PyMobile

Build real Android apps in pure Python.

Write a declarative UI, run one command, install the APK on your phone.

PyPI Python Status License

PyMobile demo: from pip install to a native Android app

⚠️ Alpha software — known bugs, actively being fixed

PyMobile is at 0.10.x and is still in alpha. It builds and signs real, installable APKs today, but the API can change between minor releases and there are known bugs. I am actively working on them: fixes ship in every release — see the changelog for what has already landed and Issues for what is still open.

Good fit for personal apps, internal tools, prototypes and learning. If you depend on it, pin an exact version (pymobile-framework==0.10.2) and read the changelog before upgrading. What may change, and how much notice you get, is written down in the versioning and deprecation policy. Bug reports are genuinely welcome.

from pymobile import App, Button, Column, Label, Screen, Widget


class Home(Screen):
    title = "Hello"

    def __init__(self) -> None:
        super().__init__()
        self.taps = 0

    def build(self) -> Widget:
        self.counter = Label("Taps: 0")
        return Column(
            Label("Hello, Android!"),
            self.counter,
            Button("Tap me", on_press=self.on_tap),
            spacing=12,
        )

    def on_tap(self) -> None:
        self.taps += 1
        self.counter.text = f"Taps: {self.taps}"      # the screen redraws itself


App("Demo").run(Home())

pip install pymobile-framework
pymobile setup-sdk           # once per machine
pymobile build --native      # → apk/demo-0.1.0.apk

That APK is signed, installable and runs a real CPython interpreter on the device. No Java authoring, Gradle or Android Studio; the SDK setup downloads the JDK for you.

Table of contents

Why PyMobile
Real APKs Signed with v2+v3 schemes, containing classes.dex, resources.arsc and an embedded CPython 3.14 for ARM64.
Native views Widgets become genuine TextView, Button, EditText, Switch, ProgressBar and LinearLayout instances — not a web view or a custom canvas.
Fast About five seconds per build. An unchanged rebuild is instant.
Small setup ~800 MB of tooling, downloaded automatically. The NDK is not required.
Testable Your whole app runs and is unit-testable on a desktop, with no emulator.
Optional app dependencies Pure-Python PyPI wheels can be declared and bundled into the APK; the framework itself needs only the standard library on device.

Verified on a physical device running Android 14.

Build diagnostics and APK size

pymobile doctor             # project, entry point, pip, free space and Android SDK
pymobile doctor --strict    # exit nonzero when native tooling is missing
pymobile deps check         # check pure-Python wheels, without installing them
pymobile logs               # recent logs/traceback for this app on a connected device
pymobile logs --follow      # stream logs for the currently running app
pymobile logs --device SERIAL --lines 200
pymobile size               # compressed APK size by runtime, framework, app, dependencies
pymobile size path/to/app.apk --json

deps check needs access to the configured Python package index; a failure may mean no compatible wheel or a network/index error, not necessarily a native extension. It does not run app code or guarantee that a package works on a physical device. logs requires Android SDK platform-tools (adb), a connected and authorized device, and a recent app process or crash record in logcat. It filters by the app's process ID rather than mixing logs from other apps. APK sizes use ZIP-compressed entry sizes; the residual includes signing and archive overhead. Dependencies are attributed using their wheel RECORD metadata.

Third-party Python packages (experimental)

Declare pure-Python distributions in pymobile.toml:

[app]
name = "My App"
package = "com.example.myapp"
dependencies = ["requests==2.32.5"]

Alternatively use [project].dependencies in pyproject.toml (also when pymobile.toml is present). An explicit dependencies = [] in the app config disables that fallback. Build normally with pymobile build --native; PyMobile installs universal wheels and transitive dependencies into .pymobile/dependencies/ and packages their Python files, metadata, and data assets directly under the app root. The startup check imports from the same dependency directory.

Only pure-Python universal wheels are supported: packages requiring native extensions (for example NumPy) cannot run with a host binary on Android. Dependencies come from PyPI via pip and need network access on the first build; pin versions for reproducibility. A cached install is reused until the declared requirements change; remove .pymobile/dependencies/ to refresh unpinned packages. For HTTPS with requests, keep android.permission.INTERNET and do not use --no-ssl. This has been verified by a structural build and desktop startup smoke check, not yet by running the APK on an Android device.

Installation

Requirements: Python 3.10+, about 1 GB of free disk space, an Android 7.0+ (API 24) device.

The framework itself runs on CPython 3.10 and newer, including the 3.16 pre-releases. Verified by hand against 3.16.0a1, built from python.org: the whole suite passes (1673 passed, 8 skipped), ruff and mypy are clean, and pymobile init / preview / check-ui / build work under it. CI runs a separate, allowed-to-fail job on 3.15 and 3.16 pre-releases so a future alpha cannot break the framework unnoticed. (The phone runtime is a fixed 3.14 build bundled by the compiler — that is the interpreter inside the APK, not the one you run the framework with.)

pip install pymobile-framework

The distribution is named pymobile-framework because pymobile on PyPI belongs to an unrelated 2014 project. The import name and the CLI command are still pymobile. The GitHub repository is Maksum867/PyMobile.

Then install the Android toolchain, once per machine:

pymobile setup-sdk

This downloads JDK 17 and the Android SDK (~900 MB) into ~/.andro, including adb for connected-device installs. The NDK is not downloaded: a prebuilt native bridge (22 KB) ships inside the package. It is byte-identical for every application, so there is nothing to compile. If you want to rebuild it from C source anyway:

pymobile setup-sdk --with-ndk    # adds ~2 GB

Already have Android Studio? Point PyMobile at your existing SDK instead:

export ANDROID_HOME=~/Android/Sdk          # macOS/Linux
$env:ANDROID_HOME = "C:\...\Android\Sdk"   # Windows PowerShell

You need build-tools;35.0.0 and platforms;android-35.

If the pymobile command is not found

Common on Windows when pip's scripts directory is not on PATH. This form always works:

python -m pymobile build --native

Verify everything with:

pymobile doctor

Your first app

pymobile init myapp --name "My App" -p com.example.myapp
cd myapp
pymobile run                # preview on your machine
pymobile build --native     # produce the APK

init generates:

myapp/
├── main.py           # your application
├── pymobile.toml     # configuration
├── README.md
├── .gitignore
└── assets/           # images, fonts, data files

The smallest possible app:

from pymobile import App, Column, Label, Screen, Widget


class Home(Screen):
    def build(self) -> Widget:
        return Column(Label("Hello, Android!"))


App("My App").run(Home())

App.name is the UI title: desktop run/GUI/web previews use it instead of the name in pymobile.toml. For a native APK, a literal entry-point call such as App("Notes") also becomes the Android manifest/launcher label at build time; the running activity and Recents task receive the actual App.name on the first render. Android fixes the launcher label in the APK, so when the name is computed dynamically the manifest falls back to pymobile.toml while the running task uses the runtime value.

How it works

Three ideas explain everything else.

1. Widgets are descriptions, not views. Label("Hello") draws nothing. It is a node in a tree that serialises to JSON. A Java renderer converts that tree into real Android views and patches them in place on every update.

2. Everything platform-specific goes through a bridge.

Your Python code
       ↓
    Bridge ──┬── AndroidBridge   on device, through JNI
             └── StubBridge      on desktop, records every call

3. Therefore your app runs anywhere. On a laptop the stub bridge logs what would have happened; on a phone the same code vibrates and posts notifications. You never write if android: — the framework picks the implementation.

app = App("Demo")
print(app.platform)      # 'desktop' or 'android'
print(app.bridge.name)   # 'stub' or 'android'

The build pipeline runs twelve independent, individually timed stages:

validate → collect → compile → icons → toolchain → runtime
        → jni → dex → resources → assets → sign → verify

UI components

30+ components. All of them accept id, style, visible and enabled.

Label

Static or updatable text.

label = Label("Heading", style=Style(font_size=24, bold=True))
label.set_text("New text")

Button

Button("Save", on_press=self.save)
Button("Unavailable", on_press=self.save, enabled=False)   # taps ignored

variant= picks the intent without a Style(...) recipe per call site:

Button("Save",  variant=ButtonVariant.PRIMARY)    # the default: filled, white label
Button("Later", variant="tonal")                  # tinted background, primary label
Button("Details", variant="outlined")             # border, transparent inside
Button("Skip", variant="text")                    # just the label
Button("Delete", variant="danger")                # red, white label

The five variants mean the same thing on Android, in the browser preview, in the mockup picture and in the ASCII picture. A typo lists the ones that exist: invalid variant 'primry'; expected one of primary, tonal, outlined, text, danger.

TextInput

TextInput(
    placeholder="Your name",
    max_length=50,             # extra characters are trimmed automatically
    on_change=lambda value: print(value),
)

TextInput(password=True)       # masked
TextInput(multiline=True)      # multi-line

on_change fires only on a genuine change — writing the same value again does nothing. While the field has focus the framework never overwrites its contents, so the keyboard stays open and the caret does not jump.

Methods: set_value(text), clear().

maxlength= (the HTML spelling) still works but is deprecated in favour of max_length=; see Versioning and deprecation policy.

Switch

switch = Switch(checked=True, on_toggle=lambda state: print(state))
switch.toggle()            # returns the new state
switch.set_checked(False)

Checkbox

checkbox = Checkbox(checked=False, on_toggle=lambda state: print(state))
checkbox.toggle()
checkbox.set_checked(True)

RadioButton / RadioGroup

group = RadioGroup(
    RadioButton("Option A"),
    RadioButton("Option B"),
    on_select=lambda value: print(f"Selected: {value}"),
)
group.value              # "Option A" / None — the selected button's text
group.selected_index     # 0 / None — position, works with duplicate labels
group.select("Option B") # by text (the first button with that text)
group.select_index(1)    # by position

Buttons are tracked by position, so two options may share a label ("Other", "Other") and a label may be changed at run time.

SegmentedButtons

Horizontal selection panel (tabs or segmented control).

segmented = SegmentedButtons(
    ["Today", "Week", "Month"],
    on_select=lambda value: print(value),
)

Long labels. Every segment is as wide as its text. When they do not fit — five translated labels on a 360 dp phone — the bar scrolls sideways (the selected segment is scrolled into view) instead of squeezing a word into a column of letters. Pass wrap=True when every option should stay visible: the segments then flow onto further lines.

SegmentedButtons(["Geography", "History", "Math", "Biology", "Chemistry"])            # scrolls
SegmentedButtons(["Geography", "History", "Math", "Biology", "Chemistry"], wrap=True)  # flows

For anything other than a selection — tags, filter chips, quick replies — use Wrap.

Slider

slider = Slider(value=50, minimum=0, maximum=100,
                on_change=lambda v: print(v))

min= / max= still work as deprecated aliases of minimum= / maximum= (on Slider, Stepper, ProgressBar, ProgressText and RatingBar); they warn and are removed in 1.0.

ProgressBar

bar = ProgressBar(40, maximum=100)
bar.set_value(150)         # clamped to maximum
bar.fraction               # 0.0 … 1.0

ProgressBar(indeterminate=True)    # spinner

ProgressText

ProgressBar with a text label overlay.

ProgressText(42, maximum=100, label="Downloading")
# Shows: "Downloading 42%"

RatingBar

rating = RatingBar(value=3, maximum=5,
                   on_change=lambda v: print(v))

Dropdown

dropdown = Dropdown(
    options=["Red", "Green", "Blue"],
    on_select=lambda value: print(value),
)

Widgets that choose one of several options (Dropdown, SegmentedButtons, BottomNavigation, RadioGroup) report it with on_select; widgets that hold a value (TextInput, Slider, Stepper, RatingBar) use on_change. The old on_change= on the selection widgets is a deprecated alias of on_select=.

SearchBar

search = SearchBar(
    placeholder="Search...",
    on_change=lambda query: filter_items(query),
)

Chip / Badge

Chip("Python", on_press=lambda: print("clicked"))
Badge("3")       # notification badge

Stepper

stepper = Stepper(value=1, minimum=0, maximum=10,
                  on_change=lambda v: print(v))

Link

Clickable text that opens a URL in the system browser.

Link("Visit example.com", url="https://example.com")

DataTable

Simple table with headers and rows.

DataTable(
    headers=["Name", "Age", "City"],
    rows=[
        ["Alice", "30", "Kyiv"],
        ["Bob", "25", "Lviv"],
    ],
)

Avatar

Round avatar with initials or an image.

Avatar("MK")                           # initials
Avatar("MK", image="assets/photo.png") # image, showing "MK" until it loads

The positional argument is either initials or an image source, and Avatar guesses: a URL, a path separator or an image extension means "image", everything else is initials. State the reading outright whenever the guess would be wrong:

Avatar(text="A/B")                    # initials, whatever they look like
Avatar(image="photo")                 # an image, whatever the path looks like
Avatar("A/B", is_image=False)         # the positional is initials, not a path
Avatar("photo", is_image=True)        # the positional is an image source
Avatar("A/B", image="me.png", is_image=False)   # a photo with the initials "A/B"

is_image is three-valued: None (the default) guesses, True and False decide.


Image("assets/logo.png", fit="cover")   # contain | cover | fill | none

Paths are relative to your project directory.

Canvas, Line, Path, Shape

Vector drawing, for the things a layout cannot express: a waveform, a progress ring, a signature, a sparkline. Elements are plain data, so a drawing renders identically on the phone, in the browser preview, in the desktop window and in a golden PNG snapshot — and it can be snapshotted like any other widget.

Canvas(
    Rect(0, 0, 210, 80, color="#F5F5F5"),
    *[Line((4 + i * 5, 40), (4 + i * 5, 40 - value * 30), width=2) for i, value in enumerate(samples)],
    Line((4, 40), (204, 40), color="#B0BEC5", width=1),
    width=210,
    height=80,
)

Rect, Circle, Line, Path(points, closed=True), Polygon and Shape("rect" | "circle" | "polygon" | "text", …) cover the primitives; color, width, opacity and fill are understood by all of them. Colours default to the theme's text colour and opacity is folded into the alpha channel, so a 50 % stroke is 50 % transparent everywhere. Coordinates are in the canvas' own logical box (width × height), which every renderer scales to fit. Before this, a waveform meant forty Container strips of differing width — one nested layout per sample.

List / ListTile

A list that builds its rows lazily, a page at a time, so 10 000 items cost only what the user actually scrolls through.

