subway-access 0.5.1

Spatial analysis toolkit for evaluating NYC subway accessibility, reliability, and equity gaps.

subway-access

subway-access is a Python toolkit for reproducible NYC subway accessibility analysis. It fetches live MTA and Census data, scores every census tract for accessible-station coverage, measures elevator reliability, and produces research-ready panel datasets -- all from a single pip install.

Authored by Blaise Albis-Burdige.

What ships in the package

Data pipeline:

• Fetch MTA subway stations, ADA status, elevator/escalator availability history, equipment assets, street-level entrances, and GTFS-Pathways from public APIs
• Fetch ACS 5-year tract-level demographics (disability, senior, poverty rates)
• Cache reusable local snapshot bundles per study area
• Run the full workflow from the installed subway-access CLI

Analysis:

• Euclidean and OSM-network walk catchments
• Tract-level accessibility gap scoring and rolling station reliability
• Station-level metrics combining coverage, need, and reliability
• Borough and group-level summary aggregation
• Export to GeoJSON, CSV, and station metric formats

Composable factor pipeline (v0.4):

• Class-based Factor / Pipeline system inspired by Quantopian's Zipline
• 7 built-in factors: NeedScore, Coverage, GapScore, NearestStationDistance, NearestStationTravelMinutes, StationCount, ReliabilityWeightedCoverage
• Custom factors via subclassing -- bring in external data (housing costs, economic indicators) as first-class inputs
• PipelineResult with .to_records() and optional .to_dataframe()

Temporal panel infrastructure (v0.4):

• Multi-vintage ACS fetcher for longitudinal demographic data
• Station ADA upgrade timeline construction
• Geographic panel dataset builder (tract x year) with treatment/control splitting
• Distance-based spatial weights matrix with PySAL bridge

Helpers (v0.4):

• Multi-borough snapshot iteration with independent caching
• Generic CSV export from frozen dataclasses with auto fieldnames
• Metadata and markdown report writing utilities

10 public modules, 123 public symbols across models, io, analysis, factors, helpers, export, pipeline, temporal, and cli.

Quickstart

pip install subway-access

For the full plotting + geographic + network stack:

pip install "subway-access[all]"

Fetch a real official-data borough snapshot:

subway-access fetch-snapshot --geography borough --value Manhattan --cache-dir cache/manhattan

Then analyze the cached snapshot:

subway-access analyze-snapshot --cache-dir cache/manhattan --output-dir artifacts/manhattan

Python example

from pathlib import Path

from subway_access import analysis, models, pipeline

snapshot = pipeline.fetch_study_area_snapshot(
    models.AccessibilityQuery(geography="borough", value="Manhattan"),
    cache_dir=Path("cache/manhattan"),
)
catchments = analysis.generate_catchments(
    snapshot.stations,
    models.CatchmentRequest(minutes=10),
)
scores = analysis.score_accessibility(
    snapshot.stations,
    catchments,
    snapshot.demographics,
)
reliability = analysis.compute_reliability(
    snapshot.stations,
    snapshot.outages,
    models.TimeWindow(days=30),
)
gaps = analysis.analyze_gaps(scores)
print(len(gaps.records), len(reliability.records))

Factor pipeline

The composable factor pipeline lets you build custom classification models that run in a single pass over every tract. Each Factor receives row-level context (tract demographics, station data, catchments, and an extensible extras slot for external data) and returns a typed value.

from subway_access.factors import (
    CoverageFactor,
    FactorContext,
    GapScoreFactor,
    NearestStationDistanceFactor,
    NeedScoreFactor,
    Pipeline,
    ReliabilityWeightedCoverageFactor,
    StationCountFactor,
)

# Compose a pipeline from built-in factors.
pipe = (
    Pipeline()
    .add(NeedScoreFactor())
    .add(CoverageFactor())
    .add(GapScoreFactor())
    .add(NearestStationDistanceFactor())
    .add(StationCountFactor())
)

# Build contexts from a loaded snapshot.
contexts = [
    FactorContext(tract=t, stations=snapshot.stations, catchments=catchments)
    for t in snapshot.demographics.tracts
]

# Run all factors across all tracts.
result = pipe.run(contexts)
result.to_records()  # tuple of dicts
result.to_dataframe()  # pandas DataFrame (optional dep)

Custom factors are simple subclasses:

from subway_access.factors import Factor, FactorContext


class HousingCostFactor(Factor):
    name = "median_rent"
    dtype = "float"

    def __init__(self, rents: dict[str, float]) -> None:
        self._rents = rents

    def compute(self, context: FactorContext) -> float:
        return self._rents.get(context.tract.tract_id, 0.0)

Add reliability weighting to distinguish nominal from effective coverage:

# Build reliability scores from outage data.
reliability = analysis.compute_reliability(
    snapshot.stations, snapshot.outages, models.TimeWindow(days=365)
)
rel_scores = {r.station_id: r.reliability_score for r in reliability.records}

# Add reliability-weighted coverage to the pipeline.
pipe = pipe.add(ReliabilityWeightedCoverageFactor(rel_scores))

For a full worked example using the factor pipeline across all five boroughs with geographic choropleths, diagnostic checks, and auto-generated reporting, see examples/accessibility-change-over-time/.

