pyqt-frameless-window 0.0.4

PyQt Frameless window to inherit a variety of frameless widget

pyqt-frameless-window

PyQt frameless window

Requirements

• PyQt5 >= 5.15 - to call startSystemMove, startSystemResize which are introduced in Qt 5.15.

Setup

python -m pip install pyqt-frameless-window

Detailed Description

This is the empty window which has no frame. It looks nothing special, but it has a great feature.

It can be movable and resizable. That's not the only feature.

When you place the mouse cursor over the edge of the window, mouse cursor's shape will turn into one of those below based on direction of edge.

CursorShape in Qt Documentations

• Qt.SizeVerCursor

• Qt.SizeHorCursor

• Qt.SizeBDiagCursor

• Qt.SizeFDiagCursor

The window's minimum size is set to inner widget's recommended minimum size.

You can use this as a parent class if you want to make movable, resizable frameless window. This is no use on its own.

If you want to customize the title bar easily than use pyqt-custom-titlebar-setter, which also uses the pyqt-frameless-window.

If you don't need any title bar or min/max/close buttons or something like that, just use this as a parent class of your widget.

It can expand vertically when double-clicking the top or bottom edge of the window. Minor bug still remains, but it is not fatal at all.

Method Overview

• setResizable(f: bool) - Set resizable/none-resizable

• isResizable() -> bool - Check if window is resizable or not

• setPressToMove(f: bool) - Set movable/non-movable

• isPressToMove() -> bool - Check if window is movable or not

• setMargin(margin: int) - Set the margin which allows cursor to change its shape to resize form

• setFrameColor(color) - Set the background color. color argument type can be both QColor and str.

Example

Code Sample

from PyQt5.QtWidgets import QApplication

from pyqt_frameless_window import FramelessWindow





if __name__ == "__main__":

    import sys



    app = QApplication(sys.argv)

    ex = FramelessWindow()

    ex.show()

    sys.exit(app.exec_())

Result

Try to move and resize it.