List(
    item_count=10000,
    builder=lambda index: ListTile(
        title=f"Item {index}",
        subtitle=f"Description {index}",
        on_press=lambda: print(f"tapped {index}"),
        on_long_press=lambda: delete(index),   # touch and hold
    ),
)

The first visible_count rows (default 20) are built up front. When the last built row scrolls into view, the next page is appended in place — the scroll position is kept. The Tk and browser previews show a Load more (N of M) button instead. Rows stay built once loaded: this is incremental loading, not view recycling, so keep rows light.

items = List(item_count=10000, builder=row, visible_count=30)
items.loaded        # 30 rows built so far
items.has_more      # True
items.load_more()   # append the next page yourself (returns rows added)
items.scroll_to(250)            # build rows up to 250 and scroll to it
items.item_count = 12000; items.refresh()   # data changed

scroll_to(index, animated=True) really scrolls: the enclosing ScrollView brings row index to the top, smoothly unless animated=False. Calling it again with the same index scrolls again (the user may have scrolled away). The browser preview scrolls the row into view.

on_long_press gives a row a second action — delete, archive, rename — without a permanent button on every row. The device vibrates on the hold; the Tk and browser previews map it to a right click.

Swipe and pull to refresh

def build(self):
    return ScrollView(
        List(
            len(self.mails),
            builder=lambda i: ListTile(
                self.mails[i].subject,
                on_swipe_left=lambda: self.delete(i),     # red, like a bin
                on_swipe_right=lambda: self.archive(i),   # green
            ),
            on_refresh=self.reload,
        )
    )

def reload(self):
    return self.app.run_job(fetch_mail).then(self.show)   # spins until done
  • Swipe. Dragging a row sideways tints it (swipe_left_color / swipe_right_color, red and green by default). Let go past a third of the width — or fling it — and the row slides out and the handler runs; a short drag springs back. Only the directions that have a handler move. In tests, tile.swipe("left") does what the gesture does.
  • Pull to refresh. Pulling down a list that is scrolled to the top shows a spinner and calls on_refresh. If it returns something with then() (a run_job handle, an app.http future), the spinner keeps turning until that finishes, successfully or not; otherwise it stops when the handler returns (a cancelled job never finishes: set refreshing = False then). Set items.refreshing = True/False to drive the spinner yourself; items.pull_to_refresh() simulates the gesture.
  • The Tk and browser previews have no finger: a swipe becomes ⟵ / ⟶ buttons next to the row and the pull a ↻ Pull to refresh button.

Both gestures are implemented in the renderer itself — no AndroidX, nothing extra in the APK.

BottomNavigation

The app's primary navigation — a persistent bar of equal-width tabs (Android's bottom-navigation pattern). Unlike SegmentedButtons (a content filter), renderers pin it: bottom bar in the browser preview, tab row in the Tk window, horizontal tab bar on the device.

tabs = BottomNavigation(
    ["Home", "Stats", "Settings"],
    value="Home",
    on_select=self.show_tab,      # fires only on a real change
)
tabs.select("Stats")              # programmatic switch redraws the bar

Dialog, AlertDialog, ConfirmDialog, BottomSheet

Modal surfaces drawn as a framed, elevated card (a LabelFrame in Tk, a bordered <section> in the browser, a card with elevation on Android). open()/close() flip visible, so a closed dialog costs nothing::

self.ask = ConfirmDialog(
    "Delete entry?", "This cannot be undone.",
    on_confirm=self.delete, confirm_text="Delete",
)
...
self.ask.open()                   # shown = True, the screen redraws

Whichever button the user taps closes the dialog first and only then fires on_confirm/on_cancel/on_acknowledge, so a handler never runs while the dialog still covers the screen. AlertDialog is a message plus one button; BottomSheet(title=...) anchors the same surface to the bottom edge with rounded top corners.

Snackbar

A message at the bottom of the screen with an optional action — the classic "Note deleted · UNDO":

def delete(self, index):
    note = self.notes.pop(index)
    self.refresh()
    self.app.snackbar(
        "Note deleted",
        action="Undo",
        on_action=lambda: self.restore(index, note),
    )

It hides itself after 4 s (7 s when it has an action; duration_ms=0 keeps it until tapped or dismiss()ed), can be swiped away, and a new snackbar replaces the one on screen. It stays up across push/pop. app.snackbar() returns the Snackbar; app.current_snackbar is the one on screen (or None), so tests can check it and call .press() / .dismiss(). Unlike toast() it is drawn by the framework, so the previews and the PNG mockup show it too.

DatePicker / TimePicker

ISO-string values ("2026-09-19", "14:30") that serialise to JSON untouched. The browser preview renders real <input type="date"> / <input type="time"> controls, the device opens the native DatePickerDialog / TimePickerDialog. Out-of-range values clamp to minimum/maximum; malformed ones raise ValueError immediately.

DatePicker(value="2026-09-19", minimum="2026-01-01",
           on_change=lambda iso: print(iso))
TimePicker(value="14:30", on_change=self.on_time)

Cards, forms, tabs and other extended components

These components are exported from pymobile like the basic ones. Cards, forms, tabs, accordions, states, multi-select, calendars and the carousel are compositions of existing widget types (Column, Row, Grid, Wrap, Button, Label, Chip), so they need no new Java. Icon, IconButton, AutoComplete, RangeSlider, PageView and the charts are native types and live in ViewBuilder.java / AdvancedViews.java (the bundled classes.dex already contains them).

Card(Label("Body"), title="Profile", actions=[Button("Edit")])

Form(
    FormField("email", "Email", required=True, rules=["email"]),
    FormField("password", "Password", password=True, rules=[{"min_length": 8}]),
    on_submit=lambda values: print(values),
    messages={"required": "This field is required"},   # same keys as Validator(messages=)
)                                                       # call form.submit() from a Button

TabView({"home": HomeView(), "stats": lambda: StatsView()}, labels={"home": "Home"})
ExpansionPanel("Details", Label("…")); Accordion(panel_a, panel_b)   # one open at a time
MultiSelect({"a": "Alpha", "b": "Beta"}, ["a"], maximum_selected=2)
AutoComplete(["Kyiv", "Lviv"], threshold=2, on_select=print)
RangeSlider(20, 70, minimum=0, maximum=100, step=5, on_change=print)   # value == (low, high)
IconButton("add", label="Add item", on_press=self.add)    # label is required for TalkBack
PageView(page_a, page_b)   # or PageView(item_count=100, builder=make_page)
Carousel(page_a, page_b)   # PageView + buttons + "1 / 2" indicator
Calendar("2026-10-01"); DateRangePicker(on_change=print)   # ISO dates
BarChart({"Jan": 4, "Feb": -2}); LineChart([1, 3, 2]); PieChart({"A": 3, "B": 1})
EmptyState("Nothing here", action_label="Add", on_action=self.add); Skeleton(3)

FormField's first positional argument is its required field key; the second is the display label. Both field.validate() and form.validate() return a boolean; read field.error or form.errors for messages.

Things worth knowing:

  • Keep stateful ones (Form, TabView, PageView, MultiSelect, Calendar …) in __init__ or on self, not created fresh inside build(), when their state must survive Screen.refresh(). They repair their own parent links after a refresh.
  • Disabling a Form, TabView, Card… (enabled=False) blocks events for every widget inside it, not only for the container.
  • TabView is not a nested Screen: the owning screen renders the active content. A builder (lambda: …) creates fresh content on selection; keep the data outside.
  • Icon names are in pymobile.ICON_NAMES; they are drawn as vectors, not emoji. IconButton must be at least 48 dp and have a non-empty label.
  • RangeSlider snaps to step from minimum; the phone commits the value when the finger is lifted. PageView renders only the selected page.
  • Charts are read-only, equally spaced, and support signed values. PieChart rejects negative values. Large inputs are labelled sparsely instead of crowding the axis.
  • Remote suggestions for AutoComplete: run the request in a job and call set_options(...); debouncing belongs to the application.

Spacer

Spacer(16)     # 16 dp of empty space

Divider

Divider()                       # hairline between sections
Divider(inset=16, thickness=2)

Layout

Containers, freely nestable.

Column(a, b, c, spacing=12)                # vertical stack
Row(a, b, spacing=8, align=Align.CENTER)   # horizontal stack
Grid(a, b, c, d, columns=2, spacing=12)    # equal-width cells
Wrap(a, b, c, d, spacing=8)                # side by side, a new line when full
ScrollView(content, spacing=8)             # scrollable region
Stack(background, foreground)              # layered, last on top
SafeArea(content)                          # clears the notch and status bar

Grid

The container for cards, galleries and menus. Every cell in a column gets the same width, so two stat cards stay aligned even when one holds 5 and the other 2 h 45 m — which is exactly what Row(weight=1) cannot guarantee.

Grid(
    card("Completed", "12"),  card("Focus time", "5 h"),
    card("Breaks", "4"),      card("Average", "25 m"),
    columns=2,
    spacing=12,                       # or row_spacing= / column_spacing=
)

Rows fill left to right; the last row may be partially filled.

Wrap

A flow layout: children sit side by side at their natural size, and a new line starts when the next one does not fit. It is the container for things whose number and width are not known in advance — tags, filter chips, quick-reply buttons, translated labels — where a Row would push the last one off the screen and a Grid would give every cell the width of the widest.

Wrap(*[Chip(tag) for tag in tags], spacing=8, run_spacing=4)
Wrap(a, b, c, align="center")     # each line centred (start | center | end)

spacing is the gap between children on a line, run_spacing the gap between lines (it defaults to spacing). A child wider than the container gets a line of its own; hidden children take no room. The Android renderer, the desktop preview and the mockup break lines by the same rule.

Expanded and Flexible

Share out the space left over on the main axis.

Row(
    Expanded(Button("Start")),            # half
    Expanded(Button("Reset"), flex=2),    # twice as wide
    spacing=8,
)

Expanded makes the child fill its share, Flexible lets it stay smaller. With no child they are a flexible gap, which is the concise way to push a trailing widget to the far edge:

Row(Label("Title"), Expanded(), IconButton("menu"))   # ⋯ … fills the middle

Divider

Column(
    header,
    Divider(),                                   # hairline
    Divider(inset=16, thickness=2),              # inset, thicker
    Divider(vertical=True),                      # inside a Row
    body,
)

SafeArea

def build(self) -> Widget:
    return SafeArea(Column(...))                 # all edges
    return SafeArea(content, top=False)          # header bleeds upwards

Padding comes from the real window insets, so it is right on every device instead of a hard-coded guess.

Alignment

align positions children along the container's own axis; cross_align positions them across it.

Row(a, b, align=Align.SPACE_BETWEEN, cross_align=Align.CENTER)
Column(a, b, cross_align=Align.STRETCH)

Options: Align.START, Align.CENTER, Align.END, Align.SPACE_BETWEEN, and Align.STRETCH for cross_align.

UI accessibility and layout audit

Give controls an explicit screen-reader name when their displayed text is not enough. FormField automatically uses its visible label for the contained TextInput; other widgets accept accessibility_label=. Mark an image as decorative when it carries no information:

TextInput(accessibility_label="Plant name")
Switch(accessibility_label="Watering reminder")
Image("assets/leaf.png", accessibility_label="New leaf on a fern")
Image("assets/flourish.png", decorative=True)

The name is passed to Android as the content description and is retained by the browser preview as an ARIA label/alternative text. Check the currently rendered screen with:

python -m pymobile check-ui --width 320
python -m pymobile check-ui --screen Settings --width 320 --strict
python -m pymobile check-ui --theme dark --strict
python -m pymobile check-ui --theme light --json

The command warns about unnamed interactive controls and images, explicitly undersized control widths/heights (the default target is 48 dp), fixed widths wider than their parent, and Row contents that appear too wide for the chosen screen. It also checks explicit text colours against WCAG AA: the nearest explicit widget/container background is inherited, falling back to app.theme.color("BACKGROUND") when no background is declared. This includes custom app themes. --theme light|dark switches the app theme and rebuilds the screen before auditing it. An unspecified foreground colour is not guessed.

Ratios below 4.5:1 — 3:1 for text the heuristic treats as large (≥18 dp, or bold ≥14 dp) — are reported with the ratio and the two colours:

contrast: text #2A2233 on #191322 is 1.19:1, below WCAG AA 4.5:1

--json prints machine-readable results; --strict returns exit code 1 when any warning is found. This is a lightweight static audit, not a full Android layout or TalkBack simulator: unspecified native control sizes, font scaling, localization and device-specific behavior still need a real-device check.

Styling

Style(
    font_size=18,
    bold=True,
    italic=False,
    color=Color.PRIMARY,
    background=Color.SURFACE,
    padding=EdgeInsets.all(16),
    margin=EdgeInsets.symmetric(horizontal=8, vertical=4),
    corner_radius=8,
    elevation=2,
    align=Align.CENTER,
)

padding and margin also take shorthands: padding=16 is EdgeInsets.all(16) and padding=(16, 8, 16, 8) is left, top, right, bottom (the EdgeInsets order). A pair such as (8, 16) raises a TypeError — CSS and EdgeInsets.symmetric read it in opposite orders, so write EdgeInsets.symmetric(horizontal=16, vertical=8) instead.

Spacing between specific neighbours

spacing on a container applies the same gap everywhere. When one gap must differ, add a margin to the individual widget — the two are added, not replaced:

Column(
    header,
    Label("close to the header"),
    Label("pushed further down", style=Style(margin=EdgeInsets(top=24))),
    spacing=8,          # this one sits 8 + 24 dp below its neighbour
)

Size constraints

Style(min_width=120, max_width=200)     # a card that cannot collapse or sprawl
Style(aspect_ratio=16 / 9)              # keep a shape whatever the width
Style(min_height=44)                    # a comfortable tap target
Style(weight=1)                         # share of a Row/Column (see Expanded)
Style(width=120, height=48)             # a fixed size in dp
Style(width="match")                    # fill the parent ("wrap" also works)
Style(elevation=4)                      # a drop shadow (Android 5+)

Contradictory bounds raise immediately — Style(min_width=200, max_width=120) is a ValueError, not a widget that silently clips to nothing on device.

Built-in colours: PRIMARY, ACCENT, BACKGROUND, SURFACE, TEXT, TEXT_MUTED, SUCCESS, WARNING, ERROR, TRANSPARENT. Custom colours use #RGB, #RRGGBB or #AARRGGBB.

Styles are immutable, so a base style is safe to share:

BASE = Style(font_size=16, color=Color.TEXT)

Label("Normal", style=BASE)
Label("Error", style=BASE.merge(color=Color.ERROR, bold=True))

Invalid values fail fast: Style(color="red") raises ValueError.

EdgeInsets helpers: EdgeInsets.all(8), EdgeInsets.symmetric(horizontal=8, vertical=4), EdgeInsets(left, top, right, bottom).

