pydecay
Radioactive decay mathematics for Python — analytical single-isotope decay, Bateman chains with a matrix-exponential stability guard, branching topologies, multi-nuclide inventories with automatic progeny ingrowth, ICRP-107 nuclide data (1252 radionuclides + 246 stable endpoints = 1498 records), radiation spectra, and activity unit conversions.
Author: Daniel Deshmukh · github.com/DanielDeshmukh/pydecay · Demo
Table of contents
Install
pip install pydecay
Requires Python ≥ 3.10. Runtime dependencies: numpy, scipy, pint.
import pydecay
print(pydecay.__version__) # "0.6.0"
Quickstart
from pydecay import Nuclide, DecayChain, Inventory, decayed_activity, remaining_fraction
# Single isotope: 1000 Bq of I-131 after one half-life -> 500 Bq
i131 = Nuclide.load("I-131")
a = decayed_activity(A0=1000.0, half_life=i131.half_life, time=i131.half_life)
# Dimensionless fraction after 5 half-lives -> 0.03125
f = remaining_fraction(half_life=i131.half_life, time=5 * i131.half_life)
# Linear chain (parent -> daughter -> stable), plain floats or pint
chain = DecayChain([0.693, 0.0], names=["parent", "stable"])
print(chain.at(t="1 days", n0={"parent": 1e6, "stable": 0.0}))
# Branching: 60% / 30% to two daughters, remainder untracked
b = DecayChain.branching(
parent="P",
branches={"D1": 0.6, "D2": 0.3},
lambdas={"P": 0.7, "D1": 1e-5, "D2": 2e-5},
)
# Multi-nuclide inventory: seeds only; daughters (Tc-99m, Tc-99, ...) auto-close
inv = Inventory({"Mo-99": 1e6}, units="Bq")
print(inv.decay("8.02 days").activities())
Feature distribution
| Area | Detail | Reference |
|---|---|---|
| Single isotope | N(t)=N0·e^(−λt), λ=ln2/T½, A=λN |
Krane ch. 6; BIPM/NIST |
| Linear chains | Bateman (1910) closed form when well-separated | Bateman 1910 |
| Stability guard | scipy.linalg.expm on the generator matrix for degenerate λ, branching, or nonzero daughter ICs |
Cetnar 2006 |
| Branching | Star topologies with fractions ≤ 1 (remainder = untracked sink) | General linear ODE |
| Inventory | Multi-nuclide seeds with ICRP-107 progeny closure; immutable decay; cumulative decays; linear/log time series |
General linear ODE |
| Data | 1252 radionuclides + 246 stable endpoints = 1498 records | ICRP Publication 107 |
| Spectra | emissions / beta_spectrum (RAD/BET), lazy-loaded |
ICRP-107 RAD/BET |
| Units | seconds / atoms / Bq internally; Bq↔Ci and atoms↔grams at the boundary | NIST SP 811; BIPM SI (N_A exact) |
| Rates / ODE | dn_dt, da_dt, decay_ode_residual; Inventory.instantaneous_rates via G @ N |
dN/dt = −λN |
1. Single-isotope decay
Three “how much is left?” functions — activity, atoms, or a pure fraction:
from pydecay import decayed_activity, decayed_atoms, remaining_fraction
# 1000 Bq of I-131 after one half-life -> 500 Bq
decayed_activity(A0=1000.0, half_life="8.02 days", time="8.02 days") # 500.0
# 1e6 atoms after 24 hours
decayed_atoms(N0=1_000_000, half_life="8.02 days", time="24 hours")
# Dimensionless fraction after 5 half-lives -> 1/32 = 0.03125
remaining_fraction(half_life="8.02 days", time=5 * 8.02 * 86400) # 0.03125
- Inputs accept plain numbers (SI seconds), human strings (
"8.02 days"), or pint Quantities. - Output kind mirrors input: float in → float out; Quantity in → Quantity out.
timemust be finite and≥ 0(InvalidTimeErrorotherwise).
2. Nuclide lookup (ICRP-107)
from pydecay import Nuclide
i131 = Nuclide.load("I-131")
print(i131.half_life) # pint Quantity, e.g. 8.02 days (stored in seconds)
print(i131.half_life_s) # 692988.48
print(i131.lambda_) # decay constant (1/s)
print(i131.atomic_mass_u) # mass in u
print(i131.progeny) # ("Xe-131m", "Xe-131")
print(i131.branching) # matching branch fractions
print(i131.source) # "ICRP-107"
# Full catalog: 1252 ICRP-107 radionuclides + 246 stable endpoints = 1498 records
all_nuclides = Nuclide.load_all()
Stable endpoints report lambda_ = 0.0 and is_stable = True. Unknown names raise NuclideNotFoundError.
