sigwood 0.2.0

Hunt for C2 beacons, DNS anomalies, and cloud-account weirdness in your own logs - no SIEM, no agents.

sigwood is a local-first, command-line threat-hunting tool for self-hosters. Point it at logs you already have - Zeek, Pi-hole/dnsmasq, syslog, or CloudTrail - and it profiles what's in them, then runs a handful of detectors over them: beaconing, suspicious DNS, port scans, rare syslog events, over-long connections, and unusual CloudTrail activity.

Not a SIEM. Not an agent. Not magic. Nothing to deploy - no database, no daemon, no account. Install it, point it at a directory of logs, read the output. It runs on your own box, over logs at rest.

Status: early / pre-1.0 (0.2.0). The six detectors work and are covered by tests, but things may well change before 1.0. Feedback is welcome.

Install · FAQ · Roadmap · Known issues · Schemas

Quick start

pipx install sigwood        # or: pip install sigwood in a venv - see Installation

sigwood /var/log/           # point it at a directory
sigwood /opt/zeek/dns.log   # or a single file

That's it - no config required. Here is the kind of thing a run surfaces (illustrative output, not real network data):

dns - 1 finding · 1 H
────────────────────────────────────────────────────────────────────────────────
groups (1)
  [H]   16 sub  score=2.10-1.85  418 qry  1 src  k7x2p9qz3f.example

beacon - 2 findings · 2 H
────────────────────────────────────────────────────────────────────────────────
[H]  192.168.1.37  →  198.51.100.20:443/tcp    period=3.0m    score=0.624   480 conns
[H]  192.168.1.37  →  203.0.113.50:8443/tcp    period=10.0m   score=0.606   144 conns

syslog - 1 finding · 1 M
────────────────────────────────────────────────────────────────────────────────
rare events (1)
  [M]   Accepted password for root from 198.51.100.20 port 51900 ssh2

Read top to bottom that is a story: an internal host making high-entropy lookups under one throwaway domain, calling out to two external IPs on a fixed schedule, and a root SSH login from one of those same IPs. A finding means "unusual for your network," not "known-bad" - it is a lead to look at, not a verdict. Add -v for the evidence behind each score and the steps to run it down.

The usual invocations:

sigwood digest /var/log/messages     # orient first - a fast, factual profile of a file
sigwood graph /opt/zeek              # replay the flows as a self-contained HTML artifact
sigwood syslog /var/log              # run a single detector
sigwood init                         # detection-driven setup, writes a config
sigwood hunt                         # hunt across everything enabled in your config

No logs handy? sigwood ships a small synthetic corpus - one compromised host, no real network data - so you can watch it work first:

git clone https://github.com/helixmap/sigwood
cd sigwood
python demo/gen_corpus.py                  # writes a synthetic corpus; no network calls
sigwood hunt --config=demo/sigwood.toml    # beacons, a DGA burst, and the matching syslog trail

The generated logs live under demo/corpus/ (gitignored); the full walkthrough is in demo/README.md. Here is a full run against that corpus, and the same findings as an HTML report:

Why use sigwood?

• It runs where your logs are. No service, no database, no daemon, no agent to push. pipx install sigwood, point it at a directory, get output. The only setup step is optional: sigwood init, which just writes plain text files under ~/.sigwood/.
• Named methods. beacon uses an FFT over connection timing; dns uses HDBSCAN clustering over per-query behavior; syslog uses drain3 log-templating plus rarity scoring; aws uses a per-principal z-score composite. Every run names the technique each detector used, and -v shows the evidence behind a finding.
• Big-tent ingestion. One tool reads Zeek (NDJSON and TSV, flat or date-partitioned directories), Pi-hole/dnsmasq, flat RFC 3164 syslog (Debian and RHEL/Fedora layouts), and CloudTrail. Rotation and .gz/.bz2/.xz compression are handled for you.
• Orient before you hunt. sigwood digest FILE reports facts about a log - time span, top talkers, the shape of the mix - so you know where to point the detectors. No verdicts.
• Filter before analyze. A curated allowlist of known-harmless infrastructure ships on and drops that noise before any detector sees the data - toggle a list off by name, or drop the whole thing with --no-allowlist. Every run reports how much it hid.
• Pick the output for the job. A report to read (text, html, pdf), a lossless feed to script against (json), or a worklist to triage from (csv).