Screens and navigation

A screen builds a widget tree and receives lifecycle callbacks.

class Settings(Screen):
    title = "Settings"

    def build(self) -> Widget:
        return Column(
            Label("Second screen"),
            Button("Back", on_press=self.app.pop),
        )

    def on_mount(self):   ...   # once, when pushed onto the stack
    def on_show(self):    ...   # every time it becomes visible
    def on_hide(self):    ...   # when another screen covers it
    def on_unmount(self): ...   # once, when popped

Navigation is a stack:

app.push(Settings())            # on_hide(current) → on_mount → on_show
app.pop()                       # on_hide → on_unmount → on_show(previous)
app.pop()                       # safe to call multiple times, returns None on root

app.replace(HomeScreen())       # after login, no back to login (App shortcut)
app.reset(LoginScreen())        # on logout, clear stack (App shortcut)

app.navigator.replace(Other())  # swap the top screen (via navigator)
app.navigator.reset(Home())     # clear the stack, start fresh
app.navigator.depth             # how many screens are stacked
app.screen                      # the visible screen

Android screen swaps fade by default. Choose transition="fade", "slide", "scale" or "none" and tune transition_duration_ms on App; a back/pop reverses a slide. Widget(animate_visibility=True) opts a widget into a fade/ scale when its visible state changes; ExpansionPanel uses this by default.

On the first push, build() runs before on_mount()/on_show(). When pop() reveals an existing screen, its cached tree is invalidated before on_show(); accessing self.root or self.get(...) in the hook builds the fresh tree, otherwise rendering builds it afterwards. Use those lookups, rather than references to retired widgets, when a hook needs the rebuilt contents. push(None) and build() returning None raise clear TypeError/PyMobileError instead of raw AttributeError.

Returning from a form therefore reflects model/storage changes without an extra notification. Keep persistent state in screen/model attributes or widgets created once in __init__() and reused by build(). A newly constructed input inside each build() does not automatically retain its old draft text. See Data changed on another screen.

The root screen is never popped — pop() returns None instead of leaving a blank window. The hardware back button is wired up automatically.

Do not push the same screen object twice; that raises PyMobileError. Create a new instance each time: app.push(Settings()).

Is this screen on display?

screen.is_current is True while the screen is on top of the stack — from just before on_show until just before on_hide — and False when another screen covers it, after it was popped, or before it was pushed. It never raises and can be read from any thread, so a callback that may outlive the screen (a timer, a job result) can simply ask, without touching the private _app:

def on_rows(self, rows):
    if self.is_current:               # same as `self.app.screen is self`, but never raises
        self.table.rows = rows

Not to be confused with screen.mounted, which stays True for a screen that is on the stack but covered.

Titles that follow the language

title is a plain class attribute — fixed when the class is defined, long before a catalogue is loaded or the language changes. Name a catalogue key instead:

class Settings(Screen):
    title = "Settings"                  # shown when the key is missing
    title_key = "settings.title"        # translated before every build()

The key is looked up again each time the screen's tree is built, and switching the language rebuilds every screen on the stack, so titles (the action bar, the mockup, to_dict()) always match the current language. Screen("Fallback", title_key="settings.title") works too. A title that depends on data can be assigned inside build(): self.title = t("user.title", name=self.user). A key the catalogue lacks leaves the fallback title and is logged once, like any missing translation.

Find a widget anywhere in the current screen:

self.find("counter").set_text("5")     # matches Label(..., id="counter")

Pass the class to get a typed result — editors and mypy then know it is a TextInput, and a wrong guess fails right there instead of three calls later:

name = self.find("name", TextInput)    # TextInput | None
name = self.get("name", TextInput)     # TextInput, or WidgetNotFoundError
labels = self.root.find_all(Label)     # list[Label]

find() returns None for a missing id; get() raises WidgetNotFoundError (a LookupError) with a did you mean hint. Both raise WidgetTypeError (a TypeError) when the widget is of another class.

Screens as tabs: one shell owns the frame

Only the screen the navigator shows is rendered. app.render() — and every automatic redraw behind it — serialises navigator.current and nothing else. That single fact explains most of the surprises a tabbed app runs into:

Call On a screen the navigator owns On a screen built inside another screen (a tab)
self.refresh() rebuilds the tree; the frame is drawn when that screen is current rebuilds the tree; nothing displays it — logged once, with a pointer here
self.on("event", …) works (the screen has a running app) PyMobileError — see below
self.app works PyMobileError — a screen that was never pushed has no app

Such a nested Screen is a data holder: on_mount/on_show never run for it, self.on() cannot subscribe (a PyMobileError tells you so — subscribe from on_mount() of a screen that actually gets pushed, or use a plain object), and a refresh() on it repaints nothing. A screen stacked below the current one is different: it keeps its rebuilt tree and shows it the next time it becomes current, which is exactly what a language change relies on.

The pattern that works: a shell screen owns the frame, and the tabs are plain objects that hold data and build widgets.

class Shell(Screen):
    """The only screen that renders: BottomNavigation + the active tab."""

    def __init__(self) -> None:
        super().__init__()
        # Tabs are created out here, not in build(): refresh() runs build()
        # again, and a tab recreated there would forget the data it holds.
        self.tabs = [HomeTab(self), StatsTab(self)]
        self.active = self.tabs[0]

    def build(self) -> Widget:
        return Column(
            self.active.build(),                  # rebuilt by refresh(), below
            BottomNavigation(
                ["Home", "Stats"],
                value=self.active.title,
                on_select=self.show_tab,
            ),
        )

    def show_tab(self, name: str) -> None:
        self.active = next(tab for tab in self.tabs if tab.title == name)
        self.notify_data_changed()

    def notify_data_changed(self) -> None:
        """The single render point: every tab calls this, never self.refresh()."""
        self.refresh()


class HomeTab:
    """Data and widgets — not a Screen, so it cannot render by accident."""

    title = "Home"

    def __init__(self, shell: Shell) -> None:
        self.shell = shell
        self.items: list[str] = []

    def build(self) -> Widget:
        return Column(Label(f"{len(self.items)} items"), Button("Reload", on_press=self.reload))

    def reload(self) -> None:
        self.items = fetch_items()
        self.shell.notify_data_changed()          # the shell repaints

Two traps the pattern avoids: calling self.refresh() on a tab and waiting for a frame that never comes, and rebuilding during a frame — a refresh() from inside build() used to recurse until RecursionError. The framework now defers a redraw requested while a frame is being built (and reports a tree that redraws on every frame instead of spinning forever); the shell above is still the right structure, because it keeps one place that decides what is on screen.

Updating the screen

Change a widget and the screen redraws itself. There is no render() to forget.

class Home(Screen):
    def __init__(self) -> None:
        super().__init__()
        self.taps = 0                          # state belongs to the screen,
                                               # not to the frame being built

    def build(self) -> Widget:
        self.counter = Label(f"Taps: {self.taps}")   # id becomes "counter"
        return Column(self.counter, Button("Tap", on_press=self.on_tap))

    def on_tap(self) -> None:
        self.taps += 1
        self.counter.text = f"Taps: {self.taps}"    # that is the whole update

build() runs again on every refresh() (and on a theme or language change), so anything assigned there is reset. Keep the state in __init__ or in a model object and let build() read it — a theme switch must not zero the counter.

self.counter.text = ... and self.counter.set_text(...) do the same thing. Every public attribute works this way — text, value, checked, visible, enabled, and also style, placeholder, Badge.color, Avatar.image, ProgressText.label and the rest: assigning a different value schedules a redraw.

label.style = Style(color=Color.ERROR, bold=True)   # redraws by itself

Style is frozen: label.style.bold = True raises FrozenInstanceError, and even for a mutable object the in-place change would be invisible — the widget compares the old value with the new one. Build a changed copy and assign it:

from dataclasses import replace

label.style = replace(label.style, bold=True)       # redraws by itself

When the tree itself changed (rows added or removed), call self.refresh().

Redraws are coalesced, so a handler that updates six widgets still produces a single frame. Assigning a value that has not changed renders nothing at all, and mutating a widget on a screen that is not visible is free.

Group updates explicitly when you build them in a loop:

with app.batch():
    for label, value in zip(self.labels, values):
        label.text = value
# one render happens here
Method When to use
(nothing) a property changed — handled for you
self.refresh() the tree itself changed (rows added or removed)
self.rebuild() rebuild a tree that no frame owns (a tab, a panel)
app.notify_data_changed() explicitly invalidate covered screens and emit data:changed; optional for a simple save-and-pop
app.render() you want a frame pushed out right now

self.refresh() repaints a screen the navigator owns; a screen embedded in another screen's tree is rebuilt by the screen that builds it — see Screens as tabs. Such a screen can call self.rebuild() to re-run its build() without asking for a frame.

Data changed on another screen

pop() automatically invalidates the screen it reveals. For the usual list → form → save → back flow, save the data and pop; the list's next build() reads the updated model/storage:

class NewCard(Screen):
    def save(self) -> None:
        self.store.put(self.card)
        self.app.pop()                  # the list below rebuilds automatically

app.notify_data_changed() is still useful when other code subscribes to the public data:changed event or you want to invalidate covered screens without immediately navigating back. self.notify_data_changed() is the same call from inside a screen. The visible screen keeps its tree by default; pass rebuild_current=True when it is the one that must rebuild. Calling this before pop() remains supported, but is not required just to refresh the revealed screen.

def on_data_loaded(self) -> None:
    self.items = fetch_items()
    self.refresh()          # the number of rows changed

App("Demo", auto_render=False) restores the old manual behaviour; in that mode the first missed redraw logs a warning rather than leaving you guessing.

Threads and the UI

Widgets are not thread-safe; the UI state belongs to one place. Everything the framework calls for you runs there:

Callback Runs on
button / input handlers, on_mount, on_show, … the UI side
app.set_interval / app.set_timeout the UI side (one frame per tick)
app.run_job(...).then(...) the UI side
app.http.get_async(...).then(...) the UI side
app.dispatch(fn, *args) the UI side
the function passed to run_job / repeat_job a worker thread
set_interval(..., background=True) the timer thread
a standalone HttpClient().get_async(...).then(...) the request thread

"The UI side" is the event-loop thread on a device and the Tk thread in run --gui; in tests and the browser preview it is whichever thread calls, but under the lock that event handlers and rendering hold, so the calls never interleave. So a job callback can simply update a widget:

app.run_job(load_cards).then(lambda cards: self.show(cards))   # safe

From code that runs on your own thread — a threading.Thread, a run_job body, a background=True timer, a plain HttpClient — hand the update over:

def worker() -> None:
    data = slow_query()
    app.dispatch(self.show, data)    # show(data) runs on the UI side, one frame

dispatch returns False once the app has stopped. Keep UI-side callbacks short: a timer that blocks for a second freezes the screen for a second — put blocking work in run_job or a background=True timer.

app.toast("Saved") / app.toast("Sync failed", long=True) shows a short platform message (on the desktop it is printed / shown in the preview). For a message with an Undo button use app.snackbar().

Themes

Light and dark themes with semantic colour palette.

App("My App", theme="dark")          # or "light" (default)
App("My App", theme=Theme.dark())    # custom Theme object

app.set_theme("dark")                # switch at runtime — screen redraws
app.theme.is_dark                    # True / False
app.theme["PRIMARY"]                 # resolved colour

Built-in themes: Theme.light() and Theme.dark(). Custom themes use Theme(name, colors) with your own palette.

Keeping two palettes by hand drifts: one gets a new colour, the other does not. Theme.dark_from(light) derives the dark one from the light one — it reads each colour's perceived luminance, flips the background and surface, keeps the hue of the accents and lightens each accent until it clears 4.5:1 against the dark surface:

mocha = Theme("mocha", {"PRIMARY": "#6D5340", "BACKGROUND": "#F2ECE7", ...})
dark = Theme.dark_from(mocha)        # a warm dark theme, not a blue-grey slab
App("My App", theme=dark)

There are two small sets of design tokens as well, plain numbers so they read as intent instead of as magic values:

Card(child, spacing=Space.md)                  # Space.xs/sm/md/lg/xl = 4/8/12/16/24
Label("Total", style=Style(font_size=TextScale.title))   # caption/body/title/headline = 12/14/22/28

The active theme is available everywhere via app.theme. Color.PRIMARY is a fixed hex constant (#3F51B5); for the live theme use app.theme["PRIMARY"] (or app.theme.color("BACKGROUND")).

Storage

Key-value JSON storage with atomic writes.

app.storage["token"] = "abc123"      # set
token = app.storage["token"]         # get
del app.storage["token"]             # delete (KeyError with hint if missing)

app.storage.get("token", default="") # with default
app.storage.contains("token")        # explicit check
app.storage.exists("token")          # alias, more discoverable
"token" in app.storage               # also works
app.storage.keys()                   # all keys
app.storage.clear()                  # wipe everything

Namespaces. Two components of one app used to share a single flat key space, so a "clear cache" button wiped the login token as well. Scope a store and clear() only touches its own keys:

tokens = Storage("state.json", namespace="auth")
cache  = Storage("state.json", namespace="cache")
cache["page"] = 2
cache.clear()                        # the auth keys are untouched

Storage.mutate(key, fn) updates a value in place, so read-modify-write does not race with another thread doing the same:

app.storage.mutate("visits", lambda count: count + 1, default=0)   # 1, then 2
app.storage.increment("visits")                                    # the same, spelled out

Schema versions. A store that grows fields needs an upgrade path, and doing it by hand means a try/except around every read:

Storage(
    "profile.json",
    schema_version=2,
    migrations={
         1: lambda data: {**data, "units": "metric"},   # a step is keyed by the
        2: lambda data: {**data, "theme": "dark"},     # version it *reaches*
    },
)

Opening a file stamped with an older version runs the migrations it needs and stamps the new number; a file newer than the code is left untouched and raises a PyMobileError naming the version, because guessing at a future format is how data gets destroyed.

