Runge-Kutta

A simple implementation of Runge-Kutta for python.

Usage

Integrates a function x_dot = f(time, x, u). See the examples in the docs folder or a simple one:

from pyrk import RK4
import numpy as np
import matplotlib.pyplot as plt

def vanderpol(t, xi, u):
    dx, x = xi
    mu = 4.0 # damping

    ddx = mu*(1-x**2)*dx-x
    dx = dx

    return np.array([ddx, dx])

rk = RK4(vanderpol)
t, y = rk.solve(np.array([0, 1]), .01, 200)

y1 = []
y2 = []
for v in y:
    y1.append(v[0])
    y2.append(v[1])

plt.plot(y1, y2)
plt.ylabel('velocity')
plt.xlabel('position')
plt.grid(True)
plt.show()

Alternative

If you want to use scipy (which is good, but big), you can do:

from scipy.integrate import solve_ivp as rk45

def func(t,x,u):
    # cool differential equations
    # ...
    return x

t = 0
dt = 0.01
y = np.array([0,0,0]) # initial state

for _ in tqdm(range(steps)):
    u = np.array([1,2,3]) # some inputs to func (i.e., control effort)

    y = rk45(func, [t, t+step], y, args=(u,))

    if y.success == False:
        print("Oops")

    y = y.y[:,-1]

    # probably save t, u and y into arrays for plotting
    t += step
