quantum-circuit-drawer 0.4.0

Backend-agnostic quantum circuit drawing library with Matplotlib as the first renderer.

quantum-circuit-drawer

quantum-circuit-drawer is a Matplotlib-based library for drawing quantum circuits, plotting measurement results, and comparing outputs across several quantum ecosystems with one consistent public API.

The main idea is simple:

• build your circuit or result object the way you normally would
• call one public function
• get a stable result object back

What You Can Do

The library is centered on four user workflows:

Workflow	Public API	Typical use
Draw one circuit	draw_quantum_circuit(...)	Render a Qiskit, Cirq, PennyLane, MyQLM, CUDA-Q, or IR circuit
Compare two circuits	compare_circuits(...)	Show before/after structure, for example before and after transpilation
Plot one result distribution	plot_histogram(...)	Plot counts, quasi-probabilities, marginals, or framework-native result objects
Compare two result distributions	compare_histograms(...)	Overlay ideal vs sampled, baseline vs new run, or counts vs quasi

The public configuration is also intentionally small:

• DrawConfig for circuit rendering
• HistogramConfig for single histograms
• CircuitCompareConfig for side-by-side circuit comparison
• HistogramCompareConfig for histogram comparison

Each public config is now grouped into typed blocks ordered by responsibility:

• circuit drawing uses DrawConfig(side=..., output=...)
• circuit comparison uses CircuitCompareConfig(shared=..., compare=..., output=...)
• single histograms use HistogramConfig(data=..., view=..., appearance=..., output=...)
• histogram comparison uses HistogramCompareConfig(data=..., compare=..., output=...)

Install

Inside your local .venv:

Windows PowerShell:

.\.venv\Scripts\python.exe -m pip install quantum-circuit-drawer

Linux or WSL:

.venv/bin/python -m pip install quantum-circuit-drawer

Install only the extras you need:

Windows PowerShell:

.\.venv\Scripts\python.exe -m pip install "quantum-circuit-drawer[qiskit]"
.\.venv\Scripts\python.exe -m pip install "quantum-circuit-drawer[cirq]"
.\.venv\Scripts\python.exe -m pip install "quantum-circuit-drawer[pennylane]"
.\.venv\Scripts\python.exe -m pip install "quantum-circuit-drawer[myqlm]"

Linux or WSL:

.venv/bin/python -m pip install "quantum-circuit-drawer[qiskit]"
.venv/bin/python -m pip install "quantum-circuit-drawer[cirq]"
.venv/bin/python -m pip install "quantum-circuit-drawer[pennylane]"
.venv/bin/python -m pip install "quantum-circuit-drawer[myqlm]"

CUDA-Q remains a Linux or WSL2 path:

.venv/bin/python -m pip install "quantum-circuit-drawer[cudaq]"

Support matrix

This is the production support contract for the current release.

Input path	Support level	Platform notes
Internal IR	Strong support	Core built-in path on Windows and Linux
Qiskit	Strong support	Primary external backend on Windows and Linux
Cirq	Best-effort on native Windows	Prefer Linux or WSL for the most reliable repeated runs
PennyLane	Best-effort on native Windows	Prefer Linux or WSL for the most reliable repeated runs
MyQLM	Scoped adapter + contract support	Adapter contract is covered, but it is not a first-class multiplatform CI backend
CUDA-Q	Linux/WSL2 only	Not intended for native Windows installs

Choose Your First Task

If you want to...	Start here
Draw a circuit from a supported framework	Draw one circuit
Save a render from a script without opening a window	Save directly to a file
Plot counts or probabilities	Plot one histogram
Compare two versions of a circuit	Compare two circuits
Compare two distributions	Compare two histograms
Build a circuit without a framework dependency	Build with public IR tools
Explore framework-specific demos	Recommended demos

Draw One Circuit

from qiskit import QuantumCircuit

from quantum_circuit_drawer import DrawConfig, OutputOptions, draw_quantum_circuit

circuit = QuantumCircuit(2, 1)
circuit.h(0)
circuit.cx(0, 1)
circuit.measure(1, 0)

result = draw_quantum_circuit(
    circuit,
    config=DrawConfig(output=OutputOptions(show=False)),
)

figure = result.primary_figure
axes = result.primary_axes

This same shape works for the supported framework objects and for the public IR types.