Data persists across app restarts. On Android it uses the app's private files directory; on desktop ~/.pymobile/<package>.json with the dots replaced by dashes (com.example.notes → com-example-notes.json), so two projects open side by side never overwrite each other's data. A file named with the dots (com.example.notes.json, e.g. restored by hand) is adopted automatically the first time the dashed one is missing. Override the directory for every app with PYMOBILE_STORAGE_DIR.

default_storage_path(filename=...) returns the default store-file location as a Path; it honors PYMOBILE_STORAGE_DIR and uses pymobile_store.json by default. Use it when you need to inspect or pass the framework's standard location without opening the store:

from pymobile import default_storage_path

path = default_storage_path()
cache_path = default_storage_path("cache.json")

App("My App", storage_path="/custom/dir")         # a directory
App("My App", storage_path="/custom/store.json")  # or an explicit file

Atomic sequences

Every single operation is atomic. A read-modify-write sequence you write by hand is not — two jobs incrementing the same counter can lose an update. Use these instead:

app.storage.increment("taps")                       # atomic +1
app.storage.update("cart", lambda items: [*items, new], default=[])
app.storage.setdefault("device_id", make_id())

with app.storage.transaction() as store:            # multi-step
    balance = store.get("balance", 0)
    store["balance"] = balance - price
    store["history"] = [*store.get("history", []), price]

Typed model storage

ModelStore is an optional adapter over the existing App.storage, not a new database. It converts dataclass instances to JSON records and offers typed CRUD while leaving the simple key/value API unchanged:

from dataclasses import dataclass
from pymobile import ModelStore

@dataclass
class Task:
    id: str
    title: str
    done: bool = False

tasks = ModelStore(app.storage, Task, key="tasks", schema_version=1)
tasks.put(Task(id="task-1", title="Review the report"))  # insert or replace by id
all_tasks = tasks.all()                                     # list[Task]
first_task = tasks.get("task-1")                            # Task | None
tasks.delete("task-1")

get() and all() return detached snapshots: the dataclass is rebuilt from the stored JSON on every read, so changing a field of the returned object changes nothing until it is written back:

task = tasks.get("task-1")       # a copy
task.done = True                 # the store still has done = False
tasks.update(task)               # put() under the name the situation suggests
tasks.edit("task-1", done=False) # load, change, persist in one call

The value at key is stored as an envelope containing schema_version and records. Dataclass fields must be JSON-compatible by default; provide both to_record= and from_record= for dates, nested value objects or custom encodings. Migrations are explicit one-version steps that run atomically and are saved the first time the model store is read or written:

def migrate_v1(records):
    return [{**row, "priority": "normal"} for row in records]

tasks = ModelStore(
    app.storage, Task, key="tasks", schema_version=2,
    migrations={1: migrate_v1},       # schema 1 records → schema 2 records
)

Missing migration steps, malformed records and data written by a newer app raise ModelStoreError rather than erasing the stored value. Keep each migration with the model version that introduces it, and test upgrades from stored data.

Background jobs

Run work off the UI thread without blocking the screen.

handle = app.run_job(lambda: fetch_heavy_data())
handle.then(on_success=lambda data: self.show(data),
            on_error=lambda err: self.show_error(err))
handle.wait(timeout=10)   # block until done (rare)
handle.cancel()

# Repeating job
handle = app.repeat_job(5000, lambda: poll_server())
handle.cancel()            # stop when done

JobHandle exposes .done, .cancelled, .result, .error.

then() callbacks run on the UI side (see Threads and the UI). If on_success raises, the error is logged with its traceback and passed to on_error; the job's own result is kept. cancel() suppresses the callbacks; Python cannot interrupt a function that is already running, so done turns true only when it returns.

HTTP cache and offline mode

Disk-backed cache for GET requests.

from pymobile import HttpCache, HttpClient

client = HttpClient(
    base_url="https://api.example.com",
    cache=HttpCache(),          # or HttpCache("http-cache.json")
)

# Cached request — returns instantly from cache if fresh
response = client.get_cached("/items", ttl=300)   # 5 minutes

# If network fails, stale cache is returned (offline mode)
# response.from_cache tells you if the data came from cache

Async HTTP

Non-blocking requests that don't freeze the UI.

future = client.get_async("/items")
future.then(
    on_success=lambda r: self.update_list(r.json()),
    on_error=lambda err: self.show_error(err),
)

future.done       # True when finished
future.cancel()   # suppress callbacks
result = future.get(timeout=10)   # block if needed

Methods: get_async, post_async, put_async, delete_async. Each returns an HttpFuture for that in-flight request; use .done, .cancel(), .get() or .then(...) to observe it. get() returns a Response or raises the request error.

Input validation

Pure logic, no UI dependency.

from pymobile import Validator

v = Validator({
    "email":    ["required", "email"],
    "name":     ["required", {"min_length": 2}, {"max_length": 50}],
    "age":      ["optional", "integer", {"between": [1, 120]}],
})

errors = v.validate({"email": "bad", "name": ""})
# {"email": "must be a valid email address", "name": "is required"}

v.validate_or_raise({"email": "bad"})   # raises ValidationError

Empty values — None, "", whitespace only, an empty list — follow three rules:

  • required reports "is required" (whitespace does not count as a value);
  • optional lets the field stay empty; its other rules run only when it is filled — except matches, which still fails while the other field is filled, so a password with an empty confirmation is rejected;
  • a field with neither is validated as is: ["email"] rejects "".

integer accepts plain digits with an optional sign (not "4_2"), and number rejects "nan" and "inf".

Mapping domain errors to form fields

Keep field-level rules in the UI, and let the domain/service layer return field-keyed errors for rules the form cannot know about (for example, a unique username or an API rejection). Form.set_errors() places each message beside the FormField with the same name:

from pymobile import Form, FormField, ValidationError

form = Form(
    FormField("email", label="Email", required=True, rules=["email"]),
    FormField("username", label="Username", required=True, rules=[{"min_length": 3}]),
)

# The form has already passed its local rules. The account service can still
# reject a value for a domain reason and report the field that owns the error.
try:
    account_service.save(form.values)
except ValidationError as error:
    form.set_errors(error.errors)  # {"username": "That name is already taken."}

set_errors() replaces the form's current error mapping, marks invalid fields touched and clears messages for fields not in the new mapping. A typo or a server error keyed to a field that is not in the form raises ValueError instead of disappearing silently. Pass {} to clear all mapped errors. Keep persistence and domain validation in a repository or service, then pass its field-keyed errors back to the form.

Validators come in two forms:

  • bare strings — required, optional, email, integer, number, boolean. Use them as-is: ["required", "email"].
  • rules with an argument — length, min_length, max_length, between, min, max, matches, one_of, regex. These always need a value, so write them as a one-key mapping: {"min_length": 2}, {"between": [1, 120]}. A bare "min_length" is an error — there is no sensible default length.

Translating the messages

The built-in messages are English, but they are not hard-wired. Every rule has a stable id and an English default (DEFAULT_MESSAGES in pymobile.core.validation); a message is taken from the first of these that has it:

  1. Validator(..., messages={...}) — for one validator. The key is a rule id ("required") or "field.rule" for a single field ("email.required"); the value is a str.format template, or a callable that receives the rule's parameters as keyword arguments (handy for plural forms).
  2. the translation catalogue, under validation.<rule id> — one translation for every validator in the app, looked up when the message is produced, so a language switch at run time is followed.
  3. the English default.
Validator(
    {"email": ["required", "email"], "name": ["required", {"min_length": 2}]},
    messages={
        "required": "This field is required",
        "email.email": "Enter a valid email address",  # only the email field
        "min_length": "Use at least {minimum} characters",
    },
)

# or once, for the whole app — the same ids, prefixed with "validation.":
translations.load({
    "validation.required": "This field is required",
    "validation.email": "Enter a valid email address",
    "validation.min_length": "Use at least {minimum} characters",
}, language="en")
Rule id Default text Placeholders
required is required
email must be a valid email address
min_length / max_length must be at least {minimum} characters / must be at most {maximum} characters minimum, maximum
integer / number / boolean must be an integer / a number / a boolean
between / min / max must be between {low} and {high} low, high
matches does not match (the {"matches": "field"} form: does not match {field!r}) field
one_of must be one of: {choices} choices
regex must match {pattern!r} pattern

matches_field (the field form of matches) and length (both ends of a length rule) are also ids: an override for matches or length covers them unless the more specific id is overridden too. An id that does not exist — messages={"requird": …} — is an error at construction, not a message that silently never shows. The bare rule functions (required("")) return the same translated text, and a rule you write yourself keeps its own message.

Plugins

Extend the app without touching its code.

from pymobile import Plugin, plugins

class AnalyticsPlugin(Plugin):
    name = "analytics"

    def activate(self, app):
        app.on("screen:change", self.track)

    def track(self, event):
        print(f"screen: {event.source}")

plugins.register(AnalyticsPlugin())
# Activated automatically in App.run()

Hooks: activate(app), on_app_start(app), on_app_stop(app).

Reacting to events

Subscribe from a screen and the handler is removed when the screen goes away:

class TimerScreen(Screen):
    def on_mount(self) -> None:
        self.on("pomodoro:tick", self.on_tick)   # cancelled on unmount

    def on_tick(self, event) -> None:
        self.clock.text = event.get("remaining")

With app.on() the handler of a popped screen stays subscribed: it keeps firing, keeps the screen alive, and runs twice as soon as the screen is pushed again. self.on() avoids that. To bind a handler registered elsewhere, pass the screen: app.on("tick", handler, screen=self).

Notifications

app.notify("Done", "File saved")               # returns a notification id
app.notify("Syncing", "In progress…", ongoing=True)   # cannot be swiped away
app.notifications.cancel(notification_id)

The notification channel is created automatically. On Android 13+ you need the POST_NOTIFICATIONS permission — see below.

Requirements for notifications to work

  1. Declare the permission in pymobile.toml:
permissions = [
    "android.permission.INTERNET",
    "android.permission.POST_NOTIFICATIONS",
]
  1. Request the permission at runtime (after the screen is visible):
from pymobile import Permission

results = self.app.permissions.request(Permission.POST_NOTIFICATIONS)
if results.get(Permission.POST_NOTIFICATIONS.value, False):
    self.app.notify("Title", "Body")
  1. Check device settings — ensure notifications are enabled for the app: Settings → Apps → Your App → Notifications.

pymobile build reminds you of step 1 only when it is needed: if the project targets Android 13+ (the default), does not declare POST_NOTIFICATIONS, and its code posts a notification (app.notify(...), app.notifications.notify(...), Notifications(...)), the build prints targetSdk >= 33 without POST_NOTIFICATIONS: notifications stay hidden with the file and line of the call. An app that never notifies gets no warning. The scan covers the files that ship in the APK (exclude, tests/ and virtualenvs are skipped) and ignores comments and docstrings.

A default pymobile build --native is enough. DeviceServices.notify() creates the notification channel on every post, so you do not need to rebuild the JNI bridge with PYMOBILE_BUILD_JNI=1. That flag is only for changing the C source (see Contributing).

Troubleshooting

Symptom Cause Fix
Permission dialog doesn't show Missing from pymobile.toml Add POST_NOTIFICATIONS to permissions
notify() returns ID but nothing shows System notifications disabled Enable in device Settings → Apps → Notifications
SecurityException in logcat Permission not granted Request permission at runtime

Vibration

app.vibrate(100)                               # one shot, milliseconds
app.vibration.preset("success")
app.vibration.pattern([0, 100, 50, 100])       # [wait, buzz, wait, buzz]
app.vibration.cancel()

Presets: tick, click, double, success, error, heartbeat.

Pulses shorter than about 50 ms cannot be felt on most hardware, so short values are stretched automatically and waveforms are sent with explicit amplitudes — several devices silently ignore the default.

Files, audio, the clipboard and sharing

Six things every phone app can do and the framework could not: choose a file, play a sound, record one, copy to the clipboard, share a link, and draw.

Picking a file

file = app.pick_file("audio/*")          # PickedFile or None
if file is not None:
    print(file.path, file.name, file.size, file.mime)

picked = app.pick_files(".wav,.mp3")     # several at once
photo = app.pick_image()                 # camera or gallery

accept takes a MIME type ("audio/*"), a comma-separated list, or an extension (".wav") that is translated for you. The result is a PickedFile(path, name, size, mime) pointing at a copy in the app's own cache: a content:// URI stops being readable the moment the activity goes away, and a plain path behaves like a packaged asset. The call blocks until the user answers, the same way a permission dialog already did, so app code stays top to bottom. A cancelled picker returns None — never an exception.

Reading and saving is ordinary Python:

from pathlib import Path

seconds = len(Path(file.path).read_bytes()) / 16000   # a rough WAV estimate

Playing audio

player = app.audio("assets/beep.wav", on_end=lambda: print("done"), volume=0.8)
player.play()                 # returns at once — the UI keeps running
player.pause()                # keeps the position
player.seek(12_000)           # milliseconds
player.position, player.duration
player.volume = 0.3
player.release()

play() never blocks: Android's MediaPlayer is prepared asynchronously and the position is published from the app's own timer, so on_tick(position_ms) works on every Android version and a metronome can follow it. loop=True, mute()/unmute() and app.audio(...) (which wires the player to the app's timers) are there too. A https:// source streams.

Recording

recorder = app.recorder()
recorder.start()              # asks for RECORD_AUDIO first
...
take = recorder.stop()        # a PickedFile: same shape as a picked one
recorder.cancel()             # throw the take away

A denied microphone raises a PlatformError that says which line of pymobile.toml to add, instead of writing a zero-length file.

Clipboard and the share sheet

app.copy("https://example.com/room/42")   # True when it stuck
app.clipboard()
app.share(url="https://example.com/a b")  # the space is escaped for you
app.share("Look at this", "https://example.com", subject="Room")

share() opens the system sheet, sends the link both as the body text and as a link stream (SMS and QR scanners read the body, messengers read the stream), and returns False when the platform has nothing to share it with — so a "Share" button can tell the truth instead of silently doing nothing.

Permissions

from pymobile import Permission

app.permissions.has(Permission.CAMERA)              # bool
app.permissions.request(Permission.CAMERA)          # {'android.permission.CAMERA': True}
app.permissions.missing([Permission.CAMERA, "VIBRATE"])
app.require_permissions(Permission.CAMERA)          # raises PermissionDeniedError if denied

Catch denials with from pymobile import PermissionDeniedError. PermissionError_ remains a compatible alias of the same exception class; existing imports and exception handlers do not need to change immediately.

Three spellings are accepted: "CAMERA", "android.permission.CAMERA" and Permission.CAMERA.

app.permissions is the app-owned PermissionManager connected to the active platform bridge. Use it for permission checks and runtime requests rather than creating a second manager with a different bridge.

Three rules that save hours

1. Declare every permission in pymobile.toml. Android denies an undeclared permission silently — no dialog appears at all. The compiler warns you when code requests something the manifest lacks:

! requested in code but not declared in pymobile.toml: android.permission.CAMERA
  — Android will deny them without showing a dialog

2. Ask after the first screen is visible. A request issued before the window exists is dropped by the system. Put it in on_show(), not before app.run():

def on_show(self) -> None:
    if self.visits == 1:
        self.app.permissions.request(Permission.CAMERA)

3. Two refusals disable the dialog forever. Android then returns an instant denial. PyMobile detects this and opens the app's settings page with an explanation, instead of failing mutely.