3. Multi-nuclide inventory
List seeds only — pydecay walks the ICRP-107 progeny graph and builds one joint decay system (daughters included, down to stable):
from pydecay import Inventory
inv = Inventory({"Mo-99": 1e6}, units="Bq") # pulls in Tc-99m, Tc-99, ...
print(inv.names) # full closure, graph order
print(inv.n_species)
after = inv.decay("8.02 days") # NEW inventory (immutable)
print(after.activities()) # dict species -> Bq
print(after.numbers()) # atom counts
print(after.masses()) # grams
print(inv.total_activity()) # sum of activities (Bq float)
# Cumulative decays on [0, t]
print(inv.cumulative_decays("1 day"))
# Time series for plotting (linear or log)
t_seconds, series = inv.decay_time_series("8 days", npoints=101)
t_log, series_log = inv.decay_time_series(
"1e6 seconds", npoints=200, time_scale="log", t_start=1.0
)
Constructor units: "Bq" (default), "Ci", "atoms", "g".
Kind (plain vs pint) is mirrored by all accessors and preserved across decay.
4. Decay chains
from pydecay import DecayChain
# From raw decay constants (1/s), parent first
chain = DecayChain([0.693, 0.0], names=["parent", "stable"])
print(chain.at(t="1 days", n0={"parent": 1e6, "stable": 0.0}))
print(chain.activity(t="1 days", n0={"parent": 1e6, "stable": 0.0}))
# From real nuclide names (bundled ICRP-107 half-lives)
chain = DecayChain.from_isotopes(["Sr-90", "Y-90"])
print(chain.at(t="1 day", n0={"Sr-90": 1e6, "Y-90": 0.0}))
Solver dispatch is internal: Bateman closed form when well-separated, falls
back to scipy.linalg.expm for degenerate λ or nonzero daughter ICs.
5. Branching topologies
from pydecay import DecayChain
b = DecayChain.branching(
parent="P",
branches={"D1": 0.6, "D2": 0.3}, # fractions; sum <= 1
lambdas={"P": 0.7, "D1": 1e-5, "D2": 2e-5},
)
print(b.at(t="1 day")) # atoms of P, D1, D2
print(b.activity(t="1 day")) # Bq of P, D1, D2
Fractions must sum to at most 1.0; the remainder is an untracked sink.
6. Radiation spectra
from pydecay import emissions, beta_spectrum
# RAD emission rows (lazy-loaded)
rows = emissions("Ac-223")
# each row: energy (MeV), probability, code, ...
# BET spectrum
energies, amplitudes = beta_spectrum("Sr-90")
# energies in MeV; amplitudes = relative intensity
Both functions lazy-load on first call — they do not slow down import pydecay.
7. Unit conversions
Top-level helpers (same names as pydecay.units / pydecay.decay):
from pydecay import (
to_seconds,
bq_to_ci,
ci_to_bq,
atoms_to_grams,
grams_to_atoms,
decay_constant,
mean_lifetime_s,
)
# Time parsing: str | Quantity | number -> seconds
to_seconds("8.02 days") # 692992.0
to_seconds(3600) # 3600.0
# Activity: Bq <-> Ci (exact factor 1 Ci = 3.7e10 Bq)
bq_to_ci(3.7e10) # 1.0
ci_to_bq(1.0) # 3.7e10
bq_to_ci(1000.0) # 2.7027...e-8
# Mass <-> atoms (N_A = 6.02214076e23 /mol, exact)
atoms_to_grams(6.02214076e23, 1.0) # ~1.0 g of hydrogen-1-like mass
grams_to_atoms(1.0, 238.0508) # atoms in 1 g of U-238
# Decay kernels
decay_constant(8.02 * 86400) # λ = ln2 / T½ (1/s)
mean_lifetime_s(decay_constant(8.02 * 86400)) # τ = 1 / λ (s)
| Conversion | Formula | Exact factor |
|---|---|---|
| Bq → Ci | bq / 3.7e10 |
1 Ci = 3.7 × 10¹⁰ Bq (exact) |
| Ci → Bq | ci * 3.7e10 |
same |
| atoms → g | n * m_u / N_A |
N_A = 6.02214076 × 10²³ mol⁻¹ (exact) |
| g → atoms | m * N_A / m_u |
same |
| time → s | unit table | year = 31557600 s (365.25 d) |
| λ | ln(2) / T½ |
— |
| τ | 1 / λ |
mean lifetime |
Internally pydecay works in seconds, atoms, and becquerels; these helpers are the boundary converters. Pint Quantities are accepted wherever a time or amount is expected — output kind mirrors input.
