threejs-materials 1.1.1

Download PBR materials on demand and convert to Three.js MeshPhysicalMaterial JSON

threejs-materials

A Python library that converts PBR materials into Three.js MeshPhysicalMaterial-compatible JSON. Textures are stored as separate files on disk and only base64-encoded when sending to the viewer.

Uses pygltflib for standard glTF 2.0 file I/O (.gltf and .glb).

Supported input formats:

• glTF exports from Blender — export a mesh with the desired material to a .gltf or .glb file and load it with PbrProperties.load_gltf(). All PBR textures are read automatically via pygltflib.
• MaterialX — download MaterialX materials on demand from four open sources, bake procedural graphs into flat textures, and cache results locally. See MaterialX sources.

Studio mode (full PBR)	CAD mode (interpolate_color())

Migration from v0.x to v1.X

v1.0.0 is a breaking change. The Material class has been replaced by typed dataclasses. See Migration details for a full guide.

Installation

glTF support

pip install threejs-materials
# uv pip install threejs-materials
# uv add threejs-materials

Dependencies

• pillow >= 10.0 — image processing
• pygltflib >= 1.16 — glTF 2.0 file I/O (pure Python)
• requests >= 2.31.0 — HTTP downloads from material sources

This allows you to

• import materials from *.gltf and *.glb files (e.g. baked materials from blender)
• export materials in the internal format to *.gltf and *.glb files
• inject materials into glTF exports

MaterialX support (optional)

pip install threejs-materials[materialx]
# uv pip install threejs-materials[materialx]
# uv add --extra materialx threejs-materials

Additional dependencies

• materialx >= 1.39.4 — MaterialX SDK with TextureBaker
• openexr >= 3.3 — EXR to PNG conversion

This lets you download MaterialX files from the MaterialX sources and bake them into the internal format. However, for the latest Python, the installer tries to compile materialx and openexr. This might not be possible under Windows if no compiler is installed.

Input Formats

1 Blender glTF exports

Blender supports two main ways of building materials:

• Texture materials use image files, such as photos or painted maps, to define how a surface looks. They are straightforward to export and reuse because they rely on standard image data.
• Procedural materials are generated mathematically inside Blender. They can create detailed, seamless looks and are easy to tweak, but they are more tied to Blender's internal system.

glTF/GLB export

glTF and GLB exports handle texture materials reliably but struggle with complex procedural materials. In Blender's glTF exporter, procedural features like shader node graphs (Noise, Voronoi, Wave, etc.) are typically not supported; they often export as a flat color or lose detail. To preserve the appearance, bake procedural materials into image textures first, converting them to standard texture materials.

Baking

Baking turns a procedural material into image maps. Blender renders the material into texture files like base color, roughness, or normal maps, which then replace the procedural nodes. This ensures compatibility with glTF/GLB and other software unfamiliar with Blender's procedural system. Use Blender's built-in baking tools, or simplify the process with add-ons like SimpleBake. Workflow

1. Apply the material to a mesh in Blender (.g. to the standard cube).

2. If procedural, bake it to a texture material.

3. Go to File → Export → glTF 2.0 (.glb/.gltf).

4. Select glTF Separate (.gltf + .bin + textures) for separate texture files if needed.

5. Load in Python:

   from threejs_materials import PbrProperties
   materials = PbrProperties.load_gltf("brass_cube.gltf")   # .gltf or .glb
   brass = materials["Brushed brass"]  # access by material name


That gives you a clean, portable material workflow: procedural inside Blender, baked to textures for export. Both .gltf and .glb are supported, and texture file paths are typically resolved automatically during export.

Format mapping glTF → internal

glTF field	Internal property	Notes
pbrMetallicRoughness.baseColorFactor	color (RGB) + opacity (alpha)	Alpha < 1.0 also sets transparent: true
pbrMetallicRoughness.baseColorTexture	color texture
pbrMetallicRoughness.metallicFactor	metalness	Default 1.0
pbrMetallicRoughness.roughnessFactor	roughness	Default 1.0
pbrMetallicRoughness.metallicRoughnessTexture	metalness + roughness texture	Same packed texture assigned to both; Three.js reads G=roughness, B=metalness
normalTexture	normal texture	.scale → normalScale
occlusionTexture	ao texture
emissiveFactor	emissive
emissiveTexture	emissive texture
alphaMode: "BLEND"	transparent: true
alphaMode: "MASK"	alphaTest = alphaCutoff
doubleSided	side: 2
KHR_materials_* extensions	Corresponding internal properties	See glTF extensions table