HTTP requests

A client built on the standard library — no third-party dependency, so nothing extra lands in the APK.

from pymobile import HttpClient

client = HttpClient(
    base_url="https://api.example.com",
    headers={"Authorization": "Bearer ..."},
    timeout=10,
    retries=2,           # exponential backoff
)

client.get("/items", params={"page": 2})
client.post("/items", json={"name": "Widget"})
client.put("/items/1", json={"name": "Updated"})
client.delete("/items/1")

Synchronous verbs return a Response; HttpFuture.get() returns the same object for an asynchronous request:

response = client.get("/items")

response.status      # 200
response.ok          # True for 2xx
response.json()      # parsed JSON
response.text        # decoded text
response.content     # raw bytes
response.headers     # lowercase keys
response.elapsed     # seconds

Error statuses are returned, not raised — they are valid HTTP responses:

response = client.get("/missing")
if not response.ok:
    print(response.status)        # 404

response.raise_for_status()       # raises NetworkError for 4xx/5xx

Retries cover connection failures and 408/425/429/5xx.

HTTPS works out of the box: a bundle of root certificates is packaged into the APK, because Android provides no certificate file where OpenSSL looks for one.

For production, restrict where the client may go:

from pymobile import HttpClient, HttpSecurityPolicy

client = HttpClient(
    base_url="https://api.example.com",
    security=HttpSecurityPolicy(
        require_https=True,                        # plain http:// is refused
        allowed_hosts={"api.example.com", "cdn.example.com"},
    ),
)

A blocked URL raises NetworkError before anything is sent. The policy is checked again on every redirect, so a server cannot bounce a request to another host or downgrade it to HTTP, and Authorization/Cookie headers are dropped when a redirect leaves the original origin. Host names are compared case-insensitively. The default policy allows everything, for local development.

Remember to list android.permission.INTERNET in your config.

Languages

The device language plus a small catalogue, which is usually all a mobile app needs. gettext and .mo files keep working — the standard library is packaged in full.

from pymobile import t, translations, device_language

translations.load_dir("locales")          # locales/en.json and other catalogue files
translations.use(device_language(default="en"))

Label(t("greeting", name="Alex"))         # "Hello, Alex!"

{
  "greeting": "Hello, {name}!",
  "items": {
    "one":   "{count} item",
    "other": "{count} items"
  }
}

t("items", count=1)     # 1 item
t("items", count=3)     # 3 items
t("items", count=5)     # 5 items

The plural form is chosen by the CLDR rule of the catalogue's language — Ukrainian and Russian (one/few/many), Polish (21 → many: 21 plików), Czech, Slovak, the Baltic and South Slavic languages, Romanian, Slovenian, Arabic, Hebrew, Irish, Welsh, French/Portuguese (0 and 1 → one), languages without plurals (Chinese, Japanese, Korean, …), and the English rule for the rest. A form missing from the catalogue falls back to other, then many. An explicit zero form is used for 0 in any language. plural_category(21, "pl") returns the category directly. Lookup falls back from pt-br to pt and then to the default language. A missing key renders as a visible marker — ⟦stats.unknown⟧ — rather than as the bare key, so an untranslated string reads as a placeholder instead of a typo in the screen (it is also logged once). translations.missing = "key" restores the old bare-key output, "empty" hides it, and any string with {key} is used as the template.

Keys are flat — a dot is part of the key

A catalogue is one level of "key": "text" pairs, so the key a dotted lookup needs is the whole dotted name. A file written with sections is expanded at load time, which makes both spellings work:

{ "stats": { "balance": "Balance" } }    → key "stats.balance" (expanded on load)
{ "stats.balance": "Balance" }           → the same key, written flat

Both t("stats.balance") calls find Balance. The expansion is reported once per language, naming the section that was flattened and an example key — a catalogue written as sections used to render bare keys with nothing but a "missing translation" line per string to explain it. Pass flatten=False (or load_file(..., flatten=False)) to read the file strictly flat:

translations.load_dir("locales", flatten=True)      # {"stats": {"balance": …}} → "stats.balance"

from pymobile import flatten_catalogue              # or expand one mapping yourself

translations.load(flatten_catalogue({"stats": {"balance": "Balance"}}), language="en")

The one nested shape that is never expanded is a plural form map, whose keys are all CLDR quantity names (zero/one/two/few/many/other):

{ "items": { "one": "{count} item", "other": "{count} items" } }

Any other nested object is a namespace, so flatten_catalogue() turns it into dotted keys — name a section after its content, not after a quantity.

Switching language redraws whatever is on screen — translations.use("en-GB") is enough, because t() runs inside build() and the screen is rebuilt for you.

device_language() reads the real system setting on Android — including Android 13 per-app language overrides — and the usual environment variables on a desktop. Force one during development with PYMOBILE_LANGUAGE=en-GB.

Already using xgettext? translations.install_gettext("app", "locale") reads your compiled .mo catalogues instead.

Numbers, dates and money

Formatting follows the language too — no Babel, no ICU, nothing to install:

from datetime import date, time
from pymobile import format_number, format_percent, format_currency, format_date

format_number(1234567.891, 2)                 # 1,234,567.89
format_percent(0.256)                         # 26%
format_currency(1250, "USD")                 # $1,250.00
format_currency(9.5, "EUR", language="en-GB") # €9.50
format_date(date(2026, 10, 1), "long")        # October 1, 2026
format_date(date(2026, 10, 10), "full", language="en-GB")  # Saturday 10 October 2026
format_date(day, pattern="d MMMM")            # custom month-and-day pattern
format_time(time(14, 5))                      # 2:05 PM

The language is the active catalogue's (translations.use(...)) unless you pass language=. Built in: English (US, GB, AU, CA, IE), Ukrainian, Russian, Polish, Czech, German (DE, AT, CH), French (FR, CA, CH), Spanish (ES, MX, US), Italian, Portuguese (BR, PT), Dutch, Romanian and Turkish; other languages use English formats. Numbers are rounded half-to-even from their decimal value, so 0.1 + 0.2 prints as 0.3.

Inside a catalogue the same formats are placeholder specifiers, so the translator decides the wording and the code passes raw values:

{ "total": "Total: {sum:currency:USD}, due {day:date:long}" }

t("total", sum=1250, day=date(2026, 10, 1))   # Total: $1,250.00, due October 1, 2026

Specifiers: number, number:2, percent, percent:1, currency:EUR, date, date:long (short/medium/long/full), time, time:medium, datetime. Anything else is Python's own format spec ({x:.2f}). A value that does not fit its specifier is logged and the text is shown unformatted rather than crashing the screen.

Events

A synchronous event bus decouples UI from application logic. Each callback receives an immutable Event with a name, optional source, and get(key, default) method for its payload. app.on() returns a subscription handle that can be cancelled individually.

# framework events
app.on("app:start",     lambda e: ...)
app.on("app:stop",      lambda e: ...)
app.on("app:render",    lambda e: ...)
app.on("app:locale",    lambda e: ...)   # system language changed; e.source = "uk-UA"
app.on("screen:change", lambda e: print(e.source))

# your own events
app.events.emit("cart:updated", source="CartScreen", count=3)
app.on("cart:updated", lambda e: print(e.get("count")))

subscription = app.on("x", handler)
subscription.cancel()          # removes THIS subscription only

# remove handlers
app.off("cart:updated")                 # removes all, returns count
app.off("cart:updated", handler)        # every registration of handler
app.off("cart:updated", self.on_cart)   # bound methods work too
app.events.off_all("cart:updated")      # same as off(name), via EventBus

app.on("event", None) raises TypeError immediately instead of failing silently later. Handlers are compared with ==, so off() recognises a bound method even though self.on_cart is a new object each time. If the same function is subscribed twice (two screens), each Subscription.cancel() removes only its own registration. Inside a screen, self.on(...) is cancelled for you when the screen unmounts.

An exception inside one handler is logged and never prevents the others from running.

Timers

Schedule work without importing threading. Callbacks run on the UI side, like a button handler, so a tick can update widgets directly and draws one frame; the same code runs on desktop and device. For blocking work — a network poll — pass background=True and hand results over with app.dispatch() (see Threads and the UI).

# every second — drive a clock, poll a sensor, tick a game
ticker = app.set_interval(1000, self.on_tick)

# once, after a delay — dismiss a splash, auto-save
app.set_timeout(250, splash.dismiss)

# stop early
ticker.cancel()

Every call returns a TimerHandle with .cancel() and .cancelled. An exception inside a callback is logged and does not stop a repeating timer. All timers are cancelled automatically when the app stops, but you should still cancel a repeating timer in on_unmount() so a popped screen does not keep ticking:

def on_unmount(self) -> None:
    self.ticker.cancel()

Scheduler is the lower-level service behind these methods. App code should normally use app.set_interval() and app.set_timeout() so timer callbacks follow the app's event-loop and lifecycle rules.

Intervals do not drift

Ticks are scheduled against a fixed timeline — tick n is due at start + n × interval — so the time your callback spends working is not added to the next wait. A one-second timer is still on the second an hour later, which matters for clocks, metronomes and games.

app.set_interval(1000, self.tick)                          # aligned (default)
app.set_interval(1000, self.poll, drift_correction=False)  # fixed pause between runs

Deadlines missed while the device was asleep are skipped rather than fired as a burst, so a metronome stays in phase instead of stuttering to catch up. Use drift_correction=False for a poller that must not overlap itself.

Configuration reference

Everything lives in pymobile.toml (or a [tool.pymobile] table inside pyproject.toml).

[app]
# --- identity ---
name = "My App"                 # shown under the launcher icon
package = "com.example.myapp"   # reverse-DNS, lowercase segments
version = "1.0.0"
version_code = 1                # integer; must increase for each Play upload

# --- entry point ---
entrypoint = "main.py"
source_dir = "."

# --- Android platform ---
min_sdk = 24                    # Android 7.0 — the lowest CPython 3.14 runs on
target_sdk = 35                 # Android 15
orientation = "portrait"        # portrait | landscape | sensor | user

# Every permission requested at runtime must be listed here.
permissions = [
    "android.permission.INTERNET",
    "android.permission.VIBRATE",
    "android.permission.POST_NOTIFICATIONS",
]

# --- resources ---
icon = "assets/icon.png"        # optional; default icon used otherwise
allow_backup = false            # keep the private store out of cloud/adb backups

# --- build ---
abis = ["arm64-v8a"]
output_dir = "apk"                # not "build": that name is in most .gitignore files
optimize = false                # ship bytecode instead of sources (needs Python 3.14 on the
                                # build host, or PYMOBILE_PYTHON pointing at it)
strip_debug = true              # -OO: drop docstrings and asserts
exclude = ["docs/**", "secrets/**"]   # added to the built-in defaults
exclude_only = false                    # true = use exclude as written
Key Default Meaning
name PyMobile App display name
package org.pymobile.app unique application id
version 0.1.0 user-visible version
version_code 1 internal build number
entrypoint main.py module to execute
source_dir . root of your sources
min_sdk 24 oldest supported Android; lower values are raised to 24 with a warning
target_sdk 35 Android version you target
orientation portrait screen orientation
permissions ["…INTERNET"] manifest permissions
icon (none) path to a square PNG
allow_backup false let Android back up the app's private data
abis ["arm64-v8a"] architectures
output_dir apk where the APK is written (used to be build; the build warns when an older APK is still sitting there)
optimize false package .pyc when enabled; for --native the bytecode must match the device's Python 3.14 — the build uses the running interpreter when it is 3.14, or a python3.14/PYMOBILE_PYTHON interpreter when the host differs, and only falls back to sources with a warning when neither exists (which is why the init template ships optimize = false)
strip_debug true compile with -OO
exclude (none) glob patterns to skip, added to the built-in list (**/__pycache__/**, **/*.pyc, **/tests/**, tests/**, **/test_*.py, .git/**, .venv/**, venv/**, build/**, dist/**, apk/**)
exclude_only false true = exclude replaces the built-in list (advanced; the build then warns if output_dir would ship itself)

Every value is validated before the build starts, and each error carries a fix:

✗ Invalid package name 'Bad_Package'
  hint: Use reverse-DNS with lowercase segments, e.g. com.example.myapp

exclude adds to the built-in patterns: writing exclude = ["docs/**"] never drops the build/** rule, so the output directory (and the previous APK inside it) is not packaged. The default apk/ is excluded for the same reason. exclude_only = true turns that off and the build then warns when it can see that output_dir would ship itself. The defaults are exported as pymobile.core.config.DEFAULT_EXCLUDE.

Inspect the resolved configuration with pymobile info or pymobile info --json. In Python, load_config() reads the configuration from the current project directory and returns a validated ProjectConfig. Pass a TOML file or a directory to load_config(path) when loading another project:

from pymobile import ProjectConfig, load_config

config: ProjectConfig = load_config()
print(config.name, config.package, config.effective_min_sdk)

Building an APK

Startup validation

Native builds execute trusted app startup code on the desktop stub in a child process by default, before packaging or reusing a cached APK. A missing screen, startup exception, or 10-second timeout fails the build. Structural builds can opt in with --check-startup.

The framework's default storage is temporary, but this is not a security sandbox: explicit file writes and network calls still happen. For Android-only startup, prefer a desktop guard. After independent device testing you can explicitly bypass the check with --skip-startup-check; the build prints an unverified-launch warning and performs only the advisory AST scan. Passing and bypassing the desktop check are not substitutes for Android-device testing.

Build mode / flag Startup behaviour
build --native validate startup by default, including before a cache hit
build structural packaging only; do not execute startup by default
build --check-startup also validate a structural build
build --native --skip-startup-check explicit bypass with an unverified-launch warning

The check and skip flags cannot be combined. The Python APIs follow the same native default: build_apk(config, native=True) and BuildPipeline(config, native=True).run(). check_startup=True/False explicitly overrides it; None uses the build-mode default. A failed check stops with a message such as Startup check failed: The app rendered nothing. and exit code 1 rather than a success message for a non-starting APK.

Build commands

pymobile build --native                    # incremental
pymobile build --native --clean            # ignore the cache
pymobile build --native -v                 # per-stage timings
pymobile build --native --icon logo.png    # override the icon
pymobile build --native --output dist      # different directory
pymobile build --native --no-optimize      # ship .py for debugging
pymobile build --native --minimal-stdlib   # drop desktop-only stdlib
pymobile build --check-startup             # also validate a structural build
pymobile build --native --no-ssl           # drop OpenSSL (no HTTPS)
pymobile build --native --abi x86_64       # for the emulator

Without --native you get a lightweight structural package used for quick checks. It does not install on a device.

After startup validation, a build with unchanged inputs can reuse its APK:

✓ up to date: my-app-1.0.0.apk (16.6 MB)

The cache tracks application sources, configuration, icons, project-local Java and packaged framework inputs. The native startup check still executes before cache reuse; a cached APK cannot turn an invalid startup into a successful build. Native builds that include the full stdlib print a size advisory recommending --minimal-stdlib. The default is unchanged so desktop-only imports are not silently removed from existing apps; test any reduced build against your app.

