signavis (Python wrapper)

Python package to embed the SignaVis DAW player in Streamlit, Jupyter, Gradio, and any HTML-capable UI. Supports waveform & spectrogram visualization, annotation, and custom player layouts.

Live demo: https://limitlessgreen.github.io/SignaVis/

Installation

pip install signavis

Optional for demos:

pip install "signavis[streamlit]"
pip install "signavis[gradio]"

Example: Load and Display Your Own Audio

You can load your own audio file (WAV, MP3, etc.) and display it as a spectrogram or waveform in any supported environment. Just read the file as bytes and pass it to render_daw_player:

Jupyter Notebook:

from signavis import render_daw_player

with open("your_audio.wav", "rb") as f:
    audio_bytes = f.read()

html = render_daw_player(audio_bytes, viewMode="spectrogram")

# Display in Jupyter:
from IPython.display import HTML
HTML(html)

Streamlit:

import streamlit as st
from signavis import render_daw_player
import streamlit.components.v1 as components

uploaded = st.file_uploader("Choose an audio file", type=["wav", "mp3", "ogg", "flac"])
if uploaded is not None:
    html = render_daw_player(uploaded.read(), viewMode="spectrogram")
    components.html(html, height=620, scrolling=False)

You can use all other options as described above to customize the player.

Quickstart

Embed a DAW player for your own audio in Streamlit, Jupyter, or any HTML UI:

from signavis import render_daw_player
html = render_daw_player(
        audio_bytes,  # bytes (WAV/MP3)
        viewMode="spectrogram",   # 'both' | 'waveform' | 'spectrogram'
        transportStyle="hero",    # 'default' | 'hero'
        showOverview=False,        # Hide overview navigator
        showFileOpen=False,        # Hide file open button
        showStatusbar=False,       # Hide status bar
        labelTaxonomy=[{"name": "Species", "color": "#0ea5e9"}],
        # ...any other BirdNETPlayer option
)

Display in Streamlit:

import streamlit.components.v1 as components
components.html(html, height=620, scrolling=False)

Display in Jupyter:

from IPython.display import HTML
HTML(html)

Player Options

For all options, see the Web API docs.

Presets & Layouts

The package includes several ready-to-use presets (see demo_streamlit.py):

• Full DAW: All controls, waveform & spectrogram, annotation
• Compact: Minimal controls, no overview/statusbar
• Preview Waveform Hero: Large play button, waveform only
• Preview Spectrogram Hero: Large play button, spectrogram only
• Ultra Compact Hero: Smallest possible embed

You can combine or override any option for your use case.

Advanced: Custom Spectrograms

You can inject your own pre-computed spectrogram data or images:

• spectrogram_data: 2D numpy array (nFrames × nMels, float32)
• spectrogram_image: PNG/JPEG bytes, data-URL, matplotlib Figure, PIL Image, or numpy uint8 array

See the Web API for details.

Demos

Streamlit:

streamlit run demo_streamlit.py

Gradio:

pip install gradio
python demo_gradio.py

Google Colab:

Try the interactive notebook demo directly in your browser—no setup required!

License

GNU AGPL-3.0