Limitations

• Multiple materials supported — load_gltf() and from_gltf() return a dict[str, PbrProperties] keyed by material name. A Blender export with multiple materials is loaded in a single call.
• Geometry is ignored — only the material and its textures are imported. The mesh, nodes, and scene hierarchy are discarded.
• Partial UV transforms — KHR_texture_transform scale and rotation are imported as texture_repeat and texture_rotation. Offset is not supported.
• glTF defaults applied — when metallicFactor or roughnessFactor are absent, glTF defaults (1.0) are used. This is correct for texture-driven materials where the scalar is a neutral multiplier.
• Fully opaque alpha ignored — when Blender exports alphaMode: "BLEND" but the baseColor texture alpha channel is entirely opaque (255 everywhere), the transparency flag is skipped. This is a common Blender export artifact.

2 MaterialX

The following sources are available for MaterialX downloads:

Source	Type	Shader model
ambientCG	Texture-based	open_pbr_surface
GPUOpen MaterialX Library	Procedural (baked)	standard_surface
PolyHaven	Texture-based	standard_surface
PhysicallyBased	Parametric (no textures)	open_pbr_surface

Browse materials on the source websites, then load them by name.

When a material is loaded the following steps are executed:

1. Download — source-specific: fetch ZIP (ambientCG, GPUOpen), individual files (PolyHaven), or generate from parameters (PhysicallyBased)
2. Bake — run MaterialX TextureBaker (GLSL preferred, MSL fallback on macOS) to flatten procedural graphs into texture images
3. Fallback merge — if the baker can't handle certain textures, merge from the original document
4. EXR to PNG — convert any EXR textures to 8-bit PNG
5. Extract — map shader inputs to MeshPhysicalMaterial properties with texture file references
6. Cache — write JSON + texture files to ~/.materialx-cache/

Converted materials are cached in ~/.materialx-cache/ as a small JSON file (property values + texture filenames) plus a companion directory with the texture images:

~/.materialx-cache/
    gpuopen_car_paint_1k.json              # few KB — values + texture refs
    gpuopen_car_paint_1k/                  # texture images
    ambientcg_onyx015_1k.json
    ambientcg_onyx015_1k/
        ...

Textures are only base64-encoded when to_dict() is called (for sending to the Three.js viewer). This keeps the cache lightweight and allows multiple materials to share the same texture files without duplicating large blobs in memory.

To force re-conversion, clear the cache with clear_cache(name=...) or delete the files manually.

Shader model coverage

Supported models: standard_surface, gltf_pbr, open_pbr_surface. Other models produce empty output with a logged warning.

Feature	standard_surface	gltf_pbr	open_pbr_surface
Base color	Yes	Yes	Yes
Metalness	Yes	Yes	Yes
Roughness	Yes	Yes	Yes
Normal map	Yes	Yes	Yes
Specular	Yes (weight, color, IOR)	Yes (weight, color, IOR)	Yes (weight, color, IOR)
Transmission	Yes	Yes (+ attenuation)	Yes (+ attenuation)
Emission	Yes	Yes	Yes
Clearcoat	Yes	Yes	Yes
Clearcoat normal	Yes	Yes	Yes
Sheen	Yes	Yes	Yes (fuzz)
Iridescence	Yes	Yes	Yes
Anisotropy	No (see note)	Yes	No (see note)
Opacity	Yes	Yes (alpha/alpha_mode)	Yes (geometry_opacity)
Displacement	Yes (model-independent)	Yes	Yes
Dispersion	No	Yes	Yes
Normal scale	No (baked into texture)	Yes	No (baked into texture)
Thin-walled	No	No	Yes (→ DoubleSide)
Subsurface	No	No	No

Subsurface scattering is not mapped — Three.js MeshPhysicalMaterial has no SSS support.

Anisotropy is only mapped for gltf_pbr, where anisotropy_strength corresponds directly to glTF/Three.js anisotropyStrength. For standard_surface (specular_anisotropy) and open_pbr_surface (specular_roughness_anisotropy), anisotropy is not mapped — these models split roughness into directional axes (α·(1±a)), while glTF boosts one axis from base roughness (mix(α, 1, s²)). The models are structurally incompatible and no scalar remap produces correct results across different roughness values.

MaterialX limitations

• Materials

  • Single material per document — only the first material is used when a .mtlx file contains multiple materials. A warning is logged.
  • First shader node — if a material has multiple shader nodes (e.g. surface + volume), only the first surface shader is extracted.