Inside the APK:

AndroidManifest.xml          generated from your config
classes.dex                  launcher activity and the view renderer
resources.arsc               compiled resources
lib/arm64-v8a/*.so           CPython, OpenSSL, SQLite, the JNI bridge
assets/app/                  your code and the pymobile package
assets/python/               standard library and CA certificates
res/mipmap-*/icon.png        icons, five densities
META-INF/                    signature (v2+v3)

Builds are reproducible: identical inputs produce an identical APK payload. Every zip entry carries a fixed timestamp, so the archive does not change with the clock; the signature block itself (META-INF/*.RSA) is produced by apksigner and is the one part that may differ between two runs. The file is written to a temporary path and moved into place, so an interrupted build never leaves a corrupt artifact.

Running on the emulator (x86_64)

The Android Studio emulator runs x86_64 system images, and an arm64 APK does not start there. Build an x86_64 one — the prebuilt bridge ships for both architectures, so still no NDK:

pymobile build --native --abi x86_64       # → build/my-app-1.0.0-x86_64.apk
pymobile install --abi x86_64              # uses adb; auto-selects the only connected device

--abi overrides abis from pymobile.toml for one build. The emulator APK gets an -x86_64 suffix so it never overwrites the phone build. The minimal SDK install includes adb but not a virtual device. To use PyMobile's optional emulator instead of Android Studio, install its multi-GB image (still no NDK), then start the default AVD:

pymobile setup-sdk --with-emulator
# Terminal 1 — leave this running; it creates the default AVD on first start.
pymobile emulator start
# Terminal 2 — after Android finishes booting:
pymobile install --abi x86_64

pymobile emulator create --name NAME and pymobile emulator list manage additional AVDs; pass --sdk PATH to select a non-default SDK (it overrides ANDROID_HOME). A phone with USB debugging enabled works too. Use pymobile install --device SERIAL when multiple devices are connected, and adb logcat -s pymobile python to inspect app output. The emulator requires hardware virtualization (KVM on Linux); it is optional and can need several additional GB of storage.

Signing

Android installs an update only if it is signed with the same key as the installed app.

Debug builds are signed with a per-app key created on the first build in ~/.pymobile/keystores/<package>-debug.jks — outside build/, so pymobile clean and build --clean keep the signature. Set PYMOBILE_KEYSTORE_DIR to share the key between machines or CI runs (store it as a CI secret). A key left in build/ by pymobile ≤ 0.7.3 is adopted automatically.

Release builds use your own keystore. Pass the passwords through the environment, not the command line (arguments end up in shell history and ps):

export PYMOBILE_KS_PASS='…'          # keystore password
export PYMOBILE_KEY_PASS='…'         # key password (defaults to the keystore's)
pymobile build --native --keystore release.jks --key-alias upload

--ks-pass / --key-pass still work but print a warning. Keep the keystore and its passwords backed up: without them you cannot publish updates.

Size

A hello-world APK is 16.6 MB, down from 21.6 MB in 0.2.0. The official CPython Android runtime ships every support library twice — libcrypto.so and libcrypto_python.so are byte-identical, and only the _python names are actually linked — so 5 MB of each APK was the same three libraries repeated. That is fixed for every build; no flag needed.

Two opt-in flags trim further:

Flag Saves Cost
--minimal-stdlib ~1.7 MB no pydoc, unittest, venv, pdb, xmlrpc on device
--no-ssl ~4.7 MB no HTTPS at all — HttpClient over TLS stops working

With both, the same app is 11.7 MB. --no-ssl only makes sense for an app that talks to nothing, or over plain HTTP on a local network.

21.6 MB   0.2.0
16.6 MB   0.3.0                              duplicate libraries removed
11.7 MB   0.3.0 --minimal-stdlib --no-ssl

Application icon

icon = "assets/icon.png"

Provide a square PNG, JPG or WebP — 512×512 works best. It is resized into all five densities (48, 72, 96, 144 and 192 px). Install the icons extra for high-quality resampling:

pip install "pymobile-framework[icons]"

Without it the icon is copied unscaled; the build still succeeds. With no icon configured, a bundled default is used, so a build never fails over a missing asset:

The bundled PyMobile launcher icon

(The PyMobile mark is also the icon of anything built with pymobile init before you replace it — icon = "assets/icon.png" is all it takes.)

Installing on a phone

Without a cable: copy the .apk to your device through cloud storage or a messenger, open it there and allow installation from unknown sources.

Over USB, with USB debugging enabled:

adb install -r build/my-app-1.0.0.apk

adb lives in ~/.andro/sdk/platform-tools/.

Debugging

Read the installed framework version with pymobile.__version__; include it in bug reports and compatibility diagnostics:

import pymobile

print(pymobile.__version__)

Everything your app prints, including tracebacks, goes to logcat:

adb logcat -s pymobile pymobile.stdout pymobile.stderr
Tag Contents
pymobile framework and renderer messages
pymobile.stdout your print() output
pymobile.stderr exceptions and tracebacks

If a single widget fails to render, it is replaced by red text naming the error while the rest of the screen keeps working — on the device and in every desktop preview alike. The same applies to a callback that raises: the failure is logged with its traceback and the app stays alive, so one bad handler cannot close the window.

Diagnostics

from pymobile import get_diagnostics

info = get_diagnostics()
# {"framework_version": "0.10.2", "platform": "android",
#  "python": "3.14.0", "log_level": "debug", "handlers": [...]}

File logging

App("My App", log_level="debug", log_file="app.log")

Testing your app

pip install pymobile-framework ships a pytest plugin, so a test of your app needs no scaffolding: an app on a recording stub bridge, storage in a temporary folder, a driver that walks the screens like a user, and screenshot-style snapshots of a screen's text picture. The fixtures are there as soon as pymobile is installed (with pytest 7 or newer) — no conftest.py, nothing to import:

Fixture What you get
pymobile_session app + stub bridge + driver, set up and torn down for you: .start(screen), .app, .bridge, .driver, .screen
pymobile_app the App (created, not running — app.run(FirstScreen()))
pymobile_bridge the recording StubBridge: calls_named(...), notifications, last_tree
pymobile_driver a Driver: open, press, change, back, navigate, find
pymobile_snapshot compares the current screen's text picture with a golden file
pymobile_png compares the current screen's mockup picture with a golden PNG — catches colour changes the text picture cannot
def test_the_quiz_flow(pymobile_session):
    session = pymobile_session
    session.start(Menu())
    session.driver.navigate("Menu.start, Quiz.answer=42, Quiz.next")   # press, type, press
    assert session.driver.find("score").text == "42/10"


def test_the_menu_looks_right(pymobile_session, pymobile_snapshot):
    pymobile_session.start(Menu())
    pymobile_snapshot()            # snapshots/test_menu__test_the_menu_looks_right.txt


def test_the_menu_keeps_its_colours(pymobile_session, pymobile_png):
    pymobile_session.start(Menu())
    pymobile_png()                 # snapshots/test_menu__test_the_menu_keeps_its_colours.png


def test_open_a_screen_directly(pymobile_session):
    pymobile_session.start(Menu())
    pymobile_session.driver.open("ResultScreen", score=7)     # by name, with arguments
    assert pymobile_session.screen.score == 7

Navigation in tests. driver.press(id), driver.change(id, value) (types into a TextInput, picks a Dropdown option, sets a Slider, flips a Switch with True/False), driver.back() and driver.navigate("Menu.start, Quiz.next") all go through the same path as a real tap, so callbacks, navigation and redraws run exactly as on the phone. A step is [Screen.]widget[=value]; the Screen. prefix asserts where the step is taken, so a route that drifted fails at the step that matters. A wrong widget id names the closest ones (Did you mean 'start'?), and pressing a disabled widget or a Label is an error, as it would be for a finger. If your code builds its own App (a main()), call it and then Driver.attach().

Renderer IDs. driver.tree() and pymobile preview --ids expose qualified IDs such as 1:save. driver.find("1:save") and driver.press("1:save") accept the current generation's ID; raw IDs such as "save" remain supported. Use the prefix actually returned by the tree/preview rather than hard-coding 1. After navigation, re-read the tree: an ID from a retired screen generation raises WidgetNotFoundError, even when the new screen also has a widget named save.

Snapshots. pymobile_snapshot() renders the screen with render_ascii and compares it with snapshots/<test module>__<test name>.txt next to the test (pymobile_snapshot(widget, "name") picks the file; a second unnamed check in one test gets _2). A missing file is written and the test passes with a warning — unless the CI environment variable is set, where a snapshot nobody committed is a failure. A changed screen fails with a diff; accept it with pytest --pymobile-update-snapshots (or PYMOBILE_UPDATE_SNAPSHOTS=1) and commit the file.

pymobile_png(...) is the same workflow for the picture: the screen is drawn with the mockup renderer and compared byte-for-byte with a golden PNG, so a button that quietly turned grey or a chip that lost its background fails — changes the text picture cannot see. It takes the same name, the same --pymobile-update-snapshots flag and the same CI rule, plus two escape hatches for a font that renders one pixel differently elsewhere: tolerance=8 (per channel) and max_diff_ratio=0.001. A difference writes <name>.diff.png and <name>.new.png next to the golden file. It needs Pillow (pip install 'pymobile-framework[icons]'), and lives in pymobile.testing (assert_png_snapshot) for use without pytest.

Isolation. After every test the app is stopped, the process-wide bridge is reset and the language the test switched to is undone; the store lives in tmp_path. The plugin is active automatically; turn it off with pytest -p no:pymobile.testing.plugin. Everything behind the fixtures is importable without pytest (from pymobile.testing import app_session, Driver) for other runners.

Without the fixtures

StubBridge records every platform call, so no emulator is needed and tests run in milliseconds.

from pymobile import App, Button, Column, Label, Screen, Widget
from pymobile.core.bridge import StubBridge


class ProfileScreen(Screen):
    def build(self) -> Widget:
        # Save explicit references to widgets for direct test access
        self.status_label = Label("Offline")
        self.login_btn = Button("Log In", on_press=self.on_login)
        return Column(self.status_label, self.login_btn)

    def on_login(self) -> None:
        self.status_label.text = "Online"
        self.app.notify("Welcome", "You have logged in successfully")


def test_login_updates_ui_and_notifies():
    bridge = StubBridge(verbose=False)
    app = App("Test", bridge=bridge)
    screen = ProfileScreen()
    app.run(screen)

    # Trigger action directly on the widget reference
    screen.login_btn.press()

    # Verify UI state change
    assert screen.status_label.text == "Online"

    # Verify platform notification was sent via StubBridge
    assert bridge.calls_named("notify")
    spec = list(bridge.notifications.values())[0]
    assert spec.title == "Welcome"


def test_permission_denial_is_handled():
    denying = StubBridge(grant_permissions=False, verbose=False)
    app = App("Test", bridge=denying)
    assert app.permissions.request("CAMERA") == {"android.permission.CAMERA": False}

Useful members: calls, calls_named(name), notifications, granted, reset(), and the grant_permissions=False constructor flag.

Every platform call is recorded in bridge.calls under one of these names, so assertions never guess:

Recorded name Written by
notify app.notify(...)
cancel_notification app.notifications.cancel(...)
vibrate app.vibrate(...)
vibrate_pattern app.vibration.pattern(...) — and every preset(...), presets being patterns
cancel_vibration app.vibration.cancel()
toast bridge.toast(...)
request_permissions app.permissions.request(...)
render every frame pushed to the platform

Note the fourth row: a haptic assertion is bridge.calls_named("vibrate_pattern"), not "vibrate" — preset("success") plays a pattern.

Error handling

Every exception derives from PyMobileError and carries a message and an actionable hint.

from pymobile.errors import PyMobileError, NetworkError, ConfigError

try:
    response = client.get("/items")
except NetworkError as error:
    print(error.message)   # what happened
    print(error.hint)      # how to fix it
except PyMobileError:
    ...                    # catch anything from the framework
Exception Raised when
ConfigError configuration missing or invalid
NetworkError request failed, host unreachable, invalid JSON
PermissionDeniedError the user declined a permission (PermissionError_ remains a compatible alias)
ResourceError an icon or template could not be read
BridgeError a call into Android failed
PlatformError feature unavailable on this platform

The CLI prints only the message and hint. Add -v for a full traceback.

Desktop preview

For interactive, device-free testing use pymobile run --gui (Tk window) or pymobile run --web (local browser). pymobile preview renders a screen into a picture right on your laptop — no emulator, no phone. It runs your entry point with the stub bridge and draws the resulting widget tree:

pymobile preview            # text picture in the terminal
pymobile preview --ids      # annotate each widget with its id
pymobile preview --png ui.png   # a mockup of the screen as the phone draws it (needs Pillow)
pymobile preview --png ui.png --size 360x640 --theme dark
pymobile preview --png ui.png --text    # the text picture as an image (the pre-0.8 output)

--theme dark switches the application itself (App.set_theme("dark")) before the tree is built, so a build() that reads self.app.theme["SURFACE"] lays out and paints in that palette — the mockup is never asked to draw a light tree with dark colours. Desktop previews show the final state; screen and visibility motion runs in the Android renderer, not in the ASCII/PNG mockup.

A screen other than the first

By default the picture is the screen App.run() starts with. To see a screen deeper in the app without editing main.py:

pymobile preview --screen ResultScreen                          # a Screen subclass of the project
pymobile preview --screen ResultScreen --set score=7 --set total=10   # constructor arguments
pymobile preview --screen ResultScreen --args '{"score": 7}'    # the same, as JSON (bash, zsh)
pymobile preview --navigate "Menu.start"                        # press the way there
pymobile preview --navigate "Menu.start, Quiz.answer=42, Quiz.next" --png result.png
pymobile preview --tab Stats                                    # pick a bottom-navigation tab
pymobile preview --navigate "@Stats"                            # the same, as a route step

--screen NAME pushes that screen on top of the first one (the class name, or module.Class when two screens share a name). The name is looked up among the classes the entry point imported; when it is missing, every project module that defines a …Screen class is imported and the lookup is retried, so a screen in a lazily imported module is found too. --set NAME=VALUE, repeatable, passes one constructor argument: the value is read as JSON when it parses (7, true, [1, 2]) and is plain text otherwise (--set player=Anna). It needs no quoting, so it works in every shell — unlike --args, whose JSON needs its double quotes to arrive intact: fine in bash and zsh, but cmd.exe and Windows PowerShell 5.1 strip them. --args takes a JSON object for keyword arguments or a list for positional ones, and a --set overrides the same name.