8. Instantaneous rates & ODE residual
from pydecay import dn_dt, da_dt, decay_ode_residual, Inventory
# dN/dt = -λN (atoms/s)
dn_dt(1e6, "8.02 days")
# dA/dt = -λ A(t) (Bq/s)
da_dt(1000.0, "8.02 days", 0.0)
# Residual dN/dt + λN — 0 on an exact analytic trajectory
decay_ode_residual(1e6, 8.02 * 86400) # 0.0
# Multi-nuclide: joint generator rates for the full closure
inv = Inventory({"Mo-99": 1e6}, units="Bq")
inv.instantaneous_rates() # dict species -> atoms/s
9. Error handling
All package-raised errors inherit from PyDecayError:
| Exception | When |
|---|---|
NuclideNotFoundError |
Typo in nuclide name: Nuclide.load("Xx-999") |
InvalidTimeError |
Negative or infinite time; log-series bounds ≤ 0 |
InvalidHalfLifeError |
Half-life ≤ 0 or NaN in free decay helpers |
ChainDefinitionError |
Bad chain, empty/duplicate seeds, progeny cycle |
DataFormatError |
Broken data record, or spectra on a stable nuclide |
UnitError |
Bad unit string, or string on N0 / A0 / Inventory amount |
DoseDataError |
Dose rate for a nuclide with no bundled photon coefficients |
MaterialError |
Unknown shielding material or energy outside the NIST table span |
PyDecayError |
Base class — catch this to catch everything above |
from pydecay import Nuclide, NuclideNotFoundError, PyDecayError
try:
n = Nuclide.load("Xx-999")
except NuclideNotFoundError:
print("No such nuclide — check the spelling (e.g. I-131, Co-60).")
try:
...
except PyDecayError as e:
print("pydecay said:", e)
10. Dose rates & shielding
- Point-source exposure, air-kerma, and ambient H*(10) dose rates from
curated per-nuclide coefficients (31 Risø-M-2322 rows + 3 ICRP-107
fallbacks;
DoseDataErrorfor the six photon-free nuclides). Inventory.dose_rate()sums over the progeny closure and mirrors pint inputs at the edge (r="1 m"in,Quantityout).- Narrow-beam shielding:
mu,hvl/tvl(by material ormu),transmit_slab,multilayer_transmit- NIST XCOM tables bundled for seven materials (0.01-20 MeV); buildup factors reserved for v0.7.
from pydecay import dose_rate, hvl_slab, transmit_slab
dose_rate(1e6, "Co-60", r_m=1.0) # 3.07e-7 Gy/h
hvl_slab("lead", 1.25) # 0.0104 m
transmit_slab(1.0, "lead", 0.01, 1.25) # 0.513
Verification
- Worked examples (1000 Bq I-131 → 500 Bq / 31.25 Bq) asserted against the
bundled ICRP-107 half-lives in
tests/test_known_values.py. - Bateman vs
expmagreement to 1e-10; degenerate-lambda regression (0.6931 / 0.6932) must stay finite (tests/test_solver.py). - Differential cross-check against
radioactivedecay(ICRP-107): report drift, fail past 1e-3 relative (tests/test_crosscheck.py). - IAEA 47-nuclide fixture retained as a differential oracle
(
tests/test_iaea_differential.py,REL_TOL_DATA = 1.5e-2). - Hypothesis property invariants for decay laws, chains, and
Inventory. - CI coverage floor
--cov-fail-under=90.