Temporal panel

Build geographic panel datasets for difference-in-differences or spatial autoregressive panel estimation:

from subway_access.temporal import build_panel_dataset, build_upgrade_timeline

# Build an upgrade timeline from station data + known upgrade years.
timeline = build_upgrade_timeline(
    snapshot.stations,
    known_upgrades={"station_1": 2019, "station_2": 2021},
)

# Construct the panel (tract x year).
panel = build_panel_dataset(vintage_estimates, station_locations, timeline)
panel.treatment_group()  # tracts that gained accessibility
panel.control_group()  # tracts that did not
panel.to_dataframe()  # pandas DataFrame with (unit_id, period) index

The accessibility-change-over-time example builds a full 5-borough panel (2,317 tracts x 7 years = 16,219 observations) and produces a research report with treatment-vs-control balance checks, spatial weights, and model specification.

Examples

examples/ follows a self-contained project pattern. Each folder has its own pyproject.toml, README.md, main.py, and tracked reports/ output.

• fetch-borough-snapshot/ -- minimal data fetch
• borough-gap-analysis/ -- gap scoring and visualization
• outage-reliability-report/ -- station reliability analysis
• multi-borough-access-profile/ -- cross-borough comparison
• network-access-comparison/ -- Euclidean vs OSM walking network
• accessibility-change-over-time/ -- full research pipeline with factor analysis, geographic maps, temporal panel, diagnostic checks, and auto-generated report (sample report)
• factor-factory-rdd-walkthrough/ -- minimal recipe: regression discontinuity at the 800 m ADA walk-radius threshold using factor-factory engines + jellycell tearsheets
• example-template/ -- bootstrap template for new examples

Extending with factor-factory (optional)

subway-access integrates with factor-factory --- a causal-inference engine registry --- and jellycell for tearsheet rendering, via the optional [factor-factory] and [tearsheets] extras:

pip install "subway-access[factor-factory,tearsheets]"

This unlocks the subway_access.reporting module (lazy-imports; a plain pip install subway-access leaves the library fully usable without these deps) and an "Engine audit" appendix on the accessibility case study that cross-checks the headline findings with five factor-factory engine fits: two-way fixed-effects DiD (did.twfe), Sun-Abraham IW (did.sa), augmented synthetic control (scm.augmented), regression discontinuity at the 800 m walk radius (rdd.rd_robust), and Moran's I via the registry (spatial.morans_i). Each fit emits a JSON artifact consumed by the shipped jellycell findings.md.j2 tearsheet template.

For the wiring pattern, see docs/factor-factory-integration.md and the minimal recipe in examples/factor-factory-rdd-walkthrough/.

Methodology

The workflow is intentionally explicit and reproducible:

1. Select a study area through nyc-geo-toolkit (borough, community district, council district)
2. Fetch official MTA and Census sources into a local cache
3. Load cached files into typed, frozen in-memory datasets
4. Generate Euclidean walk catchments (800 m / 10-min default) or OSM network isochrones
5. Score tract centroids against accessible-station catchments via the factor pipeline
6. Compute tract need, rolling reliability, and station metrics
7. Optionally build a temporal panel for causal analysis
8. Export publishable GeoJSON, CSV, and markdown outputs

Euclidean access remains the documented baseline. The network comparison layer shows how real walking routes change the coverage picture. The factor pipeline and temporal panel support research-grade analysis on top of the same data foundation.

Documentation

• Hosted docs: subway-access.readthedocs.io
• Local preview: make docs
• Strict docs build: make docs-build

Quick links: Home, Getting Started, CLI Reference, Architecture, Python API, Contributing, Releasing, Changelog

Development

make install      # full contributor environment with all extras
make test         # pytest suite
make lint         # ruff + mypy + public API audit
make check        # lint + tests (pre-push gate)
make docs-build   # strict mkdocs build
make ci           # full local CI equivalent

License

MIT.
