sogen 0.0.1.dev3976

Sogen Windows user-space emulator bindings

Sogen exposes Python bindings for its Windows userspace emulator. The Python API is meant for scripting runs, building small analysis helpers, and quickly iterating on callbacks and hooks without rebuilding C++.

Install from PyPI:

pip install sogen

Project links:

• PyPI: https://pypi.org/project/sogen/
• Repository: https://github.com/momo5502/sogen
• Ready-made emulation root: https://sogen.dev/root.zip

What you need

The Python package still needs an emulation root at runtime. Download ready-made root here:

• https://sogen.dev/root.zip

Extract it somewhere convenient, for example:

./root

Most examples in this document use:

emulation_root="./root"

Quick start

import sogen

app = sogen.windows.create_application(
    "c:/test-sample.exe",
    emulation_root="./root",
)

app.callbacks.on_stdout = lambda text: print(text, end="")
app.start()
print("exit status:", app.process.exit_status)

Minimal example with file + port mappings

from pathlib import Path
import sogen

app = sogen.windows.create_application(
    "c:/test-sample.exe",
    emulation_root="./root",
    path_mappings={"c:/a.txt": Path("./a.txt")},
    port_mappings={28970: 28980},
)

app.callbacks.on_stdout = lambda text: print(text, end="")
app.start()
print("exit status:", app.process.exit_status)

Choosing backend

sogen.windows.create_empty() and sogen.windows.create_application() accept an explicit backend.

import sogen

emu = sogen.windows.create_empty(
    emulation_root="./root",
    backend=sogen.Backend.unicorn,
)

Available values:

• sogen.Backend.unicorn
• sogen.Backend.icicle
• sogen.Backend.whp

Default is sogen.Backend.unicorn.

High-level structure

Main entry points:

• sogen.windows.create_empty(...)
• sogen.windows.create_application(...)

Compatibility aliases currently remain at top level:

• sogen.create_empty(...)
• sogen.create_application(...)

Common objects exposed by the bindings:

• sogen.windows.Emulator / sogen.windows.WindowsEmulator
• ProcessContext
• Thread
• MemoryManager
• Hooks
• Callbacks

Common things you will do:

• run application with app.start()
• watch output with app.callbacks.on_stdout
• react to module loads with app.callbacks.on_module_load
• intercept WinAPI calls with app.hooks.apis[...]
• read/write emulator memory with read_memory() / write_memory()
• save and restore state with save_snapshot() / restore_snapshot()

Callbacks

Example: print loaded modules.

import sogen

app = sogen.windows.create_application(
    "c:/test-sample.exe",
    emulation_root="./root",
)


def on_module_load(module):
    print(f"loaded {module.name} @ 0x{module.entry_point:x}")


app.callbacks.on_module_load = on_module_load
app.start()

Useful callback slots include:

• app.callbacks.on_stdout
• app.callbacks.on_syscall
• app.callbacks.on_memory_violate
• app.callbacks.on_module_load
• app.callbacks.on_module_unload

API hooks

API hooks are registered through app.hooks.apis.

Use @sogen.windows.api_call(...) to describe calling convention and parameters. Top-level sogen.api_call(...) remains as compatibility alias.

Observe API call, then run original

import ctypes
import sogen

app = sogen.windows.create_application(
    "c:/test-sample.exe",
    emulation_root="./root",
)


@sogen.windows.api_call(cc=sogen.CallingConvention.stdcall, params=[ctypes.c_uint32])
def on_sleep(call, params):
    print(f"Sleep({params[0]})")


app.hooks.apis["Sleep"] = on_sleep
app.start()

Intercept API call and return custom value

import sogen

app = sogen.windows.create_application(
    "c:/hook-sample.exe",
    emulation_root="./root",
)


@sogen.windows.api_call(cc=sogen.CallingConvention.stdcall, params=[])
def on_get_current_process_id(call, params):
    call.return_value = 0xC0FFEE01
    return sogen.ApiContinuation.intercept


app.hooks.apis["GetCurrentProcessId"] = on_get_current_process_id
app.start()
print(app.process.exit_status)

Hook keys can be either:

• bare API name, for example "Sleep"
• qualified module form, for example "kernel32!Sleep"

Memory and state

The emulator exposes direct state access.

import sogen

emu = sogen.windows.create_empty(emulation_root="./root")
base = emu.memory.allocate_memory(0x1000, sogen.MemoryPermission.read_write)
emu.write_memory(base, b"ABCD")
print(emu.read_memory(base, 4))

state = emu.serialize_state()
emu.write_memory(base, b"WXYZ")
emu.deserialize_state(state)
print(emu.read_memory(base, 4))

For checkpoint-style workflows, use snapshots:

emu.save_snapshot()
# ... mutate state ...
emu.restore_snapshot()

Examples

Small runnable example:

• examples/python/basic_usage.py

Example setup notes:

• examples/python/README.md

Current limitations / expectations

• bindings require an emulation root
• samples in this repo assume Windows-style guest paths like c:/...
• some workflows are easiest to validate against repo sample binaries such as test-sample.exe and hook-sample.exe
• backend availability depends on platform and how Sogen was built