Save Directly To A File

from qiskit import QuantumCircuit

from quantum_circuit_drawer import DrawConfig, OutputOptions, draw_quantum_circuit

circuit = QuantumCircuit(2, 1)
circuit.h(0)
circuit.cx(0, 1)
circuit.measure(1, 0)

draw_quantum_circuit(
    circuit,
    config=DrawConfig(output=OutputOptions(output_path="bell.png", show=False)),
)

This is the most common script workflow when you want a deterministic export without opening a GUI window.

Plot One Histogram

Counts

from quantum_circuit_drawer import (
    HistogramAppearanceOptions,
    HistogramConfig,
    HistogramDataOptions,
    HistogramViewOptions,
    OutputOptions,
    plot_histogram,
)

result = plot_histogram(
    {"000": 51, "001": 14, "010": 9, "111": 49},
    config=HistogramConfig(
        data=HistogramDataOptions(top_k=3),
        view=HistogramViewOptions(sort="value_desc"),
        appearance=HistogramAppearanceOptions(show_uniform_reference=True),
        output=OutputOptions(show=False),
    ),
)

Quasi-probabilities

from quantum_circuit_drawer import (
    HistogramAppearanceOptions,
    HistogramConfig,
    HistogramDataOptions,
    HistogramKind,
    OutputOptions,
    plot_histogram,
)

result = plot_histogram(
    {0: 0.52, 3: -0.08, 4: 0.17, 7: 0.39},
    config=HistogramConfig(
        data=HistogramDataOptions(kind=HistogramKind.QUASI),
        appearance=HistogramAppearanceOptions(
            draw_style="soft",
            show_uniform_reference=True,
        ),
        output=OutputOptions(show=False),
    ),
)

Joint marginal on selected qubits

from quantum_circuit_drawer import HistogramConfig, HistogramDataOptions, OutputOptions, plot_histogram

result = plot_histogram(
    {"101": 2, "001": 1, "111": 3},
    config=HistogramConfig(
        data=HistogramDataOptions(qubits=(0, 2)),
        output=OutputOptions(show=False),
    ),
)

qubits=(0, 2) keeps the requested order, so the marginal labels are built as q0 followed by q2.

Compare Two Circuits

from qiskit import QuantumCircuit, transpile

from quantum_circuit_drawer import (
    CircuitCompareConfig,
    CircuitCompareOptions,
    OutputOptions,
    compare_circuits,
)

source = QuantumCircuit(3, 3)
source.h(0)
source.cx(0, 1)
source.cx(1, 2)
source.measure(range(3), range(3))

transpiled = transpile(source, basis_gates=["u", "cx"], optimization_level=2)

result = compare_circuits(
    source,
    transpiled,
    config=CircuitCompareConfig(
        compare=CircuitCompareOptions(
            left_title="Original",
            right_title="Transpiled",
        ),
        output=OutputOptions(show=False),
    ),
)

CircuitCompareResult gives you:

• one comparison figure
• one DrawResult per side
• structural metrics such as operation counts, measurement counts, swap counts, and differing layers

Compare Two Histograms

from quantum_circuit_drawer import (
    HistogramCompareConfig,
    HistogramCompareOptions,
    OutputOptions,
    compare_histograms,
)

ideal = {"00": 0.5, "11": 0.5}
sampled = {"00": 473, "01": 19, "10": 24, "11": 484}

result = compare_histograms(
    ideal,
    sampled,
    config=HistogramCompareConfig(
        compare=HistogramCompareOptions(
            sort="delta_desc",
            left_label="Ideal",
            right_label="Sampled",
        ),
        output=OutputOptions(show=False),
    ),
)

This is useful when you want one aligned state space and quick metrics such as total variation distance.

Build With Public IR Tools

If you do not want to depend on a framework, you can build directly with the public IR tools or use CircuitBuilder.