What it hunts

Detector	Surfaces	Method	Source
beacon	periodic C2-style callbacks	FFT over connection timing	Zeek conn.log
dns	DGA / tunneling / anomalous lookups	HDBSCAN clustering	Zeek dns.log or Pi-hole
syslog	rare events & reboots	drain3 templating + rarity	syslog (flat) or Zeek syslog.log
scan	vertical / horizontal / block / slow port scans	pattern (heuristic)	Zeek conn.log
duration	abnormally long-lived connections	heuristics	Zeek conn.log
aws	per-principal anomalous CloudTrail behavior	statistical (z-score composite)	CloudTrail *.json* (incl. .gz)

dns and syslog each answer one question across two source families - Zeek and Pi-hole for DNS, flat rsyslog and Zeek's own syslog.log for syslog - and adapt to whichever fidelity they're handed.

Run them all (sigwood hunt), select some (sigwood hunt --detect=beacon,dns), or exclude (sigwood hunt --detect='all,!syslog'). Each detector is also its own subcommand: sigwood beacon ~/zeek.

sigwood and RITA / AC-Hunter

If you know RITA (or its commercial sibling AC-Hunter), the beacon-hunting goal will look familiar - both hunt C2 in Zeek logs, and RITA is excellent at it. sigwood differs in conception: there is no database and no import step (it reads Zeek - and Pi-hole, syslog, and CloudTrail - in place), it spans several log families rather than conn/dns alone, and it ships an orientation verb (digest) for logs you haven't met yet. If you already run RITA against a dedicated Zeek sensor, keep it - sigwood is for the box where the logs already live and the analyst who wants one tool across all of them.

How a run works

discover & parse  →  allowlist (suppress)  →  detect  →  render

The loader finds files, decompresses, and normalizes every connection source to one canonical schema, absorbing storage variation (TSV vs. NDJSON, flat vs. dated directories, rotation). The allowlist suppresses known-good traffic before analysis. Detectors only analyze - they never open files, read config, or suppress. Output handlers only render. The CLI turns errors into actionable messages and owns the exit code. Every detector is also an importable Python function, handy in a notebook.

Analysis window

Pointed at a directory, an unqualified run looks back over the last default_window (7d out of the box) of that source's own data - a sensible default for a live log dir you don't want to read in full every time. Pointed at a single file, it reads the whole file. Override either way:

sigwood --since=7d ~/zeek            # last 7 days
sigwood --since=2026-05-01 --until=2026-05-08 ~/zeek
sigwood --days=2-4 ~/zeek            # 2 to 4 days ago
sigwood --all ~/zeek                 # the entire archive

CloudTrail opts out of the default window - novelty detection needs full history, so it always loads in full unless you narrow it explicitly. Times render in your local timezone (labeled as such); pass --utc or set use_utc = true for UTC. json output is always UTC.

Orient before the hunt: digest

sigwood digest /var/log/messages
sigwood digest /var/log/pihole/pihole.log   # a great first move on a Pi-hole box
sigwood digest conn.log dns.log             # several files → several cards

digest content-sniffs each file, routes it to the right summarizer (conn, dns, syslog, cloudtrail), and falls back to a fast byte-profiler - blob - for anything it doesn't recognize. A card is flush-left and factual: the file's time window, line count and size, a scale-anchored histogram, and a handful of plain-language insights ("one client accounts for 71% of queries") - facts and superlatives, never verdicts. It reads before the allowlist, because everything in the file is part of "what's in here." The blob profiler samples a big file rather than reading it, so a one-gigabyte mystery file costs the same as a one-kilobyte one.

See your logs: graph

sigwood graph /opt/zeek                       # a Zeek dir → a conn graph and a dns graph
sigwood graph /var/log/pihole/pihole.log      # a Pi-hole box → clients, domains, dispositions
sigwood graph --pihole-dir=/var/log/pihole    # same, from your configured directory
sigwood graph dns.log --out=~/graphs/         # choose where the artifact lands

graph builds a self-contained HTML artifact - one file, no server, no external resources, no network calls - that replays the flows in a log as an animated Sankey: who talked to whom, over the window, with time, speed, and filter controls. Watch the flows form and dissolve and you quickly get a sense of what's going on in the data.

A Zeek directory produces two graphs - a conn graph (hosts vs the services they reach) and a dns graph (clients vs the domains they look up). Pi-hole adds a disposition lane: alongside the domains each client queried, you can switch on a column for what Pi-hole did with each query - blocked, forwarded, cached, or local. Like digest, graph reads before the allowlist, and it states facts, not verdicts: it shows you the fat ribbon leaving your database server at 3am, and lets you decide if that's your backup window or a nightmare exfil scenario. Every artifact includes the command to hunt the data being visualized, so the visual is a door into analysis, not a substitute.