• Baking

  • 8-bit textures — the TextureBaker uses UINT8 output. HDR information (emissive, HDR environment lighting baked into textures) is clamped to [0,1]. This is acceptable for web preview but lossy for physically accurate emissive maps.
  • Global bake lock — baking operations are serialized via a threading.Lock because the MaterialX baker requires os.chdir. This is thread-safe but becomes a bottleneck under concurrent load. The lock is per-process only (threading.Lock, not multiprocessing.Lock).
  • Geometry-dependent nodes — procedurals driven by <position>, <normal>, or <tangent> cannot be baked (the baker renders on a flat UV quad with no 3D geometry).

• Image tracing

  • Single upstream image — find_upstream_image returns the first image node found when walking upstream. Complex graphs with multiple images (layered blends, channel packing before baking) will only capture one image. After baking, this is fine since the baker flattens everything to single <image> nodes.
  • No channel extraction tracking — when an image passes through extract or swizzle nodes, the specific channel being used is not recorded. The consumer must know glTF metallicRoughness packing conventions (G=roughness, B=metalness).

• EXR conversion

  • LDR clamp — EXR textures are clamped to [0,1] and converted to 8-bit PNG. Dynamic range beyond 1.0 is lost.
  • Channel naming — EXR files with non-standard channel names (not R/G/B/A) fall back to source-order channel selection, which may produce incorrect color mappings for unusual EXR layouts.

• Network

  • No retry logic — a single network failure raises an exception. The caller is responsible for retries.
  • GPUOpen pagination — the material search assumes all results fit in one API page. Materials not in the first page may not be found.
  • GPUOpen sequential package lookup — each package UUID is queried individually; materials with many packages may be slow to resolve.

• Caching

  • No cache invalidation — cached materials are never automatically refreshed. Delete the cache file manually to force re-conversion.

Output Formats

1 Three.js (internal format)

The internal format uses Three.js MeshPhysicalMaterial property names. Both MaterialX and glTF import pipelines produce the same structure. Scalar values live in PbrValues, texture references in PbrMaps.

In memory, textures are stored as filenames relative to maps_dir. When to_dict() is called (for the viewer), they are resolved to base64 data URIs:

mat = PbrProperties.from_gpuopen("Car Paint")
mat.values   # PbrValues(color=[0.944, 0.776, 0.373], metalness=1.0, ...)
mat.maps     # PbrMaps(roughness='roughness.png', normal='normal.png')
mat.maps_dir # Path('~/.materialx-cache/gpuopen_car_paint_1k')

to_dict() output:

{
  "id": "Car Paint",
  "name": "Car Paint",
  "source": "gpuopen",
  "values": {
    "color": [0.944, 0.776, 0.373],
    "metalness": 1.0,
    "roughness": 0.5,
    "ior": 1.5
  },
  "textures": {
  }
}

Each output property maps to Three.js MeshPhysicalMaterial fields:

Output property	value →	texture →
color	color	map
metalness	metalness	metalnessMap
roughness	roughness	roughnessMap
normal	—	normalMap
normalScale	normalScale	—
ao	—	aoMap
emissive	emissive	emissiveMap
emissiveIntensity	emissiveIntensity	—
ior	ior	—
transmission	transmission	transmissionMap
thickness	thickness	thicknessMap
attenuationColor	attenuationColor	—
attenuationDistance	attenuationDistance	—
clearcoat	clearcoat	clearcoatMap
clearcoatRoughness	clearcoatRoughness	clearcoatRoughnessMap
clearcoatNormal	—	clearcoatNormalMap
sheen	sheen	—
sheenColor	sheenColor	sheenColorMap
sheenRoughness	sheenRoughness	sheenRoughnessMap
iridescence	iridescence	iridescenceMap
iridescenceIOR	iridescenceIOR	—
iridescenceThicknessRange	iridescenceThicknessRange	—
anisotropy	anisotropy	anisotropyMap
anisotropyRotation	anisotropyRotation	—
specularIntensity	specularIntensity	specularIntensityMap
specularColor	specularColor	specularColorMap
opacity	opacity	alphaMap
transparent	transparent	—
alphaTest	alphaTest	—
dispersion	dispersion	—
displacement	—	displacementMap
displacementScale	displacementScale	—
side	side	—
metallicRoughness	—	metalnessMap + roughnessMap (G=roughness, B=metalness)

2 glTF

to_gltf() converts a single material to a pygltflib.GLTF2 object. collect_gltf_textures() does the same for multiple materials with shared, deduplicated textures. save_gltf() writes to disk as .gltf (JSON + external texture files) or .glb (single binary). Advanced material features are mapped to standard KHR_materials_* extensions:

