wikifi

wikifi walks a legacy codebase and writes a technology-agnostic wiki of what the system does — domains, entities, flows, integrations, and cross-cutting concerns — extracted from the source with citations back to the lines that prove it.

The output is what a migration team needs to re-implement the system on a fresh stack from the wiki alone, without recreating the legacy structure in a new language.

For the full rationale and content contract, see VISION.md. To see the output, browse .wikifi/ — wikifi run against its own source.

Quickstart

# 1. Install in the target project
uv add wikifi

# 2. Scaffold .wikifi/ and config
uv run wikifi init

# 3. Walk the codebase
uv run wikifi walk

LLM Config

.wikifi/config.toml

provider = "anthropic" # openai | local(default)
model = "claude-sonnet-4-6"
# ollama_host = "http://localhost:11434"

By default wikifi runs against a local Ollama server (Qwen 3 27B at the highest reasoning level the model exposes) — no cloud dependency, no API key, no data leaving the machine. Hosted Anthropic and OpenAI backends are opt-in.

What you get

A .wikifi/ directory in the target repo containing the synthesized wiki. The on-disk layout is at the implementor's discretion; the content contract is fixed and lives in VISION.md:

• Primary capture (extracted from source) — domains & subdomains, intent, capabilities, entities, integrations, external dependencies, cross-cutting concerns, hard specifications, and inline schematics.
• Derivative capture (synthesized from the aggregate) — personas, user stories, and 10,000-foot diagrams produced after primary content is complete.

Every claim in the wiki carries a numbered citation back to a SourceRef (file + line range + content fingerprint). Conflicting evidence across files is preserved in a "Conflicts in source" block rather than silently resolved.

CLI

walk flags:

• --no-cache — force a clean re-walk; drops the on-disk extraction + aggregation caches.
• --review — run the critic + reviser loop on derivative sections (personas, user stories, diagrams).
• --provider {ollama|anthropic|openai} — override the configured provider for this walk.

report --score runs the critic on every populated section for a 0–10 quality score.

Providers

The LLM backend is reached through a provider abstraction; swapping it never touches the rest of the system.

• OllamaProvider — default. Local server, no cloud dependency.
• AnthropicProvider — WIKIFI_PROVIDER=anthropic. Uses prompt caching with cache_control: ephemeral on the system prompt so the multi-KB extraction prompt is paid for once across hundreds of per-file calls.
• OpenAIProvider — WIKIFI_PROVIDER=openai. Relies on OpenAI's automatic prefix caching and routes the think knob to reasoning_effort on o* / gpt-5 reasoning models.

How the walk works

The walk has four responsibilities, in order:

1. Introspect — review the target's root structure (manifests, top-level layout, gitignore signals) and decide which paths carry production source worth analyzing. The walk that follows is deterministic; the agent does not re-pick scope mid-walk.
2. Filter — recognize and skip unstructured or near-empty files (stub __init__, empty fixtures, generated lockfiles) before they reach the agent. Empty input must never stall the walk.
3. Extract — for each in-scope file, extract structured findings against the primary capture sections in VISION.md. Each finding carries a SourceRef for downstream citation.
4. Synthesize — primary sections are aggregated from the per-file findings into an EvidenceBundle (body + claims + contradictions). Derivative sections (personas, user stories, diagrams) are produced after primary content is complete, never inferred from a single file.

Supporting machinery:

• Repo graph (wikifi/repograph.py) — regex-driven static analysis builds an import / reference graph and classifies each file's FileKind (application code, SQL, OpenAPI, Protobuf, GraphQL, migration, other). Each file's neighborhood is injected into the extraction prompt so per-file findings can describe cross-file flows.
• Specialized extractors (wikifi/specialized/) — schema files (SQL, OpenAPI, Protobuf, GraphQL, migrations) bypass the LLM and run through deterministic parsers. Structured findings reach the same notes store, so the rest of the pipeline is unchanged.
• Content-addressed cache (wikifi/cache.py) — extraction findings are keyed by (rel_path, sha256(file_bytes)); aggregation bodies are keyed by a hash of the section's notes payload. Re-walks skip every file whose fingerprint hasn't changed; resumability after a crash is a free property of the same cache.
• Critic + reviser (wikifi/critic.py) — opt-in via walk --review. Scores derivative sections against their brief and upstream evidence, identifies unsupported claims, and re-synthesizes when the score is below threshold. Only accepts a revision if it scores at least as well as the original.
• Coverage + quality report (wikifi/report.py) — wikifi report produces a per-section view of files contributing, finding count, body size, and (with --score) critic-derived quality scores.

Configuration

wikifi reads configuration from environment variables. At minimum:

• the LLM provider id and model identifier
• the local Ollama endpoint (when using the default provider)
• bounds on file size and stripped-content size, so unstructured or oversized files never reach the agent
• the agent's thinking / reasoning level — defaults to the highest the chosen model supports

A .env.example will land once the surface is finalized.

Tech stack

• Python 3.12+, packaged with uv
• Local LLM via Ollama as the default runtime; thinking-capable model at the highest available reasoning level
• Provider abstraction — Ollama default; hosted Anthropic and OpenAI slot in without touching the rest of the system
• ruff as the single tool for lint and format
• pytest + pytest-cov for tests (≥85% coverage gate)
• GitHub Actions for CI

Development

make hooks       # one-time: enables .githooks/ pre-commit + pre-push
uv sync          # install dependencies
make test        # run the test suite

See CLAUDE.md for the full development process — commands, code rules, agent workflow, and debug escalation.

Distribution

wikifi ships as a Python library (PyPI / private index) and operates as a CLI invoked from a target project rather than as a server.

License

MIT.
