prefect-slurm 0.1.1

Prefect worker for running flows on a Slurm HPC cluster

Prefect-Slurm

A Prefect worker for running flows on Slurm HPC clusters

Execute your Prefect flows on high-performance computing clusters using the Slurm workload manager. This worker seamlessly integrates with Slurm's REST API to submit, monitor, and manage flow runs as Slurm jobs.

Features

✨ Automatic API Version Detection - Supports Slurm REST API versions 0.0.40-0.0.42 with automatic detection
🔒 Secure Token Management - JWT-based authentication with file locking and proper permissions
🔄 Zombie Job Recovery - Automatically detects and handles orphaned flow runs after worker restarts
📊 Resource Management - Full Slurm job specification support for CPU, memory, and time limits
🛠️ CLI Tools - Built-in utilities for token management and worker administration
🧪 Comprehensive Testing - Both unit and integration tests

Quick Start

Installation

pip install prefect-slurm

Basic Setup

1. Create a work pool using the Slurm worker type:

   prefect work-pool create slurm-pool --type slurm


2. Configure authentication - Set up your Slurm credentials:

   export PREFECT_SLURM_USER_NAME=your_username
   export PREFECT_SLURM_API_URL=http://your-slurm-server:6820


3. Set up authentication token:

   # Generate and store token using built-in CLI
   scontrol token username=$USER lifespan=3600 | prefect-slurm token

   # Or set token directly via environment variable
   export PREFECT_SLURM_USER_TOKEN=your_jwt_token


4. Start the worker:

   prefect worker start --pool slurm-pool --type slurm


Configuration

Environment Variables

Variable	Description	Default
PREFECT_SLURM_USER_NAME	Slurm username	Required
PREFECT_SLURM_API_URL	Slurm REST API URL	Required
PREFECT_SLURM_USER_TOKEN	JWT authentication token	Optional
PREFECT_SLURM_TOKEN_FILE	Path to token file	~/.prefect_slurm.jwt
PREFECT_SLURM_LOCK_TIMEOUT	File lock timeout (seconds)	60
PREFECT_SLURM_ENV_FILE	Override environment file path	Optional

Environment Files

The worker supports loading configuration from environment files using a hierarchical discovery system. Files are loaded in priority order (later files override earlier ones):

1. System-wide: /etc/prefect-slurm/.env
2. XDG Config: ~/.config/prefect-slurm/.env (or $XDG_CONFIG_HOME/prefect-slurm/.env)
3. User Home: ~/.prefect_slurm.env
4. Current Directory (app-specific): ./.prefect_slurm.env
5. Current Directory: ./.env
6. Environment Variable Override: $PREFECT_SLURM_ENV_FILE

Example environment file (.prefect_slurm.env):

# Slurm connection settings
PREFECT_SLURM_USER_NAME=your_username
PREFECT_SLURM_API_URL=http://your-slurm-server:6820

# Optional token (alternative to token file)
PREFECT_SLURM_USER_TOKEN=your_jwt_token_here

# Optional custom token file location
PREFECT_SLURM_TOKEN_FILE=~/my_custom_token.jwt

# Optional custom lock timeout
PREFECT_SLURM_LOCK_TIMEOUT=120

You can override the automatic discovery by setting PREFECT_SLURM_ENV_FILE to point to a specific file:

export PREFECT_SLURM_ENV_FILE=/path/to/my/custom.env
prefect worker start --pool slurm-pool --type slurm

Note: CLI commands (prefect-slurm token) also support environment files, though only PREFECT_SLURM_TOKEN_FILE and PREFECT_SLURM_LOCK_TIMEOUT are relevant for CLI operations.

Work Pool Configuration

Configure your Slurm work pool with job specifications:

job_configuration:
  partition: "compute"
  cpu: 4
  memory: 8
  time_limit: 2
  working_dir: "/path/to/working/directory"
  source_files:  # Optional - omit for default Python environment
    - "~/.bashrc"
    - "~/envs/conda/bin/activate"

Environment Setup

The worker supports two environment configuration modes:

Custom Environment (when source_files are specified):

job_configuration:
  source_files:
    - "~/.bashrc"
    - "/opt/conda/bin/activate"
    - "/opt/modules/init.sh"

The worker will source these files before executing your flow. Use this for conda environments, module systems, or custom shell configurations.

Default Python Environment (when source_files is empty or omitted):

job_configuration:
  partition: "compute"
  cpu: 4
  memory: 8

The worker automatically creates a temporary Python virtual environment with the matching Prefect version installed. The environment is created in $TMPDIR/.venv_$SLURM_JOB_ID and cleaned up after job completion.

CLI Tools

The package includes a command-line utility for token management:

# Store token from scontrol output at default location
scontrol token username=$USER lifespan=3600 | prefect-slurm token

# Store token to custom location
echo "jwt_token_here" | prefect-slurm token ~/my_token.jwt

# Get help
prefect-slurm token --help

The default location for the token is ~/.prefect_slurm.jwt (can be overridden by setting PREFECT_SLURM_TOKEN_FILE) and default permissions are 600 (read/write allowed for user only)

Running the Examples

You can test the examples in the examples/ directory using the local Docker Compose Slurm cluster:

1. Start the local cluster:

   cd slurm_environment/
   docker-compose up -d


2. Wait for services to be healthy (check with docker-compose ps)

3. Deploy and run example flows (from the prefect_server container):

   # Enter the Prefect server container
   docker-compose exec prefect_server bash

   # Navigate to examples and deploy the hello world example interactively
   cd /opt/data/examples
   prefect deploy

   # Run the deployment
   prefect deployment run slurm-hello-world/slurm-hello-world-deployment


4. Monitor execution:

   • Prefect UI: http://localhost:4200
   • Check Slurm jobs (from slurm_node container): docker-compose exec slurm_node squeue
   • View worker logs: docker-compose logs slurm_submitter

The Docker environment provides a complete Slurm cluster with the worker automatically configured and example flows ready to deploy.

Architecture

The Slurm worker integrates with Prefect's execution model:

1. Worker Polling - Continuously polls Prefect API for scheduled flow runs
2. Job Submission - Converts flow runs to Slurm job specifications
3. Execution - Submits jobs via Slurm REST API with proper resource allocation
4. Monitoring - Tracks job status and reports back to Prefect
5. Cleanup - Handles zombie jobs and ensures proper flow run state management

graph TB
    A[Prefect Server] -->|polls for flows| B[Slurm Worker]
    B -->|submits jobs| C[Slurm REST API]
    C -->|schedules| D[Slurm Cluster]
    D -->|executes| E[Flow Run]
    E -->|reports status| B
    B -->|updates state| A

Requirements

• Python: 3.11+ (< 3.14)
• Prefect: 3.4.13+
• Slurm: Cluster with REST API enabled (versions 0.0.40-0.0.42 supported)
• Network: Access from worker node to both Prefect API and Slurm REST API

Development

Running Tests

# Unit tests only
pytest -m unit

# Integration tests (requires Docker)
pytest -m integration

# CLI tests
pytest -m cli

# All tests
pytest

Test Environment

The project includes Docker-based Slurm cluster for integration testing:

cd slurm_environment/
docker-compose up -d

Contributing

Contributions are welcome! This project is developed by the EBI Metagenomics team.

Development Workflow

1. Fork the repository
2. Create a feature branch
3. Make your changes with tests
4. Run the full test suite
5. Submit a pull request

License

Licensed under the Apache License 2.0. See LICENSE for details.

Support

• Issues: Report bugs and request features via GitHub Issues
• Documentation: See tests/README.md for detailed testing information