Feature	glTF extension
IOR	KHR_materials_ior
Transmission	KHR_materials_transmission
Volume (thickness, attenuation)	KHR_materials_volume
Clearcoat	KHR_materials_clearcoat
Sheen	KHR_materials_sheen
Iridescence	KHR_materials_iridescence
Anisotropy	KHR_materials_anisotropy
Specular	KHR_materials_specular
Emissive strength	KHR_materials_emissive_strength
Dispersion	KHR_materials_dispersion
Texture repeat	KHR_texture_transform

Usage

• Save to file

  from threejs_materials import PbrProperties

  mat = PbrProperties.from_gpuopen("Car Paint")
  mat.save_gltf("car-paint.gltf")   # .gltf + car-paint/ (texture files)
  mat.save_gltf("car-paint.glb")    # single binary file


• Load from file

  materials = PbrProperties.load_gltf("scene.gltf")   # .gltf or .glb
  brass = materials["Brushed brass"]              # access by name


• In-memory GLTF2 object

  gltf = mat.to_gltf()                            # pygltflib.GLTF2
  materials = PbrProperties.from_gltf(gltf)        # dict[str, PbrProperties]


• Multiple materials with texture deduplication

  from threejs_materials import PbrProperties, collect_gltf_textures

  materials = {
      "body": PbrProperties.from_gpuopen("Car Paint"),
      "wood": PbrProperties.from_gpuopen("Ivory Walnut Solid Wood"),
      "glass": PbrProperties.from_physicallybased("Glass"),
  }

  gltf = collect_gltf_textures(materials)  # pygltflib.GLTF2


• Texture repeat and rotation

  scale() is exported as the KHR_texture_transform extension on each texture reference:

  tiled = mat.scale(2, 2, rotation=90)  # 2x larger, 90° counterclockwise
  gltf = tiled.to_gltf()
  # Each texture ref: "extensions": {"KHR_texture_transform": {"scale": [0.5, 0.5], "rotation": 1.5708}}


  Note: scale(1, 1) with no rotation is a no-op for glTF export — no KHR_texture_transform extension is added.

Three.js ↔ glTF conversion

The glTF export is visually lossless for all properties except displacement. The round-trip to_gltf() → from_gltf() preserves material appearance but merges some internal representations:

Property	Round-trip behavior
All scalar values	Preserved exactly
All textures	Preserved (base64 URIs survive the round-trip)
Opacity texture	Merged into baseColorTexture alpha channel — cannot be separated back
Separate metalness + roughness textures	Packed into one metallicRoughnessTexture — comes back as same packed texture on both metalness and roughness
displacement / displacementScale	Lost — no glTF equivalent (see note below)
texture_repeat / texture_rotation / scale()	Preserved via KHR_texture_transform (rotation in radians on the wire)
Source metadata (id, source, url, license)	Not stored in glTF; from_gltf() sets source="gltf"

Round-trip example

from threejs_materials import PbrProperties

m = PbrProperties.from_gpuopen("Perforated Metal")
g = m.to_gltf()
m2 = PbrProperties.from_gltf(g)["Perforated Metal"]

Results

• Original material (m):

  PbrProperties(name='Perforated Metal', source='gpuopen', license='MIT Public Domain')
    values:  PbrValues(color=[0.665, 0.665, 0.665], metalness=1.0, ...)
    maps:    PbrMaps(color='color.png', roughness='roughness.png', normal='normal.png', opacity='opacity.png')


• After round-trip (m2):

  PbrProperties(name='Perforated Metal', source='gltf', license='')
    values:  PbrValues(color=[0.665, 0.665, 0.665], metalness=1.0, alpha_test=0.5, ...)
    maps:    PbrMaps(color='data:...;base64,...', metalness='data:...;base64,...', roughness='data:...;base64,...', normal='data:...;base64,...')


What changed:

• opacity map disappeared — it was merged into the color texture's alpha channel (glTF has no separate opacity texture). The resulting RGBA baseColorTexture is now the color texture.
• alpha_test: 0.5 appeared — since the original had an opacity texture, to_gltf() sets alphaMode: "MASK" with alphaCutoff: 0.5. On import this becomes alpha_test.
• Separate metalness + roughness textures → packed and back — glTF packs metalness and roughness into a single metallicRoughnessTexture (G=roughness, B=metalness). On import, this packed texture is assigned to both metalness and roughness properties (same texture, Three.js reads the correct channel from each).