CircuitBuilder

from quantum_circuit_drawer import CircuitBuilder, DrawConfig, OutputOptions, draw_quantum_circuit

circuit = (
    CircuitBuilder(2, 1, name="builder_demo")
    .h(0)
    .cx(0, 1)
    .measure(1, 0)
    .build()
)

draw_quantum_circuit(circuit, config=DrawConfig(output=OutputOptions(show=False)))

Raw CircuitIR

If you need complete control over wires, operations, and metadata, use the public quantum_circuit_drawer.ir types directly. The best minimal example for that path is the bundled ir-basic-workflow demo.

Modes, Hover, And 3D

The most common choices are:

• DrawMode.AUTO: notebook -> pages, normal script -> pages_controls
• DrawMode.PAGES: easiest for notebook display and export-oriented flows
• DrawMode.PAGES_CONTROLS: best default for normal scripts
• DrawMode.SLIDER: best when you want a viewport through a wide circuit
• DrawMode.FULL: best when the circuit fits comfortably in one scene

Example:

from quantum_circuit_drawer import (
    CircuitAppearanceOptions,
    CircuitRenderOptions,
    DrawConfig,
    DrawMode,
    DrawSideConfig,
    OutputOptions,
    draw_quantum_circuit,
)

result = draw_quantum_circuit(
    circuit,
    config=DrawConfig(
        side=DrawSideConfig(
            render=CircuitRenderOptions(mode=DrawMode.PAGES_CONTROLS),
            appearance=CircuitAppearanceOptions(
                hover={"enabled": True, "show_size": True},
            ),
        ),
        output=OutputOptions(show=False),
    ),
)

For 3D:

from quantum_circuit_drawer import (
    CircuitRenderOptions,
    DrawConfig,
    DrawMode,
    DrawSideConfig,
    OutputOptions,
    draw_quantum_circuit,
)

result = draw_quantum_circuit(
    circuit,
    config=DrawConfig(
        side=DrawSideConfig(
            render=CircuitRenderOptions(
                view="3d",
                mode=DrawMode.PAGES_CONTROLS,
                topology="grid",
                topology_menu=True,
            ),
        ),
        output=OutputOptions(show=False),
    ),
)

If you want to see the managed 2D controls intentionally exercised instead of configuring them from scratch, start with qiskit-2d-exploration-showcase.

Recommended Demos

The fastest way to see the current strengths of the library is to run one of the bundled showcase demos:

Demo id	What it highlights
qiskit-2d-exploration-showcase	Managed 2D exploration with Wires: All/Active, Ancillas: Show/Hide, folded-wire markers, and contextual Collapse / Expand
qiskit-control-flow-showcase	Compact Qiskit control-flow boxes plus open controls
qiskit-composite-modes-showcase	Compact versus expanded composite instructions on the same workflow
ir-basic-workflow	Framework-free rendering from the public CircuitIR types
cirq-native-controls-showcase	Cirq native controls, classical conditions, and CircuitOperation provenance
pennylane-terminal-outputs-showcase	PennyLane mid-measurement, qml.cond(...), plus terminal output boxes
myqlm-structural-showcase	Compact composite routines on the native MyQLM adapter path
cudaq-kernel-showcase	The supported closed-kernel CUDA-Q subset with reset and basis measurements
compare-histograms-ideal-vs-sampled	A lightweight comparison workflow with no framework extra required

Windows PowerShell:

.\.venv\Scripts\python.exe examples\qiskit_2d_exploration_showcase.py
.\.venv\Scripts\python.exe examples\qiskit_control_flow_showcase.py
.\.venv\Scripts\python.exe examples\qiskit_composite_modes_showcase.py --composite-mode expand
.\.venv\Scripts\python.exe examples\ir_basic_workflow.py
.\.venv\Scripts\python.exe examples\compare_histograms_ideal_vs_sampled.py

Linux or WSL:

.venv/bin/python examples/qiskit_2d_exploration_showcase.py
.venv/bin/python examples/qiskit_control_flow_showcase.py
.venv/bin/python examples/qiskit_composite_modes_showcase.py --composite-mode expand
.venv/bin/python examples/ir_basic_workflow.py
.venv/bin/python examples/compare_histograms_ideal_vs_sampled.py

The full curated catalog, including direct script commands, histogram demos, compare demos, and per-framework recommendations, lives in examples/README.md.
