S2FFT: differentiable and accelerated spherical transforms

S2FFT is a Python package for computing Fourier transforms on the sphere and rotation group (Price & McEwen 2024) using JAX or PyTorch. It leverages autodiff to provide differentiable transforms, which are also deployable on hardware accelerators (e.g. GPUs and TPUs).

More specifically, S2FFT provides support for spin spherical harmonic and Wigner transforms (for both real and complex signals), with support for adjoint transformations where needed, and comes with different optimisations (precompute or not) that one may select depending on available resources and desired angular resolution $L$.

Algorithms ⚡

S2FFT leverages new algorithmic structures that can he highly parallelised and distributed, and so map very well onto the architecture of hardware accelerators (i.e. GPUs and TPUs). In particular, these algorithms are based on new Wigner-d recursions that are stable to high angular resolution $L$. The diagram below illustrates the recursions (for further details see Price & McEwen 2024).

With this recursion to hand, the spherical harmonic coefficients of an isolatitudinally sampled map may be computed as a two step process. First, a 1D Fourier transform over longitude, for each latitudinal ring. Second, a projection onto the real polar-d functions. One may precompute and store all real polar-d functions for extreme acceleration, however this comes with an equally extreme memory overhead, which is infeasible at $L \sim 1024$. Alternatively, the real polar-d functions may calculated recursively, computing only a portion of the projection at a time, hence incurring negligible memory overhead at the cost of slightly slower execution. The diagram below illustrates the separable spherical harmonic transform (for further details see Price & McEwen 2024).

Sampling 🌍

The structure of the algorithms implemented in S2FFT can support any isolatitude sampling scheme. A number of sampling schemes are currently supported.

The equiangular sampling schemes of McEwen & Wiaux (2012), Driscoll & Healy (1995) and Gauss-Legendre (1986) are supported, which exhibit associated sampling theorems and so harmonic transforms can be computed to machine precision. Note that the McEwen & Wiaux sampling theorem reduces the Nyquist rate on the sphere by a factor of two compared to the Driscoll & Healy approach, halving the number of spherical samples required.

The popular HEALPix sampling scheme (Gorski et al. 2005) is also supported. The HEALPix sampling does not exhibit a sampling theorem and so the corresponding harmonic transforms do not achieve machine precision but exhibit some error. However, the HEALPix sampling provides pixels of equal areas, which has many practical advantages.

Installation 💻

The latest release of S2FFT published on PyPI can be installed by running

pip install s2fft

This will install S2FFT's dependencies including JAX if not already installed. As by default installing JAX from PyPI will use a CPU-only build, if you wish to install JAX with GPU or TPU support, you should first follow the relevant installation instructions in JAX's documentation and then install S2FFT as above.

Alternatively, the latest development version of S2FFT may be installed directly from GitHub by running

pip install git+https://github.com/astro-informatics/s2fft

CUDA extension support

To install the package with support for the CUDA extension module giving reduced compile times for running HEALPix transforms on the GPU, you will need to build from source on a system with CUDA (tested with version 12.3) and CMake (versions 3.19+) installed.

To install the latest development version from source in verbose mode run

pip install -v git+https://github.com/astro-informatics/s2fft

or to install a specific release tag in verbose mode run

pip install -v git+https://github.com/astro-informatics/s2fft@TAG

where TAG is the relevant version tag. The output should indicate if the CUDA install on your system is successfully detected.

Tests 🚦

A pytest test suite for the package is included in the tests directory. To install the test dependencies, clone the repository and install the package (in editable mode) with the extra test dependencies by running from the root of the repository

pip install -e ".[tests]"

To run the tests, run from the root of the repository

pytest

Documentation 📖

Documentation for the released version is available here. To install the documentation dependencies, clone the repository and install the package (in editable mode) with the extra documentation dependencies by running from the root of the repository

pip install -e ".[docs]"

To build the documentation, run from the root of the repository

cd docs
make html
open _build/html/index.html

Notebooks 📓

A series of tutorial notebooks have been rendered in, and are available for download from, the documentation.