The visual result is identical — all changes are representation differences, not data loss.

glTF export transformations

to_gltf() is mostly a field-name translation from our internal format to glTF 2.0, but seven spec-mandated transformations repackage data:

Internal	glTF equivalent	Reason
metalness + roughness textures (separate)	packed metallicRoughnessTexture (G=rough, B=metal)	glTF 2.0 core: only packed form exists
color texture + opacity texture	merged into baseColorTexture alpha channel	glTF has one base-color texture slot
opacity scalar	folded into baseColorFactor[3] (alpha)	glTF baseColorFactor is always 4 elements [r, g, b, a]
transparent / alphaTest	alphaMode enum (OPAQUE/MASK/BLEND) + alphaCutoff	glTF's alpha-handling vocabulary
iridescenceThicknessRange = [min, max]	split into iridescenceThicknessMinimum + iridescenceThicknessMaximum	KHR_materials_iridescence schema
dispersion > 0	auto-adds minimal KHR_materials_volume = {thicknessFactor: 0}	KHR_materials_dispersion spec requires volume to also be present
emissiveIntensity ≠ 1.0	KHR_materials_emissive_strength extension	glTF core has no emissive intensity — the extension is the Khronos-blessed way

All seven are required by glTF 2.0 core or by the relevant KHR_materials_* extension — none are invented by this library. Scalar values, color values, and pixel data are not altered; the data is just repackaged into the shape glTF expects.

Two minor policy choices sit inside the transformations (both emit spec-valid output, but pick among equally-valid alternatives):

• Opacity-texture-only → alphaMode = "MASK" (with alphaCutoff = 0.5) rather than "BLEND". Avoids depth-sort bleed-through on closed shapes like spheres.
• iridescenceThicknessRange = [X, X] when the MaterialX source has a single thin_film_thickness scalar (uniform thickness). Could also be emitted as [0, X]; we pick [X, X] to faithfully represent the single-scalar semantic.

Note on displacement

Displacement mapping is the only property fully lost in the glTF conversion. In practice this is rarely an issue for CAD workflows:

• Displacement is a vertex-level effect — it offsets mesh vertices along their normals based on a texture. This requires a sufficiently dense mesh to produce visible detail.
• CAD tessellation produces meshes optimized for geometric accuracy, not displacement fidelity. Large flat faces (common in CAD) are tessellated with very few triangles, making displacement ineffective.
• Even in the internal Three.js format, displacement is optional and most CAD viewers ignore it.
• For visual surface detail, normal maps (which survive the round-trip) are a better fit — they simulate surface relief without requiring extra geometry.

Common API

Loading from sources

• PbrProperties.from_gpuopen(name, resolution="1K") -> PbrProperties

• PbrProperties.from_ambientcg(name, resolution="1K") -> PbrProperties

• PbrProperties.from_polyhaven(name, resolution="1K") -> PbrProperties

• PbrProperties.from_physicallybased(name, resolution="1K") -> PbrProperties

  Download, convert, and cache a material.

  from threejs_materials import PbrProperties

  mat = PbrProperties.from_gpuopen("Car Paint", resolution="1K")
  mat = PbrProperties.from_ambientcg("Onyx015", resolution="1K")
  mat = PbrProperties.from_polyhaven("plank_flooring_04", resolution="1K")
  mat = PbrProperties.from_physicallybased("Titanium")


  The first call downloads and converts the material (takes a few seconds). Subsequent calls return the cached JSON instantly from ~/.materialx-cache/.

  Resolution

  Pass a normalized resolution (1K, 2K, 4K, 8K — case-insensitive). Each source maps it to its native format:

  Input	GPUOpen	ambientCG	PolyHaven	PhysicallyBased
  1K	1k 8b	1K-PNG	1k	n/a
  2K	2k 8b	2K-PNG	2k	n/a
  4K	4k 8b	4K-PNG	4k	n/a
  8K	—	8K-PNG	8k	n/a

  PhysicallyBased materials are parametric — no resolution needed (and not accepted).

• list_sources()

  Print available sources with clickable URLs.

  from threejs_materials.sources import list_sources

  list_sources()
  # Material sources:
  #   load_ambientcg        https://ambientcg.com/list?type=material
  #   load_gpuopen          https://matlib.gpuopen.com/main/materials/all
  #   load_polyhaven        https://polyhaven.com/textures
  #   load_physicallybased  https://physicallybased.info/


• PbrProperties.from_mtlx(mtlx_file) -> PbrProperties

  Convert a local .mtlx file without downloading anything.

  from threejs_materials import PbrProperties

  mat = PbrProperties.from_mtlx("examples/gpuo-car-paint.mtlx")


  Texture paths in the .mtlx are resolved relative to the file's location.

Customization

• material.override(**props) -> PbrProperties

  Return a new PbrProperties with value overrides. The original material is not modified. All fields on PbrValues are accepted as kwargs.

  from threejs_materials import PbrProperties

  mat = PbrProperties.from_gpuopen("Car Paint")
  red_paint = mat.override(color=(0.8, 0.1, 0.1))
  rough_red = mat.override(color=(0.8, 0.1, 0.1), roughness=0.9)


  Overrides set the value of the named property, creating it if absent. Existing textures are preserved. Calls can be chained: mat.override(color=(1,0,0)).override(roughness=0.5).