Documentation
| Page | Contents |
|---|---|
docs/index.md |
Full guide (MkDocs: mkdocs serve) |
docs/user-guide.md |
Plain-language tour of every public function |
docs/api.md |
Complete API reference with signatures |
docs/architecture.md |
Solver dispatch diagrams |
docs/math.md |
Formula derivations with citations |
docs/units.md |
Bq ↔ Ci, atoms ↔ grams, time parsing |
docs/dose.md |
Dose-rate conventions, citations, provenance table |
docs/shielding.md |
HVL/TVL, Beer-Lambert, material tables |
docs/cookbook.md |
10 exec-tested recipes (outputs verified by tests) |
docs/data-sources.md |
ICRP-107 provenance |
CHANGELOG.md |
Keep a Changelog history |
One-line summary: decayed_activity / decayed_atoms / remaining_fraction
answer “how much is left?” · Nuclide.load looks up real half-lives (1252
ICRP-107 radionuclides + 246 stable endpoints = 1498 records) · Inventory
tracks a seed mix and every daughter that grows in · DecayChain follows
parents and daughters through time · emissions / beta_spectrum give
radiation spectra · unit helpers convert Bq↔Ci, atoms↔grams, and parse times
to seconds.
Tutorials
Four executable notebooks in notebooks/ walk the public API
end to end; each cites its sources, ends with a tagged answer exercise
cell, and prints golden values asserted against
tests/golden/golden_values.json (executed on every test run):
| Notebook | Topic |
|---|---|
01_decay_basics.ipynb |
Exponential decay, half-lives, unit conversions, decay curve |
02_inventory_chains.ipynb |
Bateman chains, branching, mixed inventories |
03_dose_rates.ipynb |
Point-source kerma/ambient dose rates, inverse-square law |
04_shielding_design.ipynb |
HVL/TVL sizing, Beer-Lambert, multilayer slabs |
pip install "pydecay[tutorials]"
jupyter lab notebooks/
Development
See CONTRIBUTING.md.
Quality gates (CI):
pytest --cov-fail-under=90
ruff check src tests
mypy src
mkdocs build --strict
Frontend demo (landingpage/):
npm ci
npm run lint # prettier + typecheck + vitest + build
License
MIT — see LICENSE.
Bundled ICRP-107 data is under
src/pydecay/data/LICENSE.ICRP-07
(educational / research / not-for-profit terms).
Metadata
Release files for pydecay 0.6.1
For a detailed explanation of source distributions (sdists) and built distributions (wheels), please see the package formats documentation.
Source distribution (sdist)
| File | Size | Uploaded | Provenance | Actions |
|---|---|---|---|---|
| pydecay-0.6.1.tar.gz | 5.4 MB | Without provenance | Details for pydecay-0.6.1.tar.gz |
Built distribution (wheel)
| File | Interpreter | ABI | Platform | Actions Reset |
|---|---|---|---|---|
| pydecay-0.6.1-py3-none-any.whl | Python 3 | none | any | Details for pydecay-0.6.1-py3-none-any.whl |
Total release size: 9.7 MB
Release files / pydecay-0.6.1.tar.gz
| Download URL | pydecay-0.6.1.tar.gz |
|---|---|
| Size | 5.4 MB |
| Tags | Source |
|
SHA-256 checksum How to use checksums |
9ff556b57286322d3901bc65eb52644b922cbb925a9cc97064ff60aac20e1290
|
|
BLAKE2b-256 checksum How to use checksums |
3b2ebb63582dfd397cc165bffbf8dd31debbf63bfa65ea9e7bc04795c30dd16a
|
| Upload date | |
|
Uploaded using Trusted Publishing? What is trusted publishing? |
No |
| Uploaded via |
twine/7.0.0 CPython/3.13.14
|
Release files / pydecay-0.6.1-py3-none-any.whl
| Download URL | pydecay-0.6.1-py3-none-any.whl |
|---|---|
| Size | 4.3 MB |
| Tags | Python 3 |
|
SHA-256 checksum How to use checksums |
9d9823fff7be1201c6fc5bae94e9da5a775450d55cb67f48eed60faccc136e8d
|
|
BLAKE2b-256 checksum How to use checksums |
01bcf23c3fbfa77614a43d2797c762133679c043f2e35156a4a0b5265ddcf5d6
|
| Upload date | |
|
Uploaded using Trusted Publishing? What is trusted publishing? |
No |
| Uploaded via |
twine/7.0.0 CPython/3.13.14
|
Security for pydecay 0.6.1
Provenance
Provenance describes where a file came from. On PyPI, provenance is shared via attestations, which provide a verifiable record of the build or publishing details. View details, limitations and caveats.
No provenance found
None of the files in this release were uploaded with provenance metadata.
A note on package security
PyPI is a repository for distributing packages, not a service for auditing them. While third-party security researchers and our staff do their best to detect and remove malicious packages, PyPI cannot guarantee the quality, security or suitability of any given package.
To learn more about protecting yourself from malicious actors, visit our package security documentation.