--navigate walks a route like a user: each step is [Screen.]widget (press it), [Screen.]widget=value (type into a TextInput, pick a Dropdown option, set a Slider, flip a Switch with true/false) or <back>. The optional Screen. prefix asserts where the step is taken. @Stats selects a tab in the screen's bottom navigation by its label or value — tabs are built inline and have no id a route could name, so --tab Stats exists as the short spelling. The steps are echoed (Menu.start → Quiz), and a mistake names what is available — no screen called 'Resulz'. Did you mean 'Result'?, no widget with id 'strt'. Did you mean 'start'?. Both flags work with --png, --ids, --text, and on pymobile run (including --gui and --web, which then open on that screen) and pymobile watch, where every reload lands on the screen you are working on. The same engine backs the test fixtures — see Testing your app.

--png draws a mockup: the tree is laid out with the rules of the Android renderer (columns stretch their children, rows wrap them, Expanded shares the free space, Stack overlays, Grid has equal columns, Wrap starts a new line when the row is full, a SegmentedButtons bar that does not fit is cut at the edge because it scrolls) and painted with Material-style widgets in your theme's colours — raised grey buttons, underlined text fields, switches, list rows, dialogs over a dimmed screen and the snackbar — under a status bar and an action bar with the app name. Sizes are in dp, so spacing and proportions match the device.

It is an approximation, not a screenshot: the phone uses Roboto while the mockup uses the sans-serif face your machine has, and system colours (the action bar, the tint of switches) vary between Android versions and vendors — the mockup uses your PRIMARY colour for them. By default the picture is 360 dp wide and as tall as the content, so a long scrolling screen is shown whole; --size 360x640 shows exactly the first screenful. From Python:

from pymobile.core.ui.preview import render_mockup
render_mockup(bridge.last_tree, "home.png", theme="dark", height=640)
image = render_mockup(screen.root)       # without a path: a PIL.Image

The text PNG (--text) uses the first Unicode TrueType face it finds on the system, so Cyrillic, Greek and accented text render as text rather than boxes. Point PYMOBILE_PREVIEW_FONT at a .ttf to choose your own. The canvas is measured with the real glyph advances of that face, so long lines are never clipped. Glyphs the chosen face lacks (emoji on a bare Linux container, for instance) are patched in from a symbol face such as Symbola or Segoe UI Symbol when one is installed; anything still uncovered is logged once with a hint instead of failing silently.

The text picture shows the real layout — Row children sit side by side, ProgressBar is drawn as a filled bar, Switch shows its state:

┌──────────────────────────────┐
│ Pomodoro Focus               │
├──────────────────────────────┤
🎯 Focus
25:00
[░░░░░░░░░░░░░░░░] 0%
(Start)  (Reset)
Vibrate when done  [●] on
└──────────────────────────────┘

The same renderer is importable, so tests and notebooks can snapshot a screen too:

from pymobile.core.ui.preview import render_ascii
print(render_ascii(app.screen.build(), title="Home"))

An interactive window

pymobile run --gui opens a real window instead of printing once. Buttons run their callbacks, switches and text fields feed events back through the same path the phone uses, and navigation works — a back button appears as soon as the stack is deeper than one screen. Toasts and vibration show up in the status strip.

pymobile run --gui

It uses the standard-library Tkinter interface; some Linux distributions need the optional python3-tk OS package. An available Tk import does not imply an available display. If run --gui cannot open a window it reports an actionable error; use preview, watch or run --web on a headless machine. Trees are patched into the existing widgets when the structure has not changed, so typing in a field does not lose focus.

In a browser

pymobile run --web serves the same interactive preview over HTTP, which is what you want on a remote machine, in a container, or when Tk is unavailable:

pymobile run --web                 # banner prints http://127.0.0.1:8765;
                                   # default --host 127.0.0.1 is loopback only
pymobile run --web --port 9000
pymobile run --web --host 0.0.0.0  # listen on all interfaces (containers, SSH)

An exposed preview requires the session token printed in the URL, and a request that states a foreign Origin is refused — a page on another site must not drive the app. Behind a proxy, a tunnel or a portal that embeds the preview in an iframe, opt out explicitly:

pymobile run --web --host 0.0.0.0 --allow-origin "https://portal.example" --embed
pymobile run --web --host 0.0.0.0 --no-token        # the gateway authenticates
pymobile run --web --host 0.0.0.0 --token "$SECRET" # a token the proxy knows

--allow-origin is repeatable ('*' trusts every origin), --embed drops X-Frame-Options, and --no-token serves without a session. Each one weakens a protection, so none is enabled by default; use them only behind something that authenticates callers.

The page is plain HTML built from the same serialised tree the phone receives, so it cannot drift from the real renderer. Buttons, switches and text fields post back to the app, and the page polls for updates, so a timer tick appears on its own. Widget ids are carried into data-wid attributes, so the browser inspector tells you exactly which widget a node is.

Hot reload

pymobile dev is the loop most people want: it opens a real window with the running app and reloads it whenever a source file changes, so you edit in your editor and look at the result — no Ctrl+C, no re-run.

pymobile dev                    # GUI window + reload on save
pymobile dev --screen Settings  # start on another screen
pymobile dev --screen Result --set score=7  # constructor arguments, like `preview`

It needs Tk and a usable display. If Tk is missing or Tk imports but opening the window fails, dev explains the problem and falls back to text watch. The fallback keeps the selected screen/constructor arguments and valid watch defaults; Ctrl+C stops it normally over SSH. This automatic fallback belongs to dev, not run --gui.

pymobile watch re-renders every time you save:

pymobile watch                  # text picture on every save
pymobile watch --png ui.png     # write a mockup instead (--text for the text picture)
pymobile watch --interval 0.1   # poll faster

Editing an imported helper module counts too, not just main.py. A syntax error prints the exception and keeps watching, so a half-typed line does not end the session.

• watching /home/me/pomodoro — press Ctrl+C to stop
✓ rendered in 12 ms

• changed: main.py
✓ rendered in 11 ms

CLI reference

Command Description
pymobile init [dir] create a project (-n name, -p package, -f force)
pymobile setup-sdk install the Android toolchain (--with-ndk, --with-emulator, --path)
pymobile emulator start launch/create the optional local x86_64 AVD (create, list, --sdk)
pymobile build --native validate startup and build a signed APK (--minimal-stdlib, --no-ssl, --abi x86_64; explicit --skip-startup-check bypass)
pymobile build --check-startup also validate startup when producing a structural, non-installable package
pymobile install [APK] install an APK using adb (--abi, --device, --sdk)
pymobile run run the app on your machine (--gui window, --web browser)
pymobile dev GUI with live reload; text-watch fallback when Tk/display is unavailable (--screen, --args, --set, --ids, --interval)
pymobile watch re-render on every save (--png, --text, --ids, --interval)
pymobile preview draw a screen as a picture (--png, --size, --theme, --text, --ids)
pymobile check-ui static accessibility/layout/contrast audit (--width, --min-touch-target, --theme, --strict, --json)
pymobile widget add TYPE scaffold a project-local Python widget and auto-compiled Java renderer (-p title -p value:int)
pymobile widget-java TYPE print the shared ViewBuilder.java branch guide (-p title -p value:int, --out FILE; framework contributors)
pymobile info show the resolved configuration (--json)
pymobile doctor check environment and project health
pymobile clean remove build artifacts

run, dev, watch, preview and check-ui also take --screen NAME (with --set NAME=VALUE or --args JSON) and --navigate "Menu.start, Quiz.next" to open on a screen other than the first — see Desktop preview.

Global flags -v (verbose) and -c PATH (project directory) work both before and after the sub-command.

Extending the framework

The quickest route for a project-local widget is the scaffold command:

pymobile widget add BarChart -p title -p value:int -p values:list

It creates widgets/bar_chart.py (a ready-to-import, registered Python widget) and java/org/pymobile/app/widgets/BarChartRenderer.java (a starter Android renderer). Use it from Python with from widgets.bar_chart import BarChart. The Java starter displays its props in a labelled TextView; replace its TODO with the actual Android view and implement its update() method if needed.

Project Java files are compiled automatically into the APK as a local java/ overlay. A normal pymobile build --native compiles the framework and overlay Java sources, fingerprints project Java for caching, and verifies the renderer class made it into classes.dex — without editing the installed PyMobile package or setting a Java-build environment switch. A broken overlay is a build error, never a silent fallback to an older dex. The renderer implements WidgetRenderer and is loaded by its class name convention (org.pymobile.app.widgets.<Type>Renderer).

For full control, implement Widget yourself and register the type; or use pymobile widget-java TYPE to print the older in-framework ViewBuilder.java branch guide. pymobile widget add is the recommended project-local path; the branch guide is for framework contributors who intentionally change the shared renderer.

Native builds check the dex for the custom widget renderer before signing, so a stale prebuilt dex or a typo cannot silently leave a blank Android widget. unknown_types(screen.to_dict()) can assert that a screen contains no unknown types in a device-free test. If the widget needs no new native behavior, compose it from existing widgets (for example, Row, ProgressBar and Expanded) and skip the Java renderer entirely. For a preview-only type, declare register_widget_type("BarChart", android=False, web=True); the desktop/browser can draw it, but it is not rendered on Android.

A declared type still shows up as <BarChart> in the ASCII, browser and Tk previews until you register a drawer for it — no more if app.platform == "android" branches in application code:

from pymobile import register_preview_renderer

register_preview_renderer("BarChart", "ascii", lambda node: ["[bar chart]"])
register_preview_renderer("BarChart", "web", lambda node: '<div class="chart"></div>')

def draw_tk(preview, parent, node, background):     # preview.tk is tkinter
    preview.tk.Label(parent, text="bar chart").pack()

register_preview_renderer("BarChart", "gui", draw_tk)

The function receives the serialised node (type, id, props, style, children) and returns lines of text, HTML markup or nothing (for Tk).

Wrap is an example of a framework-level widget: class Wrap(Container) in layout.py, a WidgetCapability row in registry.py, support in the four renderers (the Android ViewBuilder facade and its collaborators, web.py, gui.py, preview.py/mockup.py), and tests for all of them.

A new Android API — add a method to Bridge, implement it in AndroidBridge and StubBridge, wrap it in a small class under core/api/.

A new build stage — write a method and add one line to BuildPipeline.run(); timing and logging come for free.

A new platform — implement Bridge once; nothing else changes.

Limitations

  • Two ABIs: arm64-v8a (phones) and x86_64 (the emulator), one per APK — pymobile build --native --abi x86_64. 32-bit devices are not supported, and there is no iOS backend.
  • APK size is about 16.6 MB (11.7 MB with --minimal-stdlib --no-ssl), dominated by the interpreter and standard library.
  • Android 7.0 (API 24) minimum. The python.org build of CPython 3.14 requires it (earlier pymobile releases declared API 21, but the app could not start there). A min_sdk = 21 left in an older pymobile.toml still builds: the APK declares 24 and the build prints a warning.
  • A new custom type_name needs an Android renderer. Prefer pymobile widget add TYPE for a project-local renderer compiled with your app. A built-in framework widget needs dispatch/capability support and a rebuilt bundled dex. Without renderer support a widget is a placeholder on the phone; native build checks fail rather than silently accepting missing support. See Extending the framework.
  • Desktop startup validation is not Android execution. Android-only startup can need a guard or an explicit, warned bypass; successful validation and APK signing do not replace installing and exercising the app on Android.
  • Translation catalogues are flat: "stats.balance" is one key, and nested JSON sections need flatten=True (see Languages).

Known issues

Current known limitations are tracked in CHANGELOG.md and on GitHub Issues. If you hit something new, report it there with a reproducer (main.py + pymobile.toml) and the device or platform. Bug reports with a regression test land faster.

Versioning and deprecation policy

PyMobile follows Semantic Versioning 2.0.0: MAJOR.MINOR.PATCH. This page is the promise; the changelog is where each release keeps it.

What the public API is

Everything this policy protects:

  • every name importable from pymobile (pymobile.__all__) and from pymobile.testing;
  • the modules and functions this README documents by path (pymobile.core.ui.preview.render_ascii, pymobile.core.bridge.StubBridge, pymobile.core.validation …);
  • the pymobile command — sub-commands, flags and exit codes;
  • the keys of pymobile.toml;
  • the serialised widget tree a renderer receives: type, id, props, style, children, and the type names and props of the built-in widgets;
  • the Python versions in the package classifiers (dropping one is a minor-release change, announced in the changelog).

Not covered: names that start with an underscore; anything the README does not document; how a preview looks (pixels, fonts, the text picture's exact layout); log and warning wording; build timings; the internals of classes.dex and libpymobile.so (only their protocol with Python is API).

What each release may contain

Release Contains
PATCH (0.9.1) Bug fixes only. No API change, no new deprecation.
MINOR (0.10.0) New features that keep old code working, and new deprecations. Before 1.0 a minor release may also make a breaking change — it is listed under Changed or Removed in the changelog.
MAJOR (2.0.0) Removal of what was deprecated, and other incompatible changes.

Until 1.0, PyMobile is alpha (see the note at the top): the API can change between minor releases. What does not change is how things go away — see the next section. From 1.0 on, an incompatible change to the public API happens only in a major release.

The deprecation cycle

Nothing in the public API is removed without going through three steps:

  1. Announce. A minor release adds the replacement and marks the old spelling deprecated. Using it emits a PyMobileDeprecationWarning that names the replacement and the release that will remove it; the changelog lists it under Deprecated; the documentation stops recommending it.
  2. Keep. The deprecated spelling keeps working, unchanged, for at least one full minor release after the one that announced it: deprecated in 0.9, it still works — and warns — in 0.10.
  3. Remove. Only after that, in the release the warning named. From 1.0 on, removals happen only in a major release, so a deprecation announced in 1.3 is removed in 2.0 at the earliest.

The one exception is a security or data-loss bug, which may change behaviour at once; the changelog says so under Security.

Seeing the warnings

PyMobileDeprecationWarning is a DeprecationWarning: Python shows it for code you run yourself (a main.py run as a script — the message carries the file and line of your call) and pytest lists it in its warnings summary. To find every use before an upgrade, or to keep them out for good, turn it into an error in CI:

pytest -W error::pymobile.deprecation.PyMobileDeprecationWarning

# pyproject.toml
[tool.pytest.ini_options]
filterwarnings = ["error::pymobile.deprecation.PyMobileDeprecationWarning"]

Deprecated now

Deprecated Use instead Since Removed in
max= on Slider, Stepper, ProgressBar, ProgressText, RatingBar; min= on Slider, Stepper maximum=, minimum= 0.9.0 1.0.0
maxlength= on TextInput max_length= 0.9.0 1.0.0
on_change= on Dropdown, SegmentedButtons, BottomNavigation on_select= 0.9.0 1.0.0

Two spellings of one argument are permanent the day the API is frozen, which is why these are retired before 1.0 and why new API gets one name only. The alternative spellings that remain — Storage.exists() next to contains(), RatingBar(value=…) next to rating, then(on_success=…) next to on_done — are documented and are not deprecated.