Installation

One name everywhere: the PyPI distribution, the command, the import package, and the config section are all sigwood. Requires Python 3.11+.

The recommended install is pipx, which gives sigwood its own isolated environment, puts the command on your PATH, and sidesteps the externally-managed-environment refusal (PEP 668) that a bare pip install hits on Debian 12+, Raspberry Pi OS, Ubuntu 23.04+, and Fedora:

# Debian / Raspberry Pi OS / Ubuntu:  sudo apt install pipx
# Fedora:                             sudo dnf install pipx
# macOS:                              brew install pipx

pipx ensurepath              # once - then reopen your shell
pipx install sigwood
sigwood --help

Prefer uv? uv tool install sigwood does the same job. A plain virtualenv also works (python3 -m venv venv && venv/bin/pip install sigwood; a minimal Debian may need sudo apt install python3-venv first). Avoid sudo pip install - it will pollute your system Python and nobody wants that.

Upgrade with pipx upgrade sigwood.

Optional extras (same spelling under pipx or pip):

pipx install 'sigwood[all]'           # fast + splunk + cloudtrail (recommended)
pipx install 'sigwood[splunk]'        # Splunk exporter
pipx install 'sigwood[cloudtrail]'    # CloudTrail (S3) exporter
pipx install 'sigwood[pdf]'           # PDF reports - opt-in, see note below

A bare install needs no C compiler on the platforms people run this on. On 64-bit machines, DNS clustering uses fast-hdbscan; on 32-bit ARM it uses stock hdbscan which is a bit slower but still works fine. The first run on a small box takes a minute or two while the scientific stack warms up (cached on disk after that); every run after is fast.

[pdf] is separate from [all] because PDF also needs native text libraries pip can't install - brew install pango on macOS, apt install libpango-1.0-0 (or dnf install pango) on Linux. Every other format works with no extra setup.

From source:

git clone https://github.com/helixmap/sigwood
cd sigwood
python3 -m venv .venv                # Python 3.11+
.venv/bin/pip install -e '.[all]'

Configuration

Configuration is optional - sigwood runs against a path with none. When you want it repeatable, sigwood init looks at the conventional locations on your box, profiles what it finds (which log families, rough size, freshness), and writes an annotated config under ~/.sigwood/ (or /etc/sigwood for a system-wide install). Re-run it any time: it merges into an existing config without clobbering settings you already have, and shows a summary of what will change before it writes anything.

Config is loaded from the first of: --config=FILE, then ~/.sigwood/config.toml, then /etc/sigwood/config.toml. Everything sigwood owns lives under ~/.sigwood/ - config, allowlists, exports, reports. A trimmed example:

[sigwood]
detect     = "all"                 # "all" | "dns,beacon" | "all,!syslog"
zeek_dir   = "/var/log/zeek"
syslog_dir = "/var/log"
# pihole_dir     = "/var/log/pihole"
# cloudtrail_dir = "/var/log/cloudtrail"

home_net       = ["10.0.0.0/8", "172.16.0.0/12", "192.168.0.0/16"]
default_window = "7d"             # lookback for a directory; "" or "all" = full
output_format  = "text"           # text | json | csv | html | pdf

Findings print to your terminal by default - keep it pipeable. Set report_dir (or pass --out=PATH) to write report files instead. Every setting a detector has is documented in a commented "engine room" section at the bottom of the generated config (you rarely need to mess around in there). And sigwood <detector> --help lists that command's flags.

Log sources it speaks

• Zeek - conn.log, dns.log, syslog.log, in NDJSON or TSV, from a flat directory or date-partitioned subdirectories. Rotation and gzip/bzip2/xz compression are transparent.
• Pi-hole / dnsmasq - DNS event logs, aggregated per domain for clustering.
• syslog - flat RFC 3164. Discovery is content-sniffed, not filename-matched, so it handles both the Debian convention (syslog, auth.log, kern.log) and the RHEL/Fedora one (extensionless messages, secure, maillog) - and won't mistake dnf.log or a binary like wtmp for a log stream.
• CloudTrail - gzipped JSON event records, read locally or pulled from S3 (see exporters below).

