Specular Differentiation

Python 3.14

The Python package specular implements specular differentiation, which generalizes classical differentiation. See References for more details.

The specular derivative is defined by averaging the angles associated with the forward and backward difference quotients:

The specular derivative of f at x is the tangent of the average of arctan of the right derivative and arctan of the left derivative.

where $f_{+}'(x)$ and $f_{-}'(x)$ are the right and left derivatives of $f$ at $x$, respectively. In contrast, the symmetric derivative takes the arithmetic mean of these derivatives. The animation below compares the two: the dashed blue and green lines have slopes equal to the specular and symmetric derivatives, respectively.

Animation comparing specular and symmetric derivatives

Installation

Requirements

specular-differentiation requires:

Python >= 3.14
numpy >= 2.4

Additional backends are available through optional dependencies:

numba: numba
jax: jax, jaxlib

Standard Installation

pip install specular-differentiation

The package is distributed as specular-differentiation and imported in Python as specular.

This installs scaled_mean, derivative, gradient, and jacobian, using NumPy by default, as well as the scalar ODE methods and the SPEG optimizer. Backend selection is available through set_backend, get_backend, use_backend, and available_backends.

Optional features

pip install "specular-differentiation[numba]"           # Numba backend
pip install "specular-differentiation[jax]"             # JAX backend

Developer installation

pip install -e ".[dev]"

Backend support

Backend	Availability	Minimum version
NumPy	Default	`numpy >= 2.4`
Numba	Optional	`numba >= 0.65`
JAX	Optional	`jax >= 0.10`, `jaxlib >= 0.10`

Quick start

The following simple example calculates the specular derivative of the ReLU function $f(x) = max(0, x)$ at the origin.

import specular

ReLU = lambda x: max(x, 0)
print(specular.derivative(ReLU, x=0))

0.41421356237309503

Documentation

LaTeX Macro

To use the specular differentiation symbol in your LaTeX document, add the following code to your preamble (before \begin{document}):

% Required packages
\usepackage[T1]{fontenc}
\usepackage{amsmath}
\usepackage{graphicx}
\usepackage{amssymb}

% specular derivative symbol
\newcommand{\sd}{\mathord{\prime\mkern-2.5mu\reflectbox{$\scriptstyle\prime$}}}

% specular Gateaux derivative symbol
\newcommand{\sGd}{%
    \mathord{\text{\normalfont\UseTextSymbol{T1}{\dj}}}%
}

% specular Frechet derivative symbol
\newcommand{\sFd}{%
    \mathord{\text{\normalfont\UseTextSymbol{T1}{\DJ}}}%
}

% specular gradient symbol
\newcommand{\sg}{%
  \mathchoice
    {\mathord{\raisebox{-0.05ex}{\rule{0pt}{1.3ex}\smash{\scalebox{1.37}[1.22]{\ensuremath{\displaystyle\blacktriangledown}}}}\mkern-1.2mu}}
    {\mathord{\raisebox{-0.05ex}{\rule{0pt}{1.3ex}\smash{\scalebox{1.37}[1.22]{\ensuremath{\textstyle\blacktriangledown}}}}\mkern-1.2mu}}
    {\mathord{\raisebox{-0.03ex}{\rule{0pt}{1.0ex}\smash{\scalebox{1.29}[1.15]{\ensuremath{\scriptstyle\blacktriangledown}}}}\mkern-0.8mu}}
    {\mathord{\raisebox{-0.02ex}{\rule{0pt}{0.8ex}\smash{\scalebox{1.18}[1.05]{\ensuremath{\scriptscriptstyle\blacktriangledown}}}}\mkern-0.5mu}}
}

For usage examples and Markdown notation, see LaTeX Macro in the User Guide.

Citing specular-differentiation

To cite this repository:

@software{specular_diff,
  author = {Jung, Kiyuob},
  title = {{specular-differentiation}},
  doi = {10.5281/zenodo.18246734},
  url = {https://github.com/kyjung2357/specular-differentiation},
  version = {1.3.3},
  year = {2026},
}

References

One dimension

[1] K. Jung. Specular differentiation in one dimension: a quasi-mean value theorem, regularity, and discontinuities. arXiv preprint arXiv:2601.09900v5, 2026.

[2] K. Jung and J. Oh. Regular specular differentiation in Euclidean spaces. arXiv preprint arXiv:2210.06062v3, 2022.

Higher dimensions

[3] K. Jung. Specular differentiation in normed vector spaces: Quasi-Mean Value and Quasi-Fermat Theorems. arXiv preprint arXiv:2601.10950v4, 2026.

Applications

[4] K. Jung. The specular ellipse method for scalar ordinary differential equations: exactness and accuracy up to fourth order. arXiv preprint arXiv:2608.30280, 2026.

[5] K. Jung and J. Oh. Nonsmooth convex optimization using the specular gradient method with root-linear convergence. arXiv preprint arXiv:2412.20747v3, 2024.

[6] K. Jung. Specular gradient methods for nonsmooth convex optimization in Euclidean spaces: a subgradient selection strategy. arXiv preprint arXiv:2605.25490, 2026.