Pinning

  • Before 1.0: pymobile-framework~=0.9.0 accepts patch releases only; move to the next minor when you have read its changelog.
  • From 1.0: pymobile-framework>=1,<2 is safe.

FAQ

Why doesn't my UI update? It should: assigning to a widget property redraws the screen by itself. If the structure changed — rows added or removed — call self.refresh() to rebuild through build(); a tab or panel that no frame owns uses self.rebuild(). If a form saves and calls pop(), the revealed screen rebuilds automatically. app.notify_data_changed() remains available for explicit invalidation and the data:changed event, but is not required for that save-and-back flow. Preserve input state in screen/model attributes or explicitly owned widgets, rather than only in widgets recreated inside build(). See Updating the screen.

Why does pymobile run show no window? By default it runs your logic through the stub bridge without native views, which is what makes apps testable without an emulator. Use pymobile run --gui for a real, clickable window, pymobile preview for a text picture, or pymobile watch to re-render on every save. See Desktop preview.

Why doesn't a 404 raise an exception? Because it is a valid HTTP response. Use response.ok or response.raise_for_status().

Why is no permission dialog shown? Either the permission is missing from pymobile.toml, or you have already denied it twice and Android has blocked further prompts. See Permissions.

Why don't notifications appear on the device? Two things must both be true: (1) POST_NOTIFICATIONS is in pymobile.toml, and (2) the permission is requested at runtime after the screen is visible. The default APK already creates the notification channel. Also check that notifications are enabled in Settings → Apps → Your App → Notifications. See Notifications.

Why doesn't my button respond? Check enabled — a disabled button ignores taps.

Why does push() raise an error? The same screen object cannot be pushed twice. Create a new instance.

Where did my print() output go? To logcat: adb logcat -s pymobile.stdout.

How do I make the APK smaller? Build with --minimal-stdlib --no-ssl if the app allows it, trim files with exclude, and list a single ABI. optimize = true (bytecode instead of sources) also helps, but only takes effect when the build runs on Python 3.14 — the device's version; elsewhere it is skipped with a warning, which is why new projects start with optimize = false.

Can I keep the config in pyproject.toml? Yes, under [tool.pymobile]. If both files exist, pymobile.toml wins.

Do I need Android Studio? No. pymobile setup-sdk downloads only the command-line tools it needs.

Contributing

git clone https://github.com/Maksum867/PyMobile.git
cd PyMobile
pip install -e ".[dev]"

pytest                  # unit tests
ruff check pymobile     # linting
mypy pymobile           # strict type checking

Internal module map

Area Implementation
CLI cli.py facade/shared helpers; cli_parser.py grammar; cli_preview.py preview/dev/watch/audit; cli_device.py adb/emulator/install
Mockup mockup.py facade; _mockup_colors, _mockup_fonts, _mockup_paint, _mockup_layout, _mockup_widgets, _mockup_chrome; typed _mockup_context contract
Android renderer ViewBuilder.java facade/state owner; ViewContainers, ViewControls, ViewInputs, ViewLists, ViewGestures, ViewStyles, ViewOverlays, ViewUpdates; FlowViews wrapping layout

Keep implementations in the appropriate module rather than regrowing the facades. Regression tests cap these split files at 1000 lines and check source/prebuilt renderer consistency.

Rebuild Java/dex and verify native packaging

The bundled Java launcher needs the SDK build-tools and JDK, not an NDK:

python -m pymobile.compiler.rebuild_dex          # rebuild the bundled classes.dex
python -m pymobile.compiler.rebuild_dex --check  # verify recorded source/dex hashes

The second command needs no SDK. It checks the SHA-256 manifest classes.sources.json, not Android runtime behaviour or cryptographic publisher authenticity. Commit the Java changes, rebuilt dex and updated manifest together. Java source hashing normalises CRLF to LF, so Windows Git checkout conversion does not invalidate provenance; dex hashing remains byte-exact. Quality and publishing workflows run the provenance check.

With the SDK/JDK available, also exercise source-built and prebuilt APKs, cache reuse and v2/v3 signatures (POSIX shell):

PYMOBILE_NATIVE_TESTS=1 python -m pytest pymobile/tests/test_remaining_p_fixes.py

For an actual release, follow maintenance/release gates, including an Android install/runtime test. A successful compile, signature or SDK-free test suite must not be reported as a passed device test.

Rebuild the JNI bridge

This separate step requires pymobile setup-sdk --with-ndk:

# macOS / Linux
PYMOBILE_BUILD_JNI=1 pymobile build --native --clean

# Windows PowerShell
$env:JAVA_HOME = "C:\Users\You\.andro\jdk-17.0.13+11"
$env:PYMOBILE_BUILD_JNI = "1"
pymobile build --native --clean

A change that removes or renames public API goes through the deprecation cycle: keep the old spelling, call pymobile.deprecation.warn_deprecated(...), add a test with pytest.warns(PyMobileDeprecationWarning) and a Deprecated changelog entry (the suite treats every other DeprecationWarning as an error, so the framework itself cannot keep using an old spelling by accident).

Issues and pull requests are welcome.

Documentation

License

MIT — see LICENSE.

Project links

Data verified by PyPI on Oct 29, 2026
Data provided by the project maintainers, verified at the time the release was uploaded to PyPI.

Key dates

PyPI data
Data sourced directly from PyPI's database.
  • Released:
Latest release

1 maintainer

PyPI data
Data sourced directly from PyPI's database.
Avatar for Maksum867 from gravatar.com Maksum867

Credits

Author: Maksym Khlystun

GitHub Statistics

Data verified by PyPI on Oct 29, 2026
The GitHub source repository was provided by the project maintainers and verified by PyPI at the time of upload. Stars, forks, and open issues/PRs are derived from that repository and have not been independently verified.

Provenance

Data verified by PyPI on Oct 29, 2026
Data provided by the project maintainers and verified by PyPI at the time of upload.

Full provenance

All 2 files in this release have provenance metadata.

View provenance details

License expression

MIT
View SPDX License List

Requires

Python >=3.10

Provides Extra

icons android dev

Tags

android apk mobile framework ui compiler

Classifiers

Metadata

Project links

Data verified by PyPI on Oct 29, 2026
Data provided by the project maintainers, verified at the time the release was uploaded to PyPI.

Key dates

PyPI data
Data sourced directly from PyPI's database.
  • Released:
Latest release

1 maintainer

PyPI data
Data sourced directly from PyPI's database.
Avatar for Maksum867 from gravatar.com Maksum867

Credits

Author: Maksym Khlystun

GitHub Statistics

Data verified by PyPI on Oct 29, 2026
The GitHub source repository was provided by the project maintainers and verified by PyPI at the time of upload. Stars, forks, and open issues/PRs are derived from that repository and have not been independently verified.

Provenance

Data verified by PyPI on Oct 29, 2026
Data provided by the project maintainers and verified by PyPI at the time of upload.

Full provenance

All 2 files in this release have provenance metadata.

View provenance details

License expression

MIT
View SPDX License List

Requires

Python >=3.10

Provides Extra

icons android dev

Tags

android apk mobile framework ui compiler

Classifiers

Release files for pymobile-framework 0.10.2

For a detailed explanation of source distributions (sdists) and built distributions (wheels), please see the package formats documentation.

Source distribution (sdist)

Source distribution for pymobile-framework 0.10.2
File Size Uploaded Provenance Actions
pymobile_framework-0.10.2.tar.gz 997.0 kB With provenance Details for pymobile_framework-0.10.2.tar.gz

Built distribution (wheel)

Table of built distributions (wheels) for pymobile-framework 0.10.2
File Interpreter ABI Platform Actions
pymobile_framework-0.10.2-py3-none-any.whl 736.6 kB With provenance Python 3 none any Details for pymobile_framework-0.10.2-py3-none-any.whl

Total release size: 1.7 MB

Release files / pymobile_framework-0.10.2.tar.gz

Download URL pymobile_framework-0.10.2.tar.gz
Size 997.0 kB
Tags Source
SHA-256 checksum
How to use checksums 		d25fb8abf1ebc15852d3b7f216cf5574ea4f7583479d9d78427280655dbc7d9e
BLAKE2b-256 checksum
How to use checksums 		220d90dcb39f1e1fdffc866dbe829b31cf93806d9ed85a475fe6f56a54eb9806
Upload date
Uploaded using Trusted Publishing?
What is trusted publishing? 		Yes
Uploaded via twine/7.0.0 CPython/3.13.16

Provenance

Provenance describes where a file came from. On PyPI, provenance is shared via attestations, which provide a verifiable record of the build or publishing details. View details, limitations and caveats.

PyPI Publish Attestation

PyPI verified that this artifact, at this checksum, originated from the publisher listed below.

Signed by GitHub Actions, verified by PyPI on Oct 29, 2026.

Transparency log
Identity
Publishing platform
GitHub Actions
Publishing repository
github.com/Maksum867/PyMobile
Publishing commit
github.com/Maksum867/PyMobile/tree/d74e4dbd08cf5117c1ce9e4614aa062f5ef91673
Workflow
Publishing configuration
github.com/Maksum867/PyMobile/blob/d74e4dbd08cf5117c1ce9e4614aa062f5ef91673/.github/workflows/publish.yml
Publishing logs
github.com/Maksum867/PyMobile/actions/runs/40926971282/attempts/1
Artifact
Subject
pymobile_framework-0.10.2.tar.gz
SHA-256 checksum
d25fb8abf1ebc15852d3b7f216cf5574ea4f7583479d9d78427280655dbc7d9e Verifying attestations

Release files / pymobile_framework-0.10.2-py3-none-any.whl

Download URL pymobile_framework-0.10.2-py3-none-any.whl
Size 736.6 kB
Tags Python 3
SHA-256 checksum
How to use checksums 		bfce100a60dbe550550bf2f328c3f968871c70b1c135af73fd22a39da5b118c5
BLAKE2b-256 checksum
How to use checksums 		a1ea4b7a8719cf3f118b612e2bb18bffd6b3fc02c47bb674de97731d2223ff82
Upload date
Uploaded using Trusted Publishing?
What is trusted publishing? 		Yes
Uploaded via twine/7.0.0 CPython/3.13.16

Provenance

Provenance describes where a file came from. On PyPI, provenance is shared via attestations, which provide a verifiable record of the build or publishing details. View details, limitations and caveats.

PyPI Publish Attestation

PyPI verified that this artifact, at this checksum, originated from the publisher listed below.

Signed by GitHub Actions, verified by PyPI on Oct 29, 2026.

Transparency log
Identity
Publishing platform
GitHub Actions
Publishing repository
github.com/Maksum867/PyMobile
Publishing commit
github.com/Maksum867/PyMobile/tree/d74e4dbd08cf5117c1ce9e4614aa062f5ef91673
Workflow
Publishing configuration
github.com/Maksum867/PyMobile/blob/d74e4dbd08cf5117c1ce9e4614aa062f5ef91673/.github/workflows/publish.yml
Publishing logs
github.com/Maksum867/PyMobile/actions/runs/40926971282/attempts/1
Artifact
Subject
pymobile_framework-0.10.2-py3-none-any.whl
SHA-256 checksum
bfce100a60dbe550550bf2f328c3f968871c70b1c135af73fd22a39da5b118c5 Verifying attestations

Security for pymobile-framework 0.10.2

Provenance

Provenance describes where a file came from. On PyPI, provenance is shared via attestations, which provide a verifiable record of the build or publishing details. View details, limitations and caveats.

Full provenance

All 2 files in this release have been uploaded with provenance metadata.

Select from 2 files

Attestation for pymobile_framework-0.10.2.tar.gz

PyPI Publish Attestation

PyPI verified that this artifact, at this checksum, originated from the publisher listed below.

Signed by GitHub Actions, verified by PyPI on Oct 29, 2026.

Transparency log
Identity
Publishing platform
GitHub Actions
Publishing repository
github.com/Maksum867/PyMobile
Publishing commit
github.com/Maksum867/PyMobile/tree/d74e4dbd08cf5117c1ce9e4614aa062f5ef91673
Workflow
Publishing configuration
github.com/Maksum867/PyMobile/blob/d74e4dbd08cf5117c1ce9e4614aa062f5ef91673/.github/workflows/publish.yml
Publishing logs
github.com/Maksum867/PyMobile/actions/runs/40926971282/attempts/1
Artifact
Subject
pymobile_framework-0.10.2.tar.gz
SHA-256 checksum
d25fb8abf1ebc15852d3b7f216cf5574ea4f7583479d9d78427280655dbc7d9e Verifying attestations

A note on package security

PyPI is a repository for distributing packages, not a service for auditing them. While third-party security researchers and our staff do their best to detect and remove malicious packages, PyPI cannot guarantee the quality, security or suitability of any given package.

To learn more about protecting yourself from malicious actors, visit our package security documentation.

Release history Release notifications | RSS feed

This release

0.10.2 This release

2 release files Full provenance

0.10.1

2 release files Full provenance

0.10.0

2 release files Full provenance

0.9.6

2 release files Full provenance

0.9.5

2 release files Full provenance

0.9.4

2 release files Full provenance

0.9.3

2 release files Change of provenance

0.9.2

2 release files Full provenance

0.9.1

2 release files Full provenance

0.9.0

2 release files Full provenance

0.8.4

2 release files Full provenance

0.8.3

2 release files Full provenance

0.8.2

2 release files Full provenance

0.8.1

2 release files Full provenance

0.8.0

2 release files Full provenance

0.7.3

2 release files Full provenance

0.7.2

2 release files Full provenance

0.7.1

2 release files Full provenance

0.7.0

2 release files Full provenance

0.6.5

2 release files Full provenance

0.6.4

2 release files No provenance

0.6.3

2 release files No provenance

0.6.1

2 release files No provenance

0.6.0

2 release files No provenance

0.5.1

2 release files No provenance

0.4.0

2 release files No provenance

0.3.0

2 release files No provenance

0.2.0

2 release files No provenance

0.1.1

2 release files No provenance

0.1.0

2 release files No provenance

Anthropic, PBC Visionary sponsor Bloomberg Visionary sponsor Hudson River Trading Visionary sponsor Meta Visionary sponsor NVIDIA Visionary sponsor Microsoft Sustainability sponsor Depot Continuous Integration AWS Cloud computing and Security Sponsor Datadog Monitoring Fastly CDN Google Download Analytics Sentry Error logging StatusPage Status page