The allowlist

sigwood filters before it analyzes: known-harmless traffic is dropped before any detector sees it, so signal isn't buried in plumbing. Two kinds of allowlist file:

• Flat files = suppression. One rule per line - an IP, a CIDR, a :port/proto, or a domain glob/regex. Matching traffic is dropped before any detector runs.
• TOML stanzas = structured suppression. The same drop, expressed as an entry that carries a comment and an optional per-detector scope (detectors = ["duration"]). A richer classification role - telling a detector what something is - is planned, but no shipped detector consumes it yet, so today a stanza suppresses.

sigwood ships three curated domain lists, toggled by name:

list	default	covers
common	on	broad internet infrastructure - CDNs, cloud, NTP, certificate validation, public DNS, OS update channels
devices	on	consumer IoT / smart-home phone-home
homelab	off	self-hosted tooling (Splunk, Proxmox, UniFi, …) - opt-in, since suppressing a product you run is a real blind spot

Nothing ad-, tracking-, or destination-specific ships - opinions differ and you may want to see those. sigwood never ships numeric connection suppressions (those depend on your hosts, and shipping them could hide real findings).

sigwood allowlist                 # what's loaded, each list's on/off state and size
sigwood allowlist show common     # the patterns in a list
sigwood allowlist enable homelab  # turn a shipped list on
sigwood allowlist disable common  # …or off
sigwood allowlist copy common     # fork a shipped list into your allowlist.d to edit

Toggles can also be set under [allowlist.lists] in config; the whole allowlist turns off for one run with --no-allowlist or permanently with enabled = false. Every detect run discloses its coverage on the banner (allowlist: suppressed 1,284 connections (12%) and 312 domains (59%) - the share of loaded rows suppressed, per kind), so a surprising suppression rate is visible at a glance.

Add your own in any domains_* file under ~/.sigwood/allowlist.d/ (the shipped domains_user is a starter). Drop-ins are additive and survive upgrades; to replace a shipped list, disable it and add your own. A malformed regex line is skipped with a notice naming its file and line, not a crash. A bare host IP with no port suppresses all traffic involving that host - powerful but dangerous, and flagged as such wherever it appears.

Pulling logs in: exporters

sigwood can fetch logs from external systems to local files, which it then analyzes like any other source - the syslog detector can't tell whether the data came from rsyslog or a Splunk export.

sigwood export splunk            # run the configured "default" query
sigwood export splunk auth       # run the configured named query: "auth"
sigwood export cloudtrail        # pull logs from S3

• Splunk - named SPL queries under [export.splunk.query.<name>]. Prefer the SIGWOOD_SPLUNK_USER / SIGWOOD_SPLUNK_PASS environment variables over plaintext credentials in config, but sigwood will not judge you.
• CloudTrail - pulls gzipped JSON from an S3 prefix. AWS authentication is not handled here: you authenticate your shell, and boto3 resolves the ambient credential chain. sigwood never reads, stores, or prompts for AWS credentials, and warns before a large egress.

Output formats

Choose by what you're doing with the findings - --format=NAME (or set output_format in config):

• text (default) - a grouped report for the terminal, with a per-detector table of the signals behind each finding.
• html - the same report as a self-contained styled file to open in a browser, print, or share. No extra dependencies; dark mode and print styles included.
• pdf - the html report rendered to PDF (one renderer, two outputs). Opt-in: pip install 'sigwood[pdf]' plus the native text libraries (see the install note above).
• json - the lossless machine feed: a single object with run_summary and findings, correctly typed for jq or a SIEM, always the full set. Carries a schema_version.
• csv - a remediation worklist: one row per finding with the next-steps, the "why", and empty status/notes columns to track as you knock items down.

text, html, and pdf are reading views - they honor -v (the curated "why it scored") and -vv (raw debug). json and csv always carry the full set.

Every text format - including html - prints to stdout by default; redirect or pipe to save (sigwood dns -f=html > report.html). pdf is binary, so it needs a destination: a pipe (-f=pdf > report.pdf) or a file. Set --out=PATH or report_dir to write files; a directory target auto-names the report and prints the path it wrote.

Building from source & running tests

git clone https://github.com/helixmap/sigwood
cd sigwood
python3 -m venv .venv                # Python 3.11+
.venv/bin/pip install -e '.[dev]'
.venv/bin/python -m pytest

main is kept runnable. Architecture tests cover the boundaries that matter - detector discovery, run planning, loader metadata, allowlist suppression, output registration, and CLI error formatting.

Acknowledgments

sigwood's mathematics-based detection - FFT for beacon periodicity, unsupervised clustering for DNS behavior - was inspired by David Hoelzer's SANS SEC595. The techniques themselves (FFT, HDBSCAN, drain3) are public-domain mathematics and open-source libraries; this implementation is independent and original, and any errors are mine. sigwood is not affiliated with or endorsed by SANS or GIAC.

License

sigwood is licensed under the MIT License.
