")) + "&amp;password=" + encode(value))
    </action>
  </container>
</piko>

Multi-line Text Editor

<piko type="m100_xml" background="black" foreground="white">
  <container direction="column" width="100pc" padding-top="3">
    <text align="center" style="bold">Text Editor</text>
    <br/>
    <text>Title:</text>
    <input submit="save_document" change="store_title" initial="" width="80pc"/>
    <br/>
    <text>Content:</text>
    <input lines="10" submit="save_document" change="store_content" initial="" width="80pc"/>
    <action name="store_title">
      var("title", value)
    </action>
    <action name="store_content">
      var("content", value)
    </action>
    <action name="save_document">
      visit("http://localhost:3000/save?title=" + encode(getvar("title")) + "&amp;content=" + encode(getvar("content")))
    </action>
  </container>
</piko>

Table Layout

<piko type="m100_xml">
  <table border="dotted thick">
    <row>
      <cell>
        <text>Header 1</text>
      </cell>
      <cell>
        <text>Header 2</text>
      </cell>
    </row>
    <row>
      <cell>
        <text>Data 1</text>
      </cell>
      <cell>
        <text>Data 2</text>
      </cell>
    </row>
  </table>
</piko>