• material.scale(u, v, fixed=True, rotation=0.0) -> PbrProperties

  Return a new PbrProperties with texture scaling and rotation applied. The original material is not modified.

  tiled = mat.scale(3, 3)                # texture appears 3x larger
  small = mat.scale(0.5, 0.5)            # texture tiles 2x in each direction
  rotated = mat.scale(2, 2, rotation=90) # 2x larger, rotated 90° counterclockwise


  scale(u, v) sets texture_repeat = (1/u, 1/v) internally. rotation is in degrees, counterclockwise, pivoted at the texture center (0.5, 0.5). In Three.js these map to texture.repeat and texture.rotation (radians); in glTF they export as KHR_texture_transform with scale and rotation. Each call replaces the full transform — to combine, pass them in the same call. Can be chained with override(): mat.override(color=(1,0,0)).scale(2, 2, rotation=45).

Variant ids

Both override() and scale() produce a distinct id on the returned material so variants don't silently collide when keyed into a dict:

mat = PbrProperties.from_gpuopen("Car Paint")
# mat.id == "Car Paint"

red = mat.override(color=(1, 0, 0))
# red.id == "Car Paint_a3f2e4b1"         ← hashed suffix
# red.name == "Car Paint"                 ← display name unchanged

chained = red.override(roughness=0.1)
# chained.id == "Car Paint_e5f6g7h8"      ← fresh hash (not appended)

The hash is the first 8 hex chars of blake2b((parent_id, kwargs)), deterministic across Python sessions. Same call with same kwargs on the same parent produces the same id — so mat.override(color=(1,0,0)) and a second call with identical args are == by id, enabling idempotent caching and {m.id: m for m in mats} dict construction without collisions. Chained calls cascade the parent id into the hash, so different chains are distinguishable even if their final state happens to coincide.

Texture scaling

The fixed parameter on scale() controls how UVs are interpreted:

• fixed=True (default): The viewer normalizes UVs so that texture density is independent of object size. A brushed aluminum pattern looks the same on a small bracket and a large panel. This is the physically correct behavior for CAD — materials have a fixed physical scale.

• fixed=False: Raw parametric UVs are used. Texture size depends on object geometry, matching standard glTF/GLB viewer behavior.

# Fixed physical scale (default) — same texture density on all parts
wood = PbrProperties.from_gpuopen("Walnut").scale(2, 2)

# Geometry-dependent — texture tiles based on surface parameterization
wood_raw = PbrProperties.from_gpuopen("Walnut").scale(2, 2, fixed=False)

The normalize_uvs flag is serialized in to_dict() as "normalizeUvs": false when disabled. Materials imported from glTF (from_gltf, load_gltf) default to normalize_uvs=False since glTF UVs are already baked into the mesh.

Import and Export

• PbrProperties.from_mtlx(mtlx_file) -> PbrProperties

  Convert a local .mtlx file. Texture paths are resolved relative to the file's location. See MaterialX for details.

  mat = PbrProperties.from_mtlx("examples/gpuo-car-paint.mtlx")


• PbrProperties.load_gltf(gltf_file) -> dict[str, PbrProperties]

  Load all materials from a .gltf or .glb file on disk. Returns a dict keyed by material name. Uses pygltflib to read the file and resolve textures automatically. Ideal for importing Blender glTF exports.

  materials = PbrProperties.load_gltf("brass_cube.gltf")   # or .glb
  brass = materials["Brushed brass"]


• PbrProperties.from_gltf(gltf) -> dict[str, PbrProperties]

  Import all materials from a pygltflib.GLTF2 object. Returns a dict keyed by material name. Accepts both file-referenced and data-URI images (file references are converted to data URIs automatically). See Three.js ↔ glTF conversion for round-trip behavior.

  from pygltflib import GLTF2

  gltf = GLTF2().load("scene.gltf")
  materials = PbrProperties.from_gltf(gltf)
  body = materials["Car Paint"]
  glass = materials["Glass"]


• material.to_gltf() -> GLTF2

  Convert a single material to a self-contained pygltflib.GLTF2 object with data-URI textures. See glTF for the schema.

  gltf = mat.to_gltf()


• material.save_gltf(path, overwrite=False)

  Save the material as a .gltf or .glb file. For .gltf, textures are written as separate files in a companion directory. For .glb, textures are embedded.

  mat.save_gltf("wood.gltf")                      # wood.gltf + wood/color.png, ...
  mat.save_gltf("wood.glb")                        # single binary file
  mat.save_gltf("wood.gltf", overwrite=True)       # overwrite existing