To install the dependencies required to run the notebooks locally, clone the repository and install the package (in editable mode) with the extra documentation, plotting, and examples dependencies by running from the root of the repository

pip install -e ".[docs,examples,plotting]"

To run the notebooks in Jupyter Lab, run from the root of the repository

jupyter lab

Usage 🚀

To import and use S2FFT is as simple follows:

For a signal on the sphere

import s2fft

# Define sampled signal to transform and harmonic bandlimit
f = ...
L = ...
# Compute harmonic coefficients
flm = s2fft.forward(f, L, method="jax")
# Map back to pixel-space signal
f = s2fft.inverse(flm, L, method="jax")

For a signal on the rotation group

import s2fft

# Define sampled signal to transform and harmonic and azimuthal bandlimits
f = ...
L = ...
N = ...
# Compute Wigner coefficients
flmn = s2fft.wigner.forward(f, L, N, method="jax")
# Map back to pixel-space signal
f = fft.wigner.inverse_jax(flmn, L, N, method="jax")

For further details on usage see the documentation and associated notebooks.

We also provide PyTorch support for our transforms, as demonstrated in the Torch frontend tutorial notebook. This wraps the JAX implementations so JAX will need to be installed in addition to PyTorch.

SSHT & HEALPix wrappers 💡

S2FFT also provides JAX support for existing C/C++ packages, specifically HEALPix and SSHT. This works by wrapping Python bindings with custom JAX frontends. Note that this C/C++ to JAX interoperability is currently limited to CPU.

For example, one may call these alternate backends for the spherical harmonic transform by:

# Forward SSHT spherical harmonic transform
flm = s2fft.forward(f, L, sampling="mw", method="jax_ssht")

# Forward HEALPix spherical harmonic transform
flm = s2fft.forward(f, L, nside=nside, sampling="healpix", method="jax_healpy")

All of these JAX frontends supports out of the box reverse mode automatic differentiation, and under the hood is simply linking to the C/C++ packages you are familiar with. In this way S2fft enhances existing packages with gradient functionality for modern scientific computing or machine learning applications!

For further details on usage see the associated notebooks.

Benchmarks ⏱️

A suite of benchmark functions for both the on-the-fly and precompute versions of the spherical harmonic and Wigner transforms are available in the benchmarks directory, along with utilities for running the benchmarks and plotting the results.

Contributors ✨

Thanks goes to these wonderful people (emoji key):

Matt Price 💻 👀 🤔	Jason McEwen 💻 👀 🤔	Matt Graham 💻 👀	sfmig 💻 👀	Devaraj Gopinathan 💻	Francois Lanusse 💻 🐛	Ikko Eltociear Ashimine 📖
Kevin Mulder 🐛	Philipp Misof 🐛 📖	Elis Roberts 🐛 📖	Wassim KABALAN 💻 👀 ⚠️	Mayeul d'Avezac 🚇	Will Graham 👀 💻 📖	Artem Basyrov 💻 ⚠️
Tanvir ✅

We encourage contributions from any interested developers. A simple first addition could be adding support for more spherical sampling patterns!

Attribution 📚

Should this code be used in any way, we kindly request that the following article is referenced. A BibTeX entry for this reference may look like:

@article{price:s2fft,
   author      = "Matthew A. Price and Jason D. McEwen",
   title       = "Differentiable and accelerated spherical harmonic and Wigner transforms",
   journal     = "Journal of Computational Physics",
   year        = "2024",
   volume      = "510",
   pages       = "113109",
   eprint      = "arXiv:2311.14670",
   doi         = "10.1016/j.jcp.2024.113109"
}

You might also like to consider citing our related papers on which this code builds:

@article{mcewen:fssht,
    author      = "Jason D. McEwen and Yves Wiaux",
    title       = "A novel sampling theorem on the sphere",
    journal     = "IEEE Trans. Sig. Proc.",
    year        = "2011",
    volume      = "59",
    number      = "12",
    pages       = "5876--5887",
    eprint      = "arXiv:1110.6298",
    doi         = "10.1109/TSP.2011.2166394"
}

@article{mcewen:so3,
    author      = "Jason D. McEwen and Martin B{\"u}ttner and Boris ~Leistedt and Hiranya V. Peiris and Yves Wiaux",
    title       = "A novel sampling theorem on the rotation group",
    journal     = "IEEE Sig. Proc. Let.",
    year        = "2015",
    volume      = "22",
    number      = "12",
    pages       = "2425--2429",
    eprint      = "arXiv:1508.03101",
    doi         = "10.1109/LSP.2015.2490676"
}

License 📝

We provide this code under an MIT open-source licence with the hope that it will be of use to a wider community.

Copyright 2023 Matthew Price, Jason McEwen and contributors.

S2FFT is free software made available under the MIT License. For details see the LICENCE.txt file.