• collect_gltf_textures(materials) -> GLTF2

  Convert multiple materials to a pygltflib.GLTF2 with shared, deduplicated textures. Returns the same type as to_gltf(). See glTF for details.

  from threejs_materials import PbrProperties, collect_gltf_textures

  gltf = collect_gltf_textures({
      "body": PbrProperties.from_gpuopen("Car Paint"),
      "glass": PbrProperties.from_physicallybased("Glass"),
  })


Utilities

• material.dump(gltf=False, json_format=False) -> str

  Return a human-readable summary of the material. Textures are abbreviated. Also used by repr(material).

  print(mat.dump())                          # Three.js properties, text
  print(mat.dump(gltf=True))                 # glTF structure, text
  print(mat.dump(json_format=True))          # Three.js properties, JSON
  print(mat.dump(gltf=True, json_format=True))  # glTF structure, JSON


• material.interpolate_color() -> (r, g, b, a)

  Estimate a single representative sRGB color from a material — useful for CAD viewers that need a flat color per object while keeping a material dictionary for full PBR rendering.

  from threejs_materials import PbrProperties

  wood = PbrProperties.from_gpuopen("Ivory Walnut Solid Wood")
  materials = {"wood": wood}      # keep for full PBR rendering
  object.material = "wood"
  object.color = wood.interpolate_color()   # (r, g, b, a) sRGB preview


  When the material has a color texture, the texture is decoded and its average (linear) is gamma-encoded to sRGB for output (requires Pillow); the scalar values.color is ignored in that case — including it produces a pre-tone-mapping color visibly darker than the on-screen render. When no texture is present, values.color (sRGB-stored — see "Color space convention" below) is returned directly. Transmission and opacity are mapped to the alpha channel so glass-like materials appear semi-transparent.

• encode_texture_base64(file_path) -> str

  Encode an image file as a base64 data URI. Automatically converts EXR to PNG.

  from threejs_materials import encode_texture_base64

  data_uri = encode_texture_base64("path/to/textures/normal.png")


Cache management

• list_cache(as_json=False)

  Print a grouped summary of cached materials, or return a list of tuples.

  from threejs_materials import list_cache

  list_cache()
  # gpuopen
  #   - Aluminum Brushed
  #   - Car Paint
  # ambientcg
  #   - Metal 009

  list_cache(as_json=True)
  # [('ambientcg', 'Metal 009'), ('gpuopen', 'Aluminum Brushed'), ...]


• clear_cache(name=None, source=None) -> int

  Delete cached material files. Returns number of files deleted.

  from threejs_materials import clear_cache

  clear_cache()                          # delete all
  clear_cache(source="gpuopen")          # delete all GPUOpen caches
  clear_cache(name="Car Paint")          # delete by name
  clear_cache(name="brick", source="ambientcg")  # combined filter


Three.js usage

From internal format (single material)

const data = JSON.parse(jsonStr);
const material = new THREE.MeshPhysicalMaterial();

for (const [key, value] of Object.entries(data.values)) {
  if (Array.isArray(value) && value.length === 3) {
    material[key] = new THREE.Color(...value);
  } else {
    material[key] = value;
  }
}

for (const [key, textureUri] of Object.entries(data.textures)) {
  material[PROPERTY_TO_MAP[key]] = new THREE.TextureLoader().load(textureUri);
}

From glTF (multi-material)

When using collect_gltf_textures() to produce a multi-material glTF JSON, load it with Three.js's GLTFLoader:

import { GLTFLoader } from "three/addons/loaders/GLTFLoader.js";

// gltfJson is the output of collect_gltf_textures(), serialized as JSON
const blob = new Blob([gltfJson], { type: "application/json" });
const url = URL.createObjectURL(blob);

const loader = new GLTFLoader();
loader.load(url, (gltf) => {
  // Materials are already created as MeshStandardMaterial / MeshPhysicalMaterial
  const materials = gltf.parser.json.materials;

  // If injected into a geometry glTF, the scene contains the full model
  scene.add(gltf.scene);

  URL.revokeObjectURL(url);
});

Alternatively, when injecting materials into an existing glTF file (e.g. from build123d), simply load that file with GLTFLoader — Three.js handles the images, textures, and materials arrays automatically, including all KHR_materials_* extensions.

Consumer notes

• Color space convention (asymmetric — both for textures and scalars):
  • Textures: include a colorSpace field when available. Three.js expects color textures (baseColor, emissive, sheenColor, specularColor) in sRGB and data textures (roughness, metalness, normal, AO, displacement) in linear. Set texture.colorSpace accordingly.
  • Scalar values.color: stored as sRGB byte ratios in [0, 1]. Three.js renders it via setRGB(r, g, b, SRGBColorSpace) (the viewer linearizes internally). A numeric tuple like (0.5, 0.5, 0.5) means perceptual midgray. Hex/named strings are sRGB at source.
  • Scalar values.emissive / sheen_color / specular_color / attenuation_color: stored as linear RGB in [0, 1]. Matches the glTF *Factor spec and Three.js's bare new THREE.Color(r, g, b) constructor convention. A numeric tuple (0.5, 0.5, 0.5) here means linear midgray (renders as ~73% sRGB perceptually). Hex strings on these fields are gamma-decoded.
  • glTF export converts values.color sRGB→linear at the boundary (baseColorFactor is linear per spec); the other color fields are passed through unchanged (already linear). from_gltf does the inverse.
  • Client-facing APIs (override(), create(), from_pymat(), PbrOverrides) accept the same per-field convention. Numeric tuples for color are sRGB; numeric tuples for emissive / sheen_color / specular_color / attenuation_color are linear. Hex/CSS strings are always sRGB at source and get gamma-decoded only for the linear-stored fields. A 4th-element alpha (or #rrggbbaa) on color lifts into the separate opacity field — explicit opacity= wins.
• Normal maps: Baked using the OpenGL convention (Y-up), matching Three.js and glTF expectations.
• Scalar x texture: When both value and texture are present, Three.js multiplies them. The library sets scalars to 1.0 (neutral) when a texture is present so the texture controls fully.
• glTF packed metallicRoughness: When imported from glTF, the packed metallicRoughnessTexture is assigned to both metalness and roughness as the same texture. Three.js reads G=roughness and B=metalness from the correct channels automatically.

Clients

build123d

build123d exports glTF geometry via OCCT's RWGltf_CafWriter, which handles meshes, nodes, and flat colors. To add PBR materials, post-process the generated glTF file by injecting material data from threejs-materials:

from build123d import export_gltf
from threejs_materials import PbrProperties, inject_materials

# 1. Build your CAD model and assign materials
body.material = Material.create("body", pbr=PbrProperties.from_gpuopen("Car Paint"))
wood.material = Material.create("wood", pbr=PbrProperties.from_gpuopen("Walnut").scale(2, 2))

# 2. Export geometry to glTF (materials are injected automatically)
export_gltf(assembly, "model.glb")

The export_gltf function in build123d automatically detects PBR materials on shapes and calls inject_materials to replace the OCCT-generated placeholder materials with full PBR data including textures and KHR extensions.

Migration details

API changes

v0.x	v1.0.0
Material(data_dict)	PbrProperties.from_dict(data_dict)
Material.gpuopen.load("Car Paint")	PbrProperties.from_gpuopen("Car Paint")
Material.ambientcg.load("Onyx015")	PbrProperties.from_ambientcg("Onyx015")
Material.polyhaven.load("plank")	PbrProperties.from_polyhaven("plank")
Material.physicallybased.load("Gold")	PbrProperties.from_physicallybased("Gold")
Material.from_gltf(gltf)	PbrProperties.from_gltf(gltf)
Material.load_gltf("file.glb")	PbrProperties.load_gltf("file.glb")
Material.from_mtlx("file.mtlx")	PbrProperties.from_mtlx("file.mtlx")
Material.list_sources()	from threejs_materials.sources import list_sources
Material.list_cache()	from threejs_materials import list_cache
Material.clear_cache()	from threejs_materials import clear_cache

Data model changes

The properties dict has been replaced by two typed dataclasses:

v0.x	v1.0.0
mat.properties["color"]["value"]	mat.values.color
mat.properties["color"]["texture"]	mat.maps.color
mat.properties["normalScale"]["value"]	mat.values.normal_scale
mat.properties["sheenColor"]["value"]	mat.values.sheen_color
mat.properties["specularIntensity"]["value"]	mat.values.specular_intensity

• PbrValues holds scalar values with snake_case field names
• PbrMaps holds texture references (file paths or data URIs) with snake_case field names
• Field names are automatically mapped to camelCase for Three.js/glTF output via to_dict()
• All fields support IDE tab completion

JSON format changes

The to_dict() output format has changed:

// v0.x
{"properties": {"color": {"value": [1, 0, 0], "texture": "data:..."}}}

// v1.0.0
{"values": {"color": [1, 0, 0]}, "textures": {"color": "data:..."}}

Cache

The cache format changed from "properties" to "values" + "textures". After upgrading, clear the cache:

from threejs_materials import clear_cache
clear_cache()
